Advantech USB-4750 Bedienungsanleitung

User Manual

USB-4750

32-Channel Isolated Digital I/O

USB Module

USB-4750 User Manual ii

The documentation and the software included with this product are copyrighted 2022

by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right

to make improvements in the products described in this manual at any time without

notice. No part of this manual may be reproduced, copied, translated, or transmitted

in any form or by any means without the prior written permission of Advantech Co.,

Ltd. The information provided in this manual is intended to be accurate and reliable.

However, Advantech Co., Ltd. assumes no responsibility for its use, nor for any

infringements of the rights of third parties that may result from its use.

Acknowledgments

Intel and Pentium are trademarks of Intel Corporation.

Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.

All other product names or trademarks are properties of their respective owners.

Product Warranty (2 years)

Advantech warrants the original purchaser that each of its products will be free from

defects in materials and workmanship for two years from the date of purchase.

This warranty does not apply to any products that have been repaired or altered by

persons other than repair personnel authorized by Advantech, or products that have

been subject to misuse, abuse, accident, or improper installation. Advantech

assumes no liability under the terms of this warranty as a consequence of such

events.

Because of Advantech’s high quality-control standards and rigorous testing, most

customers never need to use our repair service. If an Advantech product is defective,

it will be repaired or replaced free of charge during the warranty period. For out-of-

warranty repairs, customers will be billed according to the cost of replacement mate-

rials, service time, and freight. Please consult your dealer for more details.

If you believe your product to be defective, follow the steps outlined below.

1. Collect all the information about the problem encountered. (For example, CPU

speed, Advantech products used, other hardware and software used, etc.) Note

anything abnormal and list any onscreen messages displayed when the prob-

lem occurs.

2. Call your dealer and describe the problem. Please have your manual, product,

and any helpful information readily available.

3. If your product is diagnosed as defective, obtain a return merchandise authori-

zation (RMA) number from your dealer. This allows us to process your return

more quickly.

4. Carefully pack the defective product, a completed Repair and Replacement

Order Card, and a proof of purchase date (such as a photocopy of your sales

receipt) into a shippable container. Products returned without a proof of pur-

chase date are not eligible for warranty service.

5. Write the RMA number clearly on the outside of the package and ship the pack-

age prepaid to your dealer.

Part No. 2003475002 Edition 3

Printed in Taiwan September 2022

iii USB-4750 User Manual

Declaration of Conformity

This product has passed the CE test for environmental specifications when shielded

cables are used for external wiring. We recommend the use of shielded cables. This

type of cable is available from Advantech. Please contact your local supplier for

ordering information.

Test conditions for passing also include the equipment being operated within an

industrial enclosure. In order to protect the product from damage caused by electro-

static discharge (ESD) and EMI leakage, we strongly recommend the use of CE-

compliant industrial enclosure products.

Technical Support and Assistance

1. Visit the Advantech website at www.advantech.com/support to obtain the latest

product information.

2. Contact your distributor, sales representative, or Advantech's customer service

center for technical support if you need additional assistance. Please have the

following information ready before calling:

–Product name and serial number

–Description of your peripheral attachments

–Description of your software (operating system, version, application software,

etc.)

–A complete description of the problem

–The exact wording of any error messages

Document Feedback

To assist us with improving this manual, we welcome all comments and constructive

criticism. Please send all feedback in writing to [email protected].

Safety Precautions - Static Electricity

Follow these simple precautions to protect yourself from harm and the products from

damage.

To avoid electrical shock, always disconnect the power from the PC chassis

before manual handling. Do not touch any components on the CPU card or

other cards while the PC is powered on.

Disconnect the power before making any configuration changes. A sudden rush

of power after connecting a jumper or installing a card may damage sensitive

electronic components.

