Atlona AT-COMP300SL Bedienungsanleitung

AtlonA

Component Video & Analog /

Digital Audio CAT5 Extender

With Chainable Output

MODELS:

AT-COMP300SL, AT-COMP300RL

User Manual

TABLE OF CONTENTS

1. Introduction .................................................. 1

2. Installation .................................................. 2

3. Specications .................................................. 4

4. Installation Tips .................................................. 5

5. Safety Informations .................................................. 6

6. Warranty .................................................. 7

Introduction

This Extension system is designed for Component Video +Stereo Audio, Digital Audio signal

over cost effective CAT5 cable instead of Component Video and Audio cable. AT-COMP300RL

receiver has a built in chainable output to cascade the other receiver for working range over 1000ft

(300 meters). It is the optimum video performance under long cable run and perfect for multiple

monitor display.

This AV Extender is smart, fast and cost-effective, eliminating costly and bulky Component Video

and Audio cable and is the most efcient way to move multimedia content from player to display.

Used in pairs, the Component Video & Audio Extender is used in shopping malls, public address

systems, airports, train & bus station, boardrooms, trade shows and computer based training ap-

plication.

AT-COMP300SL (SENDER UNIT ): 1 IN 2 OUT

COMPONENT VIDEO WTH STEREO AUDIO CAT5 EXTENDER WITH

CHAINABLE FUNCTION

• Extends Component Video and analog / digital audio over one UTP CAT5 cable.

• Supports analog stereo audio and digital audio.

• Digital transmission on analog stereo audio for eliminating sound distortion. (Dolby

Digital,AC3, DTS passed through)

• Supports hi resolution up to 1080p.

• Long range transmission up to 300 meters (Max.)

• Dual output: 1 Component Video loop output for local, plus 1 x CAT5 RJ45 output for

remote side.

• Built in equalization, gain adjustment, chainable CAT5 output at remote unit.

• Remote unit can be daisy chained to another AT-COMP300RL receiver to extend working

range over 300 meters.

• Application for airports, train & bus stations, window display, trades shows and an

exhibitions.

AT-COMP300RL ( RECEIVER UNIT )

COMPONENT VIDEO WITH STEREO AUDIO CAT5 EXTENDER – CHAINABLE FUNCTION

• Works with AT-COMP300SL as receiver for extra remote component Video display

equipment.

• It can be daisy chained for another AT-COMP300RL to an extended working range over 300

meters and multiple displays.

• Built in equalization, gain adjustment.

• Supports up to 1080p.

• Built in LPCM 44.1K / 48K 16Bit stereo audio decode function, digital & analog audio can be

output simultaneously.

• Supports Dolby Digital (AC3) & DTS digital output.

Installation

PANEL VIEW:

AT-COMP300SL

AT-COMP300RL

Cable:

Video Link cable using hi quality CAT5E UTP/STP or CAT6 UTP cable. Please note:STP cable

can not only enhance noise rejection, but also lessen transmission range and picture sharpness

quality.

color 300 (Max)

AT-COMP300SL

AT-COMP300RL

2 3

RJ45 Dene:

Link Cable (TIA/EIA-568-B )

No. Color Signal

1. Orange-white Video Pr+

2. Orange Video Pr-

3. Green-white Video Y+

4. Blue Audio -

5. Blue-white Audio +

6. Green Video Y-

7. Brown-white Video Pb+

8. Brown Video Pb-

AT-COMP300SL Switch Setting::

DIP Switcher Setting:

1 Audio Source Select

Stereo audio input (Analog)

Digital Audio input (Coaxial)

2 Analog Sampling Frequency

48Khz

44Khz

AT-COMP300SL LED indication:

Blue power on/off

Link Cable Connector:

Green: Digital audio signal setup

Yellow: Analog Sampling Frequency, ON = 48Khz, OFF = 44Khz

AT-COMP300RL Adjustment:

EQ equalization (sharpness)

Gain signal boost (brightness)

* Recommend to adjust the EQ trimmer to the right end, then slightly turn to left side for the best picture

quality. Improper adjustment can cause picture to become unstable, even resilting in no picture display.

AT-COMP300RL LED Indication:

Blue Power on/off

Link Cable Connector:

Green: Digital audio signal setup

Caution:

The cabling must remain away from any equipment with electromagnetic wave, i.e.: microwave,

radio equipment, high voltage lines.

