How To |

Introduction

Ideally, setting up an ISDN connection is very much a straightforward process:

zConnect the router to the ISDN network interface.

zConfigure ISDN call definitions on the router. See How To Configure ISDN Calls On Allied

Telesis Routers, available from www.alliedtelesis.com/resources/literature/howto.aspx.

zSend traffic.

However, for one reason or another, there are occasions when the setup process is not as

smooth as it should be.

So if you have set up your router to communicate over ISDN, but the setup does not appear

to be working, this How To Note contains some steps you can take to try and resolve the

problem.

Which products does it apply to?

This configuration applies to the following Allied Telesis routers and switches, when a BRI or

PRI interface is installed in the base unit or through a PIC:

zAR300 series routers

zAR400 series routers

zAR700 series routers

zRapier series switches

zRapier i series switches

Related How To Notes

You also may find the following How To Notes useful:

How To Configure ISDN Calls On Allied Telesis Routers

zHow To Configure Common ISDN Access Concentration With The Firewall

How To Notes are available from www.alliedtelesis.com/resources/literature/howto.aspx.

Troubleshoot ISDN Connections

How to troubleshoot ISDN

Step 1: Is the router communicating with the ISDN

network at the signalling level?

When the router is connected to the ISDN network, either by plugging it into an NT1 if the

router has an S/T interface, or by plugging it directly into the ISDN network if the router has

a U interface, it establishes a low-level connection to the network. Basically, the router and

the network device exchange a particular set of waveforms. When the router is satisfied that

it has seen the correct waveforms, it considers the low-level connection to be established,

and the link is now ready to send data frames.

There are two ways to determine whether or not the router considers that the connection is

established:

1. Look at the external LED marked "Active". This will be lit when the connection is

established.

2. At the command prompt, enter the command:

show bri=nstate

where nis the number of the BRI interface under consideration. Interfaces are numbered

from 0.

An example of the output of the show bri=0 state command is shown in the following

figure.

The important item in this output is the second item, State. This must be shown as Activated.

If it has any other value (Inactive, Awaiting Signal, Synchronized, etc.) then the connection has

not yet been established.

If the BRI interface is Activated, then the problem lies at a higher level. Go to "Step 2: Is the

router communicating with the ISDN network at the LAPD level?" on page 4.

State for BRI instance 0:

Interface type ..... TE

State .............. Activated

Rx INFO ............ INFO 4

Tx INFO ............ INFO 3

Activate request ... no

Activated .......... yes

Synchronised ....... yes

Activation mode .... normal

Mode ............... ISDN

ISDN slots ......... B1, B2

D channel class .... high

B1 enabled ......... no

B2 enabled ......... no

B1, B2 aggregated... no

Rx multiframing .... no

Transceiver mask .. 56

If the interface is not activated, the reason could be one of the following:

1. The interface has been put into NT mode.

On the AT-AR041 and AT- AR042 multi-BRI NSM modules it is possible to put the ISDN

interface(s) into NT mode so that they can emulate a network switch interface. This can

be useful for bench testing network configurations. To see which mode the ISDN interface

is currently in, use the command:

show bri=nstate

The first item in the output, Interface Type, will have either the value NT or the value TE.

If the ISDN interface is in TE mode then it is set up correctly.

If the ISDN interface is in NT mode it is set up incorrectly, and it is a matter of changing

a pair of jumpers on the circuit board to put the interface back into TE mode.

2. There is a physical fault in the router's ISDN interface circuitry.

The router is able to test its own interface. The steps to performing the self-test are:

aCreate a BRI loopback plug and insert it into the interface socket.

If the BRI interface under consideration is on an ICM card, it is not necessary to use a

loopback plug, as the interface is capable of internal loopback, and so does not need

external loopback.

bAt the command prompt, enter the command:

enable test int=brin

where nis the number of the BRI interface under consideration. Interfaces are

numbered from 0.

This initiates a 4-minute self-test.

cWait 4 minutes, until the router outputs a message to inform you that the self-test is

complete.

Then enter the command:

show test

which will output the test results as shown in the following figure.

