AJA IPR-10G2-HDMI Betriebsanleitung

10 GigE IP Mini-Converters

SMPTE 2110 IP Transmit/Receive

Version 2.2r1

Published March 9, 2020

Installation and Operation Guide

10 GigE IP Mini-Converters SMPTE 2110 IP Transmit/Receive v2.2r1 2 www.aja.com

Notices

Trademarks

AJA® and Because it matters.® are registered trademarks of AJA Video Systems, Inc.

for use with most AJA products. AJA™ is a trademark of AJA Video Systems, Inc. for

use with recorder, router, software and camera products. Because it matters.™ is a

trademark of AJA Video Systems, Inc. for use with camera products.

Corvid Ultra®, lo®, Ki Pro®, KONA®, KUMO®, ROI® and T-Tap® are registered trademarks of

AJA Video Systems, Inc.

AJA Control Room™, KiStor™, Science of the Beautiful™, TruScale™, V2Analog™ and

V2Digital™ are trademarks of AJA Video Systems, Inc.

All other trademarks are the property of their respective owners.

this manual is subject to change without notice. No part of the document may be

reproduced or transmitted in any form, or by any means, electronic or mechanical,

including photocopying or recording, without the express written permission of AJA

Video Systems, Inc.

Contacting AJA Support

When calling for support, have all information at hand prior to calling. To contact AJA

for sales or support, use any of the following methods:

Telephone +1.530.271.3190

FAX +1.530.271.3140

Web https://www.aja.com

Support Email suppor[email protected]

Sales Email [email protected]

Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Contacting AJA Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Chapter 1 – Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Pre-Built System Conguration Modes for IPR-10G2 and IPR-10G . . . . . . . 6

10 GigE IP Mini-Converters Features . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

IPT-10G2-SDI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

IPT-10G2-HDMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

IPR-10G2-SDI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

IPR-10G2-HDMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

IPR-10G-HDMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Abbreviated Feature Comparison Chart for v2.2 . . . . . . . . . . . . . . . . . 10

Workow Diagrams and I/O Connections . . . . . . . . . . . . . . . . . . . . . . . 11

Simplied Block Diagrams and Logic Diagrams . . . . . . . . . . . . . . . . . . . 16

Frequently Asked Questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

System Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Control LAN, Ready, Link/Act, and Lock LED Behavior. . . . . . . . . . . . . . 18

Installation Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Initial Setup By Web Browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Initial Setup By AJA eMini-Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Hardware Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Settings Retained. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

REST API Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Chapter 2 – eMini-Setup . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Acquiring eMini-Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

eMini-Setup Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Installing eMini-Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

PC Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Mac Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Running eMini-Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

PC Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Mac Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Operating eMini-Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Control LAN Tab Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Media LAN 1 Tab Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Media LAN 2 Tab Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Update Tab Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Firmware Update Procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Info Tab Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Chapter 3 – 10 GigE IP Mini-Converters Web Interface. . . . . . . .30

Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Remote Control Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Networking Option – Using Only the Media LAN Port for Control and Media

Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Web Browser via Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

General Screen Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Status Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

IPT-10G2-SDI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

IPR-10G2-HDMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Cong Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

IPT-10G2-SDI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

IPR-10G2-HDMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Contents

10 GigE IP Mini-Converters SMPTE 2110 IP Transmit/Receive v2.2r1 4 www.aja.com

Presets Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Presets Screen Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Network Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Firmware Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Downloading and Installing Updated Firmware . . . . . . . . . . . . . . . . . 56

Booting the 10 GigE IP Mini-Converters from the Safeboot Firmware . . . 56

Appendix A – Specications . . . . . . . . . . . . . . . . . . . . . . . . 58

IPT-10G2-SDI Tech Specs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

IPT-10G2-HDMI Tech Specs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

IPR-10G2-SDI Tech Specs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

IPR-10G2-HDMI Tech Specs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

IPR-10G-HDMI Tech Specs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Appendix B – Safety and Compliance . . . . . . . . . . . . . . . . . . 67

Warranty and Liability Information . . . . . . . . . . . . . . . . . . . .75

Limited Warranty on Hardware. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Limitation of Liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Governing Law and Language; Your Rights . . . . . . . . . . . . . . . . . . . . . . 75

Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77

10 GigE IP Mini-Converters SMPTE 2110 IP Transmit/Receive v2.2r1 5 www.aja.com

Chapter 1 – Introduction

Overview

AJA 10 GigE IP Mini-Converters are designed for point of use applications for

encoding, transport, reception and decoding of IP based video sources. Rugged,

compact and fanless, the 10 GigE IP Mini-Converters provide the bridge between

Baseband and IP video for a range of applications, such as sending and receiving

video over IP from remote facilities in post production, source monitoring, digital

signage, and video walls. 10 GigE IP Mini-Converters ease the cost of extensive

monitoring distribution in a facility.

