ASROCK Z87E-ITX Bedienungsanleitung

User Manual

Version 1.0

Published April 2013

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,487,535;

7,003,467 & other U.S. and worldwide patents issued & pending. DTS, the Symbol, &

DTS and the Symbol together is a registered trademark & DTS Connect, DTS Interactive,

DTS Neo:PC are trademarks of DTS, Inc. Product includes soware.

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Unique Features 7

1.4 Motherboard Layout 11

1.5 I/O Panel 14

1.6 WiFi-802.11n Module and ASRock WiFi 2.4GHz Antenna 16

Chapter 2 Installation 17

2.1 Installing the CPU 18

2.2 Installing the CPU Fan and Heatsink 21

2.3 Installing Memory Modules (DIMM) 22

2.4 Expansion Slots (PCI and PCI Express Slots) 24

2.5 Jumpers Setup 25

2.6 Onboard Headers and Connectors 26

Chapter 3 Software and Utilities Operation 30

3.1 Installing Drivers 30

3.2 A-Tuning 31

3.3 Intel® Rapid Start Technology 35

3.4 Intel® Smart Connect Technology 40

3.5 Intel® Remote Wake Technology 45

3.5.1 Conguring and Using MeshCentral 45

3.5.2 Conguring and Using Splashtop 50

3.6 Intel® Extreme Tuning Utility (IXTU) 53

3.7 Start8 55

Chapter 4 UEFI SETUP UTILITY 58

4.1 Introduction 58

4.1.1 UEFI Menu Bar 58

4.1.2 Navigation Keys 59

4.2 Main Screen 60

4.3 OC Tweaker Screen 61

4.4 Advanced Screen 70

4.4.1 CPU Conguration 71

4.4.2 Chipset Conguration 73

4.4.3 Storage Conguration 75

4.4.4 Intel® Rapid Start Technology 77

4.4.5 Intel® Smart Connect Technology 78

4.4.6 ACPI Conguration 79

4.4.7 USB Conguration 81

4.4.8 Trusted Computing 82

4.5 Tools 83

4.6 Hardware Health Event Monitoring Screen 86

4.7 Boot Screen 87

4.8 Security Screen 90

4.9 Exit Screen 91

Z87E-ITX

PB 1

English

Chapter 1 Introduction

ank you for purchasing ASRock Z87E-ITX motherboard, a reliable motherboard

produced under ASRock’s consistently stringent quality control. It delivers excellent

performance with robust design conforming to ASRock’s commitment to quality

and endurance.

In this manual, Chapter 1 and 2 contains the introduction of the motherboard

and step-by-step installation guides. Chapter 3 contains the operation guide of the

soware and utilities. Chapter 4 contains the conguration guide of the BIOS setup.

1.1 Package Contents

• ASRock Z87E-ITX Motherboard (Mini-ITX Form Factor)

• ASRock Z87E-ITX Quick Installation Guide

• ASRock Z87E-ITX Support CD

• 4 x Serial ATA (SATA) Data Cables (Optional)

• 1 x I/O Panel Shield

• 1 x ASRock WiFi 2.4/5GHz Antenna

• 1 x DVI-to-D-Sub Converter

Because the motherboard specications and the BIOS soware might be updated, the

content of this documentation will be subject to change without notice. In case any modi-

cations of this manual occur, the updated version will be available on ASRock’s website

without further notice. If you require technical support related to this motherboard, please

visit our website for specic information about the model you are using. You may nd the

latest VGA cards and CPU support list on ASRock’s website as well. ASRock website http://

www.asrock.com.

2 3

English

1.2 Specications

Platform • Mini-ITX Form Factor

• Premium Gold Capacitor design (100% Japan-made high-

quality Conductive Polymer Capacitors)

A-Style • Home Cloud

• WiFi 802.11ac

CPU • Supports 4th Generation Intel® CoreTM i7 / i5 / i3 / Xeon® /

Pentium® / Celeron® in LGA1150 Package

• Digi Power Design

• 6 Power Phase Design

• DrMOS

• Supports Intel®Turbo Boost 2.0 Technology

• Supports Intel®K-Series unlocked CPU

• Supports ASRock BCLK Full-range Overclocking

Chipset • Intel®Z87

Memory • Dual Channel DDR3 Memory Technology

• 2 x DDR3 DIMM slots

• Supports DDR3 2933+(OC)/2800(OC)/2400(OC)/2133(OC)/

1866(OC)/1600/1333/1066 non-ECC, un-buered memory

• Max. capacity of system memory: 16GB

(see CAUTION)

• Supports Intel®Extreme Memory Prole (XMP)1.3/1.2

Expansion

Slot

• 1 x PCI Express 3.0 x16 slot

• 1 x half mini-PCI Express slot: For WiFi + BT module

• 1 x mSATA/full mini-PCI Express slot

Z87E-ITX

2 3

English

Graphics • Intel® HD Graphics Built-in Visuals and the VGA outputs can

be supported only with processors which are GPU integrated.

