USE AND CARE MANUAL
FOR OUTDOOR USE ONLY
ALWAYS KEEP YOUR GRILL COVERED WHEN NOT IN USE
BEFORE YOU BEGIN – We’ ve included easy-to-follow, step-by-step instructions which have been carefully written to
ensure quick assembly of your grill. Reading the instructions will be a time saver in the end.
YOU WI NEED – A Phillips screwdriver, adjustable wrench, 1/2” wrench or socket and a 1/4” nut driver or socket will
be needed to assemble this grill. All other necessary hardware has been included.
Amana™ SS 4 Burner Gas Grill
Questions,Missing or Damaged part? DO NOT RETURN PRODUCT TO STORE
Were here to help. Just call 1-800-229-5647. For faster service, have model number and
serial number on hand when calling.
2
IMPORTANT SAFETY INFORMATION
-Read this manual carefully before using your grill to reduce the risk of fire, burn
hazard or other injury.
- Extreme care should be used because of the high temperatures produced by this
appliance. CHILDREN SHOULD NOT BE LEFT UNATTENDED IN AN AREA
WHERE THE RILL IS BEIN OPERATED.
- This appliance must be kept clear from combustible materials, gasoline or other flammable vapors and liquids. Do not
allow flammable materials to come in contact with grate, burner or hot surfaces.
- Use only outdoors and provide good ventilation to avoid carbon monoxide build-up which could result in injury or death.
- Do not repair or replace any part of this appliance unless it is specifically recommended in this manual. A qualified
service technician should conduct all other service.
- Follow the installation and servicing instructions provided with this product. Have your grill installed by a qualified
service technician.
- Locate the main gas supply valve so that you know how to shut the gas off to your grill.
- If you smell gas, make sure all gas connections are tight before operation. If you continue to smell gas call a
qualified technician.
- When lighting a burner, always pay close attention to what you are doing and be certain you are pushing the igniter
that lights the burner you intend on using.
- Always keep your face and body as far away as from the grill as possible when lighting to reduce the risk of burn.
- Extinguish all flames and do not smoke while engaging gas and igniting the grill.
- A minimum distance of at least 12" must be maintained from any combustible material on both sides and the back of
the grill. Do not place the grill under any overhead unprotected combustible construction.
RECOGNIZE SAFETY SYMBO S, WORDS AND ABE S
WARNIN indicates a potentially hazardous situation which, if
not avoided, could result in death or serious injury.
NOTE indicates an important piece of information that needs to
be observed to ensure the proper operation of your grill.
INSTALLER: Please retain these instructions with the owner so that they may maintain them for
future reference.
DANGER
If you smell gas:
1. Shut off gas to the appliance
2. Extinguish any open flame
3. Open lid
4. If odor continues, keep away from the
appliance and immediately call your
gas supplier or your fire department.
WARNING
1. Do not store or use gasoline or other
flammable liquids or vapors in the
vicinity of this or any other appliance.
2. An LP cylinder not connected for use
shall not be stored in the vicinity of this
or any other appliance.
Welcome & Con ratulations
3
Please retain this manual for future reference
Amana™is a registered trademark of the Maytag Corporation and is used under license
to Sure Heat Manufacturing
© 2007 Sure Heat Manufacturing All rights reserved
Congratulations on your purchase of a new grill! We are
very proud of our product and we are completely
committed to providing you with the best service
possible. Your satisfaction is our #1 priority.
Please read this Use & Care Manual very carefully. It
contains valuable information on how to properly
maintain your new grill.
We know you’ ll enjoy your new grill and thank you for
choosing our product. We hope you consider us for
future purchases.
P EASE READ AND SAVE THESE INSTRUCTIONS
This Use & Care Manual provides specific operating
instructions for your model. Use your grill only as
instructed in this manual. These instructions are not
meant to cover every possible condition and situation
that may occur. Common sense and caution must be
practiced when installing, operating and maintaining any
appliance.
