Advantech ICR-4401 Bedienungsanleitung

LAN Industrial Router

ICR-4401

USER MANUAL

ICR-4401

any means, electronic or mechanical, including photography, recording, or any information storage and retrieval

system without written consent. Information in this manual is subject to change without notice, and does not

represent a commitment on the part of Advantech.

Advantech Czech s.r.o. shall not be liable for incidental or consequential damages resulting from the furnish-

ing, performance, or use of this manual.

All brand names used in this manual are the registered trademarks of their respective owners. The use of

trademarks or other designations in this publication is for reference purposes only and does not constitute an

endorsement by the trademark holder.

ICR-4401

Used symbols

Danger – Information regarding user safety or potential damage to the router.

Attention – Problems that can arise in speciﬁc situations.

Information, notice – Useful tips or information of special interest.

Advantech Czech s.r.o., Sokolska 71, 562 04 Usti nad Orlici, Czech Republic

Document No. MAN-0064-EN, revision from April 19, 2023. Released in the Czech Republic.

ICR-4401

Contents

1 Product Overview 2

1.1 Product Introduction ................................. 2

1.2 Hardware Overview ................................. 3

1.3 Order Codes ..................................... 5

1.4 Product Revisions .................................. 5

1.5 Package Contents .................................. 6

1.6 Product Dimensions ................................. 7

1.7 Mounting Recommendations ............................ 9

1.8 Wall Mounting ..................................... 10

1.9 DIN Rail Mounting .................................. 11

1.10 Product Label ..................................... 12

2 Hardware Functionality 13

2.1 Antennas Interfaces ................................. 13

2.2 Ethernet Interfaces .................................. 13

2.3 Power over Ethernet (PoE) PSE ........................... 14

2.4 SFP Cage ....................................... 16

2.5 Power Supply ..................................... 17

2.6 Low Power Mode ................................... 18

2.7 I/O Port Interfaces .................................. 19

2.8 Serial Interfaces ................................... 20

2.9 USB Port ....................................... 21

2.10 MicroSD Card Reader ................................ 22

2.11 LED Status Indication ................................ 24

2.12 Reset Functions ................................... 25

3 First Use 26

3.1 Accessories Connection ............................... 26

3.2 Router Conﬁguration ................................. 26

4 Technical Parameters 28

4.1 Basic Parameters ................................... 28

4.2 Standards and Regulations ............................. 29

4.3 Type Tests and Environmental Conditions ..................... 30

4.4 Parameters of WiFi .................................. 31

4.5 Parameters of I/O Ports ............................... 32

4.6 Parameters of Serial Interfaces ........................... 32

4.7 Parameters of PoE .................................. 33

4.8 System Conﬁguration ................................ 33

iii

ICR-4401

Appendix A: Troubleshooting 34

Appendix B: Customer Support 36

Appendix C: Regulatory & Safety Information 37

Appendix D: Related Documents 39

ICR-4401

List of Figures

1 Hardware Overview of the Router .......................... 3

2 Router Dimensions – Front, Top and Right view with Wall Mounting holder . . . 7

3 Router Dimensions – Front, Top and Right view with DIN holder ......... 8

4 Rotated Wall Mounting Clips ............................. 10

5 Default Position of the DIN Rail Clips ........................ 11

6 Removing Router from the DIN Rail ......................... 11

7 Label Example .................................... 12

8 Ethernet Connector Pinout of RJ45 Socket .................... 13

9 PoE PSE Funcional Scheme ............................ 14

10 SFP Module Installation ............................... 16

11 Power Connector Pinout ............................... 17

12 Position of the Grounding Screw .......................... 18

13 I/O Connector Pinout ................................. 19

14 Functional Scheme of the Binary Interface ..................... 19

15 Serial Connector Pinout ............................... 20

16 USB Connector Pinout ................................ 21

17 MicroSD Card Insertion ............................... 22

18 Resetting the Router ................................. 25

19 Router’s Web Interface ................................ 27

