Airbi Smile Bedienungsanleitung
EN
Digital thermo-hygrometer
SMILE
Thank you for choosing this instrument from Airbi.
BEFORE YOU START USING IT
Please make sure to read the instruction manual carefully. This information will help you to
familiarise yourself with your new device, to learn all of its functions and parts, to find out important
details about its first use and how to operate it, and to get advice in the event of faults.
Following and respecting the instructions in your manual will prevent damage to your instrument
and loss of your statutory rights arising from defects due to incorrect use.
ikewise, we take no responsibility for any incorrect readings and for any consequences which may
result from them.
We shall not be liable for any damage occuring as a result of non-following of these instructions.
Please take particular note of the safety advice!
Please keep this instruction manual for future reference.
SCOPE OF DELI ERY
Thermo-Hygrometer
Instruction manual
FUNCTIONS
Indication of indoor temperature and humidity.
Memory for maximum and minimum values.
Indication of indoor climate.
SAFETY INSTRUCTIONS
This product is exclusively intended for the field of application described above. It should only be
used as described within these instructions.
Unauthorized repairs, modifications or changes to the product are prohibited.
This product is not be used for medical purpose or for public information, it is only intended for
home use.
Keep this instrument and the battery out of the reach of children.
Batteries must not be thrown into a fire, short-circuited, taken apart or recharged. Risk of explosion!
Batteries contain harmful acids. ow batteries should be changed as soon as possible to prevent
damage caused by leaking.
Wear chemical-resistant protective gloves and glasses when handling leaking batteries.
Do not place your product near extreme temperatures, vibrations or shocks.
DISPLAY SCHEME
A: Display
A 1: Temperature, MAX/MIN
A 2: Humidity, MAX/MIN
A 3: Indication of indoor climate
Page 1 from 3
EN
B: Back:
B 1: Stand
B 2: MAX/MIN button
B 3: °C/°F button
B 4: Battery cover
GETTING STARTED
Open the battery compartment and remove isolation strip from battery.
Close the battery compartment.
All CD segments will be displayed for a short moment.
The unit is ready for use.
The display shows the current indoor temperature and humidity.
MAX/MIN ALUES
Press the MAX / MIN button to display the minimum measured values since the last reset.
Pressing the MAX / MIN button again will display the maximum measured values since the last
reset.
Pressing the MAX / MIN button again switches the display to the current temperature and humidity
values.
If you want to reset the minimum and maximum values, then you must hold down the MAX / MIN
button for 2-3 seconds.
SETTING OF THE TEMPERATURE UNIT
Press the °C/°F button to change between °C (Celsius) or °F (Fahrenheit) as temperature unit.
INDICATION OF ROOM CLIMATE
The climate level in the room is shown on the display by a smiley icon:
19 – 25 °C 40 – 60 % Ideal values
15–18,9 °C, 25,1–30 °C 30–39 %, 61–70 %
<15 °C, >30 °C <30 %, > 70 %
INSTALLATION
•The device can be placed on a base using a tilting stand or you can attach it to a metal surface (eg.
refrigerator) using a magnet on the back of the device.
CARE AND MAINTENANCE
Clean your instrument with a soft damp cloth. Do not use solvents or scouring agents.
Remove the battery if you do not use the product for a long period of time.
Keep the instrument in a dry place.
BATTERY REPLACEMENT
Replace the battery when the display becomes weak.
Open the battery compartment and insert a new battery CR2032, ensure that the battery polaritiy is
correct.
Close the battery compartment again.
Page 2 from 3
EN
TROUBLESHOOTING
No display on the device: Incorrect indication:
Ensure that the battery polarity is correct
Change the battery
Change the battery
If device fails to work despite these measures contact the supplier from whom you purchased it.
WASTE DISPOSAL
This product has been manufactured using high-grade materials and components which can be
recycled and reused.
Never dispose of empty batteries and rechargeable batteries in household waste.
As a consumer, you are legally required to take them to your retail store or to an appropriate
collection site depending on national or local regulations in order to protect the environment.
The symbols for the heavy metals contained are:
Cd=cadmium, Hg=mercury, Pb=lead
This instrument is labeled in accordance with the EU Waste Electrical and Electronic Equipment
Directive (WEEE).
Please do not dispose of this instrument in household waste. The user is obligated to take end-
of-life devices to a designated collection point for the disposal of electrical and electronic
equipment, in order to ensure environmentally-compatible disposal.
SPECIFICATIONS
Power consumption: battery 1 x CR2032 (included)
Measuring range temperature: -20°C…+60°C
Accuracy of temperature: +/- 1°C in range (0°C - 40°C)
Measuring range humidity: 20...95 % rH
Accuracy of humidity: +/- 5% in range (40% - 80%)
Housing dimension: 73 x 73 x 15 mm
Weight: 52 g (with battery)
Manufacturer: Bibetus, s.r.o., oosova 1, Brno 638 00, Czech republic
No part of this manual may be reproduced without written consent of manufacturer. The technical data are
correct at the time of going to print and may change without prior notice. The latest technical data and
information about your product can be found by entering your product number on our homepage.
www.airbi.eu
2/2022
Page 3 from 3