If the Result column shows the result to be good, then the BRI interface has no physical

faults (that the self-test can detect, anyway). If the result is anything other than good,

then the interface is faulty and you need to contact your distributor regarding a repair.

Board ID Bay Nick Name Part Name Rev Serial number

------------------------------------------------------------------------

Base 47 3100 NIQ-3100 M2-0 9774202

IC Module 39 0 ICM-BRI1 EXP-0303 M1-2 8620690

Duration Details

Interface State Result Type (minutes) Data( %OK ) Control

------------------------------------------------------------------------

eth0 no test - - - - - -

port0 no test - - - - - -

port1 no test - - - - - -

port2 no test - - - - - -

port3 no test - - - - - -

BRI0 complete good - 4 good(100.0) -

------------------------------------------------------------------------

3. The cable connecting the router to the ISDN network or NTI is faulty.

Try a different cable.

4. There is a fault in the ISDN network or the NT1.

If options 1, 2 and 3 do not show any faults on the router, then contact your ISDN network

provider and see if they can find the fault on their network.

Step 2: Is the router communicating with the ISDN

network at the LAPD level?

Once the router has established a signalling connection with the network, it starts sending

LAPD packets. LAPD (Link Access Protocol - D channel) is a protocol whereby the router

establishes a logical connection with the ISDN switch. It is via this protocol that the router

informs the switch of its presence, and the switch allocates the router a connection ID. An

LAPD connection has to be established before the router can make or receive ISDN calls.

To see if an LAPD connection has been established, use the command:

show lapd=n

where nis the number of the BRI interface under consideration. Interfaces are numbered

from 0.

The output of this command will be as shown in the following figure.

The most important item to look at in this output table is the very last line. If an LAPD

connection has been established, then the entry in the State column in this line will be ALIVE.

If the connection has not been established, the state will be DEAD.

If the LAPD is alive, then the problem lies at a higher layer. Go to "Step 3: Are ISDN calls

connecting successfully?" on page 5.

Interfaces:

ISDN Type TEI Mode Debug TEI

--------------------------------------------

BRI0 TE automatic off 064

--------------------------------------------

SAPs:

ISDN SAPI T200 T201 T202 T203 N200 N201 N202 k

--------------------------------------------------------------------

BRI0 063 000010 000010 000020 000100 000003 000260 000003 001

000 000010 000010 000020 000100 000003 000260 000003 001

--------------------------------------------------------------------

DLCs:

ISDN SAPI CES TEI State V(S) V(A) rxN(S) V(R) rxN(R)

--------------------------------------------------------------------

BRI0 063 000 127 bcast - - - - -

000 000 127 bcast - - - - -

001 064 ALIVE 0000 0000 0000 0000 0000

--------------------------------------------------------------------

If the LAPD is not alive, the reason could be one of the following:

1. The TEI mode has been set incorrectly.

On a Basic Rate interface, the TEI mode ought to be automatic, so that the router does

not mandate a TEI value to the switch, but will automatically accept whatever value is

assigned by the switch. The TEI mode of the BRI interface is shown in the first line of

output from the show lapd command. If the value shown in the TEI Mode column is

automatic, then the interface has been set properly. If the value is shown as non-automatic,

then the interface has not been set up properly. Use the command:

set lapd=nmode=automatic

Note: It may be necessary to set this in the router's config script, and reboot the router.

2. There is a problem in the ISDN network.

If the router is sending valid LAPD packets, and the switch is not responding correctly, then

LAPD will stay in the DEAD state. Contact your ISDN network provider and report a

network fault.

Step 3: Are ISDN calls connecting successfully?

If the router has an LAPD connection to the switch, then when an outgoing call is made from

the router, it will send call setup messages to the switch. If the switch believes that the packet

is valid and there are channels available in the ISDN network, it will forward it on to the

router at the far end of the link. The receiving router will then either accept or reject the

call, depending on the contents of the packet.

