A-200 Installation Manual

A-200 Speed Dome

Installation Manual

V1.0.2

A-200 Installation Manual

Thank you for purchasing our product. If there is any question or request, please do not hesitate to

contact the dealer or tech support at (713) 621-9779

This manual is applicable to A-200.

This manual may contain several technically inaccurate points or printing errors, and the content is

subject to change without notice. The updates will be added into the new version of this manual.

We will readily improve or update the products or procedures described in the manual.

DISCLAIMER STATEMENT

“Underwriters Laboratories Inc. (“UL”) has not tested the performance or reliability of the security

or signaling aspects of this product. UL has only tested for fire, shock or casualty hazards as outlined

in UL’s Standard(s) for Safety, UL60950-1. UL Certification does not cover the performance or

reliability of the security or signaling aspects of this product. UL MAKES NO REPRESENTATIONS,

WARRANTIES OR CERTIFICATIONS WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY

OF ANY SECURITY OR SIGNALING RELATED FUNCTIONS OF THIS PRODUCT.”

A-200 Installation Manual

Regulatory Information

FCC Information

FCC compliance: This equipment has been tested and found to comply with the limits for a digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction manual, may cause harmful interference to

radio communications. Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at his own expense.

FCC Conditions

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause

undesired operation.

EU Conformity Statement

This product and - if applicable - the supplied accessories too are marked with

"CE" and comply therefore with the applicable harmonized European standards

listed under the Low Voltage Directive 2006/95/EC, the EMC Directive

2004/108/EC.

2002/96/EC (WEEE directive): Products marked with this symbol cannot be disposed

of as unsorted municipal waste in the European Union. For proper recycling, return

this product to your local supplier upon the purchase of equivalent new equipment,

or dispose of it at designated collection points. For more information see:

www.recyclethis.info.

2006/66/EC (battery directive): This product contains a battery that cannot be

disposed of as unsorted municipal waste in the European Union. See the product

documentation for specific battery information. The battery is marked with this

symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury

(Hg). For proper recycling, return the battery to your supplier or to a designated collection point.

For more information see: www.recyclethis.info.

A-200 Installation Manual

Safety Instruction

These instructions are intended to ensure that user can use the product correctly to avoid danger or

property loss. The precaution measure is divided into Warnings and Cautions:

Warnings: Neglecting any of the warnings may cause serious injury or death.

Cautions: Neglecting any of the cautions may cause injury or equipment damage.

Warnings:

Follow these safeguards to prevent

serious injury or death.

Cautions:

Follow these precautions to

prevent potential injury or

material damage.

Warnings

All the electronic operation should be strictly compliance with the electrical safety regulations,

fire prevention regulations and other related regulations in your local region.

Please use the power adapter, which is provided by normal company. The standard of the power

adapter is 24VAC10% or 12VDC10% (depending on models). The power consumption cannot

be less than the required value.

Do not connect several devices to one power adapter as adapter overload may cause over-heat

or fire hazard.

Please make sure that the power has been disconnected before you wire, install or dismantle

the speed dome.

When the product is installed on wall or ceiling, the device shall be firmly fixed.

If smoke, odors or noise rise from the device, turn off the power at once and unplug the power

cable, and then please contact the service center.

If the product does not work properly, please contact your dealer or the nearest service center.

Never attempt to disassemble the camera yourself. (We shall not assume any responsibility for

problems caused by unauthorized repair or maintenance.)

Cautions

Do not drop the dome or subject it to physical shock, and do not expose it to high

electromagnetism radiation. Avoid the equipment installation on vibrations surface or places

subject to shock (ignorance can cause equipment damage).

Do not place the dome in extremely hot, cold, dusty or damp locations, otherwise fire or

electrical shock will occur. The operating temperature should be -30°C ~ 65°C (outdoor speed

dome) and -10°C ~ 50°C (indoor speed dome).

The dome cover for indoor use shall be kept from rain and moisture.

Exposing the equipment to direct sun light, low ventilation or heat source such as heater or

radiator is forbidden (ignorance can cause fire danger).

A-200 Installation Manual

Do not aim the camera at the sun or extra bright places. A blooming or smear may occur

otherwise (which is not a malfunction however), and affecting the endurance of sensor at the

same time.

Please use the provided glove when open up the dome cover, avoid direct contact with the

dome cover, because the acidic sweat of the fingers may erode the surface coating of the dome

cover.

