Atlantis Land A02-UP-W108 Bedienungsanleitung

NetFly U-108

Wireless 108Mbps USB Adapter

A02-UP-W108

Quick Start Guide

A02-UP-W108_GE01

Company certified ISO 9001:2000

Wireless 108Mbps USB Adapter

ENGLISH

This product is covered by Atlantis Land 3 years Fast-Swap

warranty. For more detailed informations please refer to the

web site www.atlantis-land.com.

For more detailed instructions on configuring and using the

Switch , please refer to the online manual.

ITALIANO

Questo prodotto è coperto da garanzia Atlantis Land

Fast-Swap della durata di 3 anni. Per maggiori dettagli in

merito o per accedere alla documentazione completa in

Italiano fare riferimento al CDRom o al sito

www.atlantis-land.com.

FRANCAIS

Ce produit est couvert par une garantie Atlantis Land

Fast-Swap de 3 ans. Pour des informations plus détaillées,

référez-vous svp au site Web www.atlantis-land.com.

Le manuel complet en Francais est disponible dans le

CDRom ou sur le WEB.

DEUTSCH

Dieses Produkt ist durch die Atlantis Land 3 Jahre

Fast-Swap Garantie gedeckt. Für weitere Informationen,

beziehen Sie sich bitte auf Web Site

www.atlantis-land.com.

ESPAÑOL

Este producto està cubierto de garantía Atlantis Land

Fast-Swap por 3 años. Para una información más

detallada, se refiera por favor al Web site

www.atlantis-land.com.

Wireless 108Mbps USB Adapter

-l

Registration on the web site www.atlantis-

land.com within 15 days from the purchase of

the product dismiss the customer from showing a

valid proof of purchase (Sale Receipt or Invoice)

in case of the request of intervention. For further

information we invite you to look at our web site

at the section WARRANTY.

Wireless 108Mbps USB Adapter

Thank you for purchasing the IEEE 802.11g Wireless

108Mbps USB Adapter that provides the easiest way to

wireless networking. For more detailed instructions on

configuring and using the Wireless 108Mbps USB

Adapter, please refer to the online manual.

1.1 System Requirements

Before installing the Adapter, your PC should meet the

following:

•Desktop PC with available USB V2.0 or V1.1*

•Intel® Pentium®III 600Mhz or compatible

processor with 128MB RAM

•Windows 2000/XP operating system

•Minimum 15 Mbytes free disk space for installing

the driver and utilities

•CDRom drive

*When plug the device in the USB 1.1/1.0 port, the real

throughput will be up to 6Mbps only when running 11Mbps

or higher speed

1.2 Package Contents

Unpack the package and check all the items carefully. If any

item contained is damaged or missing, please contact your

local dealer as soon as possible. Also, keep the box and

packing materials in case you need to ship the unit in the

future. The package should contain the following items:

•One IEEE802.11g Wireless 108Mbps USB

Adapter.

•One A-type USB male to female extension cable

•One Quick Start Guide

•One CD with driver/utilities and user’s manual

Wireless 108Mbps USB Adapter

1.3. Utility Installation

This section describes the procedures of installing the driver

and utility. Before insert USB Dongle into the PC USB of

your computer, please install the Utility Program first.

Make sure that the 108Mbps Wireless Network USB Dongle

is NOT inserted into the USB slot.

Go to your Windows Start menu and choose Run, type

“CDRom:\Setup.exe” in the dialog box and click OK.

Follow the instruction step by step to finish the installation.

The USB extension cable that comes with the Adapter has

Type A connectors on both ends. One is a male Type A

connector that plugs into the PC’s USB port, and the other

is a female Type A connector that plugs into the Adapter.

This USB extension cable have a special function, it can be

twist to any direction to have the best connection in the air.

It is recommended that the Pen Size Wireless USB Adapter

was vertically plane with the ground.

Wireless 108Mbps USB Adapter

After restarting the computer, insert the USB dongle into

USB port. Few seconds later, there will be a window popup.

1.3.1 Installing on Windows XP

•After the opening banner, Windows will tell you

that the new device has been detected. Click

“Next >”.

•Select “Install the software automatically

(recommended)” then click “Next>”. In next

window, click “Continue Anyway” then click

“Finish”.

Wireless 108Mbps USB Adapter

•After installing the driver of USB, there will be

another pop-up window to guide you to keep

installing the driver of USB Dongle.

•Click “Next >”. Select “Install the software

automatically (recommended)” then click

“Next>”. In next window, click “Continue

Anyway” then click “Finish”.

•To make sure if the installation is successful,

you could check it through the device

management.

1.4 Utility

Once the installation is successful, a utility program icon will

show on your desktop (108Mbps Wireless Network USB

Dongle Configuration Utility). To lunch the utility, just double

click the icon.

In the Configuration Utility, select “Site Survey” tab, and

click “Refresh” button to search the available wireless

network(s). Select the network you want.

1. If you have not enabled wireless encryption on

your network, then just click “Connect” button to

activate wireless connection immediately.

2. If the wireless encryption is enabled click

“Connect” button then choose encryption and

put correct password on the next page, then

click on Apply.

3. If doesn’t show any available wireless network,

click “Add” button to setup encryption and SSID.

Where solutions begin

Atlantis Land S.p.A.

Viale De Gasperi, 122

Mazzo di Rho – MI – Italy

[email protected]

sales@atlantis-land.com

www.atlantis-land.com
