Advantech TREK-132 Bedienungsanleitung

1 V0.22018-04-16

TREK-132 Driver Behavior

Recognition system

User manual

2 V0.22018-04-16

Contents

1. Safety precaution ········································································ P.5

2. Specification ················································································· P.5

3. Function overview ······································································ P.7

4. Features ·························································································· P.7

5. Activation conditions ································································ P.7

6. Disclaims ························································································ P.9

3 V0.22018-04-16

Safety precaution

1. Read these safety instructions carefully and keep this user

manual for later reference.

2. Never open the equipment and leave the equipment in an

environment unconditioned to keep away from humidity

and prevent electrostatic damages. For safety reasons,

the equipment should be opened only by qualified service

personnel.

3. Always shut off the vehicle power before connecting or

plugging out the cable. Do not make connections while

the power is on. Sensitive electronic components can be

damaged by sudden power surges.

4. Keep away from sharp metal cutting surface when layout

the harness, fix with the insulating tape or strap to prevent

the cable break when driving vibration.

4 V0.22018-04-16

Specification

Product size

79.5* 75* 60mm

weight

155g

DC input

9V ~36V

import current

<600mA

operating temperature

-40 –105°C

sensor format

CMOS

resolution

480P

dynamic range

74.8dB

camera FOV

D49.2°*H39°*V29°

IP rating

N/A

Function overview

1. Fatigue detection (closed eyes period and frequency)

2. Distraction detection (not watching the road ahead,

answer the phone, eat)

3. LED indicator

5 V0.22018-04-16

Red ON

Power on

Red off

System abnormal

Red flash

Firmware update

Green on

Face detected

Green off

Face not detected

Features

1. For all kinds of skin color, race of the driver

2. Applicable to wearing sunglasses (except for glasses with specular

reflection lenses)

3. Applicable to the driver of the hat (not cover eyes and facial features)

4. Applicable to interior driving environment with no light

5. Will not be any sunshine, light refraction interference identification.

6. Optimized vibration identification to significantly reduce the impact of

vibration due to driving.

7. Can immediately warning or transit to the system backend with any

the risk signal to facilitate the car signal, GPS signals, and even with

other ADAS features (such as lane departure, front car distance,

pedestrian and moving object detection, etc.), for more

comprehensively analysis fleet management risk.

6 V0.22018-04-16

OSD Description:

After the face be detected then will pop up Green Box then shows the

ready line (white) on left side.

1. Eyes detecting for sleeping, the event tiger after the eyes detecting

line disappear after 1 second.

2. Phoning detect area is located between ears and cheek.

3. Eating detect area is located between mouth and chin

4. Distraction event tiger after green box disappear after 1 second.

7 V0.22018-04-16

Activation conditions

1. System startup:

When the vehicle is ACC turned on, startup system

detection immediately.

2. Detection conditions:

The distance between driver's face and the camera sensor

would be 40 ~ 70cm.

3. Alert Timing:

When the driver's fatigue and distraction condition be

detected.

TREK-132 Installation suggestion

TREK-132 location

Notification:

1. Connected calibration LCD monitor

or linking to other monitor for

adjusting the Camera angle. But

please do not over 35o elevation angle

2. Make sure the driver’s face on

screen that needs over 1/2 ~2/3

whole display

8 V0.22018-04-16

Disclaims

This system using vision recognition by infrared camera to

processing and issued a warning, the following special

circumstances may affect the correct detection of the system:

1. Camera lens is dirty or obstructed and cannot detect facial

features.

2. When direct strong sunlight or against a strong light

reflects to camera lens.
