AR450S Quick Install Guide

Document Number C613-04045-01 REV A.

19800 North Creek Parkway, Suite 200, Bothell, WA 98011, USA.

permission from Allied Telesyn.

Allied Telesyn International, Corp. reserves the right to make changes in specifications

and other information contained in this document without prior written notice. The

information provided herein is subject to change without notice. In no event shall Allied

Telesyn be liable for any incidental, special, indirect, or consequential damages

whatsoever, including but not limited to lost profits, arising out of or related to this

manual or the information contained herein, even if Allied Telesyn has been advised of,

known, or should have known, the possibility of such damages.

All trademarks are the property of their respective owners.

Quick Install Guide 3

C613-04045-01 REV A

Models Covered By This Guide

This Quick Install Guide includes information on the following model:

■AR450S

Quick Install Guide updates can be found at

www.alliedtelesyn.co.nz/support/ar400/

Package Contents

The following items are included with each AR450S router. Contact your sales

representative if any items are damaged or missing.

■One AR450S router.

■One AC power cord.

■One power cord retaining clip.

■One terminal cable for connecting the router to a terminal or PC.

■Two UTP network cables.

■One rack-mount kit with brackets and screws.

■One AR450S Router Quick Install Guide.

■One Safety and Statutory Information booklet.

■One AR400 Series Router Documentation and Tools CD-ROM (which

includes the complete AR400 Series Document Set and utilities).

■One warranty card.

AR450S Router

AR450S Quick Install Guide

AR Router Hardware Reference

AR400 Series Software Reference

General Customer Support

Visit www.alliedtelesyn.co.nz for

the latest documentation, FAQ,

and support information

Printed Acrobat PDF

Documentation Roadmap

Website

AR400 Series User Guide

AR400 Series Safety and Statutory Information

4AR450S Router

C613-04045-01 REV A

Selecting a Site

The router should be installed on a level surface such as a desktop or bench.

When installing the router, choose a site that:

■Allows adequate airflow around the router and its vents.

■Is free of dust and moisture.

■Will maintain an ambient temperature range of 0 to 40º C (32 to 104º F) and

a humidity range of 5 to 95% non-condensing.

■Has a reliable and earthed (grounded) power supply circuit, preferably

dedicated and filtered.

■Does not expose cabling to sources of electrical noise, such as radios,

transmitters, broadband amplifiers, power lines, electric motors, and

fluorescent fixtures.

■Allows easy access to the router’s power and cable connections.

Installing the Router

This equipment must be earthed.

Follow these steps to install the router:

1. Read the safety information.

For safety information, see the Safety and Statutory Information booklet. A

copy of this booklet is supplied with each router, and can also be found on

the Documentation and Tools CD-ROM or at

www.alliedtelesyn.co.nz/support/ar400/

2. Unpack the router.

Verify the package contents. If any items are damaged or missing, contact

your sales representative.

3. Place the router in its operating location.

See the previous Selecting a Site section for guidelines on choosing a

suitable location.

4. Check the supply voltage and the router’s rated voltage.

AR450S routers are fitted with a universal mains power supply that will

function over the range 100-240 VAC and 50–60Hz.

The specific power supply requirements for a particular model are clearly

displayed on the rear or underside of the router. If the supply is outside the

accepted range for the router, the router may not operate and damage to the

router may result.

Quick Install Guide 5

C613-04045-01 REV A

5. Apply power to the router.

Fit the power cord retaining clip to the AC power inlet on the router’s rear

panel.

Connect the provided power cord to the AC power inlet and clip it in

place. Switch the router’s power switch to the ON position. The Power

LED will light continuously and the System LED will flash briefly. The Port

LEDs may also light briefly.

If the LEDs fail to light, the most likely cause is that the router is not

receiving power. Check that

• The power supply outlet’s switch (if any), and the router’s power

switch, are in the ON position

• The power cable is securely plugged in

• The power supply is operational

If the LEDs light incorrectly, refer to the AR Router Hardware Reference for

troubleshooting information.

Figure 1: Front and rear panels of an AR450S, showing the AC power inlet, power switch, console ports and

Ethernet ports, and their associated LEDs.

Configuring the Router

AR450S routers can be configured via the Command Line Interface (CLI) or

Graphical User Interface (GUI).

Using the CLI to configure a router:

1. Initiate router start-up.

Using the terminal cable supplied, connect a VT100-compatible terminal,

or the COM port of a PC running a terminal emulation program such as

Windows Terminal, to the Console RS-232 (ASYN0) port on the router’s

rear panel.

6AR450S Router

C613-04045-01 REV A

Set the communication parameters on your terminal or terminal emulation

program to:

• Baud rate: 9600

• Data bits: 8

•Parity:None

•Stopbits:1

• Flow control: Hardware

See the AR Router Hardware Reference for more information on configuring

emulation software.

2. Log in and set the password.

The log in prompt appears on the terminal or PC. If the log in prompt

doesn’t appear, press [Enter] two or three times.

