Audio Note M5 RIAA Technisches Handbuch

M5 RIAA

Owner’s Information

The M5 RIAA is a Level 3RIAA phono stage,

developed for the best possible sonic performance rather

than technical specifications. To this end, the M5 RIAA

incorporates thermionic valve technology to produce the

most accurate sound possible and has been brought to

maturity through a development process we call

comparison by contrast, which is currently unique to

Audio Note. The article from which this technique is

based, named ‘Audio Hell’, is available from Audio

Note by request.

Please read this manual carefully in order to obtain the

best possible performance from your pre-amplifier.

Audio Note wishes you many happy years of listening

pleasure.

Technology

It is well known to any audio circuit designer worth their salt that accurate

reproduction of music relies entirely on the preservation of the purity of the incoming

signal. It is therefore not a difficult step to make to realise that the complexity of the

circuitry itself must be kept to a minimum in order to retain the musicality of the

original performance.

In response to this, all Audio Note pre-amplifiers use a single-ended, zero feedback

circuit topology.The single-ended gain stage topology is simply the most linear,

demanding pure Class A valve operation and removing the need for a phase splitter,

which introduces unnecessary crossover distortion.

The Audio Note amplifier range does not make use of any kind of feedback. As a

result, they were neither designed for vanishingly small harmonic or low

intermodulation distortions, but instead for minimal non-harmonic and time base

anomalies. It is these non-harmonic amplitude and time base distortion that have a

highly perceptible and adverse affect on the signal waveform.

Our amplifiers are designed for maximum linearity without ‘corrective’ measures to

keep transient distortions to a minimum rather than introducing the recursive errors

inherent in feedback loops.

The M5 RIAA features a 6072A phono stage, a 6X5 valve rectified power supply

based on the M10’s Galahad PSU, tantalum resistors, Black Gate filter capacitors, and

Audio Note copper foil signal capacitors, HiB c-core output transformers and a

balanced output.

Unpacking & Installation

Please take care when unpacking the pre-amplifier. We recommend that you store the

packing materials in case the unit requires shipping at a later date.

Next, select a suitable location for the unit, ensuring that adequate ventilation is

provided (the valves generate a fair amount of heat). In the interest of safe, reliable

operation, situate the pre-amplifier well away from dampness or direct sunshine.

Avoid sitting the M5 RIAA close to any other equipment, such as a power amplifier,

that may be generating a strong magnetic field, or in close proximity to active mobile

telephones.

Worthwhile sonic improvements may be obtained by locating the unit on a

specifically designed audio component support system; we tend to prefer natural

materials such as wood.

Connections

Please ensure that the M5 RIAA, the power amplifier and any source equipment is

switched off before making any connections.

NOTE: It is important that all connections are firm, secure and airtight; any

oxidisation of the interconnects will result in loss of performance. Always use high

quality interconnects; Audio Note interconnects are recommended, as they are

manufactured to the same exacting standards as all of our products.

Inputs

The M5 RIAA has one phono input, which consists of a pair of RCA connectors,

colour coded red for the right channel and white for the left channel.

The input is suitable for connection to a turntable with a moving magnet (MM) type

cartridge. Turntables with moving coil (MC) type cartridges will require a step-up

transformer between the turntable and the pre-amplifier; Audio Note produce some of

the best step-up transformers available.

Outputs

The M5 RIAA provides two unbalanced outputs; again, these outputs consist of a pair

of colour coded RCA connectors. The two outputs are for connections to a line level

pre-amplifier and are identical, making them suitable for biwiring.

Ground Post

A ground connection is provided to assist in the elimination of any ground loops that

may occur. A ground loop can be identified by excessive background hum. If you

experience a ground loop, try connecting the ground connection with that of other

system components. If the hum persists, contact your dealer.

Mains Power

An IEC power connector is located on the back of the M5 RIAA. Use the supplied

power cable to connect the pre-amplifier to the mains supply. Ensure the power is off

at the switch when you do this.

Using the M5 RIAA

Once all the connections are completed and checked, make sure all power amplifiers

are off and flip the mains rocker switch located on the back panel of the pre-amplifier

to the 'on' position.

