AG Neovo RX-55 Bedienungsanleitung

www.agneovo.com

NeoV™ Optical Glass - e most

trusted hard glass protection available.

Only on AG Neovo displays

A stylish slim bezel display deﬁned

by its precise presentation of images

and colours, the RX-55 perfectly

blends in with any professional

24/7 public environments

Built on a 10-bit, 120Hz premium-grade LCD panel, the RX-55 is

armed with AG Neovo’s AIP technology that reproduces colours

and details with an exceptional faithfulness. On top of Anti-Burn-

in™ and an internal HeatControl Sensor, it also comes with

EcoSmart Sensor technologies that ensure round-the clock

operations. Given the display’s zoom function, users can easily

install a video wall matrix. Craed with both function and form

in mind, it is the aesthetic choice that makes business sense for all

sorts of public places and applications.

> 1920 x 1080 Full HD, 700 nits high brightness

> 10 bits, 120 Hz IPS panel with MotionEnhance technology

> Attractive 1.9cm aluminum slim bezel

> NeoV™ Optical Glass

> Anti-Burn-in™ technology

> AIP Technology: 3D Comb lter / Deinterlace / Noise Reduction / PIP and PBP

> e forerunner of stand-by mode: less than 0.5 watt

> EcoSmart Sensor auto adjusts brightness for ultra low power consumption

> HeatControl Sensor will automatically activate the internal cooling fan to cool

down the temp

> EcoSwitch for zero watt power consumption

> Built-in Scheduler enables to program dierent scheduled activations

> Zoom function enables the easy implementation of a video wall up to 5x5 displays

> Versatile connectivity: HDMI, CVBS in/out, DVI, VGA in/out, S-Video, YPbPr,

Audio in/out

> Durable metal housing design

> Rigorous screening of the components for mission-critical 24/7 applications

RX-55

REACH

All specications are subject to change without prior notice.

All other trademarks are the property of their respective owners.

P/C: RX5500, Version 1.1, 20120701

Speciﬁcations RX-55

Panel Panel Type

Panel Size

Max. Resolution

Refresh Rate

Pixel Pitch

Brightness

Contrast Ratio

Viewing Angle (H/V)

Colour Depth

Response Time

TFT LCD (IPS panel)

55”

1920 x 1080

120 Hz

0.63 mm

700 cd/m2 (Typical)

7000:1 (AC)

178°/178° (Typical)

10 bits, 1.06B

10 ms (GTG)

Horizontal

Resolution

TV Lines 600 (NTSC), 620 (PAL)

Frequency (H/V) H.Freq

V.Freq

31 kHz - 91 kHz

50 Hz - 85 Hz

Input VGA

DVI

HDMI

CVBS

S-Video

Component (YPbPr)

15-Pin D-Sub

24-Pin DVI-D

HDMI x 1

BNC x 1

4-Pin mini DIN or RCA

BNC x 1 set

Output VGA

CVBS

15-Pin D-Sub

BNC x 1

External Control RS-232C/UART 9-Pin D-Sub x 2 (in/out)

Audio Audio Input

Audio Output

Speaker Output

1 x stereo audio in for PC (audio

jack, 3.5 Ø)

2 x stereo audio in for YPbPr or

CVBS (RCA)

1 x stereo audio out for YPbPr or

CVBS (RCA)

5W x 2 @ 8Ω

Power AC-DC Adaptor

Power

Consumption

Internal

100 – 240V, 50 – 60Hz

< 300W (On)

< 0.5W (Active Off)

< 0 W (Off by EcoSwitch)

Sync Format Video System NTSC/PAL/SECAM/4.43NTSC/PAL-60

Operating

Conditions

Temperature

Humidity

0°C ~ 40°C (32°F ~ 104°F)

20% ~ 80%

Storage

Conditions

Temperature

Humidity

-20°C ~ 60°C (-4°F ~ 140°F)

10% ~ 90%

Mounting VESA FPMPMI Yes (400mm x 400mm)

Bezel Design Border Width 19.5 mm (0.77”)

Dimensions w/o base

(W x H x D)

w base

(W x H x D)

w/o base Packaging

(W x H x D)

1252 x 723 x 136 mm

(49.3” x 28.5” x 5.4”)

1252 x 773 x 405 mm

(49.3” x 30.4” x 15.9”)

1490 x 975 x 352 mm

(58.7” x 38.4” x 13.8”)

Weight Product Weight

Packaging Weight

w/o base 46.4 kg (102.3 lbs)

w/o base 54.8 kg (120.8 lbs)

Regulation

Approval

Certiﬁcations &

Compliance

FCC, CB, CE, CEL, CCC, BSMI, RoHS,

WEEE, REACH

Accessories Supplied

Optional

User manual, 15-Pin VGA cable,

IR remote control

Stand base

RX-55

NeoV™ Optical Glass protects against scratches,

impacts and other physical damage

e stylish aluminum slim bezel design makes a pleasant

addition to any intended environment.

Ultra-thin Bezel

e exibility in display orientation—either landscape or

portrait—means user freedom in tting whatever setting.

Easy installation of a video wall matrix. (Up to 5x5)

Anti-Burn-in™, HeatControl Sensor and EcoSmart

Sensor technologies ensure round-the-clock operations