When the router boots for the first time it automatically creates an account

with manager privileges. The account has the log in name “manager” and

the password is “friend”. Passwords are case sensitive.

At the log in prompt, enter the log in name and password.

Password: friend

The router’s command prompt appears and you can now configure the

router using the command line interface.

Change the password as soon as possible. Leaving the manager account with

the default password is a serious security risk. Make sure you remember the

new password as there is no way to retrieve it if it is lost.

Use the following command to change the account password:

set password

To display a list of help topics, enter:

help

To display help on a specific topic, enter:

help topic

Alternatively, type a question mark (?) at the end of a partially completed

command to see a list of valid options.

See the AR400 Series Router Software Reference for more information on

router start-up and configuration procedures (including a list of message

definitions).

Using the GUI to configure a router:

This section describes how to access the GUI via VLAN1, when the PC and

the router are in the same subnet, in order to configure the router. The

router’s five switch ports all belong to VLAN1 by default.

The GUI requires a PC and web browser. Supported browsers are Internet

Explorer 5.0 and greater, or Netscape 6.2.2 or 6.2.3, with JavaScript enabled.

Internet Explorer can be found on the Documentation and Tools CD-ROM

that is bundled with your router.

Quick Install Guide 7

C613-04045-01 REV A

1. Connect the PC to a router switch port.

The PC can be connected directly, or through your LAN.

To connect the PC directly to the router, use a straight-through Ethernet

cable to connect an Ethernet card on the PC to any one of the router’s

switch ports. Note the PC’s IP address and mask.

To connect via a LAN, use a straight-through Ethernet cable to connect the

router’s switch port(s) to the device(s) on the LAN. Select the LAN PC

from which you wish to configure the router. The PC should be in the same

subnet as the part of the LAN that contains the router (for example, the PC

could be connected to a hub or Layer 2 switch that is directly connected to

one of the router’s switch ports). Note the PC’s IP address and mask.

2. Access the CLI on the router.

Follow the instructions in the previous Using the CLI to configure a router

section.

3. Enable IP.

At the CLI, enter the command:

ENABLE IP

Hub or

switch

8AR450S Router

C613-04045-01 REV A

4. Assign an IP address to VLAN1.

Assign the VLAN1 interface an IP address in the subnet that the PC uses,

using the command:

ADD IP INTERFACE=vlan1 IP=ipaddress MASK=mask

5. Browse to the GUI.

If you access the Internet through a proxy server, set your browser to

bypass the proxy for the IP address you just assigned to the VLAN1

interface.

Point your web browser at the IP address of the VLAN interface.

6. Log in and set the password.

At the log in prompt, enter the log in name and password. Passwords are

case sensitive.

User Name: manager

Password: friend

The system status page appears and you can now use the GUI to configure

the router.

To ensure configuration settings are saved correctly, use the GUI menus and buttons to

navigate, not your browser’s buttons.

As a security precaution, change the password as soon as possible.

To change the password, select Management > Users from the sidebar

menu. Select the Manager account and click Modify.

7. To access context-sensitive help in the GUI.

Click on the Help Button [Help]. The Help button is located at the top of

the sidebar menu or on any popup page.

Connecting the Data Cables

Connecting the AR450S to your network:

1. Connect to the LAN and DMZ.

If you have not already done so, use a straight-through Ethernet patch

cable to connect the device(s) on your private network (LAN) to the

router’s switch port(s). Two straight-through Ethernet patch cables are

supplied with the router. By default, all five switch ports are members of

VLAN1.

If you have a public server, use a straight-through Ethernet patch cable to

connect it to the router’s Ethernet DMZ (ETH1) port. Separating public

servers from your LAN allows the firewall to provide greater protection for

your LAN. If you have multiple public servers, you can connect them to a

hub or Layer 2 switch and connect that device to the router’s DMZ port.

Quick Install Guide 9

C613-04045-01 REV A

2. Connect to the WAN.

If you intend to use a firewall, configure it before you activate the WAN link.

Once initial configuration is complete, use a straight-through Ethernet

patch cable to connect the router’s Ethernet WAN (ETH0) port to the

Ethernet port of a WAN device (such as a modem).

LEDs and What They Mean

LEDs indicate the router’s operational status and port activity.

AR450S System LEDs

LED State Function

Power Green The router is receiving power and the power

switch is in the ON position

System Amber The router is malfunctioning

Flashing The fan has failed

Off Normal operation

Full Dup Green The corresponding port is operating at full-

duplex

Off The corresponding port is operating at half-

duplex

Link/ACT Green A link has been established through the

corresponding port

Flashing Data is being transmitted through the

corresponding port

Off No link is present through the corresponding

port

100M Green The corresponding port is operating at

100Mbps

Off The corresponding port is operating at 10Mbps

10 AR450S Router

C613-04045-01 REV A

Troubleshooting Installation

If you have problems installing the router, try one or more of the following:

No LEDs Light

The most likely reason is that the router is not receiving power. Check the

following:

1. Check the supply outlet’s switch is in the ON position.

2. Test the mains power outlet to verify it is working.

If the problem persists, contact your authorised Allied Telesyn distributor or

reseller.

