FWA-6510 Startup Manual 1

Before you begin installing your card, please make sure that

the following items have been shipped:

• One FWA-6510 Internet Security Platform

• One box of accessories

• One warranty certiﬁcate

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

Note 1: Acrobat Reader is required to view any PDF

ﬁle.Acrobat Reader can be downloaded at:

www.adobe.com/Products/acrobat/readstep2.

html (Acrobat is a trademark of Adobe)

FWA-6510 Intel® Xeon® E5-2600 Series Processor

based 2U Network Application Platform

Startup Manual

Main Board Functions

• CPU: 2 x Intel® Xeon® E5-2600 processors

• PCH: Intel C600 series chipset

• BIOS: AMI 8Mbit SPI Flash

• QPI: up to 8 GT/s

• Memory: System memory: Support for DDR3

800/1066/1333/1600 memory ECC RDIMM

Primary CPU support 2 DIMMs/channel, up to 8 DIMMs

Secondary CPU support 1 DIMM/channel, up to 4 DIMMs,

Capacity up to 384 GB with 12 slots.

• PCIe Bus:

- PCH: Intel C600 series chipset

- Expansion:

4 x PCIe Gen3 x8 slots connect to NMC modules (2 per

CPU socket)

1 x PCIe Gen3 x8 slot for riser card (primary CPU)

2 x PCIe Gen1 for management boards (PCH)

- Riser card: 1 x PCIe x8 riser card, Supports

• NMC modules: 4 x NMC modules with PCIex8 gen.3

InterfacesMaximum 32 GbE ports or 8 x 10GE ports

• Storage:

- SAS/SATA: 4 x 2.5” hot-swappable SAS/SATA

- Compact Flash: 1 x CFast socket

- USB Flash Disk: 4 x USB 2.0 on-board pinheader for

USB ﬂash disk (DOM)

• System Management: IPMI, Aspeed AST2300 iBMC +

AMI MegaRAC ﬁrmware, Supports IPMI 2.0

Supports iKVM

• Dimensions/ Weight: 430 x 558 x 88 mm/ 18Kg

• Power Supply: 720 W 2U (1+1 redundant, 720 W

each),AC 100 ~ 240 V @ 50 ~ 60 Hz, full range, With

PMBus support

• Environment: Operating Non-Operating

• Temperature: 0 ~ 40° C -20° ~ 75° C

(32 ~ 104° F) (-4 ~ 167° F)

• Humidity: 5~85%@40°C 5~95%

(104° F)

Management Ports

• LAN: 2 x Intel 82574L 10/100/1000 Base-T Ethernet

• USB: 2 x USB 2.0 ports on the front

• Serial:1 x RS232 console port by RJ-45 connector on

the front.

• LCD: 16 x 2 character display, 5 buttons

• VGA: Pin header (for debug only)

• TPM: TPM1.2 compliant (Inﬁneon SLB9635TT1.2)

Specications

Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com.tw/support

http://www.advantech.com

For technical support and service, please visit our

support website at:

http://www.advantech.com/support

This manual is for the FWA-6510 series Rev. A

Part No. 2002651000

Print in China

1st Edition,

March 2012

2 FWA-6510 Startup Manual

NMC Modules

• Interface:

- GE Express Module:

Support 4 x 10/100/1000 Base-T ports by RJ45 or SFP

interface

Support 8 x 10/100/1000 Base-T ports by RJ45 interface

- 10GE Express Module:

Support 2 x 10GE ports by SFP+ interface

• Controller:

- GE Express Module:

1,2 x Intel i350-AM4 Quad Ports GE Controllers

- 10GE Express Module:

1 x Intel 82599ES Dual Ports 10GE Controller

• LAN Bypass:

- GE Express Module:

Support 2,4 segment LAN bypass by RJ45 interface

version only

Figure 1A: NMC-0107 4 ports Copper Module

Figure 2A: NMC-0108 4 ports SFP Module

Figure 3A: NMC-0803 8 ports Copper Module

Figure 4A: NMC-1004 2 ports 10G SFP+ Module

Installing the CPUs

1. Locate the CPU sockets on the board.

2. Taking one CPU at a time, remove the protective shield, if

present, and press the load lever and move it until it is clear

of the retention tab, and raise it.

3. Make sure that the alignment triangle on the CPU lines

up with correct corner on the socket, and ease the CPU

into place.

4. Close the load plate and push the load lever back down

until it engages the retention tab.

Specications Installation

FWA-6510 Startup Manual 3

Installing the Memory

The FWA-6510 system provides 12 x DDR3 DIMMs which

can support up to DDR3 800/1066/1333/1600 MHz 384GB.

1. To install the memory, please start to install the memory

from CPU0 with DIMMA1.

