Arf HandyKing EP Bedienungsanleitung

GM055PO26641106

It is designed for maximum performance. Please seek advice if one is not familiar with this kind

of electric powered precision model. Operating this model without prior preparation may cause

injuries. Remember, safety is the most important thing. Always keep this instruction manual at

hand for quick reference.

Warning ! This model is not a toy.

THE WINGS MAKER

FACTORY PRE-FABRICATED

ALMOST-READY-TO-FLY (ARF) SERIES

MADE IN CHINA

* Specifications are subject to change without notice.*

www thewingsmaker com. .

SpecificationsSpecifications

Before commencing assembly please read these instructions thoroughly, .

INSTRUCTION MANUAL

Wing Span: 46.5 in / 1180 mm

Wing Area: 565 sq in / 36.4 sq dm

Flying Weight: 53 oz / 1500 g

Fuselage Length: 52 in / 1320 mm

Requires: 4-channel radio w/ 4 mini servos. Outrunner

Motor KM0374810 w/ Propeller Adaptor HW2340102

40A Brushless ESC,11x8E Propeller, 4 cells 14.8V

3200 mAh Li-Po battery & charger.

HandyKing EP(40)

GM055PO26641106

Check all parts. If you find any defective or missing parts contact your local dealer. Please

DRY FIT and check for defects for all parts that will require CA or Epoxy for final assembly.

Any parts you find to be defective after the gluing process may be difficult to remove for

warranty replacement. The manufacturer will replace any defective parts, but will not extend

to the parts that are good before gluing to defective parts during assembly. Warranty will

not cover any parts modified by customer. For pre-assembled kits, please check proper

functions of all servos on the ground before flying. Servo gears could be damaged when

control surfaces are hit during transportation of models. The manufacturer will replace any

servos due to manufacturer`s defect, but will not cover plane crashes due to damaged

servos not detected before flying.

Symbols used throughout this instruction manual comprise of the following :-

Read through the manual before you begin, so you will have an overall idea of what to do.

INDEX

BEFORE YOU BEGIN

PARTS LIST

ASSEMBLY

SAFETY PRECAUTIONS

P.1

P.2

P.3-P.9

P.9

P.1

Cut off shaded portion.

Ensure smooth non-binding

movement while assembling.

Apply instant glue

(C.A.glue, super glue.)

Assemble left and right

sides the same way.

Peel off shaded portion

covering film.

Pay close attention here!

Apply epoxy glue.

Must be purchased separately !

Drill holes with the specified

diameter (here: 3mm). Pierce the shaded portion

covering film.

3mm

Do not overlook this symbol !

Warning!

Apply thread locker

HandyKing EP(40)

GM055PO26641106

P.2

Parts List

1.MAIN WING -- 1 pair

CLEVIS PL4112103 -- 2 pcs

STRAPER PL4112102 -- 2 pcs

FUEL TUBE D2.5xD6x5mm -- 4 pcs

HORN PL4113103 -- 2 pcs

PUSHROD Ø1.8x55mm w/ Threads (ForAileron) -- 2 pcs

SERVO MOUNTING PANEL PL5310030 -- 1 pair

SCREW PA1.7x8mm -- 8 pcs

FIBRE TAPE 17x540mm -- 2 pcs

PLYWOOD 50x50x2mm -- 2 pcs

2.FUSELAGE -- 1 set

STABILIZER & ELEVATOR -- 1 set

FIBRE TAPE 17x380mm -- 1 pc.

3.VERTICAL FIN & RUDDER -- 1 set

FIBRE TAPE 17x250mm -- 1 pc.

PLYWOOD 50x50x2mm -- 1 pc.

4.TAIL LANDING GEAR PL3410031 --1 set

SCREW PA2.6x10mm -- 2 pcs

COLLAR Ø2.1mm w/ Set Screw -- 1 set

PLYWOOD 50x50x2mm -- 1 pc.

5.MAIN LANDING GEAR -- 1 set

COLLAR Ø3.1mm w/ Set Screw -- 2 sets

MAIN WHEEL Ø62mm PL3111620 -- 2 pcs

SCREW PA2.6x10mm -- 1 pc.

PLYWOOD 46x33x3.4mm (For Main Landing Gear) -- 1 pc.

MAIN LANDING GEAR COVER -- 1 pair

6.SCREW PA1.7x8mm -- 4 pcs

FUEL TUBE d2.5xD6x5mm -- 2 pcs

CLEVIS PL4112103 --1 pc.

STRAPER PL4112102 -- 1 pc.

SERVO MOUNTING PANEL PL5310030(R) -- 1 pc.

HORN PL4113103 -- 1 pc.

PUSHROD Ø1.8x146mm w/ Threads (For Elevator) -- 1 pc.

7.SCREW PA1.7x8mm -- 4 pcs

FUEL TUBE d2.5xD6x5mm -- 2 pcs

CLEVIS PL4112103 --1 pc.

STRAPER PL4112102 -- 1 pc.

HORN PL4113103 -- 1 pc.

SERVO MOUNTING PANEL PL5310030(L) -- 1 pc.

PUSHROD Ø1.4x150mm w/ Threads (For Rudder) -- 1 pc.

8.SOCKET HEAD SCREW M3x10mm -- 4 pcs

WASHER d3xD7mm -- 4 pcs

SPINNER Ø52mm -- 1 set

9.WING TUBE Ø8x500mm -- 1 pc.

RUBBER BAND D4x30mm -- 2 pcs

HOOK Ø1.6x178mm -- 1 pc.

10.BATTERY COVER -- 1 pc.