If the receiving router accepts the call setup request, the ISDN call will come open, and the

routers will endeavour to exchange data packets. If the call does not come open, then there

will obviously be no exchange of data. In order to determine whether calls are coming open,

use the command:

show isdn log

which will output a record of the last few ISDN calls, successful or otherwise, as shown in

the following figure.

Call Name Start Time Duration Dir Number Cause

-----------------------------------------------------------------------------

tdc 12-Dec-1997 11:18:51 CLEARED OUT 035439003 U16,-

chs 12-Dec-1997 11:19:03 CLEARED OUT 073333333 N1,-

ajpwlg 12-Dec-1997 11:19:36 0:01:01 OUT 044940190 U16,-

ajpwlg 12-Dec-1997 11:23:12 0:01:01 OUT 044940190 U16,-

abb 12-Dec-1997 11:23:33 0:00:49 OUT 093560114 U16,-

ajpwlg 12-Dec-1997 11:24:05 CLEARED OUT -

ajpwlg 12-Dec-1997 11:24:25 0:01:02 OUT 044940190 U16,-

ajpwlg 12-Dec-1997 11:24:27 CLEARED OUT 044940190 N21,-

gc 12-Dec-1997 11:25:14 CLEARED OUT 3776569 N27,-

ppta 12-Dec-1997 11:25:38 CLEARED OUT 043842672 N17,-

to_boe 12-Dec-1997 11:26:13 CLEARED OUT 00441256376991 N18,-

pfricc 12-Dec-1997 11:26:38 CLEARED OUT 3432977 N17,-

-----------------------------------------------------------------------------

No ISDN logging port defined.

When it comes to diagnosing an ISDN connection, the two most important columns in this

table are Duration and Cause.

The Duration column

The Duration column tells you immediately whether or not the call ever connected. If the

entry in this column is CLEARED, then the call never connected. If the entry in this column is

a time, then the call did actually connect at the ISDN level. The reason why you were unable

to get data across will be found at a higher protocol level (PPP or IP, IPX etc). Typically, if the

duration of the call was one or two seconds, then the call would have been closed due to a

PPP negotiation failure. One of the most common causes of PPP negotiation failure is due to

PAP or CHAP authentication failing. This can be quickly checked by looking in the router log,

using the command:

show log

A PAP or CHAP authentication failure generates a log message of the form

01 01:16:06 5 PPP AUTH FAIL ppp0: PAP authentication over

isdn-dial1 failed

Note: The log message appears on the router that is doing the authenticating, which may

well be the router at the other end of the link. The way to tell which router decided

to close the call is to check the Cause column.

If the call is being disconnected due to PAP/CHAP negotiation failure, see How To Configure

PPP Authentication using PAP and CHAP for a full discussion on configuring PAP and CHAP on

the router. This How To Note is available from www.alliedtelesis.com/resources/literature/

howto.aspx

If the call seems to be being disconnected for other reasons at the PPP or IP level, then it

would probably be necessary for you to contact your Allied Telesis reseller or distributor for

technical assistance.

The Cause column

The Cause column tells you why a call was disconnected. Each entry in this column has three

parts:

1. A letter indicating which end of the link took the call down. U (for User) indicates that the

router itself closed the call. N (for network) indicates the call was closed either by a switch

in the ISDN network, or by the router at the other end of the call.

2. A cause code number, indicating the reason for the call closure.

3. An extra diagnostic number. The meaning of this diagnostic number varies from one cause

code to the next. For most cause codes, this field is actually blank. It is necessary to have

a good working knowledge of ISDN and access to ISDN standards manuals in order to

make any use of these diagnostic numbers.

The cause code number can give you a lot of information about why your call is not working.

Values commonly seen for this code are:

z16 - Normal

The call opened and was then closed by an indication from a higher layer protocol that it

was time to close the call. So, any successful call that passes data, and then is closed due

to the PPP idle timer timing out due to no more data being sent, has a cause code of 16.

