PILOT’S OPERATING HANDBOOK ALPHA 800
Alpha Unmanned Systems S.L.
Av. Fuente Nueva, 14
28703, San Sebastián de los Reyes, Madrid. SPAIN
CIF B86928009
www.alphaunmannedsystems.com
All rights reserved.
Note: All UAV Maintenance and operation documentation is designed to supplement the training given on Alpha Unmanned Systems'
comprehensive UAV Operator Course. UAV Maintenance must only be carried out by persons qualified on that Course; failure to comply may
invalidate the UAV warranty and may lead to accidents. For further information and the latest updates contact
info@AlphaUnmannedSystems.com.
Accomplished
Revised
Approved
Cosme Arin
Alejandro Madrid
Álvaro Escarpenter
Signature
Signature
Signature
Date:
Date:
Date:
31/03/2020
31/03/2020
31/03/2020
COMMERCIAL IN CONFIDENCE
OPS-M-POH A800 V2.1
Pilot Operating Handbook
www.AlphaUnmannedSystems.com
1 of 110
Version Record
Version
Date
Description
1.0
09/01/2015
Initial Version
1.1
20/04/2015
Manual updating and rebuild
1.2
10/04/2017
ALPHA 800 and fiscal address update
1.3
31/05/2017
Fixed mistake in rotor diameter
1.4
04/12/2018
General Update with new software capabilities
1.5
24/05/2019
Manual flight limitations and disclaimer
1.6
02/08/2019
General Manual update & new GCASE included
1.7
14/10/2019
Included release to service procedure after maintenance or
storage & Annexes. Minor changes.
2.0
06/11/2019
General update with V8 software capabilities
2.1
27/03/2020
Single operator proccedure update
COMMERCIAL IN CONFIDENCE
OPS-M-POH A800 V2.1
Pilot Operating Handbook
www.AlphaUnmannedSystems.com
2 of 110
PAGE INTENTIONALLY LEFT BLANK
COMMERCIAL IN CONFIDENCE
OPS-M-POH A800 V2.1
Pilot Operating Handbook
www.AlphaUnmannedSystems.com
3 of 110
TABLE OF CONTENTS
SECTION 0: SYMBOLS, ABBREVIATIONS AND TERMINOLOGY ........................................................... 5
SECTION 1: GENERAL ........................................................................................................................ 7
SECTION 2: LIMITATIONS ................................................................................................................ 13
SECTION 3: EMERGENCY PROCEDURES........................................................................................... 17
SECTION 4: NORMAL PROCEDURES ................................................................................................ 35
SECTION 5: PERFORMANCE............................................................................................................. 52
SECTION 6: WEIGHT AND BALANCE ................................................................................................ 57
SECTION 7: SYSTEMS DESCRIPTION ................................................................................................ 59
SECTION 8: SERVICE & MAINTENANCE............................................................................................ 73
SECTION 9: SUPLEMENTS................................................................................................................ 97
ANNEX 1: PREFLIGHT CHECKLIST..................................................................................................... 99
ANNEX 2: SINGLE OPERATOR PREFLIGHT CHECKLIST .................................................................... 101
ANNEX 3: RELEASE TO SERVICE PROCEDURE ................................................................................ 103
COMMERCIAL IN CONFIDENCE
OPS-M-POH A800 V2.1
Pilot Operating Handbook
www.AlphaUnmannedSystems.com
4 of 110
PAGE INTENTIONALLY LEFT BLANK
COMMERCIAL IN CONFIDENCE
OPS-M-POH A800 V2.1
Pilot Operating Handbook
www.AlphaUnmannedSystems.com
5 of 110
SECTION 0: SYMBOLS, ABBREVIATIONS AND TERMINOLOGY
AHRS
Attitude and Heading Reference System
ADS
Altitude Determination Sensors
AGL
Avobe Ground Level
AP
Autopilot
BWRD
Backward
BLOS
Beyond Line Of Sight
BVLOS
Beyond Visual Line Of Sight
CG
Center of Gravity
CCW
Counter Clockwise
CFRP
Carbon Fiber Reinforced Polymer
CHT
Cylinder Heat Temperature
CPU
Central Processing Unit
CW
Clockwise
EGT
Exit Gust Temperature
FOV
Field Of View
FWD
Forward
GCS
Ground Control Station
GDT
Ground Data Terminal
GNSS
Global Navigation Satellite System
GRP
Glass reinforced Plastic
HC
Helicopter
IAS
Indicated Air Speed
IPC
Illustrated Parts Catalog
KIAS
