Agilent Technologies HP 1660E Series Bedienungsanleitung

User’s Guide

HP 1660E/ES/EP and 1670E

Series Logic Analyzers

Publication Number 01660-97028

August 1998

For Safety information, Warranties, and Regulatory information, see

the pages behind the index.

©Copyright Hewlett-Packard Company 1994-1998

HP 1660E/ES/EP-Series Logic Analyzers

The HP 1660E/ES/EP-Series are 100-MHz State/500-MHz Timing Logic

Analyzers with a VGA resolution color display. The HP 1660ES-Series

has a 2 GSa/s digitizing oscilloscope. The HP 1660EP-Series has a built

in 32 channel pattern generator.

Logic Analyzer Features

• 130 data channels and 6 clock/data channels in the HP 1660E

• 96 data channels and 6 clock/data channels in the HP 1661E

• 64 data channels and 4 clock/data channels in the HP 1662E

• 32 data channels and 2 clock/data channels in the HP 1663E

• 3.5-inch flexible disk drive and 2 GB hard disk drive

• HP-IB, RS-232-C, parallel printer, and LAN interfaces

• BNC and TP LAN ports

• Variable setup/hold time

• 4 K memory on all channels with 8 K in half-channel mode

•Markermeasurements

• 12 levels of trigger sequencing for state and 10 levels of trigger sequencing

for timing

• Time tagging and number-of-states tagging

• Full programmability

• DIN mouse and keyboard support

Oscilloscope Features (HP 1660ES-Series only)

•500 MHz bandwidth

•2 Gigasample per second max sampling rate

•32768 samples per channel

•Marker measurements

displays time between markers, acquires until specified time between

markers in captured, performs statistical analysis on time between markers

•Lightweight miniprobes

Pattern Generator Features (HP 1660EP-Series only)

•16 output channels at 200 MHz

•32 output channels at 100 MHz

•258,048 vectors

Options

•Programmer's Guide

•Service Guide.

HP 1670E-Series Logic Analyzers

The HP 1670E-series logic analyzers are 100-MHz state/250-MHz timing logic

analyzers with VGA resolution color displays.

Features

•132 data channels and 4 clock/data channels in the HP 1670E

•98 data channels and 4 clock/data channels in the HP 1671E

•64 data channels and 4 clock/data channels in the HP 1672E

•3.5-inch flexible disk drive

•2 GB hard disk drive

•HP-IB, RS-232-C, parallel printer, and LAN interfaces

•BNC and TP LAN ports

•Variable setup/hold time

•1 M memory on all channels, 2 M in half-channel timing mode

•Marker measurements

•12 levels of trigger sequencing for state and 10 levels of trigger sequencing

for timing

•Time tagging and state tagging

•Full programmability

•DIN mouse and keyboard support

Options

•Programmer's Guide

•Service Guide

In This Book

This User’s Guide has three sections. Section 1 covers how to use the

HP 1660E/ES/EP and HP 1670E-series logic analyzers. Section 2

covers how to connect, use, and troubleshoot the HP logic analyzer via

a Local Area Network (LAN) connection. Section 3 covers the features

of the HP Symbol Utility software.

Section 1. Chapters 1 through 4 cover general product information

you need to use the logic analyzer. Chapter 5 covers how to use the

oscilloscope (1660ES-series only). Chapter 6 covers how to use the

pattern generator (1660EP-series only). Chapters 7 and 8 contains

detailed examples to help you use your analyzer in performing complex

measurements. Chapters 9 through 11 contains reference information

on the hardware and software, including the analyzer menus and how

they are used. Chapters 12 through 14 provides a basic service guide.

Section 2. Chapters 15 through 16 provides information about

connecting the logic analyzer to the network. Chapter 17 shows you

how to access the logic analyzer’s file system. Chapter 18 shows you

how to display the analyzer interface on an X Window server. Chapter

19 shows you how to retrieve measurement data, screen images, and

status information from you logic analyzer on the LAN, and how to

copy and restore configurations. Chapter 20 shows you methods for

programming the logic analyzer via the network connection. Chapter

21 contains additional information on the logic analyzer’s directory

structure and dynamic files. Chapter 22 describes what to do if you

have a problem using the logic analyzer on your network.

Section 3. Chapters 23 through 24 describe how to locate the menus

associated with the Symbol Utility. Chapter 25 describes how to use the

Symbol Utility to perform common tasks. Chapter 26 describes the

features and functions of the Symbol Utility.

In This Book

Contents

In This Book 5

SECTION 1

1 Logic Analyzer Overview

HP 1660/70-Series Logic Analyzer 28

To make a measurement 31

2 Connecting Peripherals

Connecting Peripherals 38

To connect a mouse 39

To connect a keyboard 40

To connect to an HP-IB printer 41

To connect to an RS-232-C printer 43

To connect to a parallel printer 45

To connect to a controller 46

3 Using the Logic Analyzer

Using the Logic Analyzer 48

Accessing the Menus 49

To access the System menus 50

To access the Analyzer menus 52

Contents

Using the Analyzer Menus 54

To label channel groups 54

To create a symbol 57

To examine an analyzer waveform 59

To examine an analyzer listing 62

To compare two listings 65

The Inverse Assembler 67

To use an inverse assembler 67

4 Using the Trigger Menu

Using the Trigger Menu 72

Specifying a Basic Trigger 73

To assign terms to an analyzer 74

To define a term 76

To change the trigger specification 77

Changing the Trigger Sequence 79

To add sequence levels 80

To change macros 82

Setting Up Time Correlation between Analyzers 83

To set up time correlation between two state analyzers 84

To set up time correlation between a timing and a state analyzer 85

Arming and Additional Instruments 86

To arm another instrument 86

To arm the oscilloscope with the analyzer (HP 1660ES-series only) 87

To receive an arm signal from another instrument 89

Contents

Managing Memory 91

To selectively store branch conditions (State only) 92

To set the memory length 94

To place the trigger in memory 96

To set the sampling rates (Timing only) 98

5UsingtheOscilloscope

Using the Oscilloscope 100

Calibrating the oscilloscope 101

Calibration PROTECT/UNPROTECT switch 101

Set up the equipment 101

Load the default calibration factors 102

Self Cal menu calibrations 103

Protect the operational accuracy calibration factors 105

Oscilloscope Common Menus 106

Run/Stop options 106

Autoscale 108

Time base 110

The Scope Channel Menu 111

Offset field 111

Probe field 112

Coupling field 112

Preset field 113

Contents

The Scope Display Menu 114

Mode field 114

Connect Dots field 116

Grid field 116

Display Options field 117

The Scope Trigger Menu 118

Trigger marker 118

Mode/Arm menu 118

Level field 121

Source field 123

Slope field 123

Count field 124

Auto-Trig field 125

When field 126

Count field 129

The Scope Marker Menu 130

Manual time markers options 130

Automatic time markers options 133

Manual/Automatic Time Markers option 138

Voltage Markers options 139

Channel Label field 141

The Scope Auto Measure Menu 142

Input field 142

Automatic measurements display 143

Automatic measurement algorithms 145

6 Using the Pattern Generator

Using the Pattern Generator 150
