AEG MWTK60 Bedienungsanleitung
Available Finishes/Colors
MWTK60
Stainless Steel
Notes: AEG reserves the absolute and unrestricted right to change product materials and specifications, at any time, without notice. Warranties: Please see the Use & Care manual or
AEG website for a statement of limited warranty. For more information on our entire line of products, go to www.aeg-appliances.ca or call 905.829.3980. ©AEG. All rights reserved. 1
MWTK60
24” Fully Integrated Stainless Steel Trim Kit (1-Piece)
OVERVIEW
Create a finished look for your microwaves that are placed within a
cabinet opening. This easy-to-install trim kit features a smooth clean
finish that instantly gives your kitchen a modern makeover.
FEATURES
One piece stainless steel trim kit to fit a 24” (60cm) cabinet opening
Provides an integrated look for added style in your kitchen
Oers a stylish appearance with a stainless steel finish
Compatible with Panasonic 1.6 cu.ft. Microwaves (models: Panasonic
NNSD78LS, NNSD76S or equivalent)
Works well in an appliance tower over a built-in oven, or under-
counter
TECHNICAL DETAILS
Product Dimensions In/mm (W/H)
231/2” / 151/16”
597mm / 383mm
Cut-Out Dimensions In/mm (W/H)
221/16” / 145/16”
560mm / 363mm
Notes: AEG reserves the absolute and unrestricted right to change product materials and specifications, at any time, without notice. Warranties: Please see the Use & Care manual or
AEG website for a statement of limited warranty. For more information on our entire line of products, go to www.aeg-appliances.ca or call 905.829.3980. ©AEG. All rights reserved. 2
MWTK60
Installation Details
PRODUCT DIMENSIONS (WxH - IN/MM)
Width: 231/2” x Height: 151/16”
Width: 597mm x Height: 383mm
CUT OUT DIMENSIONS (WxH - IN/MM)
Width: 221/16” x Height: 145/16”
Width: 560mm x Height: 363mm
Notes: AEG reserves the absolute and unrestricted right to change product materials and specifications, at any time, without notice. Warranties: Please see the Use & Care manual or
AEG website for a statement of limited warranty. For more information on our entire line of products, go to www.aeg-appliances.ca or call 905.829.3980. ©AEG. All rights reserved. 3
VOID CUTOUT
1. Unscrew the 4 screws holding the 2 pieces of wood in place, and retain the screws
2. Hold the MWTK-60 in place and position the 2 pieces of wood against the cabinet sides and against the MWTK. Remove the MWTK
3. Screw the 2 pieces of wood onto the base of the cabinet. The wooden strips should touch the inside of the front of the MWTK-60, and
be aligned against the side gables. (wooden stripes 18”= 46cm apart)
4. Being careful not to scratch the microwave door, lift the microwave onto the wooden strips, and move it back about 2 inches.
5. Place the MWTK-60 into position. Use the 4 screws and screw them through the flanges into the side gables.
6. Pull the microwave forward, and align the front of the microwave with the front of the MWTK-60
7. To stop the microwave from sliding backwards whilst opening it might be necessary to attach a piece of wood behind the feet of the
microwave, on the wooden supports
8. Air must be able to flow from the microwave upwards and into the room, or roof space. Failure to comply will void the manufacturer’s
warranty on the micro wave oven.
MWTK60
Installation Details
Other Product Downloads Available at aeg-appliances.ca
WARRANTY INFORMATION
AEG Appliances are designed and manufactured to the highest standards. Each appliance is
covered by a comprehensive 2-year parts and labour warranty. Refer to product warranty policy
for complete terms and conditions.
FOR PARTS & SERVICE
Euro-Parts & Service
39822 Belgrave Road, Belgrave, ON. N0G 1E0 1 866 722 2262
www.euro-parts.ca • parts@euro-parts.ca • service@euro-parts.ca
AEG appliances are imported and distributed in North America by Euro-Line Appliances Inc.
For more information, please visit one of our showrooms or www.ela.ca / www.elawest.ca
871 Cranberry Court
Oakville, ON L6L 6J7 Canada
905.829.3980
1-800.421.6332
101-1014 Homer Street
Vancouver, BC V6B 2W9 Canada
604.235.3980
1-855.352.9378
