Audiovox D2016 Bedienungsanleitung
D2016
PORTABLE 10" LCD MONITOR AND DVD PLAYER
2
Notice:
1.This Product incorporates copyright protection technology that is pro-
tected by method claims of certain U.S. Patents and other intellectual
propertyrightsownedbyMacrovisionCorporationandotherrightsown-
ers. Use of this copyright protection technology must be authorized by
MacrovisionCorporation,andisintendedforhomeandotherlimitedview-
ing uses only unless otherwise authorized by Macrovision Corporation.
Reverse engineering or disassembly is prohibited.
2.ApparatusClaimsof U.S.Patent Nos.4,631,603;4,577,216;4,819,098
and 4,907,093 licensed for limited viewing uses only.
3
Content
A.Introduction............................................................................ 4
B. Cautions and Warnings ........................................................ 4
C.Contents...............................................................................6
D. Powering and installation ..................................................... 6
E. Controls, Indicators, and Connectors ................................... 7
F. Loading and Playing a Disc .................................................. 8
G.Basic Operation......................................................................9
H. Menu .................................................................... 10
I.Display...................................................................................10
J.PlayingAudioCDS................................................................13
K. Playing MP3 Discs .......................................................... 14
L. Playing JPEG file ...........................................................16
M. Connecting to a TV or another monitor.......................... 17
N.Setup .................................................................................... 19
O.Specifications...................................................................... 22
P. Rechargeable Battery Installation and Use ......................... 22
Q.Troubleshooting ................................................................. 25
4
A. Introduction
Thank you for choosing the D2016 portable DVD player. The main
features include a 10" Wide Screen (16:9Aspect Ratio) Liquid Crys-
tal Display (LCD) monitor and a DVD player. The unit applies the
latest state of the art electronics and is designed for use in vehicles,
hotels,officesor yourhome.Theunit is constructed to provide years
of reliable, trouble-free service, and is compact so that you can take
it with you anywhere and is designed for quick and easy installation.
Please read the entire instruction manual supplied with this product
prior to using. The documentation will assist you in installing the sys-
tem properly to obtain the best equipment performance. Please save
this manual for later use.
B. Cautions and Warnings
1. Placement
To prevent fire or electric shock, do not expose this appliance to
rain or moisture. Do not place the set on an unstable cart, stand,
tripod,bracketortabletopreventitfromfalling.Keep the unit away
fromstrongmagnets,heat sources, direct sunlight,excessivedust.
If the unit is brought directly from a cold to a warm location, mois-
ture may condense inside the unit. When you move it from a cold
to a warm location, wait for about one hour before operating the
unit, or remove the disc and leave the unit turned on until the mois-
ture evaporates.
2. Installation
Ensure that the D2016 portable DVD player is installed in accor-
dancewiththe instructionsandillustrationsprovided inthismanual.
3. Caution
Do not push objects of any kind into the unit through openings;
do not spill or spray liquid of any kind on or in the system (this
may result in a fire or electric shock). Do not place anything
heavy on the unit. To ensure proper ventilation and proper
5
operation, never cover or block the slots and openings with a cloth
or other material. Keep the unit away from an open flame such as
fire, candle etc. It is hazardous to replace the battery incorrectly.
Replace the battery only with the same or equivalent type, in order
toprotecttheenvironment,pleasedisposethebatteryproperly.Do
not use the unit in temperatures higher than 95 degrees Fahren-
heit or 35 degrees Celsius.
4.Disassembly
Do not attempt to disassemble the cabinet. There is a risk of elec-
tric shock and/or exposure to Laser Radiation. Contact qualified
service personnel if your system needs repair.
5. Cleaning Unit
Whencleaning, makesurethe systemisunplugged fromthepower
source. Do not use liquid cleaners or aerosol cleaners. Use a cloth
lightly dampened with water for cleaning the exterior of the system
only.
6. Discs
Do not use irregularly shaped discs such as heart or star-shaped
discs as they may cause the unit to malfunction. Do not stick pa-
per, tape or glue on the disc. Do not expose the disc to direct sun-
light or heat sources. Do not touch the surface of disc. Handle the
disc by its edge. Clean the disc by wiping the disc from the center
out with a cleaning cloth. Remove the disc from the unit and store
it in its case after playing. Some playback operations of discs may
be intentionally fixed by software producers. Since this unit plays
discs according to the disc contents the software producers de-
signed, some playback features may not be available.Also refer to
the instructions supplied with the discs.