Also, a call that is closed due to PAP/CHAP authentication failure has a cause code of 16

because the call worked fine at the ISDN level, and was closed due to an indication from

the PPP layer. In this case, if the local router decided that the PAP/CHAP username/

password it received were invalid, then the letter preceding the cause code will be U; if

the remote router rejected the username/password sent to it, the letter proceeding the

cause code will be N.

z17 - User busy

This is just like getting the engaged signal on a voice call. All you can do is wait for a while

and try again later.

z18 - No user responding

There seems to be a device at the far end which has a LAPD connection to the switch but

it is not responding to the call setup messages. This may indicate that the device at the far

end has been set up to only make outgoing calls, or that it has a software or hardware fault

that has put it in a state whereby it is capable of maintaining a LAPD connection to the

switch, but can't actually responding to call setup requests.

z27 - Destination out of order

You are calling a valid number, but the switch does not have a valid LAPD connection on

the channel corresponding to the number you are calling. This may mean that the device

at the other end has not been properly installed yet, or is switched off. Or it may indicate

a fault in the wiring between the switch and the site where that call is terminated.

z1 - Invalid number

The number you are calling is not assigned to any connection. Check the number you are

calling.

Note: This cause code occurs if your router is connected to the centrex service, and you

are calling a number outside of the centrex extensions, but have not preceded it with

the prefix for an 'outside line'.

z34, 38, 44, 42 - ISDN network congestion or fault

If you receive these cause codes regularly, you should contact your ISDN network

provider.

z21 - Call rejected

This is probably the most commonly seen cause code on failed ISDN connections. It

almost always indicates a mistake in router configuration. This cause code occurs when

the call setup packet is successfully delivered to the router at the other end of the

connection, but the router refuses the call because it is not configured to accept the call.

There can be are a number of configuration errors that can result in a call being refused.

Common ones to look out for are:

zNo ISDN call definitions have yet been created on the receiving router.

zThe ISDN call definitions configured on the receiving router are set up to search for

particular strings in the subaddress, CLI or user-user fields in the call setup packet, but

the sending router is not putting the correct strings into the correct fields. For a full

discussion of call identification using fields of the call setup packet, see How To Configure

ISDN Calls On Allied Telesis Routers, available from www.alliedtelesis.com/resources/

literature/howto.aspx.

USA Headquarters | 19800 North Creek Parkway | Suite 200 | Bothell | WA 98011 | USA | T: +1 800 424 4284 | F: +1 425 481 3895

Asia-Pacific Headquarters | 11 Tai Seng Link | Singapore | 534182 | T: +65 6383 3832 | F: +65 6383 3830

www.alliedtelesis.com

© 2007Allied Te l esis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners.

C613-16030-00 REV B

zThere is an ISDN call definition on the receiving router that will accept the incoming

call, but there is not yet a Layer 2 interface (PPP or Frame Relay) configured to use this

call definition.

zThere is an ISDN call definition on the receiving router that will accept the incoming

call, and there is a Layer 2 interface configured over the call definition, but this

particular call definition is already taken by another incoming call.

Once you have tracked down where the configuration error lies, and remedied the problem,

the ISDN calls ought to connect correctly.

Other tips for testing ISDN connections

If pings won't bring up a call, try activating it manually.

Typically when setting up an ISDN connection, you'll configure an ISDN call definition, then

configure a dial-on-demand PPP interface over the call definition, and then assign an IP (or

IPX, AppleTalk) address to the PPP interface. Then, the normal first step to testing the setup

is to try pinging the device at the other end of the link. If there is no response to pings, you

could go through all three steps above to try and determine why its not working. However,

you can possibly bypass some of the process by trying to 'manually activate' the ISDN call,

rather than trying to bring it up using pings. This is a more direct approach to testing the

ISDN connection, and can often give you more insight into what is going on.

The command to activate an ISDN call is:

activate isdn call=call-name

This command informs the ISDN module to directly attempt a call setup. However, before

the call setup is attempted, the router checks whether there is a Layer 2 interface configured

over the call, and if so, whether that interface is currently active. If there is no Layer 2 (PPP or

FR) interface configured over the call, then you will receive the error message:

Call has no user attached

If you receive this message, then carefully check the PPP or FR interface that you have

configured over the ISDN call. The commands show ppp or show fr will show which ISDN

call the router believes the Layer 2 interface to be configured over as shown in the following

figure for interface ppp4.

