Asus DSL-AC68R Bedienungsanleitung

Quick Start Guide

DSL-AC68R

Dual-band 802.11ac Wi-Fi ADSL/VDSL

Modem Router

E9300 / First Edition / April 2014

e9300_dsl-ac68r.indd 1 2014/4/3 13:39:00

e9300_dsl-ac68r.indd 2 2014/4/3 13:39:01

Hardware Features

1. LAN 1~4 LED

2. DSL LED

3. Internet LED

4. USB 3.0 LED

5. 2.4 GHz LED

6. 5 GHz LED

7. Power LED

8. WPS button

9. Wi-Fi on/oﬀ button

1456

e9300_dsl-ac68r.indd 3 2014/4/3 13:39:01

English

10. Reset button

11. Power button

12. DC-IN jack

13. RJ-11 port

14. USB 3.0 port

15. LAN 1~4 ports

13 14 15

e9300_dsl-ac68r.indd 4 2014/4/3 13:39:01

English

• USB External HDD/Flash disk:

• ThiswirelessrouterworkswithmostUSBHDDs/Flashdisksup

to2TBandsupportsread-writeaccessforFAT16,FAT32,EXT2,

EXT3,andNTFS.

• TosafelyremovetheUSBdisk,launchthewebGUI

(http://192.168.1.1 or http://router.asus.com),clicktheUSB

iconontheNetworkMappageandclickEject USB disk.

• IncorrectremovaloftheUSBdisk,suchasduringvideo/music

streamingorfiledownloading,maycausedatacorruption.

• Forthelistoffilesystemandharddiskpartitionsthatthis

wirelessroutersupports,visit:

http://event.asus.com/networks/disksupport

• Forthelistofprintersthatthewirelessroutersupports,visit:

http://event.asus.com/2009/networks/printersupport

Package contents

Ifanyoftheitemsisdamagedormissing,contactyour

retailer.

 DSL-AC68Rwirelessmodemrouter

Network cable (RJ-45)

AC adapter

 Phonecable(RJ-11)

 Warrantycard

Quick Start Guide

 SupportCD(UserManual/utilities)

 Splitter(varieswithregions)

e9300_dsl-ac68r.indd 5 2014/4/3 13:39:01

English

Positioning your wireless router

Forthebestwirelesssignaltransmissionbetweenthewirelessrouter

andthenetworkdevicesconnectedtoit,ensurethatyou:

• Placethewirelessrouteratthecenterofyournetworkformaximum

wirelesscoverage.

• Keepthedeviceawayfrommetalobstructionsandawayfromdirect

sunlight.

• Keepthedeviceawayfrom802.11gor20MHzonlyWi-Fidevices,

2.4GHzcomputerperipherals,Bluetoothdevices,cordlessphones,

transformers,heavy-dutymotors,uorescentlights,microwave

ovens,refrigerators,andotherindustrialequipmenttoprevent

signalinterferenceorloss.

• Toensurethebestwirelesssignal,orientthethreedetachable

antennasasshowninthedrawingbelow.

• Alwaysupdatetothelatestrmware.VisittheASUSwebsiteat

http://www.asus.comtogetthelatestrmwareupdates.

90°

45°45°

e9300_dsl-ac68r.indd 6 2014/4/3 13:39:01

Before you proceed

1. Connectyourdevices.

2. Beforesettingupyournetwork,ensurethattheDSLLED

indicatorisasolidlight.

Wall Power Outlet

Power

Wall telephone

outlet

Computer

LAN

English

e9300_dsl-ac68r.indd 7 2014/4/3 13:39:01

English

3. LaunchawebbrowserandfollowtheQuickInternetSetup

(QIS) steps.

IftheQISwebpagedoesnotappearafteryoulaunched

thewebbrowser,disabletheproxysettingsontheweb

browser.

4. Setupcomplete.

e9300_dsl-ac68r.indd 8 2014/4/3 13:39:01

ASUS Recycling/Takeback Services

ASUSrecyclingandtakebackprogramscomefromourcommitment

tothehigheststandardsforprotectingourenvironment.Webelieve

inprovidingsolutionsforyoutobeabletoresponsiblyrecycleour

products,batteries,othercomponents,aswellasthepackaging

materials.Pleasegotohttp://csr.asus.com/english/Takeback.htmfor

thedetailedrecyclinginformationindierentregions.

REACH

ComplyingwiththeREACH(Registration,Evaluation,Authorisation,

andRestrictionofChemicals)regulatoryframework,wepublished

thechemicalsubstancesinourproductsatASUSREACHwebsiteat

http://csr.asus.com/english/REACH.htm

Prohibition of Co-location

Thisdeviceanditsantenna(s)mustnotbeco-locatedoroperatingin

conjunctionwithanyotherantennaortransmitter.

IMPORTANT NOTE:

Radiation Exposure Statement:Thisequipmentcomplieswith

FCCradiationexposurelimitssetforthforanuncontrolledenviron-

ment.Endusersmustfollowthespecicoperatinginstructionsfor

satisfyingRFexposurecompliance.TomaintaincompliancewithFCC

exposurecompliancerequirement,pleasefollowoperationinstruc-

tionasdocumentedinthismanual.

Declaration of Conformity for R&TTE directive 1999/5/

Essentialrequirements–Article3

Protectionrequirementsforhealthandsafety–Article3.1a

TestingforelectricsafetyaccordingtoEN60950-1hasbeencon-

ducted.Theseareconsideredrelevantandsucient.

Protectionrequirementsforelectromagneticcompatibility–Article

3.1b

TestingforelectromagneticcompatibilityaccordingtoEN301489-1

andEN301489-17hasbeenconducted.Theseareconsideredrel-

evantandsucient.

e9300_dsl-ac68r.indd 9 2014/4/3 13:39:02

Eectiveuseoftheradiospectrum–Article3.2

TestingforradiotestsuitesaccordingtoEN300328-2hasbeen

conducted.Theseareconsideredrelevantandsucient.

CE Mark Warning

ThisisaClassBproduct,inadomesticenvironment,thisproduct

maycauseradiointerference,inwhichcasetheusermayberequired

totakeadequatemeasures.OperationChannels:CH1~11forN.

America;Ch1~14forJapan;CH1~13forEurope(ETSI)
