Atlona AT-PRO3HD44M Bedienungsanleitung
User Manual
Atlona HDMI 4 by 4 Matrix Switcher
over CAT5e/6/7
AT-PRO3HD44M
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
2
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
1. Introduction ..................................................................................... 3
2. Package Contents ..................................................................................... 3
3. Features ..................................................................................... 3
4. Before You Start ..................................................................................... 4
5. Specifications ..................................................................................... 4
6. Remote Control ..................................................................................... 4
7. Panel Descriptions
a. Front Panel ..................................................................................... 5
b. Rear Panel ..................................................................................... 6
8. Connection and Installation
a. 3rd Party Control ..................................................................................... 7
b. IR Remote Control ..................................................................................... 8
c. Matrix I/O Control ..................................................................................... 9
d. EDID Set Up ..................................................................................... 10
9. RS-232
a. Connection ..................................................................................... 11
b. Command ..................................................................................... 11
c. Set Up ..................................................................................... 12
d. Baud Rate ................................................................................ 12-13
10. Resetting and Updating ..................................................................................... 13
11. Safety Information ..................................................................................... 14
12. Warranty ..................................................................................... 15
13. Atlona Product Registration ..................................................................................... 16
Table of Contents
3
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
Introduction
With the latest and more affordable HDBaseT technology extend HDMI sources up to 200ft over
CAT5e/6 (230ft over CAT6a) at 1080p or 1920x1200. The Atlona HDMI 4 by 4 Matrix Switcher
allows for effortless control of up to 8 devices through IR remote control, RS-232, 3rd party IR
control box and the front panel. With a built in loop out S/PDIF port send audio to an AVR or
Distribution Amp. To ensure all audio passes through, the 4 by 4 Matrix Switcher supports all Lossy
and Lossless formats of Dolby and DTS over HDMI.
Package Contents
Features
• 1 x AT-PRO3HD44M
• 1 x 24V/6.25A DC adaptor
• 1 x Power cord
• 1 x IR Extender
• 5 x IR Emitter
• 1 x Remote control
• 1 x Pair of dual purpose wall/rack mounts
• 1 x User Manual
• HDBaseT allows IR, RS-232, audio and visual signals to pass over a single CAT5e/6/7 cable.
• IR ports for zone dedicated control through IR remote control and 3rd party IR controllers.
• Programmable I/O memories, save I/O routes for faster switching to the most commonly used
configurations.
• EDID learning function for up to 4 video display EDIDs.
• Multiple control options such as RS-232, IR, and the front panel.
• Dolby TrueHD and DTS-HD Master Audio pass through HDMI output interface.
• Compatible with DVI/D (with DVI/D to HDMI adapter such as AT-HD610), allowing DVI/D to be
passed to displays.
• Built in source Coax loop-out to send your audio to an AVR or Amplifier for easy audio
distribution. Compatible with PCM 2Channel, Dolby 2.0, Dobly Digital 5.1, and DTS 5.1.
• HDCP compliant
IR Receiver IR Emitter
Power Cord
4
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
Specifications
Before You Start
Remote Control
Bandwidth frequency 6.75 Gbps
Input Ports 4 x HDMI (Female Type)
5 x IR 3.5mm
1 x Firmware update
Output Ports 4 x CAT 5e/6/7
4 x S/PDIF Digital Audio
1 x RS-232
5 x IR 3.5mm
Resolution outputs Video: up to 1080p@60Hz
Vesa: up to 1920x1200
Dimensions (HxWxD) 1.69x17.13x10 (inch) or 42.93x435.10x254 (mm)
Weight 7lbs or 3.18kg
Power consumption 60W
Output selection. Numbers correspond with the CAT5e/6/7
category cable outputs (1-4) on the matrix.
Input selection. Numbers correspond with the HDMI inputs (1-4)
on the matrix.
Arrow buttons are not functional for this product.
• Make sure when connecting the CAT5e/6/7 cables a 568B termination method is used.
• Make sure the matrix is connected to a component surge suppressor and line conditioner.
Note: Atlona’s warranty does not cover damage due to electrical disturbances. A component surge
suppressor and line conditioner are highly suggested especially in areas with electrical
storms.
• Be sure you’re using a mono to mono (2 conductor) 3.5mm IR cable (i.e. AT-MINIMONO6 -
available to purchase at Atlona.com) when using IR output control from 3rd party controllers,
stereo (3 conductor) 3.5mm cables are not compatible.