Please use a soft and dry cloth when clean inside and outside surfaces of the dome cover, do not

use alkaline detergents.

Please keep all wrappers after unpack them for future use. In case of any failure occurred,

please return the speed dome to the factory with the original wrapper. Transportation without

the original wrapper may result in damage on the speed dome and cost additional charge.

A-200 Installation Manual

Table of Contents

Chapter 1 Installation............................................................................................................................................ 1

1.1 Package Contents ................................................................................................................................................. 1

1.2 Installation and Cabling........................................................................................................................................ 2

1.2.1 Installing the A-200 .......................................................................................................................................... 2

1.2.2 Connecting the Cables ..................................................................................................................................... 5

1.3DIP Switch Settings............................................................................................................................................... 6

1.3.1 DIP Switches..................................................................................................................................................... 6

1.3.2 Address Settings............................................................................................................................................... 7

1.3.3 Baudrate Settings............................................................................................................................................. 9

1.3.4 Protocol Settings ............................................................................................................................................ 10

1.3.5 Communication Mode Settings...................................................................................................................... 10

1.3.6 Terminal Resistor Settings .............................................................................................................................. 11

1.4 Alarm In/Out Connections ................................................................................................................................. 11

Chapter 2 Mount Dimension................................................................................................................................12

2.1 A-200-WM Wall Mount...................................................................................................................................... 12

2.3 A-200-Corner Mount ......................................................................................................................................... 12

2.4 A-200 Pole Mount.............................................................................................................................................. 13

2.5 Pendant Mount .................................................................................................................................................. 15

Chapter 3 Mounting Applications ........................................................................................................................16

3.1 Wall Mounting Applications ............................................................................................................................... 16

3.1.1 Mounting Components .................................................................................................................................. 16

3.1.2 Wall Mounting ............................................................................................................................................... 17

3.2 Corner Mounting Applications ........................................................................................................................... 18

3.2.1 Mounting Components .................................................................................................................................. 18

3.2.2 Corner Mounting ........................................................................................................................................... 20

3.3 Pole Mounting Applications ............................................................................................................................... 21

3.3.1 Mounting Components .................................................................................................................................. 21

3.3.2 Pole Mounting................................................................................................................................................ 23

3.4 Pendant Mounting Applications......................................................................................................................... 25

3.4.1 Mounting Components .................................................................................................................................. 25

3.4.2 Pendant Mounting ......................................................................................................................................... 26

3.6.3 Ceiling Mounting................................................................................................Error! Bookmark not defined.

Appendix .....................................................................................................................................................................28

Appendix 1 Statics, Interference Lightning and Surge Protection .................................................................................. 28

Appendix 2 Waterproof .................................................................................................................................................. 32

Appendix 3 Bubble Maintenance ................................................................................................................................... 34

Appendix 4 RS485 Bus Connection................................................................................................................................. 35

Appendix 5 24VAC Wire Gauge & Transmission Distance............................................................................................... 38

Appendix 6 Table of Wire Gauge Standards ................................................................................................................... 39

A-200 Installation Manual

Chapter 1 Installation

1.1 Package Contents

Please make sure that the device in the package is in good condition and all the assembly parts are

included. The main package contents are shown in Figure 1-1.

Figure 1-1 Package Contents

Note: Do not lift the speed dome with its waterproof cables as shown in Figure 1-2, otherwise the

waterproof performance is affected.

Figure 1-2 Do Not Lift by the Cables

POWER

Pendant adapter

Allen key

Safety rope

Power adapter

A-200 Installation Manual

1.2 Installation and Cabling

1.2.1 Installing the Speed Dome

Steps:

1. Loosen the two lock screws on both sides of the speed dome. Pull the lower dome to separate it

from the back box as shown in Figure 1-3.

Note: Please do not remove the lock screws from the dome.

2. Remove the protective foam, sticker and lens cover from the dome drive.

3. Align the slots on the lower dome with the lock screws on the back box to reinstall the lower

dome. Tighten the lock screws.

Figure 1-3 Remove the Lower Dome

4. Install the dome mount. Please refer to the related sections in Chapter 2 and Chapter 3 for

specific installation methods with different mounts.

Notes:

For cement wall, you need to use the expansion screws to fix the mount. The mounting hole of

the expansion pipe on the wall should align with the mounting hole on the mount.

For wooden wall, you can just use the self-tapping screw to fix the mount.