• Supports Intel® HD Graphics Built-in Visuals : Intel® Quick

Sync Video with AVC, MVC (S3D) and MPEG-2 Full

HW Encode1, Intel® InTruTM 3D, Intel® Clear Video HD

Technology, Intel® InsiderTM, Intel® HD Graphics 4400/4600

• Pixel Shader 5.0, DirectX 11.1

• Max. shared memory 1792MB

• ree VGA Output options: DVI-I, HDMI and DisplayPort

• Supports Triple Monitors

• Supports HDMI Technology with max. resolution up to 4K ×

2K (4096x2304) @ 24Hz

• Supports DVI-I with max. resolution up to 1920x1200 @

60Hz

• Supports DisplayPort with max. resolution up to 4K × 2K

(4096x2304) @ 24Hz

• Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

HBR (High Bit Rate Audio) with HDMI (Compliant HDMI

monitor is required)

• Supports HDCP function with DVI-I, HDMI and DisplayPort

ports

• Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback

with DVI-I, HDMI and DisplayPort ports

Audio • 7.1 CH HD Audio with Content Protection (Realtek ALC1150

Audio Codec)

• Premium Blu-ray audio support

• TI® NE5532 Premium Headset Amplier (supports up to 600

Ohms headsets)

• Supports DTS Connect

4 5

English

LAN • Gigabit LAN 10/100/1000 Mb/s

• Giga PHY Intel® I217V

• Supports Intel® Remote Wake Technology

• Supports Wake-On-LAN

• Supports Energy Ecient Ethernet 802.3az

• Supports PXE

Wireless

LAN

• Supports IEEE 802.11a/b/g/n/ac

• Supports Dual-Band (2.4/5 GHz)

• Supports High speed wireless connection up to 867Mbps

• 2 antennas to support 2 (Transmit) x 2 (Receive) diversity

technology

• Supports Bluetooth 4.0 / 3.0 + High speed class II

Rear Panel

I/O

• 1 x PS/2 Mouse/Keyboard Port

• 1 x DVI-I Port

• 1 x HDMI Port

• 1 x DisplayPort

• 1 x Optical SPDIF Out Port

• 1 x eSATA Connector

• 2 x USB 2.0 Ports

• 4 x USB 3.0 Ports

• 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

• 1 x Clear CMOS Switch

• HD Audio Jack: Rear Speaker / Central / Bass / Line in / Front

Speaker / Microphone

Z87E-ITX

4 5

English

Storage • 6 x SATA3 6.0 Gb/s connectors, support RAID (RAID 0,

RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology

12 and Intel Smart Response Technology), NCQ, AHCI and

“Hot Plug” (SATA3_5 connector is shared with the eSATA

port; SATA3_4 connector is shared with the mSATA/mini-

PCI Express slot)

• 1 x eSATA connector, supports NCQ, AHCI and “Hot Plug”

functions

• 1 x mSATA 6.0 Gb/s connector (Solid-State Drive

connector), supports NCQ, AHCI functions and Full-size

mini-PCI Express modules

Connector • 1 x Chassis Intrusion header

• 1 x TPM header

• 1 x CPU Fan connector (4-pin)

• 1 x Chassis Fan connector (4-pin)

• 1 x 24 pin ATX power connector

• 1 x 8 pin 12V power connector (High Density Power

Connector)

• 1 x Front panel audio connector

• 2 x USB 2.0 headers (support 4 USB 2.0 ports)

• 1 x USB 3.0 header (supports 2 USB 3.0 ports)

BIOS

Feature

• 64Mb AMI UEFI Legal BIOS with Multilingual GUI support

• ACPI 1.1 Compliance Wake Up Events

• SMBIOS 2.3.1 Support

• CPU, DRAM, PCH 1.05V, PCH 1.5V Voltage Multi-adjust-

ment

Support

• Drivers, Utilities, AntiVirus Soware (Trial Version), Cyber-

Link MediaEspresso 6.5 Trial, Google Chrome Browser and

Toolbar, Start8, MeshCentral, Splashtop Streamer, Intel®

• Extreme Tuning Utility (IXTU)

Hardware

Monitor

• CPU/Chassis Temperature Sensing

• CPU/Chassis Tachometer

• CPU/Chassis Quiet Fan (Allow Chassis Fan Speed Auto-

Adjust by CPU Temperature)

• CPU/Chassis Fan Multi-Speed Control

• Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore

Andere Handbücher für Z87E-ITX

Inhaltsverzeichnis

Andere ASROCK Hauptplatine Handbücher

ASROCK

ASROCK T48EM1 Bedienungsanleitung

ASROCK

ASROCK B650M-H/M.2+ Bedienungsanleitung

ASROCK

ASROCK 870iCafe Bedienungsanleitung

ASROCK

ASROCK X370 Pro4 Bedienungsanleitung

ASROCK

ASROCK P43DE2 Bedienungsanleitung

ASROCK

ASROCK B560 Steel Legend Bedienungsanleitung

ASROCK

ASROCK H81 Pro-G Bedienungsanleitung

ASROCK

ASROCK H81M-ITX Bedienungsanleitung

ASROCK

ASROCK H61M-U3S3 Bedienungsanleitung

ASROCK

ASROCK M3A785GXH 128M - V1.0 Bedienungsanleitung

ASROCK

ASROCK K10N78FULLHD-HSLI - R2.0 Bedienungsanleitung

ASROCK

ASROCK Q1900M Pro3 Bedienungsanleitung

ASROCK

ASROCK G31DE-DVR Bedienungsanleitung

ASROCK

ASROCK Fatal1ty Z97 Bedienungsanleitung

ASROCK

ASROCK X399D8A-2T Bedienungsanleitung

ASROCK

ASROCK H570 Steel Legend Bedienungsanleitung

ASROCK

ASROCK 939NF4G-VSTA Bedienungsanleitung

ASROCK

ASROCK 939A785GMH/128M Bedienungsanleitung

ASROCK

ASROCK IMB-380-D Bedienungsanleitung

ASROCK

ASROCK N3150B-ITX Bedienungsanleitung

ASROCK

ASROCK Z87iCafe4 Bedienungsanleitung

ASROCK

ASROCK 4CORE1600TWINS-P35D - V1.0 Bedienungsanleitung

ASROCK

ASROCK D1541D4U Series Bedienungsanleitung

ASROCK

ASROCK A620M-HDV/M.2+ Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Bedienungsanleitung
