Ameriwood HOME 1630407COM Bedienungsanleitung

1630407COM

Entryway Storage-Black/Walnut

- Unit can tip over causing severe injury or death.

- Anchor unit to stud in wall (if instructed to).

- Do Not allow children to climb on unit.

- Put heavy items on lower shelves or drawers.

B34 1630407 COM00SF

THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.

WARNING

Follow Ameriwood Home

Date of Purchase ___ / ___ / ___

Lot Number:

Do Not Return This Product!

Contact our customer service team for help first.

Call: 1-800-489-3351 (toll free)

Monday-Friday 9am - 5pm CST

Visit: www.ameriwoodhome.com

Assembly Difficulty Meter

Easy Tough

Follow Ameriwood Home

Helpful Hints

Do NOT return this product!

Contact our friendly customer service team first for help.

Call us!

1-800-489-3351

Monday-Friday

9am - 5pm CST

Visit ameriwoodhome.com

Assembly Tips

- Open your item in the area you plan to keep it to avoid excessive heavy lifting.

- Identify, sort and count the parts before attempting assembly.

- Compression dowels are lightly tapped in with a hammer.

- Slides are labeled with a R (right) and L (left) for proper placement.

- Make sure to always face the point on the top of the Cam Lock towards the

outer edge.

- Use all the nails provided for the back panel and spread them out equally.

- Back panel must be used to make sure your unit is sturdy.

- Do NOT use harsh chemicals or abrasive cleaners on this item.

- Never push, pull, or drag your furniture.

PEOPLE NEEDED FOR ASSEMBLY: 2

ESTIMATED ASSEMBLY TIME: 1 HOUR

ameriwoodhome.com

Before You Start

Quick

Tip

Assembly

Cam Lock Fastening System

This Cam Lock Fastening System will be used throughout the assembly process.

Read through each step carefully and follow the proper order

Separate and count all your parts and hardware

Give yourself enough room for the assembly process

Have the following tools: Flat Head Screwdriver, #2 Phillips Head

Screwdriver and Hammer

Caution: If using a power drill or power screwdriver for screwing,

please be aware to slow down and stop when screw is tight.

Failure to do so may result in stripping the screw.

ameriwoodhome.com

Board Identification

Not Actual Size

Top panel

T1630407010SF

Bottom panel

T1630407020SF

Left side panel

T1630407030SF

Right side panel

T1630407040SF

Board Identification

Not Actual Size

Left back panel

T1630407050SF

Right back panel

T1630407060SF

Side panel rail

T1630407070SF

QTY: 2 PCS

Lower shelf

T1630407080SF

ameriwoodhome.com

Board Identification

Not Actual Size

Hook panel

T1630407090SF

Partition

T1630407100SF

Kick

T1630407110SF

Left fixed shelf

T1630407120SF

Lower shelf rail

T1630407140SF

Right fixed shelf

T1630407130SF

ameriwoodhome.com

Board Identification

Not Actual Size

Bottom support

T1630407150SF

Upper shelf

T1630407160SF

QTY: 2 PCS

Support tube

T1630407170SF

QTY: 4 PCS

Front support tube

T1630407180SF

QTY: 2 PCS

ameriwoodhome.com

Board Identification

Not Actual Size

Actual Size

ameriwoodhome.com

Part List

Hardware Bag Reference Number:

21630407COM0SF

Ø5/32X10mm

Screw bolt

TSF1803

2x 4

Ø5/32X12mm

Bolt

TSF0952

3x 8

x 52

Ø8X30mm

Wood dowel

TSF0501

Ø1/4X30mm

Bolt

TSF1403

4x 4

x 6

Screw

TSF0606

7 x 1

Screw

TSF1005

Ø4X38mm

Ø4X14mm

8 x 1

Screw

TSF1006

Ø3.5X14mm

Ø1/4X25mm

Bolt

TSF1416

5x 4
