PERFORMANCE

Allied Telesyn's AT-8024 Fast Ethernet managed switch

provides exceptional performance, ease of use and flexi-

bility at an affordable price. Utilizing a robust 9.6Gbps

non-blocking switching architecture for wire speed pack-

et forwarding and featuring priority queuing for weighted

packet management, the AT-8024 is ideally suited for

deployment in small and medium enterprises, in multi-

unit buildings, hotels, schools and universities.

MANAGEMENT

Although the AT-8024 switch can be used as a plug-and-

play device, an extensive range of management is provided

at no additional charge. Management features include

Web-based management, SNMP and Telnet.

RICH FEATURE SET

Richly equipped with features that include 802.1Q

VLAN tagging and IEEE 802.1p priority queuing, the

AT-8024 allows for greater network micro-segmentation

and traffic prioritization. When network managers have

bandwidth hungry or time sensitive data, these switches

can be programmed to prioritize this traffic over other

types. The AT-8024 also features IEEE 802.3ad compliant

Link Aggregation capabilities on each 10/100 port and

supports up to 4 ports in a trunk group.Auto-negotiation

and broadcast storm control capabilities on all ports are

included. Additionally the Auto-MDI/X feature allows

easy connection to other switches from any port.

ABOUT ALLIEDTELESYN, INC.

AlliedTelesyn, Inc. leads the world in network technolo-

gies for the access edge.Since the company's inception in

1987, Allied Telesyn has been developing IP-based net-

work products for use in video,voice and data networks

at the metro edge,in education,government agencies and

across the enterprise.AlliedTelesyn's access,aggregation

and core transport technologies range from simple

Ethernet adapters, hubs and media converters to robust

multi-layer Gigabit Ethernet switches and routers, wire-

less systems, DTM and WDM transport solutions for

delivering real-time voice, video and data.AlliedTelesyn's

comprehensive support and professional service pro-

grams are suited to meet the growing demands of today's

switched broadband infrastructures.

www.alliedtelesyn.com

AT-8024, Managed Fast Ethernet Switch

KEY FEATURES

9.6Gbps switch fabric

Wirespeed

Non-blocking

Web-based management

SNMP support

IEEE 802.1QVLAN tagging

IEEE 802.1p Prioritization

IEEE 802.3ad

Link Aggregation

Port security

Port mirroring

Auto MDI/MDIX

1 RU form factor

IGMP v1 and v2

Lifetime limited warranty

SWITCHES

AT-8024,24 port managed Fast Ethernet switch

AT-8024

Server

Printer

AT-8024

Printer

Workgroup

100TX Trunk

100TX

10T

PERFORMANCE

9.6Gbps switching fabric

Up to 8.8Mpps

14,880pps for 10Mbps Ethernet

148,800pps for 100Mbps Ethernet

1,488,000pps for 1000Mbps Ethernet

MAC addresses 4K

Buffer Memory 6MB

VLANs 32

Basic VLAN mode

Broadcast Storm Control

Head of Line Blocking

Half/Full Duplex

Autonegotiation

Auto MDI/MDIX

RELIABILITY

MTBF 46,000 hours

INTERFACE CONNECTIONS

10/100TX Shielded RF-45

RS232 9 pin female port

NETWORK MANAGEMENT

SNMP

Web-based management

RS232 Console Access

Command Menu Interface (ATI Omega)

Telnet

POWER CHARACTERISTICS

Voltage 100-240vAC

Current 4.0/2.0A

Frequency 50-60Hz

Power Consumption 30W Max.

ENVIRONMENTAL SPECIFICATIONS

Operating Temp. 0°C to 40°C (32°F to 104°F)

Non-Operating Temp. -25°C to 70°C (-13°F to 158°F)

Relative Humidity 95% noncondensing

PHYSICAL CHARACTERISTICS

Height 4.4cm (1.8”)

Width 44cm (17.3”)

Depth 18.5cm (7.3”)

Weight 2.7kg (6lbs)

Mounting 19" rackmountable, hardware included

STANDARDS AND COMPLIANCE

IEEE 802.3 10T Ethernet

IEEE 802.3u 100TX Ethernet

IEEE 802.3ad Link Aggregation

IEEE 802.1d Spanning Tree

IEEE 802.1p Class of Service

IEEE 802.1Q VLAN Tagging

IEEE 802.3x Flow Control

RFC 1112 IGMP Snooping v1

RFC 2236 IGMP Snooping v2

RFC 951 BootP

RFC 2131 DHCP

RFC 1350 TFTP

SNMP STANDARDS

RFC 1213 MIB II

RFC 1493 Bridge MIB

RFC 1573 Interface Group MIB

RFC 1643 Ethernet MIB

RFC 1757 Remote Network MIB

ELECTRICAL/MECHANICAL APPROVALS

UL 1950

FCC Class A

CSA 22.2 No. 950

EN55022 Class A

En 60950 (TUV)

EN50082-1

VCCI

COUNTRY OF ORIGIN

Indonesia

USA Headquarters: 19800 North Creek Pkwy, Suite 200, Bothell,WA 98011, USA • Tel: 800.424.4284 • Fax: 425.481.3895

European Headquarters: Via Motta 24, 6830 Chiasso, Switzerland • Tel: +41 (91) 697.69.00 • Fax: +41 (91) 697.69.11

www.alliedtelesyn.com

All company names,logos, and product designs that are trademarks or registered trademarks are the property of their respective owners.

617-00413-00 Rev. B

ORDERING INFORMATION

AT-8024-xx

24 port managed Fast Ethernet switch

Where xx =10 for U.S. power cord

20 for no power cord

30 for U.K. power cord

40 for Australia power cord

50 for European power cord

AT-8024, Managed Fast Ethernet Switch
