ASROCK E3C222D4U Bedienungsanleitung

Version 1.0

Published December 2014

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Rack Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished

for informational use only and subject to change without notice, and should not

be constructed as a commitment by ASRock Rack. ASRock Rack assumes no

responsibility for any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock Rack does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock Rack, its directors, ocers, employees, or agents be liable

for any indirect, special, incidental, or consequential damages (including damages

for loss of prots, loss of business, loss of data, interruption of business and the

like), even if ASRock Rack has been advised of the possibility of such damages

arising from any defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Rack’s Website: www.ASRockRack.com

Contact Information

If you need to contact ASRock Rack or want to know more about ASRock Rack,

you’re welcome to visit ASRock Rack’s website at www.ASRockRack.com; or you

may contact your dealer for further information.

ASRock Rack Incorporation

6F., No.37, Sec. 2, Jhongyang S. Rd., Beitou District,

Taipei City 112, Taiwan (R.O.C.)

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Unique Features 5

1.4 Motherboard Layout 6

1.5 Onboard LED Indicators 9

1.6 I/O Panel 11

1.7 Block Diagram 13

Chapter 2 Installation 14

2.1 Screw Holes 14

2.2 Pre-installation Precautions 14

2.3 Installing the CPU 15

2.4 Installing the CPU Fan and Heatsink 17

2.5 Installation of Memory Modules (DIMM) 18

2.6 Expansion Slots (PCI Express Slots) 20

2.7 Jumper Setup 21

2.8 Onboard Headers and Connectors 22

2.9 Unit Identication purpose LED/Switch 28

2.10 Driver Installation Guide 28

2.11 Dr. Debug 29

2.12 Dual LAN and Teaming Operation Guide 30

Chapter 3 UEFI Setup Utility 31

3.1 Introduction 31

3.1.1 UEFI Menu Bar 31

3.1.2 Navigation Keys 32

3.2 Main Screen 33

3.3 Advanced Screen 34

3.3.1 CPU Conguration 35

3.3.2 Chipset Conguration 37

3.3.3 Storage Conguration 39

3.3.4 Super IO Conguration 41

3.3.5 ACPI Conguration 42

3.3.6 USB Conguration 43

3.3.7 WHEA Conguration 44

3.3.8 Intel Server Platform Services 45

3.3.9 Serial Port Console Redirection 46

3.3.10 Voltage Control 49

3.3.11 Instant Flash 50

3.4 H/W Monitor Screen (Hardware Health Event Monitoring) 51

3.5 Boot Screen 53

3.6 Security Screen 55

3.7 Event Logs 56

3.8 Server Mgmt (Server Management) 58

3.9 Exit Screen 60

Chapter 4 Software Support

4.1 Install Operating System

4.2 Support CD Information

4.2.1 Running The Support CD

4.2.2 Drivers Menu

4.2.3 Utilities Menu

4.2.4 Contact Information

Chapter 5 Troubleshooting

5.1 Troubleshooting Procedures

5.2 Technical Support Procedures

5.3 Returning Merchandise for Service

Chapter 6 Net Framework Installation Guide

6.1 Installing .Net Framework 3.5.1 (For Server 2008 R2) 65

E3C222D4U

English

Chapter 1 Introduction

ank you for purchasing ASRock Rack E3C222D4U motherboard, a reliable

motherboard produced under ASRock Rack’s consistently stringent quality control.

It delivers excellent performance with robust design conforming to ASRock Rack’s

commitment to quality and endurance.

In this manual, chapter 1 and 2 contains introduction of the motherboard and step-

by-step guide to the hardware installation. Chapter 3 and 4 contains the conguration

guide to BIOS setup and information of the Support CD.

1.1 Package Contents

•ASRockRack E3C222D4U Motherboard

(Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm)

•User Manual

•Support CD

•4 x SATA3 Cables (50cm)

•2 x SATA3 Cables (60cm)

•1 x I/O Shield

If any items are missing or appear damaged, contact your authorized dealer.