BATTERY TIE 200mm-- 2 pcs

SPONGE 10x50x150mm -- 2 pcs

DOUBLE-SIDED TAPE 30x35mm (For Brushless ESC) -- 1 pc.

11.DECALS: GM055 DEC -- 1 set

GM055PO26641106

P.3

Bottom View Bottom View

Bottom View

Aileron Servo

Fibre Tape 17x540 mm

Aileron Servo Lead

Fibre Tape

Bottom

Plywood

50x50x2 mm

PA1.7x8mm Screw

TWM PL8210010

CLEVIS WRENCH

Clevis Pushrod

Ø1.8x55mm

FuelTube

d2.5xD6x5mm

Horn

Straper

Fuel Tube

d2.5xD6x5mm

PA1.7x8mm

GM055PO26641106

P.4

Vertical Fin & Rudder

Completed

Tail Landing Gear

Bottom View

PA2.6x10mm Screw 2.1mm Collar

Fibre Tape

17x250 mm

Fibre Tape

Wheel Ø23mm

PA2.6x10mm

1.2mm

M3x3mm Set Screw

2.1mm Collar

Bottom View

Stabilizer & Elevator

Fibre Tape

17x380 mm

Fibre Tape

Bottom

Joining surfaces should

be clean and dry. Slightly

roughen surfaces with

sandpaper for best results.

Joining surfaces should be clean and dry. Slightly roughen

surfaces with sandpaper for best results.

Plywood

50x50x2 mm

Plywood

50x50x2 mm

GM055PO26641106

Main Landing Gear

Elevator Pushrod

Bottom View

P.5

M3x3mm Set Screw

3.1mm Collar

Bottom View

Bottom View Bottom View

Wheel Ø62mm

Main Landing Gear Cover

PA2.6x10mm Screw

PA2.6x10mm

Plywood

Landing Gear

46x33x3.4mm

3.1mm Collar

PA1.7x8mm Screw

Straper Fuel Tube

d2.5xD6x5mm

PA1.7x8mm

100

Landing Gear

Fuselage

TWM PL8210010

CLEVIS WRENCH

Clevis

Pushrod

Ø1.8x146mm

FuelTube

d2.5xD6x5mm Horn

GM055PO26641106

Rudder Pushrod

Outrunner Motor / Spinner

P.6

PA1.7x8mm Screw

d3xD7mm Washer

Make sure rotating motor casing is not in contact

with wirings or anything.

Enlargeopening for better

coolingif necessary .

Optional Parts

Brushless ESC

EZ Connector

SolderSolder

TWM

KP0011310

ESC Motor

3 4

M5 Nut

d6xD15mm Washer

Ø52mm Spinner

PA3x12mm

TWM HW3111700

PROPELLERADAPTORWRENCH Completed

d3xD7mm Washer

M3x10mm

Don't over-tighten the M3 screws, too much

stress on the screws could split the firewall.

Straper Fuel Tube

d2.5xD6x5mm

PA1.7x8mm

Outrunner Motor 37/ 48 Deluxe

KM0374810

PropellerAdaptor

HW2340102

11x8E Propeller PL6211108

11x8E Propeller

PL6211108

Clevis

Pushrod

Ø1.8x150mm

Fuel Tube

d2.5xD6x5mm

Horn

TWM PL8210010

CLEVIS WRENCH

M3x10mm

Socket Head Screw

Bottom View

GM055PO26641106

P.7

Main Wing

Rubber Band

Aileron Servo Lead

Wing Tube

Ø8x500mm

Radio Equipment

Battery

Install and arrange the equipment as shown in the picture.

Outrunner Motor

Battery Tie Sponge

Sponge

Receiver

Front

Brushless

ESC

Double Sided Tape

Completed

Fuselage Bottom

Battery Cover

Completed

Hook

GM055PO26641106

P.8

Control Throws

Elevator

Rudder

Ailerons

Adjust the control throws as shown in

the diagram. These throws are good for

general flying. You can adjust according

to your personal preference.

40mm

50mm

60mm

Decals

FL01

FL06

FL03F08 FL04

FL05

FL02

FL07

WL01 WL02

WL03

WL04 WL05

WL06

WL07

SL01

SL02

SR03

SR01

SR02

SR04SL04

SL03

WR01

WR02

WR03

WR04

WR05

WR06

WR07

GM055PO26641106

P.9

Important Safety Precautions

# First time flyer should never fly by himself / herself. Assistance from experienced flyer

is absolutely necessary.

# Pre-flight adjustment must be done before flying, it is very dangerous to fly a badly

pre-adjusted aircraft.

# is specially designed to be powered by KM0374810 Outrunner Motor.

# Make sure the air field is spacious, never fly the plane too close to people and never get

too close to a running propeller. Extreme caution should be exercised when working with

electric powered models. Make sure the propeller is cleared of all objects, especially your

hands before connecting the battery to the model. Make sure you understand the

operation of the ESC (Electronic Speed Control) by studying the ESC manual. Once you

plug in the battery for electric powered model, always treat the propeller as a rotating one,

as accidental movement of the throttle stick will spin the propeller and could cause injuries.

# Check and re-tighten up all factory assembled screws, use thread locker if necessary.

Warning!

HandyKing EP(40)

C.G.

The ideal C.G. position is 130mm (5.1 in.) behind the leading edge

measured at where the wing meets the fuselage. In order to obtain

the C.G. specified, add weight to the fuselage or move the battery

position. Check the C.G. before flying.

130mm

5.1 in.

C.G.

http://www.thewingsmaker.com/instructionManuals.php
