NuIPC

cPCI-3500A series

3U CompactPCI All-in-one

Low Power Pentium CPU Module

User’s Guide

StockCheck.com

Manual Rev. 1.00: June 21, 2001

Part No. 50-15001-100

Theinformationinthisdocumentissubject to change without prior notice in

order to improve reliability, design and function and does not represent a

commitment on the part of the manufacturer.

In no event will the manufacturer be liable for direct, indirect, special,

incidental,orconsequentialdamagesarisingoutoftheuseorinabilitytouse

the product or documentation, even if advised of the possibility of such

damages.

This document contains proprietary information protected by copyright. All

rights are reserved. No part of this manual may be reproduced by any

mechanical, electronic, or other means in any form without prior written

permission of the manufacturer.

Trademarks

NuIPC is a registered trademark of ADLINK Technology Inc.

Otherproductnamesmentionedhereinare used for identification purposes

onlyand maybetrademarksand/orregistered trademarksoftheirrespective

companies.

StockCheck.com

Getting service from ADLINK

?Customer Satisfaction is always the most important thing for ADLINK

TechnologyInc.Ifyouneedanyhelporservice,please contact us and get it.

ADLINK Technology Inc.

Web Site http://www.adlink.com.tw

http://www.adlinktechnology.com

Sales & Service [email protected]

NuDAQ [email protected]

Technical NuDAM [email protected]

Support NuIPC [email protected]m.tw

NuPRO [email protected]

TEL +886-2-82265877 FAX +886-2-82265717

Address 9F, No. 166, Jian Yi Road, Chungho City, Taipei, 235 Taiwan, R.O.C.

?Please inform or FAX us of your detailed information for a prompt,

satisfactory and constant service.

Detailed Company Information

Company/Organization

Contact Person

E-mail Address

Address

Country

TEL FAX

Web Site

Questions

Product Mode

¨Computer Brand :

Environment to Use ¨M/B : ¨CPU :

¨Chipset : ¨BIOS :

¨Video Card :

¨Network Interface Card :

¨Other :

Challenge Description

SuggestionstoADLINK

StockCheck.com

Table of Contents•i

Table of Contents

Chapter 1 Introduction...........................................................1

1.1 Checklist...........................................................................1

1.2 Description........................................................................2

1.3 Features............................................................................3

1.4 Specifications of the module................................................4

Chapter 2 Hardware Installation..........................................8

2.1 Jumpers on the cPCI-3500A................................................9

2.2 Connectors on the cPCI-3500A..........................................12

2.2.1 The cPCI-3500A Module.......................................................13

2.2.2 USB Connectors......................................................................14

2.2.3 Ethernet (RJ-45) Connector..................................................14

2.2.4 Mini D-Sub Parallel Port Connector....................................14

2.2.5 Parallel Port Connector (Via Transition Cable).................15

2.2.6 PS/2 Mouse Connector..........................................................15

2.2.7 PS/2 Keyboard Connector....................................................15

2.2.8 CPU Fan Power Connector...................................................15

2.2.9 COM1 Serial Ports (RS-232 Only)........................................16

2.2.10 COM2 Serial Ports (RS-232/422/485).................................16

2.2.11 CompactPCI Connectors......................................................17

2.3 CPU Installation...............................................................19

2.4 Memory Installation..........................................................19

2.5 FDD Removal and Installation............................................20

2.6 HDD Removal and Installation............................................21

Chapter 3 Getting Start........................................................22

3.1 Using SCSI CD-ROM with cPCI SCSI interface...................22

Chapter 4 Driver Installation...............................................24

4.1 LAN Drivers Installation.....................................................26

4.1.1 Software and Drivers Support...............................................26

4.1.2 Driver Installation on Windows 2000...................................26

4.1.3 Driver Installation on Windows 98.......................................28

4.1.4 Driver Installation on Windows NT.......................................29

StockCheck.com

ii •Table of Contents

Chapter 5 Watchdog and Utilities.....................................30

5.1 Watchdog Timer Configuration...........................................30

5.1.1 WDT1 Programming..............................................................31

5.1.1.1 How to Test the WDT1?.......................................31

5.1.2 WDT2 Programming..............................................................32

5.2 Hardware Doctor Utility.....................................................34

5.3 Intel Preboot Execution Environment (PXE).........................35

Product Warranty/Service....................................................36

StockCheck.com

Introduction •1

Introduction

This manual is designed to give you information on the cPCI-3500A CPU

module. The topics covered in this chapter are as follows:

•Checklist

•Descriptions

•Features

•Specifications

1.1 Checklist

There are several standard configurations available for cPCI-3500A series

module. Please check your configurations with your dealer and check that

your package is complete and contains the items below. If you discover

damaged or missing items, please contact with your dealer.