USB-4750 User Manual iv

v USB-4750 User Manual

Contents

Chapter 1 Introduction..........................................1

1.1 Introduction ............................................................................................... 2

1.2 Hardware Features ................................................................................... 2

1.3 Software Overview.................................................................................... 2

Chapter 2 Installation............................................3

2.1 Unpacking ................................................................................................. 4

2.2 Driver Installation ...................................................................................... 5

Figure 2.1 XNavi Installer ............................................................ 5

2.2.1 Software Development Using DAQNavi SDK ............................... 5

2.3 Hardware Installation ................................................................................ 6

2.4 Hardware Uninstallation............................................................................ 7

Figure 2.2 Uninstalling USB-4750 ............................................... 7

Chapter 3 Signal Connections .............................9

3.1 Overview ................................................................................................. 10

3.2 I/O Connectors........................................................................................ 10

3.2.1 Pin Assignments ......................................................................... 10

Figure 3.1 I/O Connector Pin Assignment ................................. 10

3.2.2 I/O Connector Signal Description................................................ 11

Table 3.1: I/O Connector Signal Descriptions ........................... 11

3.2.3 LED Indicator Status Description ................................................ 11

Table 3.2: LED Indicator Status Description.............................. 11

3.3 Isolated Digital I/O Connections.............................................................. 12

3.3.1 Dry/Wet Contact Support for Digital Input................................... 12

Figure 3.2 Isolated Digital Input Connections ............................ 12

3.3.2 Isolated Digital Output Connections............................................ 12

Figure 3.3 Isolated Digital Output Connections ......................... 13

3.4 Field Wiring Considerations .................................................................... 13

Appendix A Specifications ....................................15

A.1 Isolated Digital Input................................................................................ 16

A.2 Isolated Digital Output............................................................................. 16

A.3 Optically-Isolated Counter....................................................................... 16

A.4 General ................................................................................................... 16

USB-4750 User Manual vi

Chapter 1

1Introduction

Sections include:

Introduction

Features

Specifications

USB-4750 User Manual 2

1.1 Introduction

Thank you for buying the Advantech’s USB-4750 data acquisition module. The

Advantech USB-4750 is a powerful data acquisition (DAS) module for the USB port.

It features a unique circuit design and complete functions for data acquisition and

control.

1.2 Hardware Features

USB-4750 features excellent measurement & control functions:

32 isolated digital input/output channels

High-voltage isolation up to 2,500 VDC on all channels

Dry/wet contact support

Interrupt handling capability

High-sink current for isolated output channels (200mA max./Channel)

Digital output value retained after hot system reset

Programmable Power-Up States for output channels

Wiring terminals on module

Compatible with USB 1.1/2.0 (Supports USB 1.1 data transfer rate)

Bus powered

1.3 Software Overview

Advantech offers device drivers, SDKs, third-party driver support and application

software to help fully exploit the functions of your DAQ devices. All these software

packages are available on Advantech website: http://www.advantech.com/.

The Advantech Navigator is a utility that allows you to set up, configure and test your

device, and later stores your settings in a proprietary database.

1. To set up the I/O device for your card, you could first run the Advantech Naviga-

tor program (by accessing Start/Programs/Advantech Automation/DAQNavi/

Advantech Navigator). The settings could also be saved to XML file, that can be

loaded in the applications using LoadProfile API.

2. You can then view the device(s) already installed on your system (if any) on the

Installed Device tree view. If the software and hardware installation are com-

pleted, you will see the device in the Installed Devices list.

Note! You can install up to sixteen USB-4750's to a system because of the

maximum number limit of the device BoardID.

Note! The power output of an USB port is 500 mA, while the USB-4750

requires 350 mA (Max.). This means that if an USB hub is used, it will

need an external power supply to support more than one USB-4750

device.

Note! For detailed specifications of USB-4750, please refer to Appendix A,

Specifications.

Chapter 2

2Installation

Sections include:

Unpacking

Driver Installation

Hardware Installation

Hardware Uninstallation

USB-4750 User Manual 4

2.1 Unpacking

After receiving your USB-4750 package, please inspect its contents first. The pack-

age should contain the following items:

USB-4750 Module

Shielded USB 2.0 Cable (1.72 m)

User Manual

The USB-4750 Module harbors certain electronic components vulnerable to electro-

static discharge (ESD). ESD could easily damage the integrated circuits and certain

components if preventive measures are not carefully paid attention to. Before remov-

ing the module from the anti-static plastic bag, you should take following precautions

to ward off possible ESD damage:

Touch the metal part of your computer chassis with your hand to discharge static

electricity accumulated on your body. One can also use a grounding strap.

