1. GENERAL INFORMATION
2. UNPACKING YOUR SYSTEM
3. SERVICING
4. PRECAUTIONS
IMPORTANT
ELECTRICAL INFORMATION
MAINS POWER SWITCH
The AUDICA AVR-1 DVD/Receiver includes four system
components in one box - a DVD player, FM/AM radio, surround
sound decoder and 6 channel amplifier. In addition to the AVR-1
you will need a TV and a speaker system with between two and
six channels. A full six channel speaker system is recommended
to deliver the most realistic surround-sound experience.
Care must be taken whilst unpacking your system that no part is
damaged or lost. For an inventory of what should be supplied
with the system, please refer to system specifications on page
16. Retain packaging materials so the system can be re-packed
and shipped if necessary.
Do not attempt to service this product yourself as opening covers
or panels may expose you to dangerous voltages or other
hazards. Refer all servicing to qualified personnel.
Where replacement parts are required be sure the service
technician has used replacements supplied by the manufacturer
or have the same characteristics as the original part. Use of
unsuitable parts could cause fire, electrical shock or other
hazards and may void any warranty or guarantee.
The technician must perform any safety checks to test the
performance of any repairs.
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with a slightly damp cloth.
Do not block any ventilation openings.
Install in accordance with the manufacturer's instructions.
Do not install or operate near any heat sources such as
radiators, stoves, or other apparatus that produce heat.
Unplug this apparatus during lightning storms or when
unused for long periods of time.
Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as the power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
Warning: To reduce the risk of fire or electrical shock, do not
expose this product to rain or moisture. The product must not
be exposed to dripping and splashing and no object filled
with liquids such as a vase of flowers should be placed on the
product.
No naked flame sources such as candles should be placed
on the product.
Caution: Changes or modifications not expressly approved by
the manufacturer could void the user's authority to operate this
device.
Caution: Usage of controls or adjustments or performance of
procedures other than those specified herein may result in
hazardous exposure.
These labels tell you that the unit contains a Laser component.
Do not stare at the laser lens.
This equipment has been tested and found to comply with the
limits for a Class B digital device pursuant to part 15 of the FCC
rules. These limits are designed to provide reasonable protection
against harmful radiation in a residential installation. This
equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communication. However, this is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for
help.
Mains Supply: The mains operating voltage of this unit is on the
rating plate on the rear. In the UK this is 230/240 V.
The AVR-1 is supplied with a power cord terminated with a UK
approved mains plug fitted with a 3A fuse. If
The AVR-1 does not have a power
switch. If you need to switch off the mains power to the AVR-1,
remove the mains plug from the wall outlet. For this reason,
ensure that the mains plug remains easily accessible when
installing theAVR-1.
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
the fuse needs to be
replaced, an ASTA or BSI approved BS1362 fuse rated at 3A
must be used. If you need to change
the mains plug, remove the fuse and
dispose of this plug safely
immediately after cutting it from the
cord.
Manufactured under license from Dolby Laboratories. "Dolby",
"AC-3", "Pro Logic" and the double-D symbol are trademarks of
Dolby Laboratories.
Important Safety Information
3A FUSE
BS 1362
BROWN
(Live)
BLUE
(Neutral)
4
GB
Class II construction double insulated. This
product must not be connected to earth.
CAUTION!
RISK OF ELECTRIC SHOCK
DO NOT OPEN
TO REDUCE THE RISK OF ELECTRIC SHOCK DO
NOT REMOVE COVER (OR BACK)
This symbol indicates that dangerous
voltage constituting a risk of electric
This symbol indicates that there are
important operating and maintenance
instructions in the literature