Installing the CFast and USB-DOM

1. Position a Cfast Flash disk accordingly in the Compact-

Flash disk socket and push it inward.

2. Remove the screw for the USB-DOM, and put stand-off

and fastened on the same location of screw hole, and then

install the USB-DOM on the pin header of USB, and screw

it again.

Installing the 2.5”SAS/SATA HDD

1. Remove the HDD tray from the front panel of System.

2.Put the 2.5” SAS/SATA HDD above the HDD tray and

position the screws accordingly.

3.Put the whole HDD tray with HDD back to front panel

4.Push the latch switch from left to right side for lock the

HDD tray for fastened.

Installing the Heat sinks

1. Taking one heat sink at one time, apply a small dab of

heat transfer compound to the top of the installed CPU,

and then align it and carefully lower the heat sink into place.

2. Insert and loosely engage each heat sink screw. Then

screw them in carefully to secure the heat sink.

Installing the Riser Cards

1. There is one screw on the base of the chassis.

2. Release the screw and remove the bracket.

3. Take it out.

4. Remove the dummy IO bracket and install the add-on

card.

5. Put the bracket back and screw it back in.

Installation Installation

4 FWA-6510 Startup Manual

Jumpers and Connectors

The board has a number of jumpers that allow you to con-

ﬁgure your system to suit your application. The table below

lists the function of each of the jumpers and connectors.

Connector / Jumper List (MB)

CN1 Front Panel Connector

CN2 B/B Conn. 40x2P (Connect to NAMB-

6510MGT)

CN3 WAFER BOX 2x5P for USB CONN

CN4 WAFER BOX 3P for TPM (Physical

Presence)

CN5/6/7/8 PCI-E x8 SMD Slot for PCIe Slot

#6/8/5/7

CN9 WAFER BOX 2x5P for LPC CONN

CN10 PIN HEADER 6x2P for GPIO CONN

CN11 WAFER BOX 2P for HDD Act

CN12 Mini SAS Connector

CN13 IPMB Connector for Power supply

CN14 SSI 24Pin Power Connector

CN15 WAFER BOX 2x7P for VGA CONN

CN16 BOX HEADER 5x2P for BSCAN

(chain1)

CN17 SPI Socket for BIOS(Secondary)

CN18 SPI Socket for BIOS(Primary)

CN19 IPMB Connector

CN20 WAFER BOX 2P for Chassis Intrusion

CN21 BOX HEADER 5x2P for BSCAN

(chain2)

CN22 PIN HEADER 4x1P for Volterra

CN23/CN24 SSI 8 Pin Power Connector

CN25/26/27 PCI-E x1 Straddle Slot for FAN Module

#1/2/3

CN28/29/

30/31

PCI-E x8 Straddle Slot for PCIe Slot

#4/3/2/1

JP1 PIN HEADER 3x1P for CLR RTC

Connector / Jumper List

JP2 PIN HEADER 3x1P for CLR CMOS

JP3 PIN HEADER 3x1P for BIOS Recovery

Mode Jumper

JP4 PIN HEADER 3x1P for BMC UART

Debug

Jumpers and Connectors

Connector / Jumper List (Mgmt)

CN1 RJ45-10/100/1000 Base-T Connector

for HA

CN2 RJ45-10/100/1000 Base-T Connector

for Management Port

CN3 B/B Conn. 40x2P (Connect to NAMB-

6510MB)

CN4 Dual USB Connector

CN5 USB DOM Connector

CN6 WAFER BOX 2x5P for LCM

CN7 CFast Type II Socket

CN8 RJ45 Connector for Console

CN9 USB DOM Connector

CN10 IPMB Connector for HDD Backplane

CN11 WAFER BOX 2x5P for Telco

CASE_OPEN1 WAFER BOX 2P for Chassis Instruc-

tion

SW1 DIP SW for Reset NIC1_82574L

SW2 Push SW for System Power Button

D9 CFast Card Status LED

D10 CFast Access LED

D11 Power LED

D12 Locate LED

D13 Alert LED

JP2: CMOS clear function

Pins Result

1-2 Keep CMOS data*

2-3 Clear CMOS data

*: Default

Keep CMOS data* Clear CMOS data

FWA-6510 Startup Manual 5

CN10 : External GPIO Header

Pins Result

1 VCC

2 GND

3 9554 GPIO0

4 9554 GPIO1

5 9554 GPIO2

6 9554 GPIO3

7 9554 GPIO4

8 9554 GPIO5

9 9554 GPIO6

10 9554 GPIO7

11 GND

12 VCC3

CN1: Front Panel Header

Pins Result

1 VCC

2 GND

3 Power Button

4 Reset Button

5 SMBUS Data

6 SMBUS Clock

7 VCC3

8 HDD ACT LED

CN1/2: RJ45 LAN connector (Mgmt)

LED status :

GbE Link Green (Left)

FE Link Amber (Left)

Action Link Green/Blink (Right)

Software tested list:

1. Linux Debian 2.6.18 kernel

2. Linux Redhat 6.1

This device complies with the requirements in Part 15 of

the FCC rules. Operation is subject to the following two

conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received,

including interference that may cause undesired opera-

tion.

