AG Neovo X-17 Bedienungsanleitung

www.agneovo.com

X-17

A brilliant display that delivers

advanced design, durability and

versatile performance for progressive

professional environments.

e X-17 is a highly durable 17” display that will deliver decades of

performance. Featuring NeoV™ Optical Glass, built-in video support

and multiple input options, the X-17 is well suited to professional

public environments. e strong metal casing and VESA compatible

wall mounts allows the X-17 to be mounted just about anywhere.

e unique look and versatility of the X-17 make it the perfect

display solution for any modern environment.

> NeoV™ Optical Glass

> Durable metal casing

> Swi 3 ms response time

> Crisp 3000:1 dynamic contrast ratio

> S-Video and CVBS inputs

> DVI video inputs for high quality signal

> Hot key for preferred video mode: User, Text, Movie, Game, and Graphic

> Auto-adjustment for optimal settings

> Kensington® security socket

> VESA standard wall mount

> Available colours: black, white

NeoV™ Optical Glass - e most

trusted hard glass protection available.

Only on AG Neovo displays

Speciﬁcations X-17

Panel Panel Type

Panel Size

Max. Resolution

Pixel Pitch

Brightness

Contrast Ratio

Viewing Angle (H/V)

Display Colour

Response Time

Panel Life Time

TFT LCD

17.0” (432 mm)

SXGA 1280 x 1024

0.264 mm

300 cd/m2(Typical)

3000:1 (DCR)

160°/160° (Typical)

16.2M

3 ms (GTG)

50,000 hrs (Minimum)

Frequency (H/V) H: 30 kHz - 80 kHz

V: 56 Hz - 76 Hz

Max. Pixel Clock 160 MHz

Input Analogue

Digital

S-Video

CVBS

15-Pin D-Sub

24-Pin DVI-D

4-Pin Mini Din S-Video

CVBS Jack

Power AC-DC Adaptor

Power

Consumption

External

AC 100 - 240 V, 50 - 60 Hz

< 48 W (on)

< 2 W (Stand-by)

< 1 W (Off)

NeoV™

Optical Glass

Thickness

Reﬂection Rate

Transmission Rate

Hardness

3.0 mm (0.18”)

< 1%

> 96%

> 6H (MOH’s Rating)

Plug & Play VESA DDC-2B, DDC-CI, DPMS

Operating

Conditions

Temperature

Humidity

0 °C ~ 40 °C

10% ~ 90%

Storage

Conditions

Temperature

Humidity

-20 °C ~ 60 °C

5% ~ 95%

Mounting VESA FPMPMI Yes (100 mm)

Tilt Tilt 0° ~ +15°

Dimensions Product

(W x H x D)

Packaging

(W x H x D)

408 x 398 x 175 mm

(16.1” x 15.7” x 6.9”)

495 x 510 x 228 mm

(19.5” x 20.0” x 9.0”)

Weight Product Weight

Packaged Product Weight

6.8 kg (13.9 lbs)

9.5 kg (20.9 lbs)

Regulation

Approval

Certiﬁcations &

Compliance

FCC, UL/CUL, TUV/Baurt, CE,

BSMI, CB, ISO 13406-2, GOST,

Energy Star, TUV-S, WEEE,

RoHS

Accessories Supplied Quick Guide, CD ROM

(user manual and drivers),

power cord, power adaptor,

15-Pin D-Sub cable, 24-Pin

DVI-D cable, S-Video cable,

CVBS cable

All specications are subject to change without prior notice.

All other trademarks are the property of their respective owners.

P/C: X17JV_X17J1 Version 12.0, 20080530

X-17

NeoV™ Optical Glass protects against scratches,

impacts and other physical damage

A host of input options, including analogue,

digital, S-Video, CVBS

Metal casing for secure mounting, rapid heat

dissipation and unique industrial look

Smart sophisticated design enhances any environment