Specifications

ITEM NO. AT-COMP300SL

Resolution Up to 1080p

Video Bandwidth Local 750MHz-3dB / Remote 350MHz-3dB

Video Input / Output Y/Pb/Pr RCA x 1 (Y 1V p-p 75Ω - Pb 0.7V p-p 75Ω - Pr 0.7V p-p 75Ω)

Audio Input / Output Analog audio L-R stereo audio RCA x 1( 3Vp-p Max.10KΩ)

Audio Bandwidth 20-20KHz -3dB

Analog Audio input Analog Sampling Frequency 44.1Khz or 48Khz

Audio Connector stereo audio RCA x 1 + optical coax

Link Connector 1 x RJ45

Max Distance Up to 300M (1000 feet)

Power Supply 5V DC 2000mA Regulated (External)

Power Consumption 400mA (Max)

Dimensions (mm) 125 x 95 x 30

Weight (g) 280

ITEM NO. AT-COMP300RL

Resolution Up to 1080p

Video Bandwidth 150Mhz-3dB

Video Output Y/Pb/Pr RCA x 1 (Y 1V p-p 75Ω - Pb 0.7V p-p 75Ω - Pr 0.7V p-p 75Ω)

Audio Output Analog audio output: L-R stereo audio RCA x 1( 3Vp-p Max.10KΩ)

Digital Audio output: Optical x1, RCA coax x 1

Link Connector 1 x RJ45

Loop output Connector 1 x RJ45

Max Distance Up to 300M (1000 feet)

Power Supply 5V DC 2000mA Regulated (External)

Power Consumption 600mA (Max)

Dimensions (mm) 125 x 95 x 30

Weight (g) 280

Installation Tips

1. Due to the inside of CAT5 cable containing pairs of wires twisted at different rates, AND the dif-

ferent quality on the cable itself and installation different signal arrival time at each pair may occure.

If there are big different at arrival time, that will cause skew status. This is seen on the monitor as

separation, or lack of convergence in colors. Normally it happens on long CAT 5 cable runs.

2. Recommend to use following cabling design to reduce skew status, to add special made “skew

immunized adaptor”, 2 pieces included at the package.

CAUTION: to avoid display equipment damaged, be sure to make correct cable connection and

power for both AT-COMP300SL before connecting AT-COMP300RL.

4 5

SAFETY INFORMATION

Safeguards

To reduce the risk of electric shock, do not

expose this product to rain or moisture.

If the wall plug does not t into your local

power socket, hire an electrician to replace

your obsolete socket.

Do not modify the wall plug.

Doing so will void the warranty and safety

features.

This equipment should be installed near

the socket outlet and the device should

be easily accessible in case it requires

disconnection.

Precautions

FCC Regulations state that any

unauthorized changes or modications to

this equipment not expressly approved by

the manufacturer could void the

user’s authority to operate this

equipment.

Operate this product using only the

included external power supply. Use of

other power supplies could impair

performance, damage the product or cause

res.

In the event of an electrostatic discharge,

this device may automatically turn off. If this

occurs, unplug the device, and plug it back

in.

Protect and route power cords so they will

not be stepped on or pinched by anything

placed on or against them. Be especially

careful of plug-ins, or cord exit points from

this product.

Avoid excessive humidity, sudden

temperature changes or temperature

extremes.

Keep this product away from wet locations

such as bathtubs, sinks, laundries, wet

basements and swimming pools.

Use only accessories recommended by

ATLONA to avoid re, shock or other

hazards.

Unplug the product before cleaning. Use

a damp cloth for cleaning. Do not use

cleaning uid or aerosols, which could

enter the unit and cause damage, re or

electrical shock. Some substances may

also mar the nish of the product.

Never open or remove unit panels or make

any adjustments not described in this

manual. Attempting to do so could expose

you to dangerous electrical shock or other

hazards. It may also cause damage to your

AT-COMP300SL, AT-COMP300RL. Open-

ing the product will void the warranty.

Do not attempt to service the unit. Instead

disconnect it and contact your Authorised

ATLONA reseller or contact ATLONA

directly.

WARRANTY

1. LIMITED WARRANTY

Atlona Technologies warrants that (a) its products (the “Product”) will perform substantially in accordance with the

accompanying written materials for a period of 3 YEARS from the date of receipt and (b) that the Product will be

free from defects in materials and workmanship under normal use and service for a period of 3 years. In the event

applicable law imposes any implied warranties, the implied warranty period is limited to 3 years from the date of

receipt. Some jurisdictions do not allow such limitations on duration of an implied warranty, so the above limitation

may not apply to Customer.

2. CUSTOMER REMEDIES

Atlona Technologies and its suppliers’ entire liability and Customer’s exclusive remedy shall be, at Atlona Technolo-

gies’ option, either return of the price paid for the Product, or repair or replacement of the Product that does not meet

this Limited Warranty and which is returned to Atlona Technologies with a copy of Customer’s receipt. This Limited

Warranty is void if failure of the Product has resulted from accident, abuse, or misapplication. Any replacement Prod-

uct will be warranted for the remainder of the original warranty period or 3 year, whichever is longer.

3. NO OTHER WARRANTIES

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, ATLONA TECHNOLOGIES AND ITS SUPPLI-

ERS DISCLAIM ALL OTHER WARRANTIES, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED

TO IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, WITH

REGARD TO THE PRODUCT AND ANY RELATED WRITTEN MATERIALS. THIS LIMITED WARRANTY GIVES

CUSTOMER SPECIFIC LEGAL RIGHTS. CUSTOMER MAY HAVE OTHER RIGHTS DEPENDING ON THE JU-

RISDICTION.

