ASROCK EP2C612D16-4L Bedienungsanleitung

Version 1.1

Published September 2014

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Rack Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished

for informational use only and subject to change without notice, and should not

be constructed as a commitment by ASRock Rack. ASRock Rack assumes no

responsibility for any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock Rack does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock Rack, its directors, ocers, employees, or agents be liable

for any indirect, special, incidental, or consequential damages (including damages

for loss of prots, loss of business, loss of data, interruption of business and the

like), even if ASRock Rack has been advised of the possibility of such damages

arising from any defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Rack’s Website: www.ASRockRack.com

Contact Information

If you need to contact ASRock Rack or want to know more about ASRock Rack,

you’re welcome to visit ASRock Rack’s website at www.ASRockRack.com; or you

may contact your dealer for further information.

ASRock Rack Incorporation

6F., No.37, Sec. 2, Jhongyang S. Rd., Beitou District,

Taipei City 112, Taiwan (R.O.C.)

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Unique Features 6

1.4 Motherboard Layout 7

1.5 Onboard LED Indicators 10

1.6 I/O Panel 12

1.7 Block Diagram 15

Chapter 2 Installation 17

2.1 Screw Holes 17

2.2 Pre-installation Precautions 18

2.3 Installing the CPU 19

2.4 Installing the CPU Fan and Heatsink 22

2.5 Installation of Memory Modules (DIMM) 23

2.6 Expansion Slots (PCI and PCI Express Slots) 26

2.7 Jumper Setup 27

2.8 Onboard Headers and Connectors 30

2.9 Driver Installation Guide 37

2.10 Dual LAN and Teaming Operation Guide 38

Chapter 3 UEFI Setup Utility 39

3.1 Introduction 39

3.1.1 UEFI Menu Bar 39

3.1.2 Navigation Keys 40

3.2 Main Screen 41

3.3 Advanced Screen 42

3.3.1 ACPI Conguration 43

3.3.2 Congure Super IO Settings 44

3.3.3 Serial Port Console Redirection 45

3.3.4 CSM Parameters 48

3.3.5 USB Conguration 49

3.3.6 System Conguration 50

3.3.7 Hard Disk S.M.A.R.T Settings 52

3.3.7 3rd Storage Conguration 53

3.3.8 H/W Monitor 54

3.3.9 Intel® Thunderbolt 56

3.3.10 Easy RAID Installer 57

3.3.11 Instant Flash 58

3.4 IntelRCSetup 59

3.4.1 Processor Conguration 60

3.4.2 CPU Power Management Conguration 62

3.4.3 QPI Conguration 64

3.4.4 Memory Conguration 65

3.4.5 IIO Conguration 66

3.4.6 PCH Conguration 68

3.4.7 Server ME Conguration 70

3.5 Server Mgmt 71

3.6 Security 73

3.7 Boot Screen 74

3.8 Event Logs 76

3.9 Exit Screen 78

Chapter 4 Software Support 79

4.1 Install Operating System 79

4.2 Support CD Information 79

4.2.1 Running The Support CD 79

4.2.2 Drivers Menu 79

4.2.3 Utilities Menu 79

4.2.4 Contact Information 79

Chapter 5 Troubleshooting 80

5.1 Troubleshooting Procedures 80

5.2 Technical Support Procedures 82

5.3 Returning Merchandise for Service 82

Chapter 6: Net Framework Installation Guide 83

6.1 Installing .Net Framework 3.5.1 (For Server 2008 R2) 83

EP2C612D16-4L / EP2C612D16-2L2T

English

Chapter 1 Introduction

ank you for purchasing ASRock Rack EP2C612D16-4L / EP2C612D16-2L2T

motherboard, a reliable motherboard produced under ASRock Rack’s consistently

stringent quality control. It delivers excellent performance with robust design

conforming to ASRock Rack’s commitment to quality and endurance.

In this manual, chapter 1 and 2 contains introduction of the motherboard and step-

by-step guide to the hardware installation. Chapter 3 and 4 contains the conguration

guide to BIOS setup and information of the Support CD.

1.1 Package Contents

•ASRock Rack EP2C612D16-4L / EP2C612D16-2L2T Motherboard

(SSI EEB Form Factor: 12.0-in x 13.0-in, 30.5 cm x 33.0 cm)

•4 x SATA3 Cables (50cm)

•2 x SATA3 Cables (60cm)

•1 x I/O Shield

•Support CD

•User Manual

If any items are missing or appear damaged, contact your authorized dealer.

