Advantech ICR-4461 Bedienungsanleitung

5G Industrial Router

ICR-4461

USER MANUAL

ICR-4461

any means, electronic or mechanical, including photography, recording, or any information storage and retrieval

system without written consent. Information in this manual is subject to change without notice, and does not

represent a commitment on the part of Advantech.

Advantech Czech s.r.o. shall not be liable for incidental or consequential damages resulting from the furnish-

ing, performance, or use of this manual.

All brand names used in this manual are the registered trademarks of their respective owners. The use of

trademarks or other designations in this publication is for reference purposes only and does not constitute an

endorsement by the trademark holder.

ICR-4461

Used symbols

Danger – Information regarding user safety or potential damage to the router.

Attention – Problems that can arise in speciﬁc situations.

Information, notice – Useful tips or information of special interest.

Advantech Czech s.r.o., Sokolska 71, 562 04 Usti nad Orlici, Czech Republic

Document No. MAN-0077-EN, revision from September 4, 2023. Released in the Czech Republic.

ICR-4461

Contents

1 Product Overview 2

1.1 Product Introduction ................................. 2

1.2 Product Usage Examples .............................. 3

1.3 Hardware Overview ................................. 5

1.4 Order Codes ..................................... 7

1.5 Package Contents .................................. 8

1.6 Product Dimensions ................................. 9

1.7 Mounting Recommendations ............................ 11

1.8 Wall Mounting ..................................... 12

1.9 DIN Rail Mounting .................................. 13

1.10 Product Label ..................................... 14

2 Hardware Functionality 15

2.1 SIM Card Slots .................................... 15

2.2 Antennas Interfaces ................................. 16

2.3 Ethernet Interfaces .................................. 16

2.4 Power over Ethernet (PoE) PSE ........................... 18

2.5 SFP Cage ....................................... 21

2.6 Power Supply ..................................... 22

2.7 Low Power Mode ................................... 23

2.8 I/O Port Interfaces .................................. 24

2.9 Serial Interfaces ................................... 25

2.10 USB Port ....................................... 26

2.11 MicroSD Card Reader ................................ 26

2.12 LED Status Indication ................................ 29

2.13 Reset Functions ................................... 30

3 First Use 31

3.1 Accessories Connection ............................... 31

3.2 Router Conﬁguration ................................. 31

4 Technical Parameters 33

4.1 Basic Parameters ................................... 33

4.2 Standards and Regulations ............................. 34

4.3 Type Tests and Environmental Conditions ..................... 35

4.4 Parameters of Cellular Module ........................... 36

4.4.1 Antenna Mapping .............................. 38

4.5 Parameters of GNSS ................................. 39

4.6 Parameters of WiFi .................................. 40

iii

ICR-4461

4.7 Parameters of I/O Ports ............................... 41

4.8 Parameters of Serial Interfaces ........................... 41

4.9 Parameters of PoE .................................. 42

4.10 System Conﬁguration ................................ 42

Appendix A: Troubleshooting 43

Appendix B: Customer Support 46

Appendix C: Regulatory & Safety Information 47

Appendix D: Related Documents 49

ICR-4461

List of Figures

1 Access to the Internet from LAN .......................... 3

2 Backed up Access to the Internet .......................... 3

3 Using VPN Tunnel .................................. 4

4 Serial Gateway .................................... 4

5 Hardware Overview of the Router .......................... 5

6 Router Dimensions – Front, Top and Right view with Wall Mounting holder . . . 9

7 Router Dimensions – Front, Top and Right view with DIN holder ......... 10

8 Rotated Wall Mounting Clips ............................. 12

9 Default Position of the DIN Rail Clips ........................ 13

10 Removing Router from the DIN Rail ......................... 13

11 Product Label ..................................... 14

12 SIM Cards Insertion ................................. 15

13 Ethernet Connector Pinout of RJ45 Socket .................... 16

14 PoE PSE Funcional Scheme ............................ 18

15 SFP Module Installation ............................... 21

16 Power Connector Pinout ............................... 22

17 Position of the Grounding Screw .......................... 23

18 I/O Connector Pinout ................................. 24