The 10 GigE IP Mini-Converter Transmitters take baseband HDMI or SDI input

and encode the data as SMPTE 2110. The embedded audio associated with the

video stream is also encoded to SMPTE 2110. Alternatively, analog audio can be

encoded and sent with the video stream instead.

The 10 GigE IP Mini-Converter Receivers decode SMPTE 2110 and format the data

for either HDMI or SDI output. The audio associated with the video stream is

extracted, synchronized, and then embedded into the HDMI or SDI signal as well

as output on a stereo analog RCA audio output.

All UltraHD rates (23.98, 24, 25, 29.97, 30, 50) can be received only by the IPR-10G2-

HDMI and IPR-10G-HDMI.

Both the IPR-10G2-HDMI and the IPR-10G-HDMI can provide RGB (rather than

YCbCr) to a compatible monitor if the monitor or other sink device indicates this

availability via EDID.

10 GigE IP Mini-Converters SMPTE 2110 IP Transmit/Receive v2.2r1 6 www.aja.com

Pre-Built System Configuration Modes for IPR-10G2 and IPR-

10G

There is a set of pre-built system configuration modes, or "system modes,"

available from the System Mode control on the Config page of the IPR-10G2 web

UI. These pre-built System Modes are designed to save you time so that you can

get your unit up and running quickly.

Each System Mode is built for a specific type of use case, taking into account

factors such as network conditions, protection requirements, timing, and latency

considerations.

Please see "System Modes" on page 43 for more detailed information.

NOTE: The System Modes are available only for the IPR units; they are not found on the

IPT units.

NOTE: Like the IPR-10G2-HDMI and IPR-10G2-SDI, the IPR-10G-HDMI has the System

Modes. However, since the 10G model does not have dual stream redundancy, it

does not offer the highest level of packet-level protection. It can re-order packets

into the correct order and provide Frame Sync, but it does not have the second

stream input for signal stream redundancy, nor does single stream mode provide

any dropped packet protection.

On a high level, the five pre-built System Modes are described as follows:

PTP Low Latency

• Appropriate under ideal network conditions

• Fastest method of moving data through the device (does not require signal

processing)

• Provides the least amount of packet-level and frame-level protection

• Remote sender and AJA IPR-10G2 receiver are locked to PTP

PTP Protected

• Provides the highest amount of packet-level and frame-level protection,

including redundancy support with ST 2022-7

• Maximum latency due to longer signal processing chain

• Remote sender and AJA IPR-10G2 receiver are locked to PTP

Gateway

• Bridges between PTP and Reference Video timed domains

• Provides frame-level protection

• Moderate latency due to signal processing chain

Gateway Protected

• Bridges between PTP and Reference Video timed domains

• Provides the highest amount of packet-level and frame-level protection,

including redundancy support with ST 2022-7

• Maximum latency due to longer signal processing chain

Asynchronous

• Intended as a setup environment or troubleshooting and demo tool

• Not for production

• When unable to lock to PTP or when experiencing problems with Reference

In, uses Video In to verify that video is being received from source address

• Provides frame-level protection (no packet-level protection)

• Moderate latency due to signal processing chain

10 GigE IP Mini-Converters SMPTE 2110 IP Transmit/Receive v2.2r1 7 www.aja.com

Advanced

Unlike the five pre-built System Modes just described, each of which are "safe,"

Advanced Mode does not guard against a user applying contradictory settings

that could provide unpredictable results.

Characteristics of Advanced Mode include the following:

• For custom configurations

• Has no native default settings

• Can be used to iterate and expand upon the five pre-built System Modes

described above

• Provides free-range access to:

• Video Clock Mode

• Packet Protection Mode

• Frame Sync Mode

• System Mode

• Audio Sample Rate Converter

• When selected, Advanced Mode will retain the settings of the previously

selected System Mode, and the user may proceed to customize settings as

desired. This means that any of the System Modes can be modified using

Advanced Mode and then saved as a Preset on the Presets screen.

NOTE: When working with Advanced Mode, if the configuration settings become

problematic, you can always "revert" to one of the five pre-built System Modes to

get the unit running again with established internally compatible settings.

