Allied Telesis www.alliedtelesis.com

Datasheet | Switches

AT-8000S/16

Layer 2 Managed Fast Ethernet Switch

T-8000S/16

16 port standalone 10/100TX Layer 2 switch

with 1 active SFP bay (unpopulated) and

1standby 10/100/1000T port (RJ-45)

Overview

The small form factor AT-8000S/16 provides

line-rate Layer 2 switching in an affordable,

fixed-configuration platform. Featuring easy

installation and exceptional reliability, this

10/100 switch comes with one Gigabit uplink

port with the option of the integrated copper

10/100/1000 portor a 100 or 1000 SFP slot

for fiber connectivity.

Ideal Workgroup and

Remote Office Connectivity

Designed for the smaller workgroup or remote

office this highly featured switch mirrors the

advanced feature set of the larger 8000S series

stackable products while offering the benefits of

silent operation and a portdensity aimed at

right priced functionality.

Easy Access Networking

Featuring an industry standard CLI and Allied

Telesis’ intuitive yet fully featured Web interface

the advanced features of the AT-8000S/16 are

accessible to a wide range of system

administrators. The well known CLI and Web

interfaces significantly reduce learning time and

minimizethe cost of deployment.

SecureManagement

Only authorized administrators can access the

management interface of the 8000S series.

Protocols such as SSL, SSH and SNMP v3

facilitate this protection of your network with

local or remote connections.

Securing the Network Edge

To ensure the protection of your data, it is

important to control access to your network.

Protocols such as IEEE 802.1x port-based

authentication guarantee that only known users

are connected to the network. Unknown users

who physicallyconnect can be isolated to a

pre-determined part of your network offering

guests such benefits as Internet access while

ensuring the integrity of your private network

data.

Gigabit and Fast Ethernet SFP

Support

All switches in the 8000S family support both

Gigabit and Fast Ethernet Small Form-factor

Pluggables (SFPs).This makes the 8000S series

an ideal family for environments where Gigabit

fiber switches will be phased in over time.The

8000S familyallows for connectivity to the

legacy 100FX hardware until it is upgraded to

Gigabit. Support for both speeds of SFPs allows

organizations to staywithin budget as they

migrate to faster technologies.

Key Features

Easy,Well Known Management

•Industry standard CLI

•Simple intuitive, full featured Allied Telesis

Web interface

•Secure encrypted Web and CLI management

with SSH v2 and SSL

•SNMP

•Twolevel access privileges

All the QoS Needed in the Wiring Closet

for Today’sVoice and Data Networking

•Eight priorities assigned to four queues

•IEEE 802.1p for Layer 2 QoS

•DSCP (DiffServ) for Layer 3 QoS

•IEEE 802.1p to DSCP remarking traffic ready for

transportto the Layer 3 core of the network

•Layer 2 and Layer 3 ACL

Securing the Network at its Most

Vulnerable Point

•IEEE 802.1x and RADIUS network login: for

advanced control of user authentication and

accountability

•Guest VLAN: to ensure visitors or unauthorized

users connect only to services defined by IT. E.g.

Internet

•TACACS+: for ease of management security

administration

•Layer 2 and Layer 3 ACL

•Port MAC address security options

Small Form Factor

•Standalone switch for remote locations

or where stacking is not required

•Silent operation (fanless)

Power Supply Efficiency

Allied T

elesis www.alliedtelesis.com

AT-8000S/16 |Layer 2 Managed Fast Ethernet Switch

System Configuration

Dimensions 33cm x 23cm x 4.3cm

(W x D x H) (13” x 9.1” x 1.7”)

Weight 1.95kg (4.29lb)

Mounting 19” rack-mountable hardware

included

System Capacity

64MB RAM

16MB flash memory

400Mhz CPU

Up to 4,096 VLAN ID

8,000 MAC address

Packet buffer memory 1Mbit

Performance

Wirespeed switching on all Ethernet ports for all packet

sizes

Throughput 3.87Mpps

Switching capacity 5.2Gbps

MTBF 447,901 hours

Store and forward mode

Non-blocking switch fabric

Auto MDI/MDI-X

Latency

10Mbit 85.71 µsec

100Mbit 17.30 µsec

Port speed:

10/100TX RJ-45

10/100/1000T RJ-45

100FX, 1000SX, 1000LX SFP slot

RS232 DB9 pin, male port

Internal power supply – no fan

Interface Standards

IEEE 802.3 10T

IEEE 802.3u 100TX and 100FX

IEEE 802.3z 1000SX

IEEE 802.3ab 1000T

General Standards

IEEE 802.1D Bridging

IEEE 802.3x BackPressure/ flow control

Redundancy Standards

IEEE 802.1D Spanning-Tree Protocol

IEEE 802.1W Rapid Spanning-Tree

IEEE 802.1s Multiple Spanning-Tree

BPDU guard1

IEEE 802.3ad LACP link aggregation

(with up to eight members per

group and up to eight groups per

device)

