Advantech PCA-6154 Installations- und Betriebshandbuch

PCA-6154/6154L StartupManual 1

PCA-6154/6154L Half-size Pentium®

CPU Card SBC with VGA/Ethernet

PCA-6154/6154L Half-size all-in-one Pentium®

CPU Card with VGA and Fast Ethernet

Startup Manual

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

http://www.advantech.com/epc

For technical support and service, please visit our

support website at:

http://support.advantech.com

This manual is for the PCA-6154/L series Rev.A1

Part No. 2006615410 1st Edition

Printed in Taiwan Dec. 1999

Packing List

Before you begin installing your card, please make surethat

the following materials have been shipped:

• 1 PCA-6154/6154L all-in-one single board computer

• 1 hard disk drive (IDE) interface cable (40 pin)

p/n: 1701400601

• 1 floppy disk drive interface cable (34 pin)

p/n: 1701340700

• 1 parallel port adapter (26 pin) and COM2 adapter (9 pin)

p/n:1701260303

• 1 USB cable p/n: 1703100260

• 1 CPU fan with heatsink

• 1 6-pin mini-DIN keyboard & PS/2 mouse adapter

p/n:1700060201

• 1 startup manual

• CD-ROM or disks for utility, drivers, and manual (in PDF

format)

• 1 warranty certificate

If any of these items are missing or damaged, contact your

distributor or sales representative immediately.

Note 1: For detailed contents of the PCI-6154/L, please

refer to the enclosed CD-ROM or disk (in PDF

format).

Note 2: Acrobat Reader is acquired to view any PDF

file. Acrobat Reader can be downloaded at:

www.adobe.com/Prodindex/acrobat/

readstep.html

(Acrobat is a trademark of Adobe.)

Specifications

Standard SBC Functions

•CPU: Intel Pentium® 100 ~ 233 MHz, Pentium MMX,

AMD K5, AMD K6 200 / 266 MHz, AMD K6-2 266 ~ 300

MHz, Cyrix M1, Cyrix M2 up to PR-300 MHz, or IDT Win

Chip C6 upto 200 MHz

•BIOS: Award 256 KB (2 Mbit) memory; supports plug

and play, suspend to disk

•Chipset: SiS5598

•L2 cache: On-board 512 KB synchronous (pipeline

burst) SRAM

•Green function: Features power management option

via BIOS, activated by keyboard or mouse activity.

Supports doze, sleep and suspend modes. APM 1.1

compliant

•RAM: Two 72-pin SIMM sockets. Supports 32-bit FPM or

EDO DRAM with memory capacity from 8 ~ 128 MB.

•EIDE interface: Handles up to two IDE HDDs or other

IDE devices. Supports PIO mode 4 and Ultra DMA mode

•FDD interface: Supports up to two floppy disk drives.

•Parallel port: Configured to LPT1, LPT2, LPT3 or

disabled.

Supports multi-mode parallel port (SPP/ECP/EPP)

•Serial ports: Two 16C550 UARTs, one RS-232, one

RS-232/422/485 interface

•Watchdog timer: Can generate a system reset.

Software enabled/disabled.Time interval is from 1 to 62

seconds, jumperless with run-time setup

•Keyboard/mouse connector: 6-pin mini-DIN connector

on the mounting bracket eases connection to a

keyboard or PS/2 mouse. An on-board keyboard pin

header connector is also available.

•I/O bus expansion: PC/104 connector with face-up

installation

•USB interface: Two USB connectors with fuse

protection. Complies with USB specification 1.0

•Infrared port: Fast IrDA.Transfer rate up to 4 Mbps. I/O

port programmable to COM1 (3F8), COM2 (2F8),

COM3 (3E8) or COM4 (2E8).