5
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
Panel Description
Front Panel
1. IR Receiver Window. Receives the signal from the included IR Remote Control or a 3rd party IR
Controller.
2. Power Button. Cycles the power between On (blue backlight) or Standby (red backlight) mode.
3. Function Button. Allows you to select command options. (blue backlight when selected)
a. Default: Mirrors all inputs to corresponding outputs. (i.e. 1 to 1, 2 to 2, 3 to 3, etc.)
b. All: Save a single input to all the outputs with this function.
c. Memory: Save/load the current input and output route to memory.
d. EDID: Save/Load EDIDs to individual inputs.
Note: Default setting for EDID is the highest common HD resolution of all connected
devices. (i.e. if you have resolutions ranging 720p, 1080i, and 1080p then 720p would be
the default resolution for all connected displays.)
4. Enter Button. Use to view current status for inputs and outputs or to confirm a command.
5. Cancel Button. Within the functions menu use to go back one screen or to the home screen.
Note: You cannot power off or change functions unless you go to the home screen.
6. Number buttons. Use these buttons to select input and output paths or use with the function
button to change multiple matrix settings.
1 3 4 ab c d
2 5
6
6
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
Back Panel
1. RS-232 - Connect to this port for control from a computer or 3rd party controller.
2. Matrix IR IN - Used to control matrix I/O switching from a 3rd party IR controller.
3. Matrix IR Out - Global output, combines IR for all discrete IR output ports.
4. Firmware Update - Type B USB Port used for updating the matrix firmware only
5. HDMI Input Ports - Connect HDMI sources into these ports, such as DVD players, Blu-ray players,
computers, etc.
6. Zone dedicated ports
a. IR 3.5mm mono In ports: Used in conjunction with 3rd IR party controller to extend IR
control commands to video displays over CAT5e/6/7.
b. IR Out ports: Sends IR signal to sources through a 3.5mm mono IR emitter
Note: Be sure you’re using a mono to mono 3.5mm IR cable (i.e. AT-MINIMONO6) for 3rd
party control boxes, stereo 3.5mm cables are not compatible.
c. Coax Out: Audio Loop-out for Amplifiers and AVRs.
Compatible with LPCM 2Channel, Dolby 2.0, Dobly Digital 5.1, and DTS 5.1.
d. CAT5e/6/7 Out: Extends video and bidirectional RS-232, IR, and audio signals through a
single CAT5e/6/7 cable.
7. Power Port - Use included locking DC adaptor to power the matrix switcher
26
1 3 4 5 a b c d 7
7
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
Connection and Installation
3rd Party Controller
Video Display
AT-MINIMONO6
3rd Party Controller Set Up
IR Emitter
AT-PRO3HDREC
Note: 3.5mm 3 conductor (stereo) cables are not compatible. Please use 2 conductor (mono) IR cables with IR input
ports.
Important: When using a 3rd party IR controller remember to connect a mono to mono 2 conductor IR
extender cable into the matrix IR IN port for IR control of the matrix switcher I/O.
With the feature of the IR in ports the AT-PRO3HD44M has the unique ability to
receive IR commands through a 3rd party controller and send it out through the
CAT5e/6/7 port to control the displays in any zone.
Note: Be sure to use a mono to mono (2 conductor) 3.5mm IR extender from the
3rd party controller to the AT-PRO3HD44M (example: AT-MINIMONO6)
Mono to
mono 2
conductor
IR extender
cable
Blu-ray Player
Note: With the latest HDBaseT technology there’s no need for a power source for the extenders as they receive power
over the CAT5e/6/7 cable.
8
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
Note: When using an IR remote control all sources can be controlled as well as the local display.
Note: With the latest HDBaseT technology there’s no need for a power source for the extenders as they receive power
over the CAT5e/6/7 cable.
IR Remote Control Set Up
Video Display
IR
Remote
IR Receiver
Module
Blu-ray Player
IR Emier
AT-PRO3HDREC
9
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
I/O Control
The AT-PRO3HD44M’s front panel has 3 functions: I/O control, EDID set up, and matrix settings.
The following sections go over step by step control.
