H153
© 2008 AS America Inc. Revised 2/08
SLIDING SHOWER DOOR ENCLOSURES
Product Features:
• Tempered safety glass
• Header to jamb safety lock
• Adjustable roller assembly for out-of-square
installations
• Easy clean tackless sill plate
• Jamb bumpers
• Towel bars on interior and exterior of unit
• Concealed caulking channels for
water-tight installation
❏ 6034.STE1 Obscure Glass
❏ 6034.STE2 Clear Glass
❏ 6034.STE5 Rain Glass
56" to 60" x 71-1/2"
(1422 to 1524 x 1816mm)
❏ 4834.STE1 Obscure Glass
❏ 4834.STE2 Clear Glass
❏ 4834.STE5 Rain Glass
44" to 48" x 71-1/2"
(1118 to 1219 x 1816mm)
❏ 4242.STE1 Obscure Glass
❏ 4242.STE2 Clear Glass
❏ 4242.STE5 Rain Glass
40" to 42" x 71-1/2"
(1016 to 1067 x 1816mm)
To Be Specied:
❏ Frame Finish: (specify nish)
❏ Shower Base*: (specify color)
❏ Shower Wall*: (specify color)
❏ Faucet*: (specify nish)
SLIDING
SHOWER DOOR ENCLOSURE
SEE REVERSE SIDE FOR DETAILED
DIMENSIONAL INFORMATION
* See xture and faucet section for available models
H154
© 2008 AS America Inc.
SLIDING
SHOWER DOOR ENCLOSURE
Revised 2/08