Because the motherboard specications and the BIOS soware might be updated, the con-

tent of this manual will be subject to change without notice. In case any modications of

this manual occur, the updated version will be available on ASRock Rack website without

further notice. You may nd the latest memory and CPU support lists on ASRock Rack

website as well. ASRock Rack’s Website: www.ASRockRack.com

If you require technical support related to this motherboard, please visit our website for

specic information about the model you are using.

http://www.asrockrack.com/support/

English

1.2 Specications

E3C222D4U

MB Physical Status

Form Factor uATX

Dimension 9.6" x 9.6'' (24.4 cm x 24.4 cm)

Processor System

CPU Supports Intel® Xeon® E3-1200 v3 Series Processors

Socket Single Socket LGA 1150

Chipset Intel® C222

System Memory

Capacity 4 DIMM slots

Type - Dual Channel memory technology

- Supports DDR3 1600/1333 ECC DIMM

Voltage 1.5V, 1.35V

Expansion Slot

PCIe 3.0 x 16 1 slot (PCIE6: x16/x8 switch with PCIE4)

PCIe 3.0 x 8 1 slot (PCIE4: x0/x8 switch with PCIE6)

PCIe 2.0 x 8 1 slot (PCIE7: x4)

Storage

SATA

Controller

C222: 2 x SATA3 6Gb/s, 4 x SATA2 3Gb/s, support RAID 0,

1, 5, 10 and Intel® Rapid Storage

Ethernet

Interface Gigabit LAN 10/100/1000 Mb/s

LAN Controller - 2 x RJ45 by Intel® i210 + Intel® i217

- 1 x RJ45 Dedicated IPMI LAN port

- Supports Wake-On-LAN

- Supports Energy Ecient Ethernet 802.3az

- Supports Dual LAN with Teaming function

- Supports PXE

Management

BMC Controller ASPEED AST2300

IPMI Dedicated

GLAN

1 x Realtek RTL8211E for dedicated management GLAN

Features - Watch Dog

- NMI

Gracphics

Controller ASPEED AST2300

VRAM DDR3 16MB

Output Supports D-Sub with max. resolution up to 1920x1200 @60Hz

E3C222D4U

English

Rear Panel I/O

VGA Port 1 x D-sub

USB 2.0 port 4

Lan Port - 2 + 1 (IPMI) Lan port (RJ45)

- LAN Ports with LED (ACT/LINK LED and SPEED LED)

Serial Port 1 (COM1)

UID Button/

UID LED

Internal Connector

Auxiliary Panel

Header

1 (include chassis intrusion , location button & LED , front

LAN LED , system fault LED)

TPM Header 1

IPMB Header 1

Buzzer 1

COM Header 1

BMC SMBus

Header

Fan Header 1x CPU Fan, 4x system Fan (4-pin)

ATX Power 1 (24-pin) + 1 (8-pin)

USB 3.0 Header 1 ( support 1 USB 3.0)

USB 2.0 Header 1 ( support 2 USB 2.0)

Type A USB 3.0

Port

Front Panel 1

System BIOS

BIOS Ty pe 64Mb AMI UEFI Legal BIOS

BIOS Features - Plug and Play (PnP)

- ACPI 2.0 Compliance Wake Up Events

- SMBIOS 2.8.0 Support

- ASRock Rack Instant Flash

Hardware Monitor

Temperature - CPU Temperature Sensing

- System Temperature Sensing

- System Inlet Temperature Sensing

- Card Side Temperature Sensing

Fan - CPU/Rear/Front Fan Tachometer

- CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by

CPU Temperature)

- CPU/Rear/Front Fan Multi-Speed Control

Voltage Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM,

1.05V_PCH, +BAT, 3VSB, 5VSB

English

Support OS

OS Microso® Windows®

- Server 2008 R2 (64 bit)

- Server 2012 (64 bit)

- Server 2012 R2 (64 bit)

Linux®

- RedHat Enterprise Linux Server 5.10/6.5(32 / 64 bit)

- CentOS 5.10 / 6.5 (32 / 64 bit)

- SUSE Enterprise Linux Server 11 SP3 (32 / 64 bit)

- FreeBSD 9.2 (32 / 64 bit)

- Fedora core 19 (64 bit)

- Ubuntu 12.04.2 (64 bit) / 12.10 (64 bit)

Virtual

- VMWare® ESXi 5.5

Environment

Temperature Operation temperature: 10°C ~ 35°C / Non operation

temperature: -40°C ~ 70°C

* For detailed product information, please visit our website: http://www.asrockrack.com/