Static port trunk

Quality of Services (QoS)

QoS in Layer 2 (IEEE 802.1p compliant Class of

Service)

Traffic prioritization using IEEE 802.1p, ToS, DSCP fields

Map IEEE 802.1p priorities to CoS queues to prioritize

traffic at egress

Strict Scheduling and Weighted Round Robin

VLANs

IEEE 802.1Q VLAN tagging

Up to 256 VLANs

Port-based VLANs

MAC-based VLANs

Private VLANs

GARP VLAN Registration Protocol (GVRP)

Multicast Standards

RFC 1112 IGMP snooping (ver. 1)

RFC 2236 IGMP snooping (ver. 2)

RFC 3376 IGMP snooping (ver. 3)

RFC 3376 IGMP querier

Option to forward/filtering of unregistered MC frames1

IPv61

IPv6 QoS

IPv6 ACL

IPv6 Host

RFC 2461 IPv6 neighbor discovery

RFC 2463 ICMPv6: Internet Control Message

Protocol version 6

RFC 1981 Path MTU discovery

Dual-stack IPv4/IPv6 protocol

IPv6 Tunnelling over IPv4

IPv6 Network management

IPv6 Applications: WEB/SSL Telnet

server/SSH, AAA/Radius, Management

ACLs, SNTP, PING, TFTP/Copy, Syslog

Management and Monitoring

WEB, CLI, Serial

RFC 1157 SNMPv1/v2c

RFC 2570 SNMPv3

RFC 1213 MIB-II

RFC 1573 Evolution of MIB-II

RFC 1215 TRAP MIB

RFC 1493 Bridge MIB

RFC 2863 Interfaces group MIB

RFC 1643 Ethernet like MIB

RFC 1757 RMON 4 groups:

Stats, History, Alarms, Events

RFC 2674 IEEE 802.1Q MIB

RFC 1866 HTML

RFC 2068 HTTP

RFC 854 Telnet

RFC 783 TFTP

LLDP1

LLDP-MED1

IP address allocation

RFC 951/ RFC 1542 BootP / DHCP

Manual

RFC 2030 SNTP (Simple Network Time Protocol)

Syslogevent

Dual software images

Security

Management Security: user name

and password protection

SSHv2 Telnet management

SSLv3 Web management

RFC 1492 TACACS+

RFC 2138 RADIUS Authentication

IEEE 802.1x Port-based network access control

IEEE 802.1x Dynamic VLAN1

IEEE 802.1x RADIUS accounting1

IEEE 802.1x Multi-session mode1

IEEE 802.1x Action on violation1

IEEE 802.1x Guest VLAN timeout1

IEEE 802.1x Authentication not-required1

Security login banner1

Guest VLANs

RFC 2865 IEEE 802.1x port-based network

access control

MAC-based network access control

ACL - Access Control Lists

Fault Protection

Broadcast storm control

USA Headquarters |19800 North Creek Parkway |Suite 100 |Bothell |WA 98011 |USA |T: +1 800 424 4284 |F: +1 425 481 3895

Asia-Pacific Headquarters |11 Tai Seng Link |Singapore |534182 |T: +65 6383 3832 |F: +65 6383 3830

www.alliedtelesis.com

©2009 Allied Telesis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners. 617-000174 Rev.L

AT-8000S/16 |Layer 2 Managed Fast Ethernet Switch

Power Characteristics

Voltage input 100-240V AC

Voltage output 12vDC

Current 0.75A

Power consumption 13.80W2

Power supply efficiency 71.35%

Heat dissipation 102.45BTU/hour

Clock frequency 166MHz

Acoustic noise 14.8dB

Environmental Specifications

Operating temp 0°C to 40°C (32°F to 104°F)

Storage temp -25°C to 70°C (-13°F to 158°F)

Relative humidity 10% to 90% non-condensing

Storage humidity 5% to 95% non-condensing

Operating altitude Maximum 3,000m (9,843ft)

Electrical/ Mechanical Approvals

Safety UL 1950 (UL/cUL), EN60950 (TUV)

EMI FCC Class A, EN55022 Class A,

VCCI Class A, C-Tick, EN61000-3-2,

EN61000-3-3

Immunity EN55024

RoHS compliant

Package Description

One AT-8000S/16 switch

Power cord AC

Rack-mount kit

Rubber feet for desktop installation

RS232 management cable

Install guide and user guide in CD and at

www.alliedtelesis.com

Country of Origin

China

Ordering Information

AT-8000S/16-xx

16port standalone 10/100TX Layer 2 switch with 1

active SFP bay (unpopulated) and 1 standby

10/100/1000T port (RJ-45)