Please record your model and serial numbers below for
future reference. This information is found on the serial
plate located on the inside of the grill door.
NOTE: Use only soap and water to clean serial plate.
Model Number: ______________________________
Serial Number: ______________________________
Purchase Date: ______________________________
as Type: __________________________________
Please complete and mail in the Product
Registration Card included with your grill.
Questions?
1-800-229-5647
for written inquiries:
Sure Heat Manufacturing
3130 Moon Station Rd
Kennesaw, GA 30144
Please attach sales receipt here for
future reference.
Register Your Product
The PRODUCT REGISTRATION CARD
shoul be fille in completely, signe
an returne to Sure Heat Manufacturing.
General Safety Instructions
4
Do not use the rotisserie in the rain.
Electrical Grounding Instructions
This appliance (rotisserie motor) is equipped with a
three-prong (grounding) plug for your protection
against shock hazard and should be plugged directly
into a properly grounded three-prong receptacle. Do
not cut or remove the grounding prong from this plug.
Keep any electrical supply cords and the fuel supply
hose away from any heated surfaces.
The Spare L.P. Gas Tank Barrier must be installed to
prevent storage of spare L.P. Gas Tanks. Failure to
comply with these instructions could result in a fire or
explosion that could cause serious bodily injury, death,
or property damage.
FO YOU SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flames.
3. Open grill hood.
4. If odor continues, immediately
call your gas supplier and local Fire Dept.
CALIFORNIA PROPOSITION 65 - WA NING: The
Burning of gas ooking fuels generates some
by produ ts whi h are on the list of substan es whi h are
known by the State of California to ause an er or
reprodu tive harm. California law requires businesses to
warn ustomers of potential exposure to su h substan es.
To minimize exposure to these substan es, always operate
this unit a ording to the use and are manual, provide
good ventilation when ooking with gas.
This applian e is not intended to be installed in or
on re reational vehi les or boats. FO OUTDOO USE ONLY
DO NOT try lighting this applian e without reading the
“ LIGHTING INST UCTIONS” se tion of this manual.
FO YOU SAFETY
DO NOT store or use gasoline or other flammable vapors
and liquids in the vi inity of this or any other applian e.
An LP cylinder not onne ted for use shall not be stored in
the vi inity of this or any other applian e.
TESTED IN ACCO DANCE WITH ANSI
Z21.58b-2002/CSA 1.6b-M02 STANDA D FO
OUTDOO COOKING GAS APPLIANCES. THIS
G ILL IS FO OUTDOO USE ONLY.
Che k your lo al building odes for the proper method of
installation. In the absen e of lo al odes, this unit should be
installed in a ordan e with the
National Fuel Gas Code No. Z223.1-2002 and the
National Ele tri al Code ANSI/NFPA No. 70-1990
Never atta h an unregulated gas line to the applian e.
Conne tion to an unregulated gas line an ause ex essive
heat or fire.
Always have a qualified servi e te hni ian perform diffi ult
onversions or modifi ations.
Do not use the grill in garages, breezeways, sheds or any
en losed area. Never operate the grill in en losed areas as
this ould lead to a arbon monoxide buildup, whi h ould
result in injury or death. Pla e the grill on a level surfa e.
Avoid moving the grill while it is operation.
NOTE: Do Not operate the main burners and infrared
back burner at the same time. This can cause warping of
the roll top grill hood.
SS 4 Grill Features
5
1. Roll top grill hood
2. Rear Infrared Burner
3. rilling/cooking surface
4. Side shelf
5. Towel bar/utensil hanger
6. Control knob: Rear infrared burner
7. Control knobs: main burners
8. Hood Handle
9. Warming shelf
10. Side burner
11. Control knob: side burner
12. Electronic igniter: main burners, side burner
and rear infrared burner
13. Cart with doors
1
2
4
5
6
7
8
9
10
11
12
13
3
Gettin Started
49600113 Self-Tapping Screws x13
49600206 Wheel Channel Nuts x6
49600101 "S" Hooks x3
All hardware is shown actual size.