10 GigE IP Mini-Converters Features

IPT-10G2-SDI

• SMPTE ST 2110 audio, video transmitter including support for ST 2022-7

• Essence support: SMPTE 2110-10, 2110-20, 2110-30

• Rugged, quiet, fanless design

• 2x 10 GigE SFP+ cages for media LAN with status light (for media transport,

control, and timing input), SFP+ modules not included)

• 1x 1 GigE RJ45 socket for control LAN with status light

• Complete control interface on any web browser from a built-in web server

• Customizable control with AJA REST API

• Control supported over dedicated management Ethernet port and in-band

over media ports

• NMOS Rx discovery and control according to standards IS-04 v1.2 and IS-05

v1.0

• Ember+ control (no discovery, control only)

• AJA REST API control (discovery via SSDP or MDNS)

• 1x 3G-SDI Input

• 1x 3G-SDI Loop Out

• Support for HD up to 1080 60p, YCbCr 4:2:2

• Concealment of errors due to packet loss

• Full 10-bit pixel processing pipeline

• Embedded SDI audio input (up to eight channels)

• 2x RCA analog audio input

• 1x BNC Reference Out, allowing incoming baseband sources to be locked to

PTP timing

10 GigE IP Mini-Converters SMPTE 2110 IP Transmit/Receive v2.2r1 8 www.aja.com

• 1x mini-USB port for initial network configuration with AJA eMini-Setup

software (alternative setup method)

• 5-year international warranty and support

IPT-10G2-HDMI

• SMPTE ST 2110 audio, video transmitter including support for ST 2022-7

• Essence support: SMPTE 2110-10, 2110-20, 2110-30

• Rugged, quiet, fanless design

• 2x 10 GigE SFP+ cages for media LAN with status light (for media transport,

control, and timing input), SFP+ modules not included)

• 1x 1 GigE RJ45 socket for control LAN with status light

• Complete control interface on any web browser from a built-in web server

• Customizable control with AJA REST API

• Control supported over dedicated management Ethernet port and in-band

over media ports

• NMOS Rx discovery and control according to standards IS-04 v1.2 and IS-05

v1.0

• Ember+ control (no discovery, control only)

• AJA REST API control (discovery via SSDP or MDNS)

• Dedicated HDMI transmitter with full size (standard type A) HDMI 1.4b (24/30-

bits per pixel) input up to HD 60p, 4:2:2, 10-bit, YCbCr

• Concealment of errors due to packet loss

• Full 10-bit pixel processing pipeline

• Embedded SDI audio input (up to eight channels)

• 2x RCA analog audio input

• 1x BNC Reference Out, allowing incoming baseband sources to be locked to

PTP timing

• 1x mini-USB port for initial network configuration with AJA eMini-Setup

software (alternative setup method)

• 5-year international warranty and support

IPR-10G2-SDI

• SMPTE ST 2110 audio, video receiver including support for ST 2022-7

• Essence support: SMPTE 2110-10, 2110-20, 2110-30

• Rugged, quiet, fanless design

• 2x 10 GigE SFP+ cages for media LAN with status light (for media transport,

control, and timing input), SFP+ modules not included)

• 1x 1 GigE RJ45 socket for control LAN with status light

• Complete control interface on any web browser from a built-in web server

• Customizable control with AJA REST API

• Control supported over dedicated management Ethernet port and in-band

over media ports

• NMOS Rx discovery and control according to standards IS-04 v1.2 and IS-05

v1.0

• Ember+ control (no discovery, control only)

• AJA REST API control (discovery via SSDP or MDNS)

• 2x 3G-SDI Output (mirrored)

• Support for HD up to 1080 60p, YCbCr 4:2:2

• Concealment of errors due to packet loss

• Full 10-bit pixel processing pipeline

• Embedded SDI audio output (up to eight channels)

10 GigE IP Mini-Converters SMPTE 2110 IP Transmit/Receive v2.2r1 9 www.aja.com

• 2x RCA analog audio output

• 1x BNC Reference for analog/tri-level reference input, allowing baseband

output to be locked to the facility baseband clock (instead of PTP)

• 1x mini-USB port for initial network configuration with AJA eMini-Setup

software (alternative setup method)

• 5-year international warranty and support

IPR-10G2-HDMI

• SMPTE ST 2110 audio, video receiver including support for ST 2022-7

• Essence support: SMPTE 2110-10, 2110-20, 2110-30

• Rugged, quiet, fanless design

• 2x 10 GigE SFP+ cages for media LAN with status light (for media transport,

control, and timing input), SFP+ modules not included)

• 1x 1 GigE RJ45 socket for control LAN with status light

• Complete control interface on any web browser from a built-in web server

• Customizable control with AJA REST API

• Control supported over dedicated management Ethernet port and in-band

over media ports

• NMOS Rx discovery and control according to standards IS-04 v1.2 and IS-05

v1.0

• Ember+ control (no discovery, control only)