To set an input to an output
To mirror all inputs and outputs
To route one input to all outputs
To save an I/O route to memory
To load a saved I/O route
Feedback =”Input # saved to
Output #”
Feedback =”Mirroring In and Out”
Feedback =
”Input # saved to all”
Feedback =
”Memory # saved”
Feedback =
”Memory # loaded”
Matrix Front Panel Functions
--->
--->
--->
--->
--->
--->
--->
--->
--->
--->
--->
--->
--->
--->
--->
--->
--->
---> --->
--->
--->
--->
--->
--->
--->
--->
--->
--->
--->
--->
--->
--->
--->
--->
--->
--->
---> --->
AT-PRO3HD44M
Select Input Number
AT-PRO3HD44M
Select Input Number
AT-PRO3HD44M
Select Input Number
AT-PRO3HD44M
Select Input Number
AT-PRO3HD44M
Select Input Number
Select Function Option
Select Function Option
Select Function Option
Select Function Option
1 Save in/out route
2 Select memory route
1 Save in/out route
2 Select memory route
Select input number
to save to all outputs
Input # to all outputs
Press enter to confirm
Save to memory (1-4) #
Press enter
Select Memory route 1-4
Press enter to load
Mirror In to Out
Press enter to confirm
Select output number
Press enter to confirm
home screen
home screen
home screen
home screen
home screen
10
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
When the matrix is completely connected and turned on it will load the default EDID, which is
the highest common native resolution of the devices. (i.e. With devices connected that range from
720p, 1080p, 2 channel audio, multi-channel audio and 3D, the default resolution will be 720p.
Multi-channel audio and 3D are not available on default unless all devices have these
features.)
There are two options when setting up EDID: Default and Copy. In order to have any options other
than default different EDIDs must first be copied. The AT-PRO3HD44M can copy up to 4 EDIDs to
memory.
EDID Set Up
To save an EDID
To load a saved EDID
--->
--->
--->
--->
--->
--->
--->
--->
AT-PRO3HD44M
Select Input Number
AT-PRO3HD44M
Select Input Number
Select Function Option
Select Function Option
home screen
home screen
1 To copy up to 4 EDIDs
2 To choose input EDID
1 To copy up to 4 EDIDs
2 To choose input EDID
Input #
Select an input port
Input # Press Enter
Current: Default
Input: # Mode:
1. Default 2. Saved
Input: # Select saved
EDID memory 1-4 (#)
Use EDID memory # + enter
_ _ _
--->
--->
--->
--->
Copy from output #
Save to Memory (1-4) #
Copy from output #
Save to Memory (1-4) #
Feedback=
”Saved port # EDID to
Memory # [Failed/Passed]”
Feedback = ”Save memory # EDID
to input #”
--->
--->
--->
--->
--->
--->
--->
--->--->
--->
---> --->
--->
--->
--->
Atlona EDID - ATL
Pioneer EDID - PIO
Toshiba EDID - TSB
EX.
Andere Handbücher für AT-PRO3HD44M
1
Dieses Handbuch passt für folgende Modelle
1
Inhaltsverzeichnis
Andere Atlona Matrix-Umschalter Handbücher
Atlona
Atlona AT-PRO3HD44M Bedienungsanleitung
Atlona
Atlona AT-UHD-H2H-44M Bedienungsanleitung
Atlona
Atlona AT-HD-V44M Bedienungsanleitung
Atlona
Atlona AT-HDR-H2H-88MA Bedienungsanleitung
Atlona
Atlona AT-PROHD88M-SR Bedienungsanleitung
Atlona
Atlona AT-HD-V22M Bedienungsanleitung
Atlona
Atlona AT-SAV-84M Bedienungsanleitung
Atlona
Atlona AT-SDI82M Bedienungsanleitung
Atlona
Atlona AT-HD-V88M Bedienungsanleitung
Atlona
Atlona AT-UHD-PRO3-88M Bedienungsanleitung
Atlona
Atlona AT-UHD-CLSO-824 Bedienungsanleitung
Atlona
Atlona AT-DVI0808 Bedienungsanleitung
Atlona
Atlona AT-PROHD88M-SR Bedienungsanleitung
Atlona
Atlona AT-PROHD1616M-SR Bedienungsanleitung
Atlona
Atlona AT-HD-V42M Bedienungsanleitung
Atlona
Atlona AT-UHD-H2H-88M Bedienungsanleitung
Atlona
Atlona AT-HD-SC-500-b Bedienungsanleitung
Atlona
Atlona AT-COMP-42M Bedienungsanleitung
Atlona
Atlona AT-AV0808N Bedienungsanleitung
Atlona
Atlona AT-HD-V24M Bedienungsanleitung