Make contact between the anti-static bag and ground before opening.

After taking out the module, you should first:

Inspect the module for any possible signs of external damage (loose or damaged

components, etc.). If the module is visibly damaged, please notify our service depart-

ment or our local sales representative immediately. Avoid using a damaged module

with your system.

Avoid physical contact with materials that could hold static electricity such as

plastic, vinyl and Styrofoam.

Andere Handbücher für USB-4750

Inhaltsverzeichnis

Andere Advantech Steuereinheit Handbücher

Advantech

Advantech PCM-233A Installations- und Betriebshandbuch

Advantech

Advantech PCM-3526 Installations- und Betriebshandbuch

Advantech

Advantech RISC Module SOM-A2552 Bedienungsanleitung

Advantech

Advantech APAX-5202P Bedienungsanleitung

Advantech

Advantech ADAM-5000 Series Bedienungsanleitung

Advantech

Advantech ADAM-6051 Bedienungsanleitung

Advantech

Advantech AIW-357 DK-G1P Bedienungsanleitung

Advantech

Advantech SOM-5897 Bedienungsanleitung

Advantech

Advantech SOM-5962 Bedienungsanleitung

Advantech

Advantech EWM-W179M201E Bedienungsanleitung

Advantech

Advantech ADAM-3750 3-Wire Series Installations- und Betriebshandbuch

Advantech

Advantech MIC-75G30 Installations- und Betriebshandbuch

Advantech

Advantech PCM-3618 Bedienungsanleitung

Advantech

Advantech ADAM-2510Z Bedienungsanleitung

Advantech

Advantech PCM-261 Installations- und Betriebshandbuch

Advantech

Advantech PCM-233A Installations- und Betriebshandbuch

Advantech

Advantech PCM-3347 Series Bedienungsanleitung

Advantech

Advantech PCM-3664 Installations- und Betriebshandbuch

Advantech

Advantech ADAM-3656 Installations- und Betriebshandbuch

Advantech

Advantech MIC-75G20-10B1 Installations- und Betriebshandbuch

Advantech

Advantech PCM-3117 Installations- und Betriebshandbuch

Advantech

Advantech ADAM-3016 Bedienungsanleitung

Advantech

Advantech Network Device USB-4761 Installations- und Betriebshandbuch

Advantech

Advantech AMAX-3285IO Installations- und Betriebshandbuch

Beliebte Steuereinheit Handbücher anderer Marken

Festo

Festo Compact Performance CP-FB6-E Stücklistenhandbuch

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Bedienungsanleitung

JS Automation

JS Automation MPC3034A Bedienungsanleitung

JAUDT

JAUDT SW GII 6406 Series Kurzanleitung

Spektrum

Spektrum Air Module System Bedienungsanleitung

BOC Edwards

BOC Edwards Q Series Bedienungsanleitung

KHADAS

KHADAS BT Magic Bedienungsanleitung

Etherma

Etherma eNEXHO-IL Bedienungsanleitung

PMFoundations

PMFoundations Attenuverter Bedienungsanleitung

GEA

GEA VARIVENT Bedienungsanleitung

Walther Systemtechnik

Walther Systemtechnik VMS-05 Bedienungsanleitung

Altronix

Altronix LINQ8PD Montageanleitung

Eaton

Eaton Powerware Series Bedienungsanleitung

WAGO

WAGO 750-407/040-000 Bedienungsanleitung

Sony

Sony CCU-590 Bedienungsanleitung

Graco

Graco 25D614 Bedienungsanleitung

Task Force Tips

Task Force Tips YE-RF-900 Programmierhandbuch

Shini

Shini SPV-U Series Bedienungsanleitung