• AJA REST API control (discovery via SSDP or MDNS)

• Dedicated HDMI receiver with full size (standard type A) HDMI 1.4b (24/30-bits

per pixel) output up to HD 60p, 4:2:2, 10-bit, YCbCr/RGB, or UltraHD 30p,4:2:2,

10-bit, YCbCr, or UltraHD 50p, 4:2:0, 8-bit, YCbCr

• ST 2022-7 is supported up to HD 1080p (UltraHD not supported)

• Concealment of errors due to packet loss (error concealment functionality

supported up to 1080p 60, UltraHD not supported)

• Full 10-bit pixel processing pipeline (except for UHD p50)

• Embedded HDMI audio output (up to eight channels)

• 2x RCA analog audio output

• 1x BNC Reference for analog/tri-level reference input, allowing baseband

output to be locked to the facility baseband clock (instead of PTP)

• 1x mini-USB port for initial network configuration with AJA eMini-Setup

software (alternative setup method)

• 5-year international warranty and support

IPR-10G-HDMI

• SMPTE 2110 audio, video receiver

• Essence support: SMPTE 2110-10, 2110-20, 2110-30

• Rugged, quiet, fanless design

• 1x 10 GigE SFP+ cages for media LAN with status light (for media transport,

control, and timing input), SFP+ modules not included)

• 1x 1 GigE RJ45 socket for control LAN with status light

• Complete control interface on any web browser from a built-in web server

• Customizable control with AJA REST API

• Control supported over dedicated management Ethernet port and in-band

over media ports

• NMOS Rx discovery and control according to standards IS-04 v1.2 and IS-05

v1.0

• Ember+ control (no discovery, control only)

10 GigE IP Mini-Converters SMPTE 2110 IP Transmit/Receive v2.2r110 www.aja.com

• AJA REST API control (discovery via SSDP or MDNS)

• Dedicated HDMI receiver with full size (standard type A) HDMI 1.4b (24/30-bits

per pixel) output up to HD 60p, 4:2:2, 10-bit, YCbCr/RGB, or UltraHD 30p, 4:2:2,

10-bit, YCbCr, or UltraHD 50p, 4:2:0, 8-bit, YCbCr

• Concealment of errors due to packet loss (error concealment functionality

supported up to 1080p 60 – UltraHD is not supported)

• Full 10-bit pixel processing pipeline (except for UHD p50)

• Embedded HDMI audio output (up to eight channels)

• 2x RCA analog audio output

• 1x mini-USB port for initial network configuration with AJA eMini-Setup

software (alternative setup method)

• 5-year international warranty and support

Abbreviated Feature Comparison Chart for v2.2

Model UltraHD

Support

Reference

Functions

System

Modes

2022-7

support

RGB 4:4:4

10-bit

IPT-10G2-SDI Ref Out Up to

1080 p60

IPT-10G2-HDMI Ref Out Up to

1080 p60

IPR-10G2-SDI Ref In Supported Up to

1080 p60

IPR-10G2-HDMI Up to

UHD p50

Ref In Supported Up to

1080 p60

Up to

1080 p60

IPR-10G-HDMI Up to

UHD p50

Supported Up to

1080 p60

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere AJA Empfänger Handbücher

AJA

AJA RovoRx-HDMI Betriebsanleitung

Beliebte Empfänger Handbücher anderer Marken

Garmin

Garmin GA 23 Bedienungsanleitung

Aiphone

Aiphone PS-12F Bedienungsanleitung

IMES

IMES TCS-01CA-PMI Bedienungsanleitung

BWI Eagle

BWI Eagle AIR-EAGLE SR Handbuch

AMIMON

AMIMON AMN12310 WHDI Bedienungsanleitung

Dual

Dual DMCPA79BT Betriebsanleitung

Sound Associates

Sound Associates SA652P Bedienungsanleitung

Sherwood

Sherwood NewCastle R-772 Bedienungsanleitung

Audio

Audio A10-RX Series Bedienungsanleitung

AllSee

AllSee PushShare PSRV1.1 Bedienungsanleitung

DEMAG

DEMAG DRC-DR D2 Bedienungsanleitung

Teleco

Teleco TVRCL868A02 Bedienungsanleitung

Bosch

Bosch RF3222E Bedienungsanleitung

Kramer

Kramer 631R Bedienungsanleitung

Xpress

Xpress xmc10 Bedienungsanleitung

JVC

JVC KD-MR1BTS Bedienungsanleitung

Omega Engineering

Omega Engineering UWTC-REC3 Bedienungsanleitung

e-survey

e-survey E300 Pro Bedienungsanleitung