Jumpers and Connectors Jumpers and Connectors

9 7

531

6 4 21012

PH_6x2V_S2.00mm

1 81 8

RJ45 for LAN Connectors

1 81 8

←RIGHTLEFT →

Software Installation

Specications

6 FWA-6510 Startup Manual

Board Placement

CPU1

CN31 CN1

CN3

CN6

CN4

CN28

CN2

CN11

CN14

CN13

CN20

CN16

CN32

CN15

CN9

CN10

CN8

JP1

JP2

JP3

JP4

SATA1

SATA2

CN29

CN30

CPU2

DIMM H1

DIMM G1

DIMM A1

DIMM A2

DIMM B1

DIMM B2

DIMM D2

DIMM D1

DIMM C2

DIMM C1

DIMM E1

DIMM F1

CN24

CN27

FAN1

CN26

FAN2

CN22

CN25

CN23

CN21

CN19

CN17

CN18

CN5

CN7

SW3

FWA-6510 Startup Manual 7

Board Placement

CASE_OPEN1

CN3

CN2SW2 CN8CN4

D13

CN11

D11

D12

CN5

CN7

CN10

SW1

CN1

CN9

Andere Handbücher für FWA-6510

Inhaltsverzeichnis

Andere Advantech Computerhardware Handbücher

Advantech

Advantech PCA-6011 Installations- und Betriebshandbuch

Advantech

Advantech MIC-7 Series Installations- und Betriebshandbuch

Advantech

Advantech IPC-619 Bedienungsanleitung

Advantech

Advantech PCA-6011 Installations- und Betriebshandbuch

Advantech

Advantech PPC RFID 98R3P300010 Installations- und Betriebshandbuch

Advantech

Advantech PCE-GIGE2 Installations- und Betriebshandbuch

Advantech

Advantech POC-W243 Series Bedienungsanleitung

Advantech

Advantech PCIE-1756 Bedienungsanleitung

Advantech

Advantech SOM-4463D-S8B2E Bedienungsanleitung

Advantech

Advantech MIO-5377 Bedienungsanleitung

Advantech

Advantech PCM-23U1DG-CE Installations- und Betriebshandbuch

Advantech

Advantech PCA-6276 Bedienungsanleitung

Advantech

Advantech AIMB-723 Bedienungsanleitung

Advantech

Advantech PCA-6178 Bedienungsanleitung

Advantech

Advantech LGA 1700 Bedienungsanleitung

Advantech

Advantech SOM-C350 Bedienungsanleitung

Advantech

Advantech SOM-4450 ETX Bedienungsanleitung

Advantech

Advantech AMAX-4870 Installations- und Betriebshandbuch

Advantech

Advantech SKY-MXM-T1000 Bedienungsanleitung

Advantech

Advantech MIC-715 Bedienungsanleitung

Advantech

Advantech PPC-IPS Bedienungsanleitung

Advantech

Advantech IPC-610B Bedienungsanleitung

Advantech

Advantech SOM-5992 Bedienungsanleitung

Advantech

Advantech ADAM CPU 821 Series Bedienungsanleitung

Beliebte Computerhardware Handbücher anderer Marken

EMC2

EMC2 VNX Series Betriebsanleitung

Panasonic

Panasonic DV0PM20105 Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Bedienungsanleitung

Gigabyte

Gigabyte B660M DS3H AX DDR4 Bedienungsanleitung

Raidon

Raidon iT2300 Bedienungsanleitung

National Instruments

National Instruments PXI-8186 Bedienungsanleitung

Hauppauge

Hauppauge WinTV-HVR-2250 Bedienungsanleitung

Kontron

Kontron CP6002 Bedienungsanleitung

Manhattan

Manhattan 702843 Bedienungsanleitung

Aphex

Aphex 230 Bedienungsanleitung

AMD

AMD Phenom II Betriebshandbuch

Intel

Intel NUC 12 Pro Bedienungsanleitung

dbx

dbx Zone Pro 1260 Bedienungsanleitung

Galaxy

Galaxy GHDX2-2430S-24F4D Bedienungsanleitung

Intel

Intel AXXRMFBU4 Bedienungsanleitung

Kontron

Kontron DIMM-PC/MD Bedienungsanleitung

ST X-NUCLEO-SAFEA1B Betriebsanleitung

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Bedienungsanleitung
