Audio Note P2 SE Technisches Handbuch

P2 SE

Signature

STEREO POWER AMPLIFIER

OWNER’S INFORMATION

1) IMPORTANT SAFETY INFORMATION

2) CE DECLARATION OF CONFORMITY

DISPOSAL

POWER REQUIREMENTS

3) INTRODUCTION

5) OVERVIEW

UNPACKING AND INSTALLATION

6) CONNECTION

7) OPERATION

8) TECHNICAL SPECIFICATIONS

9) WARRANTY INFORMATION

10) CONTACT INFORMATION

CONTENTS

SUCH REPLACEMENT MUST ONLY BE CARRIED OUT BY A

QUALIFIED SERVICE TECHNICIAN.

Do not attempt to replace any fuses without first disconnecting the unit

from the mains electricity supply.

! IMPORTANT SAFETY INFORMATION !

RISK OF SHOCK OR ELECTROCUTION! INTERNAL OPERATING

VOLTAGES ARE LETHAL!

Do not remove top cover, unless specifically instructed to do so in the user

manual.

This unit contains fuses and other safety components in accordance with

BS60065 requirements.

In the event of failure, replacement fuse or safety component must be of

the same part type and value.

This product generates high levels of heat. Adequate ventilation must

be provided. Do not restrict airflow through any ventilation slots or

place the unit on any surface that may restrict airflow.

Valve equipment operates at extremely high temperatures;

KEEP OUT OF THE REACH OF CHILDREN AND ANIMALS.!

Do not store or operate this unit in areas of high humidity or in close

proximity to water / moisture.

Do not expose or immerse the unit in liquid of any kind.

This product must be earthed –ensure that the mains supply cable earth /

ground is correctly connected.

OTHER SAFETY PRECAUTIONS: -

Never touch the power cord with wet hands.

Always remove the power cord by grasping the plug, not the cable.

Never expose the unit to excessive heat or magnetism.

Never let an inexperienced person repair or reassemble the unit.

Never put anything, especially metal objects, inside the unit.

Never place excessive weight on the unit.

POWER REQUIREMENTS

Power requirements for electrical equipment vary depending on your geographical

location. Please ensure that your unit meets the power requirements in your area.

The power requirement for your unit is marked on the serial number plate, located on

the rear panel.

If you are in doubt, please contact your dealer before plugging the unit into the mains

supply.

CE DECLARATION OF CONFORMITY

DISPOSAL

This product must not be disposed of as normal household waste. To

prevent possible harm to the environment please separate the product

from other waste to ensure that it can be recycled in an environmentally

safe manner. Please contact your retailer or the appropriate local

government office for collection facilities.

We declare under our sole responsibility that this product is in conformity

with the following standards or standardized documents:

BS EN 60065 in accordance with the regulations 73/23/EEC, 89/336/EEC

(from 1 January 1997)

CE 94

Peter Qvortrup,

Director

Audio Note (UK) Limited

25 Montefiore Road

Hove

East Sussex

BN3 1RD

United Kingdom

Tel: +44 (0)1273 220 511

Fax: +44 (0)1273 731 498

Thank you for purchasing this Audio Note (UK) product. With the correct care it

should give you many years of pleasure and enjoyment.

Please take the time to read all of the information in this manual before connecting

your new component to an electrical supply or your system, to ensure both your

safety and satisfaction.

Please note that due to our desire to continually improve products, specifications are

subject to change without notice. Therefore it is important to refer to the manual that

is supplied with your product for the most accurate information; manuals downloaded

from our website or obtained from other sources may no longer fully apply to your

product.

If you have any questions regarding the information contained within this document

or your new component, please feel free to contact us: -

Audio Note (UK) Limited

25 Montefiore Road

Hove

East Sussex

BN3 1RD

United Kingdom

Tel: +44 (0)1273 220 511

Fax: +44 (0)1273 731 498

e-mail: [email protected]o.uk

INTRODUCTION

Congratulations on your purchase of the Audio Note (UK) P2 SE Signature stereo

power amplifier.

It is a Pure Class A, Single Ended valve design, which preserves the entire musical

waveform as one ‘whole’, producing a level of performance that is radically superior

to the majority of current designs.

Part selection is optimized to realize the most neutral and realistic sonic reproduction.

Some of the superior quality components utilized in the P2 SE Signature include: -

Audio Note (UK) Copper foil capacitors used in the most critical areas.

Audio Note (UK) Tantalum resistors used in the most critical areas.

Custom designed output transformers, manufactured by Audio Note (UK).

These output transformers –one of the most critical areas of valve amplifier

design – allow the P2 SE Signature to produce impressively extended and

controlled bass.

The Signature transformers are our custom manufactured IHiB, C-Core copper

wound models, which are quite possibly the finest examples of output

transformers for this type of amplifier available in the World today.

