Advantech SPC-57 Bedienungsanleitung

SPC-57

5.7” STN LCD Smart Panel

Computer with IntelRXscaleRCPU

and WindowsRCE.NET

Users Manual

manufacturer reserves the right to make improvements to the products described in

this manual at any time without notice.

No part of this manual may be reproduced, copied, translated or transmitted in any

form or by any means without the prior written permission of the original

manufacturer. Information provided in this manual is intended to be accurate and

reliable. However, the original manufacturer assumes no responsibility for its use, nor

for any infringements upon the rights of third parties that may result from such use.

Acknowledgements

IBM, PC/AT, PS/2 and VGA are trademarks of International Business Machines

Corporation.

Intel®is trademark of Intel Corporation.

Microsoft®Windows®CE.NET is a registered trademark of Microsoft Corp.

All other product names or trademarks are properties of their respective owners.

For more information on this and other Advantech products, please visit our websites

at:

http://www.advantech.com

For technical support and service, please visit our support website at:

http://eservice.advantech.com.tw/eservice/

This manual is for the SPC-57 series products.

1st. Edition: July 2004

FCC Class A

This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment is

operated in a residential environment. This equipment generates, uses, and can radiate

radio frequency energy. If not installed and used in accordance with this user's manual,

it may cause harmful interference to radio communications. Note that even when this

equipment is installed and used in accordance with this user's manual, there is still no

guarantee that interference will not occur. If this equipment is believed to be causing

harmful interference to radio or television reception, this can be determined by

turning the equipment on and off. If interference is occurring, the user is encouraged

to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment and the receiver

• Connect the equipment to a power outlet on a circuit different from that to which the

receiver is connected

• Consult the dealer or an experienced radio/TV technician for help

Warning! HIGH VOLTAGE!!!

Please do NOT touch the inverter between main board and LCD panel

with your hands or any other electric conductors.

Warning! Any changes or modifications made to the equipment which are not

expressly approved by the relevant standards authority could void your

authority to operate the equipment.

Packing List

Before you begin to use SPC, please make sure that the following materials have been

shipped.

zSPC-57 Smart Panel Computer

zWindows®CE.NET end user license agreement (for Windows®CE.NET

version)

zAdvantech Software Support CD (Windows®CE.NET)

• Readme.txt

• Datasheet

• User manual

•Windows®CE.NET 4.2 platforms SDK (for Windows®CE.NET)

• Microsoft ActiveSync Version 3.7 install files (for Windows®CE.NET).

zPower connector

zPlastic Stylus for touch-screen

z1 x USB client ActiveSync cable

zWarranty card

z1 X 4P to 4P power cable (for SPC-57E only)

If any of these items are missing or damaged, contact your distributor or sales

representative immediately.

Additional Information and Assistance

Step 1: Visit the Advantech web site at www.advantech.com/risc where you can find

the latest information about the product.

Step 2: Contact your distributor, sales representative, or Advantech's customer service

center for technical support if you need additional assistance. Please have

the following information ready before you call:

• Product name and serial number

• Description of your peripheral attachments

• Description of your software (operating system, version, application software,

etc.)

• A complete description of the problems

• The exact wording of any error messages

Safety Instructions

1. Read these safety instructions carefully.

2. Keep this User's Manual for later reference.

3. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth.

Do not use liquid or spray detergents for cleaning.

4. For plug-in equipment, the power outlet socket must be located near the equipment

and must be easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a reliable surface during installation. Dropping it or letting it

fall may cause damage.

7. The openings on the enclosure are for air convection. Protect the equipment from

overheating. DO NOT COVER THE OPENINGS.

8. Make sure the voltage of the power source is correct before connecting the

equipment to the power outlet.

9. Position the power cord so that people cannot step on it. Do not place anything over

the power cord.

10. All cautions and warnings on the equipment should be noted.

11. If the equipment is not used for a long time, disconnect it from the power source

to avoid damage by transient over voltage.

12. Never pour any liquid into an opening. This may cause fire or electrical shock.

13. Never open the equipment. For safety reasons, the equipment should be opened

only by qualified service personnel.

14. If one of the following situations arises, get the equipment checked by service

personnel:

a. The power cord or plug is damaged.

b. Liquid has penetrated into the equipment.

c. The equipment has been exposed to moisture.

d. The equipment does not work well, or you cannot get it to work according

to the user's manual.

e. The equipment has been dropped and damaged.

f. The equipment has obvious signs of breakage.

15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE

THE STORAGE TEMPERATURE MAY GO BELOW -20° C (-4° F) OR ABOVE

60° C (140° F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT

SHOULD BE IN A CONTROLLED ENVIRONMENT.