The M5 RIAA is a vacuum tube design and therefore requires about 45 seconds

warm-up time. After this the remaining system components may be turned on.

NOTE: Always turn the phono stage on before turning on the pre-amplifier and

always turn the pre-amplifieroff before turning off the phono stage. This will prevent

any buzzing or popping sounds from occurring.

No further action is required, the M5 RIAA will act silently as a dedicated phono

stage, volume and balance adjustment etc. can be made on the line stage pre-

amplifier.

The M5 RIAA will improve over time and will start to sound increasingly well

balanced. This is because of the “bedding in” time taken by new electrical

components inside the unit. Also, the pre-amplifier’s sound quality improves as the

unit reaches its normal, stable operating temperature. Only a rear panel on/off switch

is provided as the unit is designed for continuous operation. The M5 RIAA need not

be switched off each time after use. It is interesting to note that continuous operation

not only results in optimum sonic performance (since the unit is maintaining a

constant operating temperature) but also causes less electrical stress and so extends

component and valve life.

Cleaning

Cleaning the pre-amplifier is best done with a soft brush -some photographic stores

are able to provide suitable brushes. Alternatively, a soft cotton cloth may be used

with a mild propriety cleaner for removing dirt build-up. Strong or alcohol based

solvents may damage the finish of this product. Ensure the pre-amplifier is switched

off and cold when cleaning. Do not wet the unit.

Replacing and Upgrading the Valves

Replacement NOS valves can be purchased from Audio Note when valves fail or

should you wish to experiment with different types of valves. A list of valves and

equivalents can be found at www.audionote.co.uk. Contact your dealer if you are

unsure what valves you should use or how to install them.

Line and phono stage valves should provide you with 5 years of continuous operation,

rectifier valves should last much longer.

Warranty and Servicing

Audio Note warrants that this product will be free from defects in materials and

workmanship for one year from the original date of purchase from an appointed

Audio Note dealer. The valves are warranted for three months.

In the event that your Audio Note product requires servicing, please contact your

Audio Note dealer. If the component needs to be shipped, please use the original

packaging materials and include a copy of the sales purchase with a note, explaining,

in as much detail as possible, the problems that your are experiencing with the unit.

Any modification not authorised by Audio Note will invalidate any warranty.

If you require technical support or have any questions, please direct them to your

local Audio Note dealer or alternatively contact us directly at:

Customer Support

Audio Note (UK) Limited

25 Montefiore Road

HOVE

East Sussex

BN3 1RD

United Kingdom

TEL: +44 (0)1273 220511

FAX: +44 (0)1273 731498

EMAIL: [email protected]

Specifications

Weight 7kg

Dimensions 135(h) x 440(w) x 410(d) mm

Max Power Consumption 30W

Fuse Ratings 1A anti-surge (110/120 V supply)

400mA anti-surge (220/240 V supply)

Input Impedance 47kO

Gain @ 1kHz 37dB

Max Output (rms) 28V

Output Impedance < 5kO

Tube Compliment 2x 6X5, 2x ECL82, 2x OB2, 3x 6072A

NOTE: Due to Audio Note’s ongoing research and development programme,

specifications are due to change without notice.

Safety Information

HEAT: By the nature of vacuum tubes, this product generates high levels of

heat. Adequate ventilation must be provided. Do not restrict the airflow

through any of the ventilation slots or place the amplifier on any surface that

may restrict airflow.

CAUTION: The vacuum tubes and other nearby parts operate at extremely

high temperatures -KEEP OUT OF REACH OF CHILDREN.

HUMIDITY: Do not store or operate this unit in areas of high humidity or in

close proximity to water. Do not expose the unit to liquid.

EARTHING: The product must be earthed -ensure that the mains supply cable

is earthed.

SAFETY COMPONENTS: Internal fuses and other safety components are

located inside this unit in accordance with BS 60065 requirements. In the

event of component failure, replacements must be of the same part type. Such

replacements must be carried out by a qualified service technician.

SHOCK: Internal operating voltages are lethal. Do not remove the top cover.

Do not replace fuse without first disconnecting the unit from the mains

supply.

This product complies with CE standards
