Ameriwood HOME 8948335COM Bedienungsanleitung

8948335COM

HomeVanityWithDrawers

B348948335COM0

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

FollowAmeriwoodHome

Tube

You

DateofPurchase___/___/___

LotNumber:

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐800‐489‐3351(tollfree)

Monday‐Friday9am‐5pmCST

Visit:www.ameriwoodhome.com

AssemblyDifficultyMeter

Easy Tough

‐Anchorunittostudinwall

‐DoNotallowchildrentoclimbonunit

‐Putheavyitemsonlowershelvesordrawers

‐Twopeoplerequiredforassembly

Unitcantipovercausingsevereinjuryordeath.

WARNING

NOT FOR COMMERCIAL USE

ContactUs!

HelpfulHints

2

ameriwoodhome.com

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐800‐489‐3351

Monday‐Friday

9am‐5pmCST

Visitameriwoodhome.comtoviewthe

limitedwarrantyvalidintheU.S.andCanada.

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.



‐Identify,sortandcountthepartsbeforeattemptingassembly.



‐Compressiondowelsarelightlytappedinwithahammer.



‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.



‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.



‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.



‐Backpanelmustbeusedtomakesureyourunitissturdy.



‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.



‐Neverpush,pull,ordragyourfurniture.

Tube

You

PEOPLENEEDEDFORASSEMBLY:1‐2

3

ameriwoodhome.com

BeforeYouStart



Quick

Tip

Assembly



Readthrougheachstepcarefullyandfollowtheproperorder



Separateandcountallyourpartsandhardware

Partsarelabeledonthesurfaceoredgeofthepart



Giveyourselfenoughroomfortheassemblyprocess



Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.



4

ameriwoodhome.com

BoardIdentification

Notactualsize

LeftPanel

38948335010 RightPanel

38948335020

LeftPartition

38948335030

RightPartition

38948335040

Top

38948335050

Bottom

38948335060

FrontPanel

38948335070

LeftDrawerFront

38948335080

RightDrawerFront

38948335090

LeftDrawerSide(x2)

38948056100

RightDrawerSide(x2)

38948056110

DrawerBack(x2)

38948056120

DrawerBottom(x2)

39996340031910D

BackPanel

K894800000

This piece is paperboard construction.

It is not made from wood, but is

required for the assembly of your unit.

ABCD

IJKL

5

ameriwoodhome.com

BoardIdentification

Notactualsize

6

ameriwoodhome.com

PartList

ActualSize

(x8)

#A22920

connector

(x8)

#A22910

connectorbolt

(x2)

#A21960

hiddenfastener

(x8)

#A23030

confirmat

(x16)

#A14220

1/2"screw

(x20)

#A11080

7/16"screw

(x2)

#A17400

7/8"bolt

(x10)

#A12120

7/16"screw

(x8)

#A21970

drivefastener

(x20)

#A21110

nail

(x2)

#A52365

knob

(x4)

#A54205

drawerbracket

(x1)

#A53510

anglebracket

1234

7

ameriwoodhome.com

PartsList

Notactualsize

LeftCabinetMember

RightCabinetMember

LeftDrawerRunner

RightDrawerRunner

(x2)

#A56750

drawerslide

(x4)

#A44820

leg

(x2)

#A70420

2"grommet

(x1)

#A70430

3"grommet

14a

14b

14c

14d

8

ameriwoodhome.com

STEP1

(x8)

9

ameriwoodhome.com

STEP2

(x4)

Besureconnector(4)ispositioned

asshownbeforeinsertingintohole.

Tapwithahammertofullyinsert.

Markedwitha"L"

(x3) (x1)

14a

finishededge

10

ameriwoodhome.com

STEP3

(x2)

(x6)

(x1)

Besureconnector(4)is

positionedasshown

beforeinsertingintohole.

Tapwithahammerto

fullyinsert.

14a

14b

Markedwitha"L"

Markedwitha"R"

14a

14b

RIGHTSIDE

LEFTSIDE

finishededge
