H90 Startup Manual 1

Before you begin installing your card, please make sure that

the following items have been shipped:

• 1 x H90 Startup Manual

• 1 x SATA data cables

• 1 x SATA power cables

• 2 x CPU power cables (8P)

• 1 x I/O port bracket

If any of these items are missing or damaged, please

contact your distributor or sales representative immediately.

Note 1:  AcrobatReaderisrequiredtoviewanyPDFle.

Acrobat Reader can be downloaded at: https://

www.adobe.com/downloads.html (Acrobat is a

trademark of Adobe)

ASMB-H90 LGA 4094 HYGON EATX Server Board with

16 x DDR4, 4 x PCIe x16, 2 x PCIe x8, 10 x SATA3,

2 x M.2, 4 x USB3.2 Gen1, Dual GbE, IPMI

Startup Manual

Standard M/B Functions

• CPU: SP3 LGA4094 For Hygon 2 and Hygon 3 (Socket

compatible AMD EPYC™ 7003 Series processors)

• BIOS: Byosoft 256 Mbit SPI BIOS

• System Memory: 16* DDR4-2666/2933/3200 registered

ECC DIMM, Max. Capacity 512 GB

Note 2: Due to the inherent limitations of the PC archi-

tecture, the system may not fully detect 512 GB

RAM when 512 GB RAM is installed.

• SATA Interface: 10 SATA 6Gb/s port (7-pin)

• Serial Ports: 1 RS-232 (D-Sub) at rear IO

• Watchdog Timer: 255 level timer intervals

• USB Port: Supports up to 4 x USB 3.2 Gen1 ports (2 rear

ports, 2 ports from onboard 20-pin header)

VGA Interface

• Chipset: ASPEED AST2500

• Display Memory: 64 MB

• Resolution: Supports VGA up to resolution 1920 x 1200

@ 60 Hz refresh rate

Ethernet Interface

• Interface: 10/100/1000 Mbps Base-T

• Controller: LAN1/2: Intel X710 (optional SKU)

Mechanical and Environment

• Dimensions (L x W): 304 x 330 mm (12” x 13”)

• Power Supply Voltage: +3.3 V, +5 V, ±12 V, +5 Vs

• Power Consumption (mainboard only, excluding IO

device): Max. load: +3.3 V @ 12.646 A, +5 V@ 3.004 A,

+12 V @ 24.731 A,+5 Vsb @ 0.18 A, -12 V@ 0.082 A,

12V_8P @ 24.88 A

• Weight: 1.05 kg (weight of board)

• Operating Temperature: 0 ~ 60° C (depending on CPU)

SpecicationsPacking List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

For technical support and service, please visit our

support website at:

http://support.advantech.com

months extra warranty for Free at:

http://www.register.advantech.com

This manual is for the H90 series Rev. A1

Part No. 20420H9000

Printed in China

1st Edition

February 2023

2 H90 Startup Manual

The board has a number of jumpers that allow you to con-

gureyoursystemtosuityourapplication.Thetablebelow

lists the function of each of the jumpers and connectors.

Connectors

Label Function

ATXPWR1 ATX 24-pin main power connector

ATX12V1, ATX12V2 Processor power connector

SPI_CN1 Primary BIOS SPI ROM

SPI_CN2 Secondary BIOS SPI ROM

VGA_HDR1 Front VGA header

SYSFAN1, SYSFAN2

SYSFAN3, SYSFAN4 SYSTEM FAN connector

CPUFAN1, CPUFA2 CPU FAN connector

DIMMA0, DIMMB0,

DIMMC0, DIMMD0,

DIMME0, DIMMF0,

DIMMG0, DIMMH0

DDR4 slot (CPU0/CPU1)

SLIMSAS1,

SLIMSAS2 Slimline SAS x8 connector

FRHDD_BP1 Front BP I2C connector

CN2 HDT header (Debug)

JFP1, JFP1+JFP2,

JFP3 Front panel header

SLOT12V1 For PCIe slot 12V input only

LAN1, LAN2 RJ-45 GbE LAN connector

SPI_IPMI TPM SPI connector

M2_CN1 M.2 connector (PCIe x2)

M2_CN2 M.2 connector (PCIe x2)

PMBUS1 PMBUS connector to communi-

cate with power supply

SATA1~SATA10 SATA 1~10 connector

JFP4 Front panel header (for 3rd party

Chassis)

SGPIO0, SGPIO1 SATA SGPIO header

PCIEX16_SLOT1 PCIE x16 slot (x16 link) (CPU)

PCIEX8_SLOT2 PCIE x8 slot (x8 link) (CPU)

PCIEX16_SLOT3 PCIE x16 slot (x16 link) (CPU)

PCIEX8_SLOT4 PCIE x8 slot (x8 link) (CPU)

PCIEX16_SLOT5 PCIE x16 slot (x16 link) (CPU)

PCIEX16_SLOT6 PCIE x16 slot (x16 link) (CPU)

USB_FRONT1 Front panel USB connector

CN4 Custom Flash (Reserved)

Jumpers and Connectors (Cont.)

CN5 BMC programming header

IPMB1 IPMB header

CN1 UART debug port

FPGA_JTAG CPLD programming header

LAN1/LAN2 10G RJ45 (Option)

LAN1_USB3 USB 3.2 port 1, 2 (Type A); IPMI

LAN (RJ45)

VGA1, COM1 VGA & COM connector

Jumper list

Label Function

CASE_CN1 Chassis case open alarm

JP1

CMOS clear

JP2 BMC debug port

JP3 SGPIO debug port

JP4 PSU_ON

JP1: CMOS clear function

Closed pins Result

1-2

Keep CMOS data

2-3 Clear CMOS data

*: Default

Keep CMOS data Clear CMOS data

This device complies with the requirements in Part 15 of

the FCC rules. Operation is subject to the following two

conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received,

including interference that may cause undesired opera-

tion.

Jumpers and Connectors

Declaration of Conformity

H90 Startup Manual 3

Installation Note

JP1: CMOS clear function

Closed pins Result

1-2 Keep CMOS data ((DEFAULT)

2-3

Clear CMOS data

Installation Note (Cont.)

Figure 1: Board Layout: Jumper and Connector Locations

ATXPWR1

ATX12V1

ATX12V2

PMBUS1

JP1

CN1

CPUFAN1

CPUFAN2

SYSFAN2

SYSFAN1

SYSFAN4

SYSFAN3

CASE_CN1

SLOT12V1

FRHDD_BP1

JFP1+JFP2

IPMB1

SW1

RSTBTN

PWRBTN

SGPIO0

JP2

SGPM1

SGPS1

M.2_CN1

M.2_CN2

SLIMSAS1

SATA1/SATA2

FPGA JTAG1

SGPIO1

SPI_TPM1

BZ1

USB_FRONT1

VGA_HDR1

JFP3

SATA3~

SATA10

JFP4

JFP1

JP4

SLIMSAS2

SPI_CN2

SPI_CN1

CN5

SW4

CN2

ISMR1

BSCAN1

JP3

CPU0

CPU1

DIMMA0~D0

CPU1

DIMME0~H0

CPU1

DIMMA0~D0

CPU0

DIMME0~H0

CPU0

PCIEX16_SLOT1

PCIEX8_SLOT2

PCIEX16_SLOT3

PCIEX16_SLOT6

PCIEX16_SLOT5

PCIEX8_SLOT4

VGA1_COM1

LAN1_USB3

LAN1

LAN2

CN4

Board Layout