Two People Required to Assemble rill
Tools Needed:
Phillips screwdriver
Adjustable wrench
1/2” wrench or socket
1/4” nut driver or socket
6
7
SS 4 Grill Out of Box
2a
12b
2c
5a
2e
1a
12c 3e
4a
11b
712a
11a 61b 1c
Open Box Carefully – Lay Out All Parts
2a. Cart Side Left
12b. T 30 Main rate
2c. Cart Side Right
5a. Cart Door Left
5b Cart Door Right
2e. Cart Back
1a. Cart Base
12c. Bread Warmer rate
3e. Cart Brace
4a rill Assembly
11b Drip Pan
7 Side Burner Shelf Assembly
12a Flavor rid
11a Condiment Basket
6 Side Shelf Left Assembly
1b Caster Assembly Left (Swivel wheels)
1c Caster Assembly Right (Swivel Wheels with lock)
Not Shown: Plastic bag containing:
Igniter Wire
Screw Packages
Side Burner Igniter
Side Burner Knob
Side Burner Beze
Tank Ring
5b
STEP ONE
a. Set the cart base on the floor and then lay the left
wheel channel on the left and the right wheel
channel on the right side of the cart base.
b. Pick up the left side of the cart base and set the
fixed wheel channel in place by inserting the
attached bolts through the three (3) holes in the
cart bottom.
c. Pick up the right side of the cart base and set the
swivel wheel channel in place by inserting the
attached bolts through the three (3) holes in the
cart bottom.
SS 4 Assembly
8
1c
1b
1a
STEP TWO
a. Place the left cart side onto the two (2) outer fixed
wheel channel bolts, make sure the large flange
is toward the front of the cart base.
b. Secure the left cart side in place by hand tightening
nuts onto the wheel channel bolts.
c. Place the right cart side onto the two (2) outer
swivel wheel channel bolts, make sure the large
flange is toward the front of the cart base.
d. Secure the right cart side in place by hand
tightening nuts onto the wheel channel bolts.
e. Place the cart back onto the two (2) rear wheel
channel bolts.
f. It will be necessary to push the top of the left and
right sides outward slightly to get the cart back
down completely on the base.
SS 4 Assembly
9
2f
2c
2a
2d
2f
2b
2e
SS 4 Assembly
10
STEP THREE
a. Press the sides back together making sure that the
side flanges cover the cart back flange.
b. Attach three (3) self tapping screws through the
pre-drilled holes on the left cart side into the cart
back. Repeat for right cart side.
c. Fasten two (2) nuts onto the back wheel channel
bolts.
d. Tighten all six (6) wheel channel nuts with a
wrench.
e. Attach the Spare L.P. as Tank Barrier by
inserting the tabs into the slot on the base of the
cart, and then attaching the flat end of the
bracket to the pre-drilled hole at the back of the
cart with a self-tapping screw. Make certain to
attach the self-tapping screw from the
outside of the cart.
The Spare .P. Gas Tank
Barrier must be installed
to prevent storage of spare .P. Gas
Tanks. Failure to comply with these
instructions could result in a fire or
explosion that could cause serious
bodily injury, death, or property dam-
age.
3a
3b
3b
3c
3a
3d
3e
Andere Handbücher für SS 4
1
Inhaltsverzeichnis
Andere Amana Grill Handbücher
Amana
Amana SS 5 Bedienungsanleitung
Amana
Amana AM26LP-P Bedienungsanleitung
Amana
Amana AM30LP-P Bedienungsanleitung
Amana
Amana AM33LP-P Bedienungsanleitung
Amana
Amana AM30LP-P Bedienungsanleitung
Amana
Amana SS 5 Bedienungsanleitung
Amana
Amana AM27LP Bedienungsanleitung
Amana
Amana SS 4 Bedienungsanleitung
Amana
Amana AM26LP Bedienungsanleitung
Amana
Amana AM27 Bedienungsanleitung