Where xx = 10 for US power cord

20 for no power cord

30 for UK power cord

40 for Australian power cord

50 for European0 power cord

Accessories

Small Form Pluggables (SFPs)

AT-SPFX/2

Multi-mode Fiber, 2km, 100FX, SFP, 1310nm

AT-SPFX/15

Single-mode Fiber, 15km, 100FX, SFP, 1310nm

AT-SPFX/40

Single-mode Fiber, 40km, 100FX, SFP, 1310nm

AT-SPTX

Copper, GbE Small Form-factor Pluggable (SFP)

AT-SPSX

Multi-mode Fiber, GbE Small Form-factor Pluggable (SFP)

850nm

AT-SPLX10

Single-mode Fiber, 10km, GbE SFP, 1310nm

AT-SPLX40

Single-mode Fiber, 40km, GbE SFP, 1310nm

AT-SPLX40/1550

Single-mode Fiber, 40km, GbE SFP, 1550nm

-SPZX80

Single-mode Fiber, 80km, GbE SFP, 1550nm

AT-SPZX80/xxxx

Single-mode Fiber, CWDM, 80km GbE SFP

CWDM wavelengths:

Where xxxx = 1470

1490

1510

1530

1550

1570

1590

1610

1New feature on AT-S94 version 3.0.0.32

2Worst case load condition for actual measured power on sample unit

Inhaltsverzeichnis

Andere Allied Telesis Netzwerk-Router Handbücher

Allied Telesis

Allied Telesis AT-GS950/16 Bedienungsanleitung

Allied Telesis

Allied Telesis AT-WR4500 Series Bedienungsanleitung

Allied Telesis

Allied Telesis AT-IE510-28GSX-80 Bedienungsanleitung

Allied Telesis

Allied Telesis Rapier AR 700 Series Bedienungsanleitung

Allied Telesis

Allied Telesis AT-8000GS/48 Bedienungsanleitung

Allied Telesis

Allied Telesis AR725 Anwendungshandbuch

Allied Telesis

Allied Telesis AT-FS724L Bedienungsanleitung

Allied Telesis

Allied Telesis AR2050V Installationshandbuch

Allied Telesis

Allied Telesis WebSmart AT-FS750/24POE Bedienungsanleitung

Allied Telesis

Allied Telesis AT-AR220E Bedienungsanleitung

Allied Telesis

Allied Telesis CentreCOM AT-3675 Bridge Bedienungsanleitung

Allied Telesis

Allied Telesis AT x900-48FS Bedienungsanleitung

Allied Telesis

Allied Telesis AT-GS950/16 Bedienungsanleitung

Allied Telesis

Allied Telesis AR725 Installations- und Betriebsanleitung

Allied Telesis

Allied Telesis AT-AR750S-dp Bedienungsanleitung

Allied Telesis

Allied Telesis TurboStack AT-TS90TR Bedienungsanleitung

Allied Telesis

Allied Telesis AT-8116 Bedienungsanleitung

Allied Telesis

Allied Telesis AT-AR441S Bedienungsanleitung

Allied Telesis

Allied Telesis AT-GS950/8 Bedienungsanleitung

Allied Telesis

Allied Telesis 86222-06 Bedienungsanleitung

Allied Telesis

Allied Telesis AT-AR415S Bedienungsanleitung

Allied Telesis

Allied Telesis AT-9724TS Bedienungsanleitung

Allied Telesis

Allied Telesis Routers and Switches Bedienungsanleitung

Allied Telesis

Allied Telesis AT-8550/SP Series Bedienungsanleitung

Beliebte Netzwerk-Router Handbücher anderer Marken

Allnet

Allnet ALL0333AU Bedienungsanleitung

HomeSeer

HomeSeer HT-SEL Bedienungsanleitung

Sercomm

Sercomm Genesis OC3505D Bedienungsanleitung

Billion

Billion BIPAC 5102 Series Bedienungsanleitung

TP-Link

TP-Link TD-8817 Bedienungsanleitung

Motorola

Motorola MR1900 Bedienungsanleitung

Digi

Digi IX14 Bedienungsanleitung

Cisco

Cisco NCS 540 Handbuch

XAVi

XAVi X8821e Bedienungsanleitung

BEC

BEC 6200WZL Bedienungsanleitung

MikroTik

MikroTik hAP ac3 Series Bedienungsanleitung

Korenix

Korenix JetNet 5428G Series Bedienungsanleitung

NETGEAR

NETGEAR FS526T - Switch Bedienungsanleitung

Korenix

Korenix JetNet 5710G Series Bedienungsanleitung

Automated Logic

Automated Logic ZN551 Betriebsanleitung

Cisco

Cisco ASR 1000 Series Bedienerhandbuch

EnGenius

EnGenius ESR-9710 Bedienungsanleitung

Cisco

Cisco 805 Series Bedienungs- und Sicherheitshinweise