Please make sure that the wall is strong enough to withstand more than 8 times the weight of

the dome and the mount.

5. Configure the dome address, baud rate, protocol and other parameters through DIP switch SW1

and SW2 which you can see after removing the lower dome. Please refer to Section 1.3 DIP

Switch Settings for details.

Notes:

Lock

Screw

Back Box

Lower Dome

Sticker

Protective

Foam

Lens Cover

A-200 Installation Manual

You do not have to set the address, baud rate, protocol and other parameters of network speed

dome through DIP switches.

The SD card slot of network speed dome is shown in Figure 1-5.

Figure 1-4 DIP Switches

Figure 1-5 SD Card Slot for Network Dome

6. Mounting the speed dome to the A-200-WM.

Steps:

(1) Apply thread tape to the thread of the pendant adapter and rotate the pendant adapter to

the mount. Secure the pendant adapter to the mount with a set screw (supplied).

(2) Loosen the lock screws of the adapter, as shown below:

SD Card Slot

A-200 Installation Manual

Figure 1-6 Install the Pendant Adapter

(3) Hook the back box of the speed dome to the mount with the safety cable. Route the cables

through the mount.

(4) Align the direction label of pendant adapter with the label of the back box to install the

speed dome. Rotate the back box counterclockwise or clockwise tightly. Secure the back box

and the pendant adapter with two lock screws.

Note: Please remove the protective film on the lower dome after the installation is finished.

Figure 1-7 Align the Direction Label

①

②

①

②

Lock Screw

Labels

Lock

Screw

Pendant Adapter

Loosen the

Lock Screws

Safety Cable

Andere Handbücher für A-200

Inhaltsverzeichnis

Andere advidia Sicherheitskamera Handbücher

advidia

advidia P-240 Bedienungsanleitung

advidia

advidia A-15 Bedienungsanleitung

advidia

advidia A-200 Bedienungsanleitung

advidia

advidia M-26-FW Bedienungsanleitung

advidia

advidia A-44 Bedienungsanleitung

advidia

advidia M-87-V Bedienungsanleitung

advidia

advidia B-5360 Bedienungsanleitung

advidia

advidia M-400-P Bedienungsanleitung

advidia

advidia A65 Bedienungsanleitung

advidia

advidia M-44-V-T-V2 Bedienungsanleitung

advidia

advidia M-46-F Bedienungsanleitung

advidia

advidia A-17 Bedienungsanleitung

advidia

advidia P-24 Bedienungsanleitung

advidia

advidia A-14 Bedienungsanleitung

advidia

advidia B-31 Bedienungsanleitung

advidia

advidia B-38-V Bedienungsanleitung

advidia

advidia M-49-FW Bedienungsanleitung

advidia

advidia A-46 Bedienungsanleitung

advidia

advidia A-200 Bedienungsanleitung

advidia

advidia M-49-FW Bedienungsanleitung

advidia

advidia A-44 Bedienungsanleitung

advidia

advidia A-45 Bedienungsanleitung

advidia

advidia A-47 Benutzerhandbuch

advidia

advidia A-28-Z Bedienungsanleitung

Beliebte Sicherheitskamera Handbücher anderer Marken

Okina USA

Okina USA SIR36-870VF650LP Bedienungsanleitung

Divio

Divio NDR155PA Bedienungsanleitung

Canon

Canon VB-C500D Bedienungsanleitung

Easy Access

Easy Access EasyGuard Bedienungsanleitung

Vivotek

Vivotek FD9389-EHV-v2 Bedienungsanleitung

TUYA

TUYA COSMO W2 Bedienungsanleitung

Eusso

Eusso UNC7500-IR Einrichtungshandbuch

urmet domus

urmet domus 1096/204 Bedienungsanleitung

VC VC20 series Bedienungsanleitung

Axis

Axis Q1614 Bedienungsanleitung

ieGeek

ieGeek DD201 Bedienungsanleitung

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Bedienungsanleitung

Vicon

Vicon V662-D-1 Betriebsanleitung

Grundig

Grundig GCH-K0274P Bedienungsanleitung

Lorex

Lorex VANTAGE LBC7032 Bedienungsanleitung

4xem

4xem WPT Bedienungsanleitung

Samsung

Samsung SCV-3082 Bedienungsanleitung

Vitek

Vitek VTC-C544 Bedienungsanleitung