The sound pressure level at the operator's position according to IEC 704-1:1982 is

no more than 70dB (A).

DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech

disclaims all responsibility for the accuracy of any statements contained herein.

Wichtige Sicherheishinweise

1. Bitte lesen sie Sich diese Hinweise sorgfältig durch.

2. Heben Sie diese Anleitung für den späteren Gebrauch auf.

3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Verwenden Sie

Keine Flüssig-oder Aerosolreiniger. Am besten dient ein angefeuchtetes Tuch zur

Reinigung.

4. Die NetzanschluBsteckdose soll nahe dem Gerät angebracht und leicht zugänglich

sein.

5. Das Gerät ist vor Feuchtigkeit zu schützen.

6. Bei der Aufstellung des Gerätes ist auf sicheren Stand zu achten. Ein Kippen oder

Fallen könnte Verletzungen hervorrufen.

7. Die Belüftungsöffnungen dienen zur Luftzirkulation die das Gerät vor überhitzung

schützt. Sorgen Sie dafür, daB diese Öffnungen nicht abgedeckt werden.

8. Beachten Sie beim. AnschluB an das Stromnetz die AnschluBwerte.

9. Verlegen Sie die NetzanschluBleitung so, daB niemand darüber fallen kann. Es

sollte auch nichts auf der Leitung abgestellt werden.

10. Alle Hinweise und Warnungen die sich am Geräten befinden sind zu beachten.

11. Wird das Gerät über einen längeren Zeitraum nicht benutzt, sollten Sie es vom

Stromnetz trennen. Somit wird im Falle einer Überspannung eine Beschädigung

vermieden.

12. Durch die Lüftungsöffnungen dürfen niemals Gegenstände oder Flüssigkeiten

in das Gerät gelangen. Dies könnte einen Brand bzw. elektrischen Schlag auslösen.

13. Öffnen Sie niemals das Gerät. Das Gerät darf aus Gründen der elektrischen

Sicherheit nur von authorisiertem Servicepersonal geöffnet werden.

14.Wenn folgende Situationen auftreten ist das Gerät vom Stromnetz zu trennen und

von einer qualifizierten Servicestelle zu überprüfen:

a - Netzkabel oder Netzstecker sind beschädigt.

b - Flüssigkeit ist in das Gerät eingedrungen.

c - Das Gerät war Feuchtigkeit ausgesetzt.

d - Wenn das Gerät nicht der Bedienungsanleitung entsprechend funktioniert

oder Sie mit Hilfe dieser Anleitung keine Verbesserung erzielen.

e - Das Gerät ist gefallen und/oder das Gehäuse ist beschädigt.

f - Wenn das Gerät deutliche Anzeichen eines Defektes aufweist.

Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt 70

dB(A) oder weiger.

DISCLAIMER: This set of instructions is given according to IEC704-1.

Advantech disclaims all responsibility for the accuracy of any statements

contained herein.

CHAPTER

General Information

This chapter gives background

Information of the SPC-57

Sections include:

• Introduction

• Specification

• LCD Specification

• Touchscreen Specification

• Power

• I/O ports

• Mounting

• Dimension and cutout

1.1 Introduction

Intel® XScale®, Ultra Low Power, Embedded Applications Anywhere!!

Advantech smart panel computers enable great embedded flexibility when powered

by Intel® XScale® technology. Built with an Intel PXA255 CPU, LCD display,

touchscreen, and pre-installed with Microsoft® Windows CE .NET 4.2 and LAN, the

SPC series provide the best cost-effective and stable solution to customers for a

diverse range of embedded applications. The great features of SPC, ultra low power,

compact size, IP65 front bezel, and fanless

Removable back cover: The back cover of the SPC series is easily removed to fit

customer application needs. With the flexibility of a removable back cover, customers

can better utilize the location and type of I/O by designing their own back for

seamless integration.

Dust and spill resistant: IP65 rated front bezel for protection from dust and water

damage.

Fanless and ultra low power consumption

Compact size

Rich connectivity for external accessories: GPS modules, wireless LAN modules,

GPRS modules are verified to work well with the SPC series.

SM bus for battery power: SPC keep the SM bus interface inside, users can equip

battery through SM bus to provide mobility on their own solution. The SM bus is

made through I2C

Versatile I/O: RS-232, RS-485, USB host, LAN, PCMCIA slot, CF slot, audio jack,

DIO, etc.

Applications

•Factory automation in manufacturing and warehousing

•Kiosks in public places –airports, information centers, railway stations and

shopping malls

•HMI: Human Machine Interface

•Entertainment –Gaming, Casino

•Hotel, Restaurant, and Hospitality

•Medical and health care in Hospital

•Portable/Mobile device

•In-vehicle device

1.2 Specifications

There are 2 models of SPC-57 series, SPC-57E and SPC-57C. SPC-57C is the fully

enclosure with standard external I/O connector. SPC-57E is without back cover,

without standard external I/O connector, and without Flash memory on board.