•The cPCI-3500A module (May be equipped with different speed or

capacityof CPU, RAM, HDD. Those items may vary according to the

different configuration request)

•The mini D-Sub to DB25 female parallel port transition cable

(Ordering Model Number: CB-MLPT01)

•This User’s Manual

•ADLINK CD

Note: The package of cPCI-3500A OEM version (non-standard

configuration,functionality or package) mayvary accordingto the

different configuration request.

StockCheck.com

2•Introduction

1.2 Description

ThecPCI-3500A series are Low Power Pentium-MMX processor module for

3UCompactPCIformfactor. ThemoduleisbasedontheIntel 430TXchipset

and is fully designed for harsh industrial environment.

There are four standard pre-configured sub-models:

•cPCI-3500A/CA : 3U CompactPCI Low Power Pentium-MMX CPU

module in 3-slot (12TE/HP) width, equipped with Low Power

Pentium-266, 64MB RAM, 5GB (or above) 2.5” ATA HDD and

separable slim type floppy disk drive module

•cPCI-3500A/CB : 3U CompactPCI Low Power Pentium-MMX CPU

module in 3-slot (12TE/HP) width, equipped with Low Power

Pentium-266,64MB RAM, 32MBFlashDisk andseparable slim type

floppy disk drive module

•cPCI-3500A-2S/CA:3UCompactPCILowPowerPentium-MMX CPU

module in 2-slot (8TE/HP) width, equipped with Low Power

Pentium-266, 64MB RAM and 5GB (or above) 2.5” ATA HDD without

slim floppy disk drive module

•cPCI-3500A-2S/CB : 3U CompactPCI Low Power Pentium-MMX

CPU module in 2-slot (8TE/HP) width, equipped with Low Power

Pentium-266, 64MB RAM and 32MB Flash Disk without slim floppy

disk drive module

StockCheck.com

Introduction •3

1.3 Features

•PICMG 2.0 CompactPCI Specification R2.1 Compliant

•PICMG 2.1 CompactPCI Hot Swap Specification R1.0 Compliant

•Standard 3U form factor

•Design for Socket-7 Low Power Pentium-MMX CPU

•Supports up to PPGA Low Power Pentium CPU at 266MHz

•One 144-pin SO-DIMM socket supports up to 256MB RAM

•Build-in housing for 2.5” low profile HDD

•Separable slim type floppy drive module

•Two on-board EIDE 44-pin connector

•Build-in two USB ports, two serial ports, one parallel port

•Separate PS/2 type keyboard and mouse connectors

•Supports7bus-master PCI devices on CompactPCI bus peripheral

slots

•On-board 10/100Mb Ethernet port by Intel 82559 controller

•SupportsIntelpre-bootexecutionenvironment(PXE)forremoteboot

•One DOC socket supports up to 144MB DiskOnChip

•3 or 2 slots width configurations are available for customized

applications

StockCheck.com

4•Introduction

1.4 Specifications of the module

General CompactPCI Features

•PCI Rev.2.1 compliant

•PICMG 2.0 CompactPCI Rev. 2.1 compliant

•PICMG 2.1 CompactPCI Hot Swap Specification R1.0 Compliant

Form Factor

•Standard 3U CompactPCI (board size: 100mm x 160mm)

•3-slot (12TE/HP, 60.9mm) wide, incl. separable slim type floppy or

2-slot (8TE/HP, 40.6mm) wide without floppy module

CPU/Cache

•Intel Socket-7 PPGA Low Power Pentium-MMX up to 266MHz

•On-board 512KB L2 cache

•Front side bus (FSB) frequency: 66MHz

Chipset

•Intel 430TX chipset

•Intel 82439TX(MTXC) and 82371EB(PIIX4E)

BIOS

•Award PnP BIOS with 2Mb Flash ROM

•BIOS write protection, provide anti-virus capability

•Customized power-on screen (for OEM project)

•DMI BIOS Support: Desktop Management Interface (DMI) allows

userstodownloadsystemhardware-level information such as CPU

type, CPU speed, internal/external frequencies and memory size

•Green Function: Power management via BIOS, activated through

mouse/keyboard movement

Host Memory

•One 144-pin SO-DIMM socket, Max. 256MB un-buffered SDRAM

module

IDE Ports

•Bus Master IDE controller, two 44-pin EIDE interfaces support up to

four IDE devices

•Support PIO Mode 3/4 or Ultra DMA/33 IDE devices

StockCheck.com