VGA interface

•Chipset: SiS5598 built-inVGA function

•Architecture: Universal memory architecture

•Display memory: Share system RAM 1 MB ~ 4 MB

100Base-T Ethernet interface (PCA-6154 only)

•Chipset: REALTEK RTL8139. PCI bus 100/10 Mbps

Ethernet

2PCA-6154/6154L StartupManual

Locating Jumpers

Locating connectors (component side)

Jumpers and Connectors

Specifications Cont.

controller

• I/O address jumperless setting

• Built-in boot ROM

SSD function

• Supports M-Systems' DiskOnChip®2000 Flash disk up

to 144 MB

Mechanical and environmental specifications

•Board size: 185 x 122 mm

•Max. power requirements: +5V @ 5.5 A, +12 V @ 100

•Operating temperature: 0 ~ 60° C (32 ~ 140° F)

•Board weight: 0.5 kg (1.2 lbs)

PCA-6154/6154L jumpers

Number Function

JP2 CPU clock ratio select

JP3 CPU core voltage select

JP4 Watchdog timer select

JP5 Real-time clock (RTC) power and CMOS

select

JP7 DiskOnChip®2000 Flash disk memory

segment

JP8 COM2 RS-232/422/485 selection

JP9 CPU clock select

JP10 CPU clock optimize enable

Table 1-2: PCA-6154/6154L connectors

Number Function

CN1 IDE port

CN2 Floppy disk connector

CN3 Parallel port

CN4 CPU fan power connector

CN5 Infra red port

CN6 Main power connector

CN7 VGA connector

CN8 100/10 Mbps network connection

(PCA6154 only)

CN9 USB 1 and USB 2 ports

CN10 COM2 port

CN11 COM1 port

CN12 PC/104 A1~ A32, B1~ B32

CN13 PC/104 C1~ C20, D1~ D20

CN14 External keyboard

CN15 Keyboard and PS/2 mouse

CN16 Front panel connector

CN17 HDD LED

Locating jumpers (component side)

Main

USB

COM2

Eth-

ernet

VGA

FIR

Par-

allel

Front

panel

Flop-

CPU

fan

IDE

hard

HDD

SIMM

(Bank

SIMM

(Bank

PC/ PC/ Exter-

nal

COM1

Key-

board

CPU DOC

2000

JP9

JP3JP2 JP4

JP7

JP8

JP10

JP5

PCA-6154/6154L StartupManual 3

CPU clock ratio select (JP2)

Pentium CPU, AMD K5, K6, Cyrix M1, IDT C6

100 MHz 166 MHz

1.5 x 66 2.5 x 66

*133 MHz 200 MHz

2 x 66 3 x 66

150 MHz 233 MHz

2 x 75 3.5 x 66

266 MHz 300 MHz

4 x 66 4.5 x 66

* default setting

Refer to the CPU speed reference table (below) for

instructions on adjusting the internal clocks according to

the base CPU speed.

CPU speed reference table

CPU Speed (MHz) 100 *133 150 166 200 233 266 300

Clock setting 66 66 75 66 66 66 66 66

Frequency ratio 1.5 2 2 2.5 3.0 3.5 4 4.5

* default setting

System/PCI clock setting (JP9)

System (MHz) *66 75

PCI (MHz) 33 37.5

JP9

* default setting

CPU voltage select (JP3)

Pentium CPU, AMD K5, K6, Cyrix M1, M2, IDT C6

1.9V 2.0V

2.2V 2.3V

2.4V 2.5V

2.6V 2.5V

2.8V 2.9V

3.0V 3.1V

3.2V 3.27 V

*3.3 V 3.45 V

* default setting

Watchdog timer system reset select (JP4)

*System Reset IRQ15

JP4

)8PJ(584/224/232-SRrofsgnittes2MOC

desolcsniP232-SR*224-SR584-SR

2-1noffoffo

4-3ffonono

6-5ffoffono

8-7ffonono

9-7no--

21-01- nono

21-11no--

41-31- no-

51-31no--

81-61- no-

81-71no--

* default setting

DOC2000 address setting (JP7)

Address JP7

Disable

D800-D9FF

*D000 ~ D1FF

E000 ~ E1FF

CC00 ~ CDFF

DC00 ~ DDFF

D400 ~ D5FF

* default setting

4PCA-6154/6154L StartupManual

PCA-6154 Mechanical Drawing

mechanical drawing (component side)

RTC power and CMOS clear (JP5)

*Normal CMOS data clear

JP5

* default setting

DLL circiut for CPU clock optimization (JP10)

Disable *Enable

JP10

Buzzer enable/disable (CN16)

*Enable Disable

CN16

* default setting

14 2
