ASROCK J1900D2Y Bedienungsanleitung

Version 1.1

Published January 2015

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Rack Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished

for informational use only and subject to change without notice, and should not

be constructed as a commitment by ASRock Rack. ASRock Rack assumes no

responsibility for any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock Rack does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock Rack, its directors, ocers, employees, or agents be liable

for any indirect, special, incidental, or consequential damages (including damages

for loss of prots, loss of business, loss of data, interruption of business and the

like), even if ASRock Rack has been advised of the possibility of such damages

arising from any defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Rack’s Website: www.ASRockRack.com

Contact Information

If you need to contact ASRock Rack or want to know more about ASRock Rack,

you’re welcome to visit ASRock Rack’s website at www.ASRockRack.com; or you

may contact your dealer for further information.

ASRock Rack Incorporation

6F., No.37, Sec. 2, Jhongyang S. Rd., Beitou District,

Taipei City 112, Taiwan (R.O.C.)

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Unique Features 5

1.4 Motherboard Layout 6

1.5 Onboard LED Indicators 9

1.6 I/O Panel 11

1.7 Block Diagram 13

Chapter 2 Installation 14

2.1 Screw Holes 14

2.2 Pre-installation Precautions 14

2.3 Installation of Memory Modules (SO-DIMM) 15

2.4 Expansion Slots (PCI Express Slots) 16

2.5 Jumper Setup 17

2.6 Onboard Headers and Connectors 19

2.7 Dr. Debug 25

2.8 Driver Installation Guide 26

2.9 Dual LAN and Teaming Operation Guide 27

Chapter 3 UEFI Setup Utility 28

3.1 Introduction 28

3.1.1 UEFI Menu Bar 28

3.1.2 Navigation Keys 29

3.2 Main Screen 30

3.3 Advanced Screen 31

3.3.1 CPU Conguration 32

3.3.2 DRAM Conguration 34

3.3.3 ACPI Conguration 35

3.3.4 Congure Super IO Settings 36

3.3.5 Serial Port Console Redirection 37

3.3.6 CSM Parameters 40

3.3.7 USB Conguration 41

3.3.8 Chipset Conguration 42

3.3.9 Storage Conguration 44

3.3.10 H/W Monitor 46

3.3.11 Instant Flash 48

3.4 Server Mgmt 49

3.5 Security 51

3.6 Boot Screen 52

3.7 Event Logs 54

3.8 Exit Screen 56

Chapter 4 Software Support 57

4.1 Install Operating System 57

4.2 Support CD Information 57

4.2.1 Running The Support CD 57

4.2.2 Drivers Menu 57

4.2.3 Utilities Menu 57

4.2.4 Contact Information 57

Chapter 5 Troubleshooting 58

5.1 Troubleshooting Procedures 58

5.2 Technical Support Procedures 60

5.3 Returning Merchandise for Service 60

Chapter 6: Net Framework Installation Guide 61

6.1 Installing .Net Framework 3.5.1 (For Server 2008 R2) 61

J1900D2Y

English

Chapter 1 Introduction

ank you for purchasing ASRock Rack J1900D2Y motherboard, a reliable

motherboard produced under ASRock Rack’s consistently stringent quality control.

It delivers excellent performance with robust design conforming to ASRock Rack’s

commitment to quality and endurance.

In this manual, chapter 1 and 2 contains introduction of the motherboard and step-

by-step guide to the hardware installation. Chapter 3 and 4 contains the conguration

guide to BIOS setup and information of the Support CD.

1.1 Package Contents

•ASRock Rack J1900D2Y Motherboard

(mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm)

•Support CD

•User Manual

•2 x SATA3 Cables (50cm)

•1 x SATA HDD Power Cable

•1 x I/O Shield

If any items are missing or appear damaged, contact your authorized dealer.

