ADTRAN IQ Probe 1200214L1 Bedienungsanleitung

61200214L1-1A

August 1998

IQ Probe

Frame Relay

Monitoring Probe

USER MANUAL

IQ Probe Unit 1200214L1

ESP 4-wire SW56 DBU Card 1204001L1

ESP V.34 DBU Card 1204002L1

ESP ISDN DBU Card 1204004L1

ESP External DCE Card 1204006L1

Trademark Information:

OpenView is a registered trademark of Hewlett-Packard Company.

SunNet Manager is a registered trademark of Sun Microsystems, Inc.

Netview is a registered trademark of IBM.

IQ View is a trademark of ADTRAN, Inc.

This product includes software developed by the University of California, Berkeley,

and its contributors.

901 Explorer Boulevard

P.O. Box 140000

Huntsville, AL 35814-4000

Phone: (256) 963-8000

Printed in USA.

ABOUT THIS MANUAL

This manual is arranged so you can quickly and easily find the

information you need. The following is an overview of the

contents of this manual:

• Chapter 1, Introduction, familiarizes you with frame relay

networks and IQ Probe highlights.

• Chapter 2, Installation, describes the IQ Probe connectors (pin

assignments are given in Appendix A) and provides an

installation diagram.

• Chapter 3, Operation, explains how to operate your IQ Probe

using either the front panel or a terminal interface.

• Chapter 4, Applications, provides examples of some common

IQ Probe applications. This chapter includes network dia-

grams as well as configuration examples.

• Chapter 5, Configuration Overview, explains how to access the

IQ Probe configuration menu and provides menu trees for

both the front panel and the terminal interface.

• Chapters 6 through 9 provide brief explanations for selections

made in the Configuration menus. These chapters are based

on the first level menu branches of the Configuration menu:

DTE Port, DCE Port, Dial Backup, and System Configuration.

• Chapter 10, Statistics, describes how to access statistical

information from the IQ Probe.

• Chapter 11, Testing, explains how to access the IQ Probe

diagnostic features, including PVC loopback and ping tests.

• Chapter 12, Activating Dial Backup Options, provides infor-

mation on the dialing options accessed through the Main

menu.

• Appendix A provides pinouts for the IQ Probe connectors.

• Appendix B contains product specifications.

Notes provide additional useful information.

Cautions signify information that could prevent service interruption.

Warnings provide information that could prevent damage to the

equipment or endangerment to human life.

IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS

Whenusingyourtelephoneequipment,pleasefollowthesebasicsafetyprecautions

to reduce the risk of fire, electrical shock, or personal injury:

1. Do not use this product near water, such as near a bath tub, wash bowl, kitchen

sink, laundry tub, in a wet basement, or near a swimming pool.

2. Avoidusingatelephone(otherthanacordless-type)duringanelectricalstorm.

There is a remote risk of shock from lightning.

3. Do not use the telephone to report a gas leak in the vicinity of the leak.

4. Use only the power cord, power supply, and/or batteries indicated in the

manual. Do not dispose of batteries in a fire. They may explode. Check with

local codes for special disposal instructions.

FCC regulations require that the following information be provided in this manual:

1. This equipment complies with Part 68 of the FCC rules. On the bottom of the ESP DBU card is

a label that shows the FCC registration number and ringer equivalence number (REN) for this

equipment. If requested, provide this information to the telephone company.

2. If this equipment causes harm to the telephone network, the telephone company may temporarily

discontinue service. If possible, advance notification is given; otherwise, notification is given

as soon as possible. The telephone company will advise the customer of the right to file a

complaint with the FCC.

3. The telephone company may make changes in its facilities, equipment, operations, or

procedures that could affect the proper operation of this equipment; advance notification and

the opportunity to maintain uninterrupted service are given.

4. If experiencing difficulty with this equipment, please contact ADTRAN for repair and

warranty information. The telephone company may require this equipment to be

disconnected from the network until the problem is corrected, or it is certain the equipment is

not malfunctioning.

5. This unit contains no user-serviceable parts.

6. An FCC compliant telephone cord with a modular plug is provided with this equipment. This

equipment is designed to be connected to the telephone network or premises wiring using an

FCC compatible modular jack, which is Part 68 compliant.

7. The following information may be required when applying to the local telephone company for

dial backup service:

Service Type REN/SOC FIC USOC

56 kbps Digital Interface 6.0F 04DU5-56 RJ-48S

64 kbps Digital Interface 6.0F 04DU5-64 RJ-48S

Loop Start (V.34) 0.8B/0.4A 02LS2 RJ-11C

8. The REN is useful in determining the quantity of devices you may connect to your telephone

line and still have all of those devices ring when your number is called. In most areas, the sum

of the RENs of all devices should not exceed five. To be certain of the number of devices you

may connect to your line as determined by the REN, call your telephone company to

determine the maximum REN for your calling area.

