ASMB-785 Startup Manual 1

Before you begin installing your card, please make sure that

the following items have been shipped:

• 1 ASMB-785 Startup Manual

• 1 Driver CD (user’s manual is included)

• 2 Serial ATA HDD data cables

• 2 Serial ATA HDD power cables

• 1 I/O port bracket

• 1 Warranty card

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

Note: Acrobat Reader is required to view any PDF

ﬁle.Acrobat Reader can be downloaded at:

http://www.adobe.com/downloads/ (Acrobat is a

trademark of Adobe)

ASMB-785 LGA 1151 Intel Xeon E3-1200 v5/ 6th Gener-

ation Core Series ATX Server Board with DDR4, 4 PCIe,

3 PCI, 6 USB 3.0, 6 COM, 6 SATA3, Quad/Dual LANs

Startup Manual

Standard SBC Functions

• CPU: Intel LGA1151 Xeon E3-1200 v5 /Core i3/i5/i7

series processors

• BIOS: AMI 128 Mb SPI BIOS

• Chipset: Intel® C236

• System memory: Dual Channel DDR4 ECC/Non-ECC

1600/1866/2133 MHz unbuffered DIMM, Max. 64 GB

Note: Due to the inherent limitations of PC architecture,

the system may not fully detect 32 GB RAM

when 64 GB RAM is installed.

• SATA3 Interface: 6 SATA3 6Gb/s ports to support Intel

Matrix Storage with software RAID 0, 1, 10 & 5. (for

Windows only)

• Serial ports: Six serial ports, only supports RS-232

• Keyboard/Mouse connector: Supports standard PS/2

keyboard and mouse via KMBS1 pin header

• Watchdog timer: 255 level timer intervals (sec)

• USB 3.0: Supports up to Six USB 3.0 ports. Four ports

are in rear I/O, and two ports are on-board pin header.

• USB 2.0: Supports up to seven USB 2.0 ports (1* Type-A)

Display Interface

• Chipset: CPU integrated Intel HD graphics controller

• Display Memory: 1 GB maximum shared memory with 2

GB and above system memory installed

• Resolution:

- Supports RGB up to 1920 x 1200 resolution @ 60 Hz

refresh rate

- Supports DVI up to 1920 x 1200 resolution@ 60 Hz

refresh rate

Ethernet Interface

• Interface: 10/100/1000 Mbps

• Controller: LAN1:Intel

I219LM; LAN2 ~ LAN4: Intel®

I201AT

Mechanical and Environmental

• Dimensions (L x W): 244 x 304 mm (9.6” x 12”)

• Power supply voltage: +3.3 V, +5 V, ±12 V, 5 Vsb

• Power consumption: Max. load: +3.3 V @ 0.96 A, +5 V

@ 1.58 A, +12 V @ 0.32 A, +12 V (8P) @ 7.21 A, +5 Vsb

@ 0.11 A, -12 V @ 0.06 A

• Operating temperature: 0 ~ 60° C (Depends on CPU

speed and cooler solution)

• Weight: 0.75 kg (weight of board)

Specications

Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

For technical support and service, please visit our

support website at:

http://support.advantech.com.tw/support/new_de-

fault.aspx

This manual is for the ASMB-785 series Rev. A1

Part No. 2001S78510

Print in China

1st Edition,

November 2015

2 ASMB-785 Startup Manual

Connector list

LPC1

Low pin count connector for

Advantech TPM LPC and

RS232/485 modules.

VOLT1 Voltage Display

PMBUS1 PMBUS connector to communi-

cate with power supply

LPT1 Parallel port

AUDIO1 Audio Connector

BH2 For optional battery kit

EX_THR1 For thermometer kit

SGPIO1, SGPIO2 Serial General Purpose I/O

JFP1 Power Switch / Reset connector

JFP2 External speaker / HDD LED

connector/ SM Bus connector

JFP3

Keyboard Lock and Power LED

Suspend: Fast ﬂash (ATX/ AT)

System On: ON (ATX/ AT)

System Off: OFF (ATX/AT)

SPDIF_OUT1 SPDIF Audio output pin header

BMC1 BMC connector to support IPMI-

1000 module

Jumper list

Label Function

JCMOS1 CMOS clear

JME1 Intel ME Disable Jumper for ME/

BIOS update

JWDT1 Watch Dog Reset

JUSB1

Rear window USB2.0/3.0 port

power source switch between

+5 VSB and +5 V

JUSB2

On board USB2.0/3.0 port

power source switch between

+5 VSB and +5 V

CPUFAN_

SEL1,SYSFAN_SEL1

FAN PWM(1-2)/DC mode selec-

tion(2-3)

PSON1 AT(1-2) / ATX(2-3)

JCASE1 Case Open

JPEG1, JPEG2

PCIEX16_SLOT6 PCIe Link

swtich between one x16 or two

x8 or x8, two x4

JGREEN1 Enable/Disable deep sleep

mode

JTHR_SEL1 To select on board or external

thermometer

The board has a number of jumpers that allow you to con-

ﬁgure your system to suit your application. The table below

lists the function of each jumper and connector.

