Model FM2642 Wall Mount
Full Motion Television Wall Mount
2
Introduction
Congratulaons on the purchase of your new Audio Soluons™ FM2642 Television Wall Mount. For
maximum benet, please read the enre manual before beginning installaon.
NOTE: This model has been designed to work with most 26 to 42 inch Plasma, LED and LCD televisions
with a maximum weight of 66lbs (30kg).
Safety Instructions
Please read this enre manual carefully before mounng this bracket to avoid bodily injury and/or any
property loss. If you do not understand these direcons, or have any doubts about the safety of the
installaon, please call a qualied contractor or contact the Audio Soluons™ customer service department
@ 1-866-839-9187. Please check carefully to ensure there are no missing or defecve parts. Our
customer representaves can quickly assist you with installaon quesons and missing or defecve parts.
Replacement parts for products purchased through authorized dealers will be shipped to you directly. Do
not aempt to use any parts not provided by the manufacturer. Using other screws could cause injury or
property loss. Never use defecve parts, as improper installaon may cause damage or serious injury. Do
not use this product for any purpose not explicitly specied by Audio Soluons™. Audio Soluons™ cannot
be liable for damage or injury caused by incorrect mounng, incorrect assembly, or incorrect use.
• Read these instrucons.
• Keep these instrucons.
• Heed all warnings.
• Follow all instrucons.
• Besuretochooseawallconstructedusing2x4studsorsolidconcrete,orotherreinforcement
strongenoughtosupporttheweightoftheTV.Thelocaonshouldbesafefromhazardssuchas
waterorcrushableitems.DONOTATTEMPTTOMOUNTTHISUNITTOAHOLLOWWALL!
Hollow Wall or Decorative Cardboard
NO!
Figure 1 - Hollow Wall WARNING!
• WARNING: Use only the supplied screws intended for the current applicaon to avoid personal injury
or property damage.
GETTING STARTED
3
Opening the Package
The FM2642 Wall Mount and accompanying hardware have been carefully packed in a carton designed to
protect it from transportaon damage. Aer opening the carton, check that the components are in good
condion and that all listed contents are included.
Package Contents
• Mounng Plate (x1)
• Wall Bracket (1)
• Extension Arm (x4)
• Mounng/Assembly Hardware
• Leveling Tool
• This User Manual
Mounting Instructions
Please read all enclosed instrucons and verify hardware contents carefully before mounng.
GETTING STARTED
4
Wall Plate Mounting Hardware
#PartImage Descripon Qty
1 Square Head
Screw
2
2 Concrete
Anchor
2
3 M8 Washer 2
4 M6 x 10 Bolt 8
5M8 x 12 Bolt 2
6 Allen Wrench 2
TV Bracket Assembly Hardware
#PartImage Descripon Qty
A M4 x 12 Bolt 4
BM5 x 12 Bolt 4
CM6 x 12 Bolt 4
DM8 x 16 Bolt 4
EM4 x 30 Bolt 4
FM5 x 30 Bolt 4
GM6 x 35 Bolt 4
HM8 x 40 Bolt 4
GETTING STARTED
#PartImage Descripon Qty
I M4/M5
Spacer
4
JM8/M6
Spacer
4
KM4/M5
Washer
4
LM6/M8
Washer
4
M M4 Washer 4
NM5 Washer 4
OM6 Washer 4
PM8 Washer 4
5
STEP 1
Read and understand all of the enclosed instrucons and verify that all parts are present and appear in
good working order before you begin.
STEP 2
Aach the Wall Plate to the wall.
Wood Stud Mounting
The Wall Plate must be mounted, at the top and boom, to a solid wooden stud. Locate the stud and mark
the center and edge locaons. Posion the Wall Plate over the marked wooden stud and mark for drilling.
Using the correct size drill bit, pre-drill a 2.5” deep hole in each marked locaon. Aach the Wall Plate to
the wall using the included square head screws and M8 washers, making sure to mount it right side up, as
illustrated in Figure 2.
NOTE: Do not use the concrete anchors illustrated in Figure 2 for wood stud mounng.
Concrete Wall Mounting
Choose a solid wall area (avoid securing the mount to mortar joints between concrete blocks or bricks).
Using the correct size drill bit, pre-drill a 2.5” hole in each marked locaon. Insert the concrete anchor into
the hole and then aach the Wall Plate to the wall using the included square head screws and M8 washers
(Figure 2).
Figure 2 - Wood Stud/Concrete Mounting
INSTALLATION
6
INSTALLATION
STEP 3
In the hardware bag provided, locate the 4 pan head bolts that t the thread paern for your television.
Depending on the spacing of holes on the back of your television, choose from the various mounng
opons listed below to aach the mounng bracket to your television. If necessary, use the M6 x 10 bolts
(A) to connect the included extension arms vercally, horizontally or diagonally to reach the television
mounng holes. Gently thread the screws into the television holes by hand. DO NOT USE AN ELECTRIC
OR BATTERY DRILL unl you are certain you have the right size thread. DO NOT OVER TIGHTEN the screws
(Figure 3).
NOTE: Use the proper bolts and washers that correspond to the mounng holes on the back of the TV.
Take care to ghten by hand rst or damage to the mounng holes can occur. Some TVs without a at
back may require the use of a spacer when aaching the brackets. If applicable, make sure the two TV
brackets are even and that they’re using the same mounng holes on the bracket. Uneven assembly will
cause the TV screen to slant.
Figure 3 - Attach Bracket to TV
7
A
Figure 4 - Attach Bracket/Diagonal Arms
Figure 5 - Attach Bracket/Vertical Arms
INSTALLATION
8
A
Figure 6 - Attach Bracket/Horizontal Arms
NOTE: You will need at least 2 people to nish this mounng procedure. To avoid possible injury, do not
aempt to mount the TV alone.
NO!YES!
Figure 7 - Two Person Install WARNING!
INSTALLATION
9
STEP 4
Next, hang the pre-assembled TV unit on the Wall Plate. Slide the protruding M8 x 12 head hex bolt (A)
on the bracket aached to your TV into the groove on the mounted Wall Plate, illustrated in Figure 8. Use
a second M8 x 12 bolt (B) to secure the TV assembly to the wall plate, and then ghten the top bolt (A) on
the TV assembly.
A
B
Figure 8 - Attach TV Assembly to Wall Plate
INSTALLATION
10
STEP 5
NOTE: Angle adjustment should be done by at least two people.
• (A) With assistance, adjust the bracket arm at the joint nearest the wall up to 170 degrees or at the
middle joint up to 360 degrees. Pay aenon to wiring to ensure wires are not damaged during angle
adjustment. See Figure 9.
• (B) With assistance, swivel the television le/right up to 90 degrees. See Figure 9.
• (C) While another person is holding the television assembly, loosen the handles on either side of
the mounng bracket to lt the television up to 5 degrees back or 30 degrees forward. Tighten the
handles when the desired angle is achieved. See Figure 9.
ABC
Figure 9 - Adjust Angle
INSTALLATION
