Advantech RR75i v2 Bedienungsanleitung

GSM-R Router

RR75i v2

USER’S MANUAL

12-02-21

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

RR75i v2

Advantech B+B SmartWorx – Americas

Advantech B+B SmartWorx

707 Dayton Road

Ottawa, IL 61350 USA

Website

www.advantech-bb.com

Advantech – Europe

Advantech Czech s.r.o.

Sokolska 71

562 04, Usti nad Orlici,

Czech Republic

Website

www.advantech-bb.com

2020 Advantech Czech s.r.o. No part of this publication may be reproduced or transmitted in any form or

by any means, electronic or mechanical, including photography, recording, or any information storage and retrieval

system without written consent. Information in this manual is subject to change without notice, and does not

represent a commitment on the part of Advantech.

Advantech Czech s.r.o. shall not be liable for incidental or consequential damages resulting from the furnish-

ing, performance, or use of this manual.

All brand names used in this manual are the registered trademarks of their respective owners. The use of

trademarks or other designations in this publication is for reference purposes only and does not constitute an

endorsement by the trademark holder.

12-02-21

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

RR75i v2

Used symbols

Danger – Information regarding user safety or potential damage to the router.

Attention – Problems that can arise in speciﬁc situations.

Information, notice – Useful tips or information of special interest.

GPL licence

Source codes under GPL licence are available free of charge by sending an email to:

[email protected].

Please see http://ep.advantech-bb.cz/devzone for more information.

Advantech Czech s.r.o., Sokolska 71, 562 04 Usti nad Orlici, Czech Republic

Document No. MAN-0015-EN, revision from May 19, 2020. Released in the Czech Republic.

12-02-21

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

RR75i v2

Contents

1 Safety Instructions 2

2 WEEE directive 3

3 Router description 4

4 Contents of package 5

5 Router Design 6

5.1 Router versions .................................... 6

5.2 Delivery identiﬁcation ................................ 7

5.3 Order codes ...................................... 8

5.3.1 Order code structure ............................. 8

5.3.2 Order code examples ............................ 8

5.4 Basic dimensions of plastic box ........................... 9

5.5 Basic dimensions of metal box ........................... 9

5.6 Mechanical dimensions and mounting recommendations ............. 10

5.7 Removal from the DIN rail .............................. 12

5.8 Description of the front panel ............................ 13

5.8.1 Status indication ............................... 14

5.8.2 Power connector PWR ............................ 15

5.8.3 Antenna connector ANT (and AUX) ..................... 16

5.8.4 SIM card reader ............................... 17

5.8.5 Ethernet port ................................. 17

5.8.6 PORT1 .................................... 19

5.8.7 PORT2 .................................... 19

5.8.8 USB Port ................................... 20

5.8.9 I/O Port .................................... 21

5.8.10 Reset ..................................... 23

6 First use 24

6.1 Connecting the router before ﬁrst use ....................... 24

6.2 Start .......................................... 25

6.3 Conﬁguration ..................................... 25

6.3.1 Conﬁguration over web browser ....................... 25

6.3.2 Conﬁguration over Telnet .......................... 25

7 Technical parameters 26

12-02-21

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

RR75i v2

7.1 Technical parameters of router ........................... 26

7.2 Technical parameters of module .......................... 26

7.3 Technical parameters of processor ......................... 27

7.4 Technical parameters I/O port ............................ 27

7.5 Technical parameters of expansion port ...................... 27

8 Related Documents 28

9 Troubleshooting 29

9.1 FAQ .......................................... 29

10 Customers Support 32

10.1 Customer Support for NAM ............................. 32

10.2 Customer Support for Europe ............................ 32

10.3 Customer Support for Asia ............................. 32

iii

12-02-21

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

RR75i v2

List of Figures

1 Contents of package ................................. 5

2 Front panel RR75i v2B ................................ 6

3 Front panel RR75i v2F ................................ 6

4 Front panel RR75i v2B SL .............................. 6

5 Front panel RR75i v2F SL .............................. 6

6 Label examples .................................... 7

7 Basic dimensions of plastic box ........................... 9

8 Basic dimensions of metal box ........................... 9

9 Space around antennas ............................... 10

10 Space around antennas for SL ........................... 10

11 Cable routing ..................................... 11

12 Cable routing for SL version ............................. 11

13 Space in front of connectors ............................. 11

14 Space in front of connectors – SL .......................... 11

15 Default position of plastic and metal DIN rail clip ................. 12

16 Removal from the DIN rail .............................. 12

17 Front panel RR75i v2F ................................ 13

18 Front panel RR75i v2F ................................ 13

19 Power connector ................................... 15

20 Connection of power supply connector ....................... 15

21 Connection of power supply ............................. 15

22 External antenna ................................... 16

23 Connecting of the antenna .............................. 16

24 Ejected SIM holder .................................. 17

25 Ethernet connector .................................. 18

26 Connection of ethernet cable ............................ 18

27 Example of router connection ............................ 18

28 PORT1 cable connection .............................. 19

29 PORT2 cable connection .............................. 20

30 USB connector .................................... 20

31 Connection PLC to the router ............................ 21

32 Connection ﬂash memory to the router ....................... 21

33 I/O connector ..................................... 21

34 Connection of I/O cable ............................... 22

35 Connection of input and output to the router .................... 22

36 Router reset ...................................... 23

37 Router connection .................................. 24

12-02-21

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

RR75i v2

List of Tables

1 Router versions .................................... 6

2 Delivery identiﬁcation ................................ 7

3 Type of port #1 .................................... 8

4 Type of power supply ................................. 8

5 Order code examples ................................ 8

6 Front panel description ................................ 13

7 Router status indication ............................... 14

8 Connection of power connector ........................... 15

9 Connection of Ethernet connector .......................... 17

10 Connection of USB connector ............................ 20

11 Connection of I/O port ................................ 21

12 Description of reset and restart router ....................... 23

13 Technical parameters of router ........................... 26

14 Technical parameters of module .......................... 26

15 Technical parameters of processor ......................... 27

16 Technical parameters I/O port ............................ 27

12-02-21

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

RR75i v2

1. Safety Instructions

Please, observe the following instructions:

•The router must be used in compliance with all applicable international and national laws

and in compliance with any special restrictions regulating the utilization of the router in

prescribed applications and environments.

•To prevent possible injury and damage to appliances and to ensure compliance with

all relevant provisions, use only the original accessories. Unauthorized modiﬁcations or

the use of unapproved accessories may result in damage to the router and / or a breach

of applicable regulations. Unauthorized modiﬁcations or use of unapproved accessories

may void the warranty.

•The router can not be opened.

•Turn off the router and disconnect it from power supply before handling the SIM card.

•Caution! The SIM card could be swallowed by small children.

•Input voltage must not exceed 36 V DC max.

•Do not expose the router to extreme ambient conditions. Protect the router against dust,

moisture and high temperature.

•Only routers with appropriate certiﬁcation and labelling should be used in locations where

ﬂammable and explosive materials are present, including gas stations, chemical plants,

or locations in which explosives are used. We remind users of the duty to observe the

restrictions concerning the utilization of radio devices at such places.

•Switch off the router when traveling by plane. Utilization of the router on a plane may

endanger the operation of the plane or interfere with the mobile telephone network, and

may be unlawful. Failure to observe these instructions may result in the suspension or

cancellation of telephone services for the respective client and / or may result in legal

sanctions.

•When using the router in close proximity to personal medical devices, such as cardiac

pacemakers or hearing aids, you must proceed with heightened caution.

•The router may cause interference when used in close proximity to TV sets, radio re-

ceivers or personal computers.

•It is recommended that you create an appropriate copy or backup of all important settings

that are stored in the memory of the device.

12-02-21

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

RR75i v2

2. Product Disposal Instructions

The WEEE (Waste Electrical and Electronic Equipment: 2012/19/EU) directive was in-

troduced to ensure that electrical/electronic products are recycled using the best available

recovery techniques in order to minimize impact on the environment. This product contains

high quality materials and components which can be recycled. At the end of it’s life this pro-

duct MUST NOT be mixed with other commercial waste for disposal. The device contains the

battery. Remove the battery from the device before disposal. The battery in the device needs

to be disposed apart accordingly. Check the terms and conditions of your supplier for disposal

information.

12-02-21

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

RR75i v2

3. Router description

GSM-R router RR75i v2 is used to wirelessly connect various equipments and devices

via Ethernet interface 10/100 to the internet or intranet. Thanks to the support of an interna-

tional wireless communications standard for railway communication (GSM-R, Global System

for Mobile Communications – Railway) this router is used for secure and highly reliable com-

munication in the railway network. Among the main advantages of RR75i v2 router includes

high modularity – router offers a number of serial or wireless interfaces for connecting user

devices.

As a standard, this industrial router is equipped with one Ethernet 10/100, one USB Host

port, one binary input/output (I/O) port and one SIM card. To save and backup communication

data a version with two SIM cards is available. The wide range of interface options of the router

further expands expansion Port1 and Port2, which are selected by the customer. For Port1

are available: Ethernet port 10/100, serial interface ports RS232/RS485/RS422/MBUS or in-

puts/outputs (I/O – CNT). Port2 may be equipped with serial interfaces RS232/RS485/RS422/

MBUS, wireless interfaces WIFI/WMBUS, SDH expansion port or inputs/outputs (I/O – CNT).

Both of ports can be ﬁtted with internal switch (exp. port SWITCH). This wireless router is

supplied either in a plastic or metal casing, based on the requirements of the customer.

Conﬁguration is done via web interface protected by password. The GPRS/EDGE router

supports creation of VPN tunnels using technologies IPsec, OpenVPN and L2TP to ensure

safe communication. Web interface provides detail statistics about the wireless router activi-

ties, signal strength, detailed log, etc. Router supports functions: DHCP, NAT, NAT-T, DynDNS,

NTP, VRRP, control by SMS and many other functions.

Other diagnostic functions ensuring continuous communication include automatic inspec-

tion of PPP connection offering an automatic restart feature – in case of connection losses,

or hardware watchdog which monitors the status of the router. With the help of a special win-

dow (start up script window) you may insert Linux scripts for various actions. For some appli-

cations the key option to create several different conﬁgurations for one wireless GPRS/EDGE

router, the so-called proﬁles (maximum of 4), and the option to switch between them (for exam-

ple via SMS, binary input status, etc.) is essential. Cellular wireless routers may automatically

upgrade conﬁguration and ﬁrmware from server. This allows mass reconﬁguration of many

routers in one time.

For easy use additional software may be used – communication VPN server Digicluster

and software for router monitoring R-SeeNet.