Connector list

Label Function

ATXPWR1 ATX 24 Pin main power connec-

tor (for System)

ATX12V1 Processor power connector(for

CPU)

SATA0~5 SATA III (6Gb/s)

USB7_8, USB9_10,

USB11_12 USB 2.0 Port (Header)

USB13 USB 2.0 Port (USB Type A)

USB3_4 USB 3.0 Port (Header)

PCI_SLOT1,

PCI_SLOT3,

PCI_SLOT5

PCI slot

PCIEX4_SLOT2,

PCIEX4_SLOT7 PCIe x4 slot (Gen3 x4 link)

PCIEX16_SLOT4,

PCIEX16_SLOT6

PCIE x16 slots (one Gen3 x16

link for slot 6 or two Gen3 x8

link)

DIMMA0,DIMMA1,

DIMMB0,DIMMB1 DDR4 288-pin slot

CPUFAN0 CPU FAN connector

SYSFAN0,SYSFAN1,

SYSFAN2,SYSFAN3 System FAN connector

LAN1_USB1_2,

LAN2_USB5_6

LAN1 / USB 3.0 port 1, 2 stack

connector

LAN2 / USB 3.0 port 5, 6 stack

connector

LAN3_4 LAN3 & LAN4 connector

VGA1_COM1 VGA+COM connector

DVI1_DVI2 DVI-D connector

KBMS1 External keyboard and mouse

connector(6 pin)

SPI_CN1 SPI ﬂash card pin header

LANLED1, LANLED2 LAN LED extension connector

SMBUS1 SM Bus From PCH

GPIO1 8-bit GPIO header

FPAUD1 Audio front panel header

COM2, COM3_4,

COM5_6 Serial port: RS-232

Jumpers and Connectors Jumpers and Connectors (Cont.)

ASMB-785 Startup Manual 3

JPCICLK1 PCI slot clock selection between

33 and 66 MHz

JWDT1: Watchdog timer output option

Closed Pins

Result

1-2 System reset*

2-3 NC

*: Default

PSON1: ATX, AT mode selector

Closed Pins

Result

1-2 AT Mode

2-3 ATX Mode*

*: Default

JCMOS1/JME1: CMOS clear/ME update function

Closed pins Result

1-2

Keep CMOS data/Disable ME update*

2-3 Clear CMOS data/Enable ME update

*: Default

Keep CMOS data/Disable ME update Clear CMOS data/Enable ME update

System Reset 1-2 Closed NC 2-3 Closed

1 2 3

AT Mode 1-2 closed ATX Mode 2-3 closed

1 2 3

JFP1, JFP2

Pin.3 #PWR_SW

Pin.6

GND

Pin.9 #RST_SW

Pin.12 GND

*Power button pin is located in Pin 3 & 6 of front panel

connector

The CD disc contains a driver installer program that will

lead you through the installation of various device drivers

needed to take full advantage of your motherboard.

The computer is supplied with a battery-powered realtime

clock circuit. There is a danger of explosion if battery is

incorrectly replaced. Replace only with same or equivalent

type recommended by the manufacturer. Discard used bat-

teries according to manufacturer’s instructions.

This device complies with the requirements in Part 15 of

the FCC rules. Operation is subject to the following two

conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received,

including interference that may cause undesired opera-

tion

3 6 9 12 PWRSW RESET

HDDLED

SNMP

JFP1

1(+) 4 7 10(-)

HDDLED

SM_BUS

SPEAKER

JFP2

PWRLED & KEYLOCK

12345JFP3

2(+) 5(-) 8 11

Jumpers and Connectors (Cont.) Installation Note

Declaration of Conformity

Software Installation

4 ASMB-785 Startup Manual

Board Layout: Jumper and Connector Locations

Board Layout

LAN3_4

VGA1_COM1

DVI1_DVI2

PMBUS1

AUDIO1

LAN1_

USB1_2

LAN2_

USB5_6

ATXPWR1

SYS

FAN0

JFP3

JCMOS1

COM2

PCIEX4_SLOT2

GPIO1

ATX12V1

EX_

THR1

FPAUD1

PCIEX16_SLOT4

PCIEX4_SLOT7

SYSFAN_

SEL1

PSON1

Intel LGA1151 Socket

DIMM A0

DIMM A1

DIMM B0

DIMM B1

SMBUS1

VOLT1

JUSB2

CPU FAN0

JTHR_SEL1

LAN LED

1 & 2

JGREEN1

JWDT1

JPEG1~3

SYS

FAN1 & 2

JFP1 + JFP2

COM3_4

JCASE1

COM5_6

SATA1~SATA5

JUSB1

Intel C236 PCH

USB3_4

KBMS1

USB7_8

USB9_10

USB11_12

SPDIF_OUT1

SYSFAN3

PCIEX16_SLOT6

JME1

SPI_CN1

CPUFAN_

SEL1

PCI_SLOT1

PCI_SLOT3

PCI_SLOT5

LPC1

LPT1

USB13

SATA0

BMC1

BH2

JPCICLK1

SGPIO1 & 2

SYS_LED1