The P2 SE Signature fulfills all Audio Note (UK) Level 2 criteria: -

Pure Class A Single Ended Pentode operation

Materials and component quality

P2 SE SIGNATURE STEREO POWER AMPLIFIER

Please take care when unpacking your P2 SE Signature stereo power amplifier.

Choose a clean, clear location to unpack your unit. Be aware that the amplifier is

quite heavy; before attempting to unpack or lift the unit, check the weight and if

necessary use more than one person so that it can be moved safely and easily.

We recommend that you retain and carefully store all of the original packing

materials, in case transportation / shipping is required at a later date.

Select a suitable location for the unit. This should be a dry, dust free and level area,

preferably shielded from direct sunlight and free from vibration. Also ensure that the

location is stable and capable of carrying the weight of the unit.

A suitable mains power outlet must be close to the location; power cords must not be

pulled or stretched tightly in an attempt to reach a wall socket. If the power cord will

not easily reach the socket, choose a closer location!

Please ensure that adequate ventilation for the unit is provided, and that airflow

through any ventilation slots in the unit is not restricted. We recommend a distance of

at least 30cm free space is maintained above the unit, and preferably it should be

sited in free space or on the top shelf of your equipment rack or table. Please also

remember that valve equipment operates at extremely high temperatures, so a

position that is inaccessible to any children or animals is essential.

UNPACKING AND INSTALLATION

Line inputs Being a stereo power amplifier, the P2 SE Signature is fitted with one

pair of single ended / RCA inputs. Looking from behind the amplifier,

they are located at bottom / right hand side of the rear panel. The

Black socket is for the Left channel, the Red socket is for the Right

channel. Connect the output from your preamplifier to these inputs.

Speakers Each channel is equipped with 3 colour coded binding posts for

connection to your speakers, located on the rear panel.

Looking from the front of the amplifier, the 3 binding posts on the left

are for the LEFT channel and the 3 binding posts on the right are for

the RIGHT channel. Additionally, each set of binding posts is marked

‘LEFT’ and ‘RIGHT’.

Connect the amplifier’s black speaker output binding post marked as

“0” to the black / negative terminal (also marked “ –“) on the speaker.

Connect the amplifier’s red speaker output binding post marked

“8 Ohm” to the red / positive terminal (also marked “ + “) on the

speaker. The other red speaker output binding post is marked

“4 Ohm” and may be used with 4 Ohm speakers. If you are uncertain

whether your speaker system is specified as 4 or 8 Ohm, try the

following test once all other connections are made and the amplifier is

operational. Compare the sound quality using a familiar recording with

the speakers connected to the 8 ohm connections and then the 4 Ohm

connections respectively. The selection that produces the best

frequency balance and maximum dynamics should be used.

Ground Post A ground post is provided for connection to those source components

that also use a separate ground terminal.

Mains The P2 SE Signature features an IEC 320 mains inlet socket. Use the

supplied mains cable to connect the unit to the local mains supply.

The mains fuse and a spare are located in the inlet socket fuse

drawer.

Special Note –Make sure that all connectionsare tight and clean. For

best results use good quality audio interconnects. Although it is

perfectly acceptable to use cables manufactured by other companies,

for best results and performance, we recommend our own Audio Note

(UK) range of interconnects and loudspeaker cables. For further

information, please consult your nearest Audio Note (UK) dealer, or

alternatively please feel free to contact us directly.

CONNECTION

Once all the connections are completed and checked, ensure that the volume control

of your preamplifier / source is at the minimum setting.

Turn on all components in the signal chain BEFORE the P2 SE Signature; it should

always be the LAST component to be switched ON, and the FIRST to be switched

OFF.

Turn on the amplifier by using the rotary switch located on the right of the front panel.

The red front panel light should now be lit. The amplifier requires approximately 45

seconds to initialize before it is ready for operation.

Volume Control Unlike most Stereo power amplifiers, the P2 SE Signature is

equipped with a volume control. When in use with a

preamplifier, set the P2 SE Signature volume control so that

the preamplifier’s volume control is operating in its optimum

range, usually between the 9 o’clock and 3 o’clock positions.

This will usually result in the P2 SE’s volume control being set

at roughly the 12 o’clock position.

When using the P2 SE Signature with a line level source, use

the volume control to set the desired listening level.

Bedding in The new amplifier requires about 200 hours of initial use (called

“bedding in”) before the circuitry becomes stable and optimum

performance is realized.

As the amplifier “beds in” the sound will become increasingly

smoother, detailed and open.

Once the amplifier has “bedded in” a warm up time of

approximately 30 to 45 minutes is required each time the

amplifier is switched on before optimum sonic performance is

reached.