Indicated Air Speed in Knots
LiPo
Lithium Polymer battery
LiFe
Lithium Iron phosphate battery
LOS
Line Of Sight
LUT
Look Up Tables
MTOW
Maximum Take-off Weight
MMEL
Master Minimum Equipment List
NSEW
Nort, South, East & West
PCM
Power & Communications Module
PEP
Peak Envelope Power
PFD
Primary Flight Display
PLL
Phase Locked Loop
PTU
Pan Tilt Unit
PWM
Pulse Width Modulation
PY
Payload
RMS
Root Mean Square
RX
Receiver
SN
Serial Number
SW
Software
TX
Transmitter
COMMERCIAL IN CONFIDENCE
OPS-M-POH A800 V2.1
Pilot Operating Handbook
www.AlphaUnmannedSystems.com
6 of 110
TO
Take Off
UAV
Unmanned Aerial Vehicle
VTOL
Vertical Take-off and Landing
WP
Waypoint
FP
Flight Plan
COMMERCIAL IN CONFIDENCE
OPS-M-POH A800 V2.1
Pilot Operating Handbook
www.AlphaUnmannedSystems.com
7 of 110
SECTION 1: GENERAL
TABLE OF CONTENTS
1.1 Introduction....................................................................................................................... 8
1.2 The ALPHA 800 UAV........................................................................................................... 8
1.2.1 Alpha 800 dimensions ................................................................................................ 9
1.2.2 Engine ........................................................................................................................ 9
1.2.3 Rotors ...................................................................................................................... 10
Main Rotor ........................................................................................................... 10
Tail Rotor.............................................................................................................. 10
1.2.4 Fuel and Oil .............................................................................................................. 10
1.2.5 Weights.................................................................................................................... 10
1.2.6 The VECTOR ............................................................................................................. 10
1.2.7 The GCS.................................................................................................................... 11
COMMERCIAL IN CONFIDENCE
OPS-M-POH A800 V2.1
Pilot Operating Handbook
www.AlphaUnmannedSystems.com
8 of 110
1.1 Introduction
This handbook contains 8 sections and gives the operator a general overall description of the
Alpha 800 UAV.
1.2 The ALPHA 800 UAV
The Alpha 800 is a rotary wing unmanned aircraft that operates as a helicopter with the
possibility of vertical take-off and landing, hovering and navigating in automatic flight
according to a previously-loaded flight plan. The operation is monitored by a Ground Control
Station (GCS) and communications between the UAV and the GCS are in real time, allowing
the ground operator to observe the images captured by the video camera installed on-board
or the data from any other client-specified payload, as well as to have full manual UAV control
by means of a joystick.
The ALPHA 800 can be used for a wide range of applications where an onboard operator’s
presence is not necessary. Avoiding risk to humans, unmanned aerial vehicles can be used for
military or civilian applications, such as aerial surveillance and reconnaissance, fire detection,
monitoring of law enforcement, etc.
The ALPHA 800 is a tactical, automatic VTOL UAV. It is suitable for day or night, non-military
or “Intelligence, Surveillance, Target Acquisition and Reconnaissance” (ISTAR) missions. The
ALPHA 800 can provide, depending on the configuration, from 2 to 3 hour endurance missions
with multiple payload capabilities.
Avoiding the need for highly qualified personnel, ALPHA 800 can complete its entire mission
automatically, from take-off to landing by means of a compact, redundant flight control
system.
COMMERCIAL IN CONFIDENCE
OPS-M-POH A800 V2.1
Pilot Operating Handbook
www.AlphaUnmannedSystems.com
9 of 110
1.2.1 Alpha 800 dimensions
Figure 1-1 - ALPHA 800 dimensions
1.2.2 Engine
Number of Engines
1
Number of Cylinders
1
Cylinder material
Aluminum
Piston displacement
29 cc
Fuel Metering
Carburetor
Engine Type
Two-stroke gasoline engine
Power Rating
2 KW @ 13000 rpm
Table 1-2 - Engine features