SPC-57E and SPC-57C can fulfill different applications and various demands from

the customer.

SPC-57C

System kernel

CPU Intel PXA-255 200MHz on board

OS Windows CE .NET 4.2

SDRAM 64MB SDRAM on board

Flash 32MB on board for OS pre-installed

WDT PXA-255 internal

RTC HT1381, backup by internal backup battery

Boot loader 1MB AMD Flash ROM for boot loader

Display

LCD 5.7” STN QVGA 320 x 240

Touch screen 4 wire resistant touch screen

VGA chip PXA-255 internal

I/O

RS-232 Full 9 pin RS-232 X 3; D-sub 9-pin external connector X 1; Pin

headers inside the case X 2

RS-485 RS-485 X 1, D-sub 9-pin external connector

RJ-45 10/100 base-T RJ-45 connector X 1

USB USB host X 2; USB client X 1

PCMCIA PCMCIA slot type II X 1

CF CF slot type II X 1

Digital I/O 8 DI & 8 DO. Pin header output. Provide API to access DIO

GPIO 8 GPIO. Pin header output inside the case. Default as hotkey

Audio Audio line out jack X 1

Power

V-in range DC 10V ~ 28V

Protection Over current protection

Electric pole reverse protection

SM bus For smart battery, pin headers

Inhaltsverzeichnis

Andere Advantech Touchscreen Handbücher

Advantech

Advantech PPC-321W TGL Bedienungsanleitung

Advantech

Advantech PPC-105 Bedienungsanleitung

Advantech

Advantech PPC-L106T Bedienungsanleitung

Advantech

Advantech PPC-153 Bedienungsanleitung

Advantech

Advantech IPPC-6172A Series Bedienungsanleitung

Advantech

Advantech UTC-318H Bedienungsanleitung

Advantech

Advantech PPC-150 Series Bedienungsanleitung

Advantech

Advantech PPC-S155T Bedienungsanleitung

Advantech

Advantech PPC-3211SW Installations- und Betriebshandbuch

Advantech

Advantech PPC-3100-RE9A Installations- und Betriebshandbuch

Advantech

Advantech PPC-L126 Bedienungsanleitung

Advantech

Advantech PPC-415W Installations- und Betriebshandbuch

Advantech

Advantech SPC-200 Series Bedienungsanleitung

Advantech

Advantech IPPC-6152A Bedienungsanleitung

Advantech

Advantech TPC-1251T-Exxx Series Bedienungsanleitung

Advantech

Advantech PCM-3335 Bedienungsanleitung

Advantech

Advantech PPC-612 Installations- und Betriebshandbuch

Advantech

Advantech PPC-4211W Bedienungsanleitung

Advantech

Advantech TPC-650H Bedienungsanleitung

Advantech

Advantech PPC-157T Bedienungsanleitung

Advantech

Advantech UTC-307GP-ATB0E Installations- und Betriebshandbuch

Advantech

Advantech POC-174 Bedienungsanleitung

Advantech

Advantech PPC-3150SW-PN4A Bedienungsanleitung

Advantech

Advantech PPC-L61T Bedienungsanleitung

Beliebte Touchscreen Handbücher anderer Marken

FlowLine

FlowLine Data loop Bedienungsanleitung

ALPEX

ALPEX AEx-8 P Series Bedienungsanleitung

Ltech

Ltech E5S Bedienungsanleitung

Harman

Harman AMX MODERO S MSD-701-L2 Bedienungsanleitung

Acnodes

Acnodes PC 1150 Bedienungsanleitung

AIS

AIS IP10IA99 series Bedienungsanleitung

IBASE Technology

IBASE Technology ASTUT-152-RE1S Bedienungsanleitung

YASKAWA

YASKAWA TP 610C Bedienungsanleitung

B&R

B&R Power Panel C Series Bedienungsanleitung

Beijer Electronics

Beijer Electronics X2 control Bedienungsanleitung

AXIOMTEK

AXIOMTEK GOT321W-521 Bedienungsanleitung

TRIDONIC.ATCO

TRIDONIC.ATCO x-touchBOX Bedienungsanleitung

Qomo

Qomo QIT1386 Bedienungsanleitung

DFI

DFI KS104-CD Bedienungsanleitung

AMX

AMX AXP-PPC Leitfaden

Sartorius

Sartorius X3 PR 5410 Bedienungsanleitung

AMX

AMX Modero X Series Bedienungsanleitung

B&R Industries

B&R Industries MAPPC900-ENG Bedienungsanleitung