Cleaning No special maintenance is required for the amplifier. Use a

soft, clean lint free cloth to remove any surface marks from the

casework. For finger marks / grease, use a soft, clean lint free

cloth, lightly moistened with a solution of warm water and mild

detergent. Do not use any alcohol or solvent based cleaning

products, as they may damage the finish of the amplifier.

ENSURE THAT THE AMPLIFIER IS SWITCHED OFF AND

DISCONNECTED FROM THE MAINS ELECTRICITY

SUPPLY BEFORE UNDERTAKING ANY CLEANING.

Valve Life The valves supplied with your amplifier should provide

approximately 4000 hours of operation. They are specially

selected by us, and should only be replaced with matched

pairs. Please consult your Audio Note (UK) dealer should your

valves need replacing.

OPERATION

INPUT IMPEDANCE

100 KOhm Line Level

INPUT SENSITIVITY

430mV for full output

MAXIMUM OUTPUT

18 watts RMS per channel into 4 or 8 Ohm loads

CHANNEL BALANCE

+/-0.3dB

TUBE COMPLIMENT

2 x 6SL7

4 x 5881 / 6L6WGB

FUSE RATINGS

2A anti-surge (110 / 120V supply)

1.2A anti-surge (220 / 240V supply)

MAX. POWER CONSUMPTION

90 Watts

UNIT WEIGHT

17 KG

SHIPPING WEIGHT

(ORIGINAL PACKAGING)

20 KG

UNIT DIMENSIONS

140mm (h) x 295mm (w) x 450mm (d)

SHIPPING DIMENSIONS

(ORIGINAL PACKAGING)

240mm (h) x 400mm (w) x 550mm (d)

NOTE

Due to Audio Note (UK)’s ongoing research and

development program, specifications are subject

to change without notice.

TECHNICAL SPECIFICATIONS

Andere Handbücher für P2 SE

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Audio Note Verstärker Handbücher

Audio Note

Audio Note VINDICATOR Silver Signature Technisches Handbuch

Audio Note

Audio Note M5 RIAA Technisches Handbuch

Audio Note

Audio Note Shinri Technisches Handbuch

Audio Note

Audio Note MEISHU Phone Technisches Handbuch

Audio Note

Audio Note CONQUEROR Silver Signature Low Gain Technisches Handbuch

Audio Note

Audio Note L2 Line Preamplifier Bedienungsanleitung

Audio Note

Audio Note M2 Balanced informatio Technisches Handbuch

Audio Note

Audio Note M2 Phono Technisches Handbuch

Audio Note

Audio Note Mono Block 300b/2A3 Bedienungsanleitung

Audio Note

Audio Note SORO Phono SE Technisches Handbuch

Audio Note

Audio Note Kegon Technisches Handbuch

Audio Note

Audio Note KASSAI Balanced Technisches Handbuch

Audio Note

Audio Note Kassai Bedienungsanleitung

Audio Note

Audio Note KAGEKI BALANCED Technisches Handbuch

Audio Note

Audio Note P3 Tonmeister Silver Signature Technisches Handbuch

Audio Note

Audio Note M5 Phono Technisches Handbuch

Audio Note

Audio Note Kegon Bedienungsanleitung

Audio Note

Audio Note M2 Phono Technisches Handbuch

Audio Note

Audio Note M Zero Bedienungsanleitung

Audio Note

Audio Note I Zero Bedienungsanleitung

Audio Note

Audio Note M8 Phono Technisches Handbuch

Audio Note

Audio Note P2 SE Technisches Handbuch

Audio Note

Audio Note MEISHU Phono Silver Signature Technisches Handbuch

Audio Note

Audio Note M1 RIAA Technisches Handbuch

Beliebte Verstärker Handbücher anderer Marken

ASTRO

ASTRO HVO V40 P Bedienungsanleitung

Marantz

Marantz SUPERSCOPE BLA-545 Montageanleitung

NAD

NAD CI980 Bedienungsanleitung

Technics

Technics SE-CH770 Bedienungsanleitung

Harman Kardon

Harman Kardon HK6300 Bedienungsanleitung

NAD

NAD T975 Bedienungsanleitung

McIntosh

McIntosh MA6850 Bedienungsanleitung

Electro-Harmonix

Electro-Harmonix ENGLISH MUFF’N Bedienungsanleitung

Viatron

Viatron Autrix Bedienungsanleitung

GME

GME GA9800 Bedienungsanleitung

Atlas

Atlas CP700 Bedienungsanleitung

Roland

Roland KC-1000 Bedienungsanleitung

Pyle

Pyle PFMRA350BW Bedienungsanleitung

Advantage

Advantage S-250 Bedienungsanleitung

IRT Electronics

IRT Electronics DVA-3007 Bedienungsanleitung

Dimavery

Dimavery BA-100 Series Bedienungsanleitung

Sony

Sony XM-S400D Bedienungsanleitung

Schertler

Schertler ROY X Bedienungsanleitung
