Manchester Supplement

8000-2627-02, Rev. A AMERICAN DYNAMICS 1

DeltaDome™

Programmable

Surveillance Camera

This document supplements information found in

the DeltaDome Programmable Surveillance

Camera Configuration Utility Operator's Manual

(8000-2612-02).

Additional Commands

The following tables summarize the special

commands available when using the dome in a

Manchester network. These commands are

available when you enter the number listed and

press the Set Preset or Call Preset button on the

controller.

Set Commands: This table describes the

functions that can be performed when you enter

the number listed then press the Set Preset button.

Command Function

65 Set Preset Reset Dome

66 Set Preset Starts Dome Configuration Menu

67 Set Preset Activate / Deactivate V-phase

delay setting adjustment

68 Set Preset Cancel Pattern Programming

69 Set Preset Save Pattern Programming

70 Set Preset Program Pattern 1

71 Set Preset Program Pattern 2

72 Set Preset Program Pattern 3

Call Commands: This table describes the

functions that can be performed when you enter

the number listed then press the Call Preset button.

Command Function

66 Call Preset Resume Auto Focus / Auto Iris

67 Call Preset Rotate dome 180°from current

position (“flip”)

69 Call Preset Repeats following pattern

70 Call Preset Run Pattern 1

71 Call Preset Run Pattern 2

72 Call Preset Run Pattern 3

Operating Parameters

Presets: Only 64 presets may be programmed

when the dome is installed in a Manchester

network.

Auxiliaries: The dome provides four connections

for auxiliaries. When used on a Manchester

network, Auxiliaries 1 through 3 are supported.

Auxiliary 4 is not supported.

The dome supports three latching auxiliaries. A

latching auxiliary remains activated until it is

manually deactivated. For example if the auxiliary

is a light, the light remains on until it is manually

turned off. The dome does not support momentary

auxiliaries.

Alarm Inputs: When operating on a Manchester

network, the dome can be programmed to respond

to any of the four available alarm inputs. However,

the dome cannot transmit alarm input states to the

host controller. If transmitting the alarm state to the

host controller is required, the alarm device must

be wired directly to the host controller.