4. NO LIABILITY FOR DAMAGES

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL ATLONA TECHNOLO-

GIES OR ITS SUPPLIERS BE LIABLE FOR ANY DAMAGES WHATSOEVER (INCLUDING WITHOUT LIMITA-

TION, SPECIAL, INCIDENTAL, CONSEQUENTIAL, OR INDIRECT DAMAGES FOR PERSONAL INJURY, LOSS

OF BUSINESS PROFITS, BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, OR ANY OTHER

PECUNIARY LOSS) ARISING OUT OF THE USE OF OR INABILITY TO USE THIS PRODUCT, EVEN IF ATLONA

TECHNOLOGIES HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN ANY CASE, ATLONA

TECHNOLOGIES’ AND ITS SUPPLIERS’ ENTIRE LIABILITY UNDER ANY PROVISION OF THIS AGREEMENT

SHALL BE LIMITED TO THE AMOUNT ACTUALLY PAID BY YOU FOR THE PRODUCT. BECAUSE SOME JU-

RISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR

INCIDENTAL DAMAGES, THE ABOVE LIMITATION MAY NOT APPLY TO YOU.

ATLONA

2151 O’toole Ave, Ste D

San Jose CA 95131

Toll Free: 1-877-536-3976

International: 408-954-8782

FAX: 408-954-8792

Website: www.atlona.com

E-MAIL: [email protected]

Andere Handbücher für AT-COMP300SL

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Atlona Extender Handbücher

Atlona

Atlona AT-HD-RG100SR Bedienungsanleitung

Atlona

Atlona AT-HDTX Bedienungsanleitung

Atlona

Atlona AT-2VGA300SL Bedienungsanleitung

Atlona

Atlona AT-UHD-EX-100CE-RX-PSE Bedienungsanleitung

Atlona

Atlona AT-HD4-V40SRS Bedienungsanleitung

Atlona

Atlona AT-DVI15SRS Bedienungsanleitung

Atlona

Atlona AT-HD-V40SRS Bedienungsanleitung

Atlona

Atlona AT-RS232SRS Bedienungsanleitung

Atlona

Atlona AT-HD-IR40SR Bedienungsanleitung

Atlona

Atlona AT-HD4-SI40SR Bedienungsanleitung

Atlona

Atlona AT-UHD-EX-70-2PS Series Bedienungsanleitung

Atlona

Atlona AT-PRO2HD1616M-RX Bedienungsanleitung

Atlona

Atlona AT-DVI50S Bedienungsanleitung

Atlona

Atlona AT-DVI40SRS Bedienungsanleitung

Atlona

Atlona AT-VGA180AR Bedienungsanleitung

Atlona

Atlona AT-HDF30SR Bedienungsanleitung

Atlona

Atlona AT-HD4-V40SRS Bedienungsanleitung

Atlona

Atlona AT-HD4-SI40SR Bedienungsanleitung

Atlona

Atlona AT-DVITX-RSNET Bedienungsanleitung

Atlona

Atlona AT-HDVS-150-TX-WP Bedienungsanleitung

Atlona

Atlona AT-VGA100-SR Bedienungsanleitung

Atlona

Atlona AT-PRO2HDREC-DA Bedienungsanleitung

Atlona

Atlona AT-UHD-EX-100CE-KIT Bedienungsanleitung

Atlona

Atlona AT-HDMI40SR Bedienungsanleitung

Beliebte Extender Handbücher anderer Marken

SY HDBT-60T Bedienungsanleitung

Appsys ProAudio

Appsys ProAudio ADX-16 Bedienungsanleitung

IDK

IDK OPF-TH1000-A Bedienungsanleitung

Enable-IT

Enable-IT 824WP Bedienungsanleitung

Worx

Worx Landroid RadioLink WA0864 Technisches Datenblatt

TP-Link

TP-Link TL-WA730RE Bedienungsanleitung

Camplex

Camplex CMX-HDMI-SFPL Bedienungsanleitung

SC&T

SC&T HE03-4K Bedienungsanleitung

Marmitek

Marmitek MegaView70 Bedienungsanleitung

Samsung

Samsung SCS-26UC4 Bedienungsanleitung

Foxun

Foxun SX-GES24 Bedienungsanleitung

MuxLab

MuxLab 500771 Bedienungsanleitung

foxunhd

foxunhd SX-AEX01 Bedienungsanleitung

TERK Technologies

TERK Technologies LFIRX2 Bedienungsanleitung

Devolo

Devolo Audio Extender Handbuch

Edimax

Edimax EW-7438RPn V2 Bedienungsanleitung

Shinybow USA

Shinybow USA SB-6335T5 Bedienungsanleitung

SECO-LARM

SECO-LARM ENFORCER EVT-PB1-V1TGQ Bedienungsanleitung