ICR-4401

List of Tables

1 Hardware Overview of the Router .......................... 4

2 Order Codes Overview ................................ 5

3 HW Revisions History ................................ 5

4 Contents of Package ................................. 6

5 Ethernet Connector Pinout Description of RJ45 Socket .............. 13

6 PoE PSE Parameters ................................ 15

7 Tested SFP Modules ................................. 16

8 Power connector pinout ............................... 17

9 Connection of I/O Ports ............................... 19

10 Connection of RS232 ................................ 20

11 Connection of CAN Bus ............................... 20

12 Connection of RS485 ................................ 20

13 USB Connector Pinout ................................ 21

14 Technical Speciﬁcations of MicroSD Card ..................... 22

15 LED Status Indication ................................ 24

16 Basic Parameters ................................... 28

17 Standards and Regulations ............................. 29

18 Type Tests and Environmental Conditions ..................... 30

19 Technical Parameters of WiFi ............................ 31

20 Electrical Characteristics of Binary Inputs ..................... 32

21 Parameters of Serial Interfaces ........................... 32

22 System Conﬁguration ................................ 33

ICR-4401

1. Product Overview

1.1 Product Introduction

The ICR-4401 is a LAN Router &Powerful Edge Computing Gateway focused on the

global market.

This router is an ideal solution for demanding IoT applications such as industrial routers

and gateways, digital signage, industrial computers, and tablets, etc.

The router, assembled in a robust metal box, is equipped with ﬁve 1Gb Ethernet ports,

one SFP cage together with interfaces of RS232,RS485,CAN bus, two binary inputs and

two binary outputs. A microSD card can be inserted under this cover as well. The desig-

nated router models can be equipped with a WiFi module with 3x3 MIMO antennas.

Conﬁguration of the router may be done via a password-protected Web interface. Web

interface provides detailed statistics about the router’s activities, signal strength, detailed sys-

tem log etc. The router supports VPN tunnels using IPSec (), OpenVPN,GRE,L2TP or PPTP

to make sure safe communication. IPv6 Dual Stack,DHCP,NAT,NAT-T,DynDNS,DNS

proxy,VLAN,QoS,NTP,VRRP, port forwarding, primary connection backup and many other

functions are supported.

The router supports the Low Power Mode and hardware watchdog, which monitors the

router status and performs an automatic restart if required.

The user may insert Linux scripts which are started on various actions. It is possible to

create up to four different conﬁgurations for the same router. These conﬁgurations can be

switched when necessary via Web interface or binary input status.

The router can automatically upgrade its conﬁguration and ﬁrmware from your central

server. WebAccess/DMP and WebAccess/VPN remote device management platforms are

supported as well.

Examples of possible applications

• mobile ofﬁce

• security system

• remote monitoring

• vending and dispatcher machines

ICR-4401

1.2 Hardware Overview

The router case preview is shown in Figure 1. A short description of hardware parts of the

router is listed in Table 1, including the links to the chapters with a detailed description.

Figure 1: Hardware Overview of the Router

ICR-4401

# Item/Caption Type Description

1 LEDs — Status LED indication; see Chapter 2.11.

2 RST — Button to reboot the router or to restore the default

conﬁguration; see Chapter 2.12.

3 PWR 2-pin

terminal

Power supply socket; see Chapter 2.5.

4 ETH2 SFP cage SFP cage socket for modules with speed up to 10 Gbps;

see Chapter 2.4.

5 ETH1 RJ45 1 Gb Ethernet connection for the second LAN; see Chap-

ter 2.2.

6 ETH0 RJ45 1 Gb Ethernet switched connection (with four ports) for the

ﬁrst LAN; see Chapter 2.2.

7 USB USB-A USB 2.0 host port; see Chapter 2.9.

8 SERIAL & I/O 14-pin

terminal

RS232, RS485, CAN bus, binary input, and binary output

interfaces. See Chapter 2.7 for more information, Chap-

ter 4.5 for I/O parameters, and Chapter 4.6 for serial inter-

face parameters.

9 WIFI1 R-SMA Connectors for the WiFi antennas. See Chapter 2.1 for

more information and Chapter 4.4 for WiFi parameters.

10 Grounding

screw

M3 Pay attention to proper grounding; see Chapter 2.5.

11 microSD slot microSD MicroSD card slot; see Chapter 2.10.

12 Wall clips — Wall mounting clips, included as standard accessories;

see Chapter 1.8.

Table 1: Hardware Overview of the Router
