Product Features

Technical Specification

For More Information:

www.ATTOTech.com

or to Purchase:

www.ATTOStore.com

(716) 691-1999

RAID Adapter

3-Gb SAS/SATA II Connectivity with

Integrated RAID Support

The ATTO ExpressSAS R30F RAID Adapter

combines 3-Gb SAS/SATA II connectivity with six-

teen internal ports and integrated RAID support

making it the ideal SAS RAID adapter for both IT

and digital media environments requiring flexible

connectivity options and the highest performance

with data protection.

The ATTO ExpressSAS host adapter product

family provides enhanced reliability and

performance thanks to more than 15 years of

experience with SCSI hardware and storage

connectivity solutions. Using PCI Express bus tech-

nology and sixteen internal port configuration, the

ATTO ExpressSAS R30F RAID adapter delivers

blazing fast performance with transfer rates of up to

3-Gb per second per port. With four internal x4 Mini

SAS connectors, the R30F provides connectivity of

up to 16 internal SAS/SATA targets. The R30F also

features 512MB of ECC-protected DDR2 DRAM to

allow support for multiple RAID groups.

The ATTO ExpressSAS R30F RAID adapter is

engineered for the most stringent IT server and

digital media workgroup environments. To satisfy

the data protection requirements of these

environments, ATTO leverages it’s time tested

ATTO RAID Stack (ARS™) technology based on a

proven RAID core that is compatible with multiple

operating systems, applications, and drives.

The easy-to-use GUI utility enables RAID

management, monitoring, and configuration. ATTO

also incorporates it’s field proven Advanced Data

Streaming (ADS™) technology to meet the most

demanding performance requirements of data

intensive applications. In addition, ATTO provides

industry standard PCIe to SAS control using Serial

SCSI Protocol (SSP), Serial ATA Tunneling

Protocol (STP), and Serial Management Protocol

(SMP)

Technical Highlights

• x8 PCIe host interface

• Half-height

• 16 internal ports

• Outstanding performance

with up to 3-Gb/sec per

port

• Highly configurable

RAID (0, 1, 4, 5, 6, 10, 50,

60, JBOD and DVRAID

support)

• SAS, SATA and SATA II

connectivity

• Internally connect up to

16 direct attached drives

• Exclusive Advanced Data

Streaming (ADSTM)

technology

• User friendly GUI

configuration utility

• Driver support for

Windows®, Linux and

Mac® OS X

• RoHS Compliant

• 3-year standard

product warranty

Blazing Fast Performance

• Up to 3-Gb/sec per port

transfer rates with SAS, SATA

and SATA II attachment

• Increased bandwidth through

x8 PCI Express host interface

• Point-to-point technology

delivers full throughput to

each connected storage

device

Smooth Data Streaming

• Alleviate data transfer

bottlenecks and move data

more efficiently while

managing latency with

ATTO’s exclusive ADS™

technology

• Improve I/O through

optimized data movement

One Click Installation

• One-click installation allows

for quick and easy set-up

• Simple GUI based utility for

effortless adapter

configuration

• BIOS setup utility provides

flexibility for custom

applications

ExpressSAS R30F RAID Adapter

ExpressSAS R30F

16 Port SAS RAID Adapter

Rev 1/09

Technical Specification Power Behind the Storage

For More Information:

Hardware Specifications

Applications • Support for IT server and digital media workgroup solutions requiring high-bandwidth and data

protection. Applications include audio/video, VOD, fixed content, database and other data intensive

environments.

Maximum Transfer Rate • Up to 3-Gb/sec per port

Advanced Capabilities • Device support for SAS, SATA and SATA II

• SES Support

• S.M.A.R.T Support

• Support for Staggered drive spin-up

• Pass-through mode to support tape devices

• Support for RAID levels 0, 1, 4, 5,6, 10, 40, 50, 60, JBOD and DVRAID

• On-line capacity expansion (OCE)

• Hot spare, auto-rebuild

• Native Command Queuing

• Cache memory—512MB ECC protected memory

• User friendly GUI for RAID setup

PCI Bus Specifications • x8 PCI Express host interface

• Supports PCI Express Base Spec 1.0a

Connectivity • Easy-to-install low-profile connection bracket; full-height bracket included in Finished Goods packaging

• Four x4 Internal Mini SAS (SFF-8087) connectors

Software Specifications

Driver Support • Windows® Server 2003, 2008, XP, Vista

• Linux (Red Hat and SuSE)

• Mac® OS X

Agency Approvals

Safety and Environmental • FCC Rules, Part 15, Class B

• CE Mark: CISPR 22:2002

• EN55022:2002, Class B

Compliancy • RoHS Compliant

Environmental & Physical Specifications

Dimensions • Length 8.640”

• Height 2.900”

Operating Environment • Temperature: 0-60° C (32°-140°F)

• Humidity: 5 - 95% non-condensing

Storage Environment • Temperature: -40°-70°C (-40°-157°F)

• Humidity: 5 - 95% non-condensing

Power • 12V @ 1.44A

• 3.3V @ 0.54A

Airflow • 150 lf/m (min) recommended

Ordering Information

Model Number • ESAS-R30F-000 (RoHS)

ExpressSAS 16 Port RAID Adapter

3-Gb SAS/SATA II Connectivity with Integrated RAID Support

ExpressSAS R30F RAID Adapter