9. This equipment may not be used on coin service provided by the telephone company.

Connection to party lines is subject to state tariffs. (Contact your state public utility

commission or corporation commission for information.)

FEDERAL COMMUNICATIONS COMMISSION

RADIO FREQUENCY INTERFERENCE STATEMENT:

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to

Part15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainstharmfulinterference

whentheequipmentisoperatedinacommercialenvironment.Thisequipmentgenerates,uses,andcanradiate

radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause

harmful interference to radio frequencies. Operation of this equipment in a residential area is likely to cause

harmful interference in which case the user will be required to correct the interference at his own expense.

Shielded cables must be used with this unit to ensure compliance with Class A FCC limits.

Change or modifications to this unit not expressly approved by the

party responsible for compliance could void the user's authority to

operate the equipment.

CANADIAN EMISSIONS REQUIREMENTS

This digital apparatus does not exceed the Class A limits for radio noise emissions

from digital apparatus as set out in the interference-causing equipment standard

entitled "Digital Apparatus," ICES-003 of the Department of Communications.

Cet appareil nuerique respecte les limites de bruits radioelectriques applicables aux

appareils numeriques de Class A prescrites dans la norme sur le materiel brouilleur:

"Appareils Numeriques," NMB-003 edictee par le ministre des Communications.

CANADIAN EQUIPMENT LIMITATIONS

Notice: The Canadian Industry and Science Canada label identifies certified

equipment. This certification means that the equipment meets certain telecom-

munications network protective, operational, and safety requirements. The

Department does not guarantee the equipment will operate to the user's satisfac-

tion.

Before installing this equipment, users should ensure that it is permissible to be

connected to the facilities of the local telecommunications company. The equip-

ment must also be installed using an acceptable method of connection. In some

cases, the company's inside wiring associated with a single line individual

service may be extended by means of a certified connector assembly (telephone

extension cord). The customer should be aware that compliance with the above

conditions may not prevent degradation of service in some situations.

Repairs to certified equipment should be made by an authorized Canadian

maintenance facility designated by the supplier. Any repairs or alterations made

by the user to this equipment, or equipment malfunctions, may give the telecom-

munications company cause to request the user to disconnect the equipment.

Users should ensure for their own protection that the electrical ground connec-

tions of the power utility, telephone lines and internal metallic water pipe

system, if present, are connected together. This precaution may be particularly

important in rural areas.

Users should not attempt to make such connections themselves, but

should contact the appropriate electric inspection authority, or an

electrician, as appropriate.

The Load Number (LN) assigned to each terminal device denotes the percentage

of the total load to be connected to a telephone loop which is used by the device,

to prevent overloading. The termination on a loop may consist of any combina-

tion of devices subject only to the requirement that the total of the Load Num-

bers of all devices does not exceed 100.

ISDN Service Ordering Information for the ADTRAN IQ Probe With ISDN Dial

Backup

For ADTRAN IQ Probe ISDN dial backup applications, the following guide can be

used as an aid in ordering basic ISDN service from your local telephone company.

TheADTRANIQProbe ISDNincludesNT1andTerminaladapter functionalityand

supports data rates up to 128 kbps.

Request an ISDN Basic Rate Interface (BRI) line with the following features:

U-interface reference point

2B1Q line coding

1B+D Service (supports up to 64 kbps)

2B+D Service (supports up to 128 kbps)

The IQ Probe ISDN supports the following switch types and software protocols:

Lucent 5ESS Custom, 5E6 and later software, National ISDN-1

NT1 DMS-100 BCS-32 and later software (Pvc1), National ISDN-1 (Pvc2)

Siemens EWSD National ISDN-1

Request that the ISDN line allocate one DYNAMIC Terminal Endpoint Identifier

(TEI) for the number.

For service offered from an Lucent 5ESS, request a point-to-point line with the

following features:

Feature: Value

B1 Service: On Demand (DMD)

Data Line Class: Point-to-Point

Maximum B Channels: 1 (1B+D) or 2 (2B+D)

Circuit Switched Data (CSD) Bearer Channels: Any

Number of CSD Calls: 1 (1B+D) or 2 (2B+D)

Terminal Type: Type A

Turn the Following Features Off:

Packet Mode Data

Multi-line Hunt

Multiple Call Appearances

Electronic Key Telephone Sets (EKTS)

Shared Dictionary Numbers

Accept Special Type of Number

Intercom Groups

Network Resource Selector (Modem Pools)

Message Waiting

Hunting

InterLata Competition

For service offered from a Northern Telecom DMS-100, request a Point-to-Point

Multi-Point line with the following features:

Line Type: Basic Rate, Functional

Electronic Key Telephone Sets (EKTS): No

Call Appearance Handling (CACH): No

Non-Initializing Terminal: No

Circuit Switched Service: Yes

Packet Switched Service: No

TEI: Dynamic

Bearer Service: Circuit Switched voice and data permitted on any B channel (packet mode

data not permitted)