Because the motherboard specications and the BIOS soware might be updated, the con-

tent of this manual will be subject to change without notice. In case any modications of

this manual occur, the updated version will be available on ASRock Rack website without

further notice. You may nd the latest memory and CPU support lists on ASRock Rack

website as well. ASRock Rack’s Website: www.ASRockRack.com

If you require technical support related to this motherboard, please visit our website for

specic information about the model you are using.

http://www.asrockrack.com/support/

English

1.2 Specications

EP2C612D16-4L / EP2C612D16-2L2T

MB Physical Status

Form Factor SSI EEB

Dimension 12'' x 13'' (30.5 cm x 33.0 cm)

Processor System

CPU Intel® Xeon processor E5-2600/4600 v3 series

Socket Dual Socket LGA 2011 R3

Chipset Intel® C612

System Memory

Capacity 16 DIMM slots

Type - Quad Channel DDR4 memory technology

- Supports 2133/1866/1600 ECC DIMM,RDIMM,NVDIMM

and LRDIMM

Voltage 1.2V

Expansion Slot (Slot 6 is the closest to the CPU)

Slot 1 x8 (x8/x8 with Slot 2, CPU2)

Slot 2 x16 (CPU2)

Slot 3 x8 (x8/x8 with Slot 4)

Only PCIE 3 slot supports the underbolt Add-in Card.

e underbolt Add-in Card is only supported on Windows 8 / 7.

Slot 4 x16

Slot 5 x8 (CPU2)

Slot 6 x16

Storage

SATA

Controller

Intel® C612 : 10 x SATA3 6.0 Gb/s

Additional

SATA

Controller

Marvell 9172: 2 x SATA3 6Gb/s

EP2C612D16-4L / EP2C612D16-2L2T

English

Ethernet

Interface EP2C612D16-2L2T:

10G by Intel X540 ; 1000 /100 /10 Mbps by Intel i210

EP2C612D16-4L:

1000 /100 /10 Mbps by Intel i350 / Intel i210

LAN EP2C612D16-2L2T:

2 x RJ45 GLAN by Intel® i210

2 x RJ45 10G base-T by Intel® X540*

1 x RJ45 Dedicated IPMI LAN port

- Supports Wake-On-LAN

- Supports Energy Ecient Ethernet 802.3az

- Supports Quad LAN with Teaming function

- Supports PXE

- LAN1 supports NCSI

EP2C612D16-4L:

2 x RJ45 GLAN by Intel® i210

2 x RJ45 GLAN by Intel® i350

1 x RJ45 Dedicated IPMI LAN port

- Supports Wake-On-LAN

- Supports Energy Ecient Ethernet 802.3az

- Supports Dual LAN with Teaming function

- Supports PXE

- LAN1 supports NCSI

Management

BMC Controller ASPEED AST2400

IPMI Dedicated

GLAN

- 1 x Realtek RTL8211E for dedicated management GLAN

Features - Watch Dog

- NMI

Graphics

Controller ASPEED AST2400

VRAM DDR3 16MB

Rear Panel I/O

VGA Port 1 x D-Sub

USB 3.0 Port 2

Lan Port - 4 + 1 (IPMI) Lan port (RJ45)

- LAN Ports with LED (ACT/LINK LED and SPEED LED)

Serial Port 1 (COM1)

English

Internal Connector

Auxiliary Panel

Header

1 (includes chassis intrusion, location button & LED, front

LAN LED)

TPM Header 1

IPMB Header 1

Fan Header 2x CPU Fan, 6x system Fan (4-pin)

ATX Power 1 (24-pin) + 2 (8-pin)

USB 3.0 Header 1 ( support 2 USB 3.0)

USB 2.0 Header 1 ( support 2 USB 2.0)

Type A USB 3.0

Port

underbolt

AIC Connector

System BIOS

BIOS Ty pe 128Mb AMI UEFI Legal BIOS

BIOS Features - Plug and Play (PnP)

- ACPI 2.0 Compliance Wake Up Events

- SMBIOS 2.8 Support

- ASRock Rack Instant Flash

Hardware Monitor

Temperature - CPU Temperature Sensing

- System Temperature Sensing

- Card Side Temperature Sensing

Fan - CPU/Rear/Front Fan Tachometer

- CPU Quiet Fan (Allow CPU Fan Speed Auto-Adjust by CPU

Temperature)

- CPU/Rear/Front Fan Multi-Speed Control

Voltage Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM,

1.05V_PCH, +BAT, 3VSB, 5VSB