LEDs Light Incorrectly

If the System LED stays on, the router software has encountered a fatal

condition. Contact your authorised Allied Telesyn distributor or reseller.

No Response From the Terminal

1. Is the terminal cable correct for both the terminal and the router? Test the

cable operation by connecting Txd and Rxd (pins 2 and 3) together at the

router end of the cable. Characters typed on the terminal should be echoed

back to the screen.

2. Are the terminal or terminal emulation software communication

parameters set correctly? Refer to the AR Router Hardware Reference for more

information on setting communications parameters.

3. Contact your authorised Allied Telesyn distributor or reseller for assistance.

1. Passwords are case sensitive. Check your spelling and that you are using the

right combination of upper and lowercase characters.

2. Contact your authorised Allied Telesyn distributor or reseller for assistance.

Documentation and Tools CD-ROM

The Documentation and Tools CD-ROM bundled with each router contains the

complete Document Set for your router. The CD-ROM also includes tools for

managing your router.

The Document Set includes:

■The AR400 Series Router Safety and Statutory Information booklet, which

provides safety and statutory information.

■This Quick Install Guide.

■The AR400 Series User Guide, which provides an introduction to the router

and its operational features and characteristics.

■The AR Router Hardware Reference, which provides detailed information on

the hardware features of AR routers.

Inhaltsverzeichnis

Andere Allied Telesis Netzwerk-Router Handbücher

Allied Telesis

Allied Telesis AR725 Installations- und Betriebsanleitung

Allied Telesis

Allied Telesis AT-AR256E v3 Bedienungsanleitung

Allied Telesis

Allied Telesis AT-8000GS/24POE Bedienungsanleitung

Allied Telesis

Allied Telesis AT-9408LC/SP Series Bedienungsanleitung

Allied Telesis

Allied Telesis AT-8000S Series Bedienungsanleitung

Allied Telesis

Allied Telesis CentreCOM AT-3726XL Montage- und Bedienungsanleitung

Allied Telesis

Allied Telesis AR Router Series Anwendungshandbuch

Allied Telesis

Allied Telesis AT-FS705L Bedienungsanleitung

Allied Telesis

Allied Telesis AT-AR236E Bedienungsanleitung

Allied Telesis

Allied Telesis AR750S Bedienungsanleitung

Allied Telesis

Allied Telesis VPN Bedienungsanleitung

Allied Telesis

Allied Telesis AT-FS724L Bedienungsanleitung

Allied Telesis

Allied Telesis AT-FS724L Bedienungsanleitung

Allied Telesis

Allied Telesis WebSmart AT-FS750/16 Bedienungsanleitung

Allied Telesis

Allied Telesis AT-GS950/8 Bedienungsanleitung

Allied Telesis

Allied Telesis AT-GS950/8 Bedienungsanleitung

Allied Telesis

Allied Telesis AT-AR220E Bedienungsanleitung

Allied Telesis

Allied Telesis AT-9724TS Bedienungsanleitung

Allied Telesis

Allied Telesis AT-8000S/16 Bedienungsanleitung

Allied Telesis

Allied Telesis AT-8000GS/48 Bedienungsanleitung

Allied Telesis

Allied Telesis AR725 Anwendungshandbuch

Allied Telesis

Allied Telesis AR400 Series Originalbetriebsanleitung

Allied Telesis

Allied Telesis AT-AR221E Bedienungsanleitung

Allied Telesis

Allied Telesis AT 9748TS/XP AT-9748TS/XP-20... Bedienungsanleitung

Beliebte Netzwerk-Router Handbücher anderer Marken

Allnet

Allnet ALL0333AU Bedienungsanleitung

HomeSeer

HomeSeer HT-SEL Bedienungsanleitung

Sercomm

Sercomm Genesis OC3505D Bedienungsanleitung

Billion

Billion BIPAC 5102 Series Bedienungsanleitung

TP-Link

TP-Link TD-8817 Bedienungsanleitung

Motorola

Motorola MR1900 Bedienungsanleitung

Digi

Digi IX14 Bedienungsanleitung

Cisco

Cisco NCS 540 Handbuch

XAVi

XAVi X8821e Bedienungsanleitung

BEC

BEC 6200WZL Bedienungsanleitung

MikroTik

MikroTik hAP ac3 Series Bedienungsanleitung

Korenix

Korenix JetNet 5428G Series Bedienungsanleitung

NETGEAR

NETGEAR FS526T - Switch Bedienungsanleitung

Korenix

Korenix JetNet 5710G Series Bedienungsanleitung

Automated Logic

Automated Logic ZN551 Betriebsanleitung

Cisco

Cisco ASR 1000 Series Bedienerhandbuch

EnGenius

EnGenius ESR-9710 Bedienungsanleitung

Cisco

Cisco 805 Series Bedienungs- und Sicherheitshinweise
