10GbE BASE-T Card

User’s Manual

COM Express Type 7 10GBASE-T Network Adapter Card

Manual Rev.: 1.0

Revision Date: July 7, 2017

Part Number: 50-1J091-1000

ii Preface

Preface

All rights are reserved. No part of this manual may be reproduced by any mechanical, electronic, or other means in

any form without prior written permission of the manufacturer.

Disclaimer

The information in this document is subject to change without prior notice in order to improve reliability, design, and

function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer

be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use

the product or documentation, even if advised of the possibility of such damages.

Environmental Responsibility

ADLINK is committed to fulfill its social responsibility to global environmental preservation through compliance with

the European Union's Restriction of Hazardous Substances (RoHS) directive and Waste Electrical and Electronic

Equipment (WEEE) directive. Environmental protection is a top priority for ADLINK. We have enforced measures to

ensure that our products, manufacturing processes, components, and raw materials have as little impact on the

environment as possible. When products are at their end of life, our customers are encouraged to dispose of them

in accordance with the product disposal and/or recovery programs prescribed by their nation or company.

Trademarks

Product names mentioned herein are used for identification purposes only and may be trademarks and/or

registered trademarks of their respective companies.

Revision History

Revision Description Date By

1.0 Initial release 2017-07-07 JC

10GbE BASE-T Card

Preface iii

Table of Contents

Preface................................................................................................................................ii

List of Figures ...................................................................................................................iv

List of Tables......................................................................................................................v

1. Introduction................................................................................................................1

2. Specifications............................................................................................................3

2.1. Interface......................................................................................................................3

2.2. 10GbE PHY................................................................................................................3

2.3. Dimensions.................................................................................................................3

2.4. Operating Temperatures.............................................................................................3

2.5. Specification Compliance ...........................................................................................3

2.6. Functional Diagram.....................................................................................................4

2.7. Mechanical Drawing ...................................................................................................5

3. Pinouts and Signal Descriptions..............................................................................7

3.1. Input Interface Definitions...........................................................................................7

4. Module Interfaces and Configuration ......................................................................9

4.1. 10GbE BASE-T Card Layout......................................................................................9

4.2. 10GbE Adapter Card Installation..............................................................................10

4.3. LED Indicators..........................................................................................................11

Getting Service.................................................................................................................12

iv Preface

List of Figures

Figure 1: 10GbE BASE-T Card Functional Block Diagram......................................................................4

Figure 2: 10GbE BASE-T Card Mechanical Drawing...............................................................................5

Figure 3: 10GbE BASE-T Card Layout ....................................................................................................9

Figure 4: 10GbE Adapter Card Installed on Express-BASE7 with Type 7 COM Express Module....... 10

10GbE BASE-T Card

Preface v

List of Tables

Table 1: 10GbE BASE-T Card Pin Definitions .........................................................................................7

Table 2: LED Descriptions..................................................................................................................... 11

vi Preface

This page intentionally left blank.

10GbE BASE-T Card

Introduction 1

1. Introduction

The ADLINK 10GbE BASE-T Card is a 10GbE copper network adapter card that delivers fast 10Gbps network

access. It converts up to four 10GBASE-KR interfaces & related sideband signals to four 10GbE copper interfaces

(10GBASE-T signals) through 10GbE copper PHY.

The 10GbE BASE-T Card can only be used on products that are PICMG COM Express Type 7 (COM.0 Rev. 3.0)

compliant.

By using the 10GbE BASE-T Card with an Express-BASE7 reference carrier board and COM Express Type7

module (with 10GbE controller supporting copper mode), customers can quickly emulate the functionality of their

end product for software development and hardware verification. Applications include entry level cloud storage

platforms and communications servers.

2 Introduction

This page intentionally left blank.

10GbE BASE-T Card

Specifications 3

2. Specifications

2.1. Interface

Input Up to four 10GBASE-KR & related sideband signals from COM Express Type7 module

through 164-pin edge connector (PCIe x16 slot PCIEKR on Express-BASE7)

Output Up to four 10G copper signals (10GBASE-T)

2.2. 10GbE PHY

PHY Intel® Ethernet Connection X557-AT2 (two 10GbE ports, default BOM configuration)

Converts 10GBASE-KR and sideband signals to 10GBASE-T signals

Note: Four 10GbE ports optionally supported by project basis with 2nd copper PHY on

10GbE BASE-T card.

EEPROM Dedicated EEPROM for PHY firmware

2.3. Dimensions

•168 mm x 107 mm (PCB only, including edge connector)

2.4. Operating Temperatures

Standard Operating

Temperature 0°C to +60°C

2.5. Specification Compliance

zPICMG COM.0: Rev 3.0 Type 7

4 Specifications

2.6. Functional Diagram

164-pin Edge Connector

Figure 1: 10GbE BASE-T Card Functional Block Diagram