19 Functional Scheme of the Binary Interface ..................... 24

20 Serial Connector Pinout ............................... 25

21 USB Connector Pinout ................................ 26

22 MicroSD Card Insertion ............................... 27

23 Resetting the Router ................................. 30

ICR-4461

List of Tables

1 Hardware Overview of the Router .......................... 6

2 Order Codes Overview ................................ 7

3 Contents of Package ................................. 8

4 Ethernet Connector Pinout Description of RJ45 Socket .............. 16

5 PoE PSE Parameters ................................ 20

6 Tested SFP Modules ................................. 21

7 Power connector pinout ............................... 22

8 Connection of I/O Ports ............................... 24

9 Connection of RS232 ................................ 25

10 Connection of CAN Bus ............................... 25

11 Connection of RS485 ................................ 25

12 USB Connector Pinout ................................ 27

13 Technical Speciﬁcations of MicroSD Card ..................... 27

14 LED Status Indication ................................ 29

15 Basic Parameters ................................... 33

16 Standards and Regulations ............................. 34

17 Type Tests and Environmental Conditions ..................... 35

18 Technical Parameters of Cellular Module ...................... 37

19 Cellular Module Antenna Mapping ......................... 38

20 Technical Parameters of GNSS ........................... 39

21 Technical Parameters of WiFi ............................ 40

22 Electrical Characteristics of Binary Input ...................... 41

23 Parameters of Serial Interfaces ........................... 41

24 System Conﬁguration ................................ 42

ICR-4461

1. Product Overview

1.1 Product Introduction

The ICR-4461 is an Ultra-high-speed 5G NR (New Radio) Router and Powerful Edge

Computing Gateway focused on the global market, including the NAM region.

Thanks to its ultra high-speed data transfer capabilities, offering up to 3.4 Gbps for down-

loads and 900 Mbps for uploads, this router is an ideal solution for demanding IoT appli-

cations, including industrial routers and gateways, digital signage, industrial computers, and

tablets, among others.

For optimal performance on the cellular network, the router utilizes 4x4 MIMO technology.

Two antennas for GNSS can be connected to the router using shared SMA connectors with

the cellular antennas.

The router is housed in a robust metal enclosure and features ﬁve 1Gb Ethernet ports,

one SFP cage, and interfaces for RS232,RS485, and CAN bus. It also includes two binary

inputs and two binary outputs.

To ensure cellular connection redundancy, the router provides two SIM card readers on

the rear side, conveniently located under the SIM cover. Additionally, there is a slot for a

microSD card under this cover. Select router models can be equipped with a WiFi module

featuring 3x3 MIMO antennas.

Conﬁguration of the router can be performed through a password-protected web interface,

which provides detailed statistics about the router’s activities, signal strength, and a com-

prehensive system log. The router offers support for VPN tunnels using various protocols

including IPSec,OpenVPN,GRE,L2TP, or PPTP, ensuring secure communication.

Other supported features include IPv6 Dual Stack,DHCP,NAT,NAT-T,DynDNS,DNS

proxy,VLAN,QoS,NTP,VRRP, control via SMS, port forwarding, primary connection

backup, and many more.

The router provides diagnostic functions including automatic monitoring of the PPP con-

nection, automatic restart in case of connection losses, Low Power Mode, and a hardware

watchdog that monitors the router’s status.

Users can insert Linux scripts that are triggered by various actions. It’s possible to cre-

ate up to four different conﬁgurations for the same router, and these conﬁgurations can be

switched when needed through the web interface, SMS, or binary input status.

The router can automatically upgrade its conﬁguration and ﬁrmware from your central

server. Support is also provided for the WebAccess/DMP and WebAccess/VPN remote device

management platforms.

Examples of possible applications

• mobile ofﬁce

• remote monitoring

• security system

• vending and dispatcher machines

• ﬂeet management

• telematic

• telemetric

ICR-4461

1.2 Product Usage Examples

The router is primarily intended for these basic situations:

I. Access to the Internet from LAN

Figure 1: Access to the Internet from LAN

II. Backed up access to the Internet (from LAN)

Figure 2: Backed up Access to the Internet

ICR-4461

III. Secure networks interconnection or using VPN

Figure 3: Using VPN Tunnel

IV. Serial Gateway

Figure 4: Serial Gateway