Because the motherboard specications and the BIOS soware might be updated, the con-

tent of this manual will be subject to change without notice. In case any modications of

this manual occur, the updated version will be available on ASRock Rack website without

further notice. You may nd the latest memory and CPU support lists on ASRock Rack

website as well. ASRock Rack’s Website: www.ASRockRack.com

If you require technical support related to this motherboard, please visit our website for

specic information about the model you are using.

http://www.asrockrack.com/support/

English

1.2 Specications

J1900D2Y

MB Physical Status

Form Factor mini-ITX

Dimension 6.7'' x 6.7'' (17.0 cm x 17.0 cm)

Processor System

CPU Supports Intel® Quad-Core Processor J1900(2 GHz)

Chipset Soc

System Memory

Capacity 2 x DDR3/DDR3L SO-DIMM slots

Type - Dual Channel DDR3/DDR3L memory technology

- Supports DDR3/DDR3L 1333/1066 non-ECC, un-buered

memory Max. capacity of system memory: 16GB

Voltage 1.35V /1.5V

Expansion Slot

Slot 1 x1 (PCIe 2.0)

Storage

SATA

Controller

J1900: 2x SATA2 3Gb/s

Ethernet

Interface 1000 /100 /10 Mbps

LAN 2 x RJ45 by Intel® i210

1 x RJ45 Dedicated IPMI LAN port

- Supports Wake-On-LAN

- Supports Energy Ecient Ethernet 802.3az

- Supports Dual LAN with Teaming function

- Supports PXE

Management

BMC Controller ASPEED AST2300

IPMI Dedicated

GLAN

-1 x Realtek RTL8211E for dedicated management GLAN

Features - Watch Dog

- NMI

Graphics

Controller ASPEED AST2300

VRAM DDR3 16MB

Output Supports D-Sub with max. resolution up to 1920x1200 @60Hz

Rear Panel I/O

VGA Port 1 x D-Sub

USB 2.0 Port 1

USB 3.0 Port 1

J1900D2Y

English

LAN Port RJ45: 2 + 1 (IPMI)

LAN Ports with LED (ACT/LINK LED and SPEED LED)

HDMI 1

UID Buttom/

LED

DC IN 1 x DC Jack

Internal Connector

Auxiliary Panel

Header

1 (include chassis intrusion , location button & LED, front LAN

LED)

TPM Header 1

IPMB Header 1

Buzzer 1

Fan Header 4 x 4-pin

ATX Power 1 (24-pin)

Type A USB 2.0

Port

PSU SMB

Header

Speaker Header 1

System BIOS

BIOS Ty pe 64Mb AMI UEFI Legal BIOS

BIOS Features - Plug and Play (PnP)

- ACPI 2.0 Compliance Wake Up Events

- SMBIOS 2.8.0 Support

- ASRock Rack Instant Flash

Hardware Monitor

Temperature - CPU Temperature Sensing

- System Temperature Sensing

- System Inlet Temperature Sensing

- Card Side Temperature Sensing

Fan - CPU/Rear/Front Fan Tachometer

- CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by

CPU Temperature)

- CPU/Rear/Front Fan Multi-Speed Control

Voltage Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM,

1.05V_PCH, +BAT, 3VSB, 5VSB

English

Support OS

OS Microso® Windows®

- Server 2008 R2 SP1 (64 bit)

- Server 2012 (64 bit)

- Server 2012 R2 (64 bit)

Linux®

- RedHat Enterprise Linux Server 6.5 (32 / 64 bit)

(SATA AHCI mode)

- CentOS 6.5 (32 / 64 bit) (SATA AHCI mode)

- Fedora core 19 (32 / 64 bit) (SATA AHCI mode)

- FreeBSD 9.2 (32 / 64 bit) (SATA AHCI mode)

Environment

Temperature Operation temperature: 10°C ~ 35°C / Non operation

temperature: -40°C ~ 70°C

is motherboard supports Wake from on Board LAN. To use this function, please make

sure that the “Wake on Magic Packet from power o state” is enabled in Device Manager

> Intel® Ethernet Connection > Power Management. And the “PCI Devices Power On” is

enabled in UEFI SETUP UTILITY > Advanced > ACPI Conguration. Aer that, onboard

LAN1&2 can wake up S5 under OS.

If you install Intel® LAN utility or Marvell SATA utility, this motherboard may fail Win-

dows® Hardware Quality Lab (WHQL) certication tests. If you install the drivers only, it

will pass the WHQL tests.