Check carefully that the name of the ISDN call reported by show ppp or show fr is exactly

the same as the name of the call you are trying to activate. Note that the call name is just the

string that appears after the "isdn-" in the Over column.

Name Enabled ifIndex Over CP State

-----------------------------------------------------------------------------

ppp4 YES 08 IPCP CLOSED

isdn-ntdial LCP STARTING

-----------------------------------------------------------------------------

Andere Handbücher für Rapier AR 300 Series

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Allied Telesis Netzwerk-Router Handbücher

Allied Telesis

Allied Telesis AR2050V Installationshandbuch

Allied Telesis

Allied Telesis AR750S Installations- und Betriebsanleitung

Allied Telesis

Allied Telesis AT-8000C Referenzhandbuch

Allied Telesis

Allied Telesis AT-FS705LE Bedienungsanleitung

Allied Telesis

Allied Telesis AR750S Bedienungsanleitung

Allied Telesis

Allied Telesis AT-FS724L Bedienungsanleitung

Allied Telesis

Allied Telesis Rapier AR 700 Series Anwendungshandbuch

Allied Telesis

Allied Telesis AT-8000S/16 Bedienungsanleitung

Allied Telesis

Allied Telesis AT-AR3050S Bedienungsanleitung

Allied Telesis

Allied Telesis AT-AR256E v3 Bedienungsanleitung

Allied Telesis

Allied Telesis AR750S-DP Installations- und Betriebsanleitung

Allied Telesis

Allied Telesis SwitchBlade AT-AR440S Bedienungsanleitung

Allied Telesis

Allied Telesis AT-9724TS Bedienungsanleitung

Allied Telesis

Allied Telesis AT-8000S Series Bedienungsanleitung

Allied Telesis

Allied Telesis AR400 Series Bedienungsanleitung

Allied Telesis

Allied Telesis WebSmart AT-FS750/16 Bedienungsanleitung

Allied Telesis

Allied Telesis AT-9724TS Bedienungsanleitung

Allied Telesis

Allied Telesis AT-8550/SP Series Bedienungsanleitung

Allied Telesis

Allied Telesis AT-AR236E Bedienungsanleitung

Allied Telesis

Allied Telesis AT-9724TS Bedienungsanleitung

Allied Telesis

Allied Telesis AR745 Bedienungsanleitung

Allied Telesis

Allied Telesis AT-GS950/8 Bedienungsanleitung

Allied Telesis

Allied Telesis AT-GS950/8 Bedienungsanleitung

Allied Telesis

Allied Telesis AT-AR221E Bedienungsanleitung

Beliebte Netzwerk-Router Handbücher anderer Marken

Allnet

Allnet ALL0333AU Bedienungsanleitung

HomeSeer

HomeSeer HT-SEL Bedienungsanleitung

Sercomm

Sercomm Genesis OC3505D Bedienungsanleitung

Billion

Billion BIPAC 5102 Series Bedienungsanleitung

TP-Link

TP-Link TD-8817 Bedienungsanleitung

Motorola

Motorola MR1900 Bedienungsanleitung

Digi

Digi IX14 Bedienungsanleitung

Cisco

Cisco NCS 540 Handbuch

XAVi

XAVi X8821e Bedienungsanleitung

BEC

BEC 6200WZL Bedienungsanleitung

MikroTik

MikroTik hAP ac3 Series Bedienungsanleitung

Korenix

Korenix JetNet 5428G Series Bedienungsanleitung

NETGEAR

NETGEAR FS526T - Switch Bedienungsanleitung

Korenix

Korenix JetNet 5710G Series Bedienungsanleitung

Automated Logic

Automated Logic ZN551 Betriebsanleitung

Cisco

Cisco ASR 1000 Series Bedienerhandbuch

EnGenius

EnGenius ESR-9710 Bedienungsanleitung

Cisco

Cisco 805 Series Bedienungs- und Sicherheitshinweise
