Audiovox CDC-TO3 Bedienungsanleitung

CAUTION: FOLLOW THE CONNECTION SEQUENCE DESCRIBED BELOW TO ENSURE PROPER

RECOGNITION OF THE CD CHANGER BY THE FACTORY RADIO.

DO NOT FORCE CONNECTORS TOGETHER. LINE UP LOCATING TABS AND CAREFULLY

MATE CONNECTORS.

INSTALLATION INSTRUCTIONS FOR THE CDC-TO3: (See Installation Diagram)

1. Mount the CD Changer in the rear of the vehicle. Refer to the installation instructions supplied with

the CD Changer.

2. Be sure the ignition switch and the radio are in the off position.

CAUTION: If not, the radio will not recognize the changer.

3. Remove the factory radio from the dash panel.

4. Disconnect the power/speaker harness between the car and the radio.

5. Connect the CDC-TO3 to the Changer using the 5 Meter DIN Cable supplied with the CD Changer.

6. Plug the 12 Pin Connector from the CDC-TO3 into the mating socket on the rear of the factory radio.

7. Re-connect the radio power/speaker harness.

8. Reset the Changer and insert the CD magazine.

9. Re-install the radio into the dash panel.

10. Turn on the ignition and radio and perform an operation check.

OPERATION CHECK:

1. Load CD’s into the CD Changer magazine and insert the magazine into the changer.

2. Start vehicle and allow CD Changer to cycle. Perform a brief functional test to verify proper

operation according to the Owner’s Manual.

INSTALLATION GUIDE FOR:

Model CDC-TO3

128-5524

CD CHANGER INTERFACE

for TOYOTA VEHICLES

1998-99 Avalon

1998-99 Camry

1998-99 Celica

1998-99 Corolla

1998-99 Land Cruiser

1998-99 Paseo

1998-99 4-Runner

1998-99 RAV4

1998-99 Sienna*

Compatible with following Toyota factory radio models in above vehicles (model number is printed on face

panel of radio):

IMPORTANT

Works in conjuction with Audiovox 6 Disc and 10 Disc CD Changer (except P-1000)

For use with Toyota vehicles factory radios as listed in the following vehicles:

1998\ T-100

1998-99 Tacoma

1998-99 Tercel

11801

11802

16408

16410

16808

16810

51800

56808

A51707

A51801

A56409

AD1701

AD1702

AD6401

AD6801

AD6802

Page 1

* NOTE: CDC-TO3 does not work in conjunction with Sienna steering wheel controls.

CDC-TO3

12-PIN

CD CHANGER

CONNECTOR 15-PIN

SPEAKER/POWER

CONNECTOR

ANTENNA JACKS

FACTORY RADIO

REAR VIEW

12-PIN

CONNECTOR

8-PIN DIN

CONNECTOR

5 METER DIN

CABLE

(SUPPLIED W/

CD CHANGER)

6 DISC OR 10 DISC CD CHANGER

Model: CDC-TO3

CD CHANGER INTERFACE

FOR TOYOTA VEHICLES

Audiovox Corporation, Hauppauge, NY PROD. CODE: 000

To Factory Radio

To CD Changer

Made in Taiwan 132-5576

Page 2