6
7.Regional Coding
Both the DVD player and disc are coded by region. These
regional codes must match in order for the disc to play. If the
codes don’t match, the disc won’t play. This unit’s code is region
1. DVDs with other regional codes cannot be played in this unit
C. Contents
1. 1 x 10’’ LCD Monitor & DVD Player Combo
2. 1 x Remote Control with battery (CR2025)
3. 1 x Audio/VideoAdapter Cable
4. 1 x AC to DCAdapter
5. 1 x DC PowerAdapter
6. 1 x Instruction Manual
7. 1 x Rechargeable Battery
D. Powering and installation
1. Powering the system indoors (Refer to Figure 1)
Plugone end of theAC toDC adapter into theDC input jack onthe
leftsideofthe main unit, then plug theotherendintothe 110~240V
AC power receptacle.
2. Powering the system in a car
Plug one end of the DC Power adapter into the DC input jack on
the unit, then plug the other end into the vehicle power outlet.
Figure 1
Note: Unplug the D2016 when not in use.
DC 9V
ON OFF
OUT I N
A
/V TV PORT
USB
7
11) Cover OpenActuator
12) Charge Indicator
13) Headphone Jack 1*
14) Headphone Jack 2
15) Volume Control
16) Brightness Control
17) LCD Panel Shut Off Switch
18) Wide Button
19)Previous/Next/Pause/Stop/Play
20) Menu Button
21) Up/Down/Left/Right/OK Button
E. Controls, Indicators, and Connectors
1. Unit View (Refer to Figure 2)
Figure 2
1) Battery Release Button
2) DC 9-12V Input Jack
3) AV Jack
4) AV In/Out Switch
5) USB Port
6) Game Port
7) Power On/Off Switch
8) SD Card Slot
9) Power Indicator
10) Remote Control Sensor
1
2
3
4
5
7
8910 11
12
13
14
15
16
17
18
19
20
6
21
* Connecting to headphone jack number 1 will disable the
internal speakers
8
2. Remote Control (Refer to figure 3)
1) Setup Button
2) Up Button
3) Skip- Button
4) Enter Button
5) Reverse/Left Keypad
6) DOWN Button
7) Numeric Button
8) Display Button
9) Zoom Button
10) SD/USB/DVD Button
11) Skip+ Button
12) A-B Repeat Button
13) Forward/Right Keypad
14) 1/All Repeat Button
15) Stop Button
16) Menu Button
17) Subtitle Button
18) Audio Button
19) Play/Pause Button
F. Loading and Playing a Disc
a. After connecting power to the unit, power on “DVD player” with the
power switch. The power indicator will light.
b. Open the disc tray by sliding the OPEN switch in the direction of
the arrow. Place a disc in the tray with label side facing up.
c. Close the tray by pressing the area marked “PRESS” .The unit will
load the disc and start playing.
d. Rotate BRIGHTNESS and VOLUME to adjust the LCD’s bright-
ness and the DVD player’s volume.
e. To stop playing a disc, press STOP.
Figure 3
9
G. Basic Operation
POWER
OPEN
PLAY /PAUSE
STOP
NEXT
PREVIOUS
FORWARD
REVERSE
LEFT/RIGHT/UP/DOWN
ENTER
NUMBERS
MENU
REPEAT
A-B
DISPLAY
SUBTITLE
AUDIO
ZOOM
SETUP
Turn the unit on/off
Remove/load the disc
Start Play/Execute item or setting
Still Picture
(1 time) Stop at the present playing point /
(2 times) Stop playing
Go to the next chapter, track or scene
during play back
Go back to the previous chapter, track
or scene during play back
Scan forward at 2, 4, 8,16 or
32 times speed
Scan backward at 2, 4, 8, 16 or
32 times speed
UsedforMenu Navigation
Execute item or confirm setting
Select item or setting
Display the main menu of the disc
Repeat playing title, chapter, or track
Repeat a specific portion from
pointA to point B of the disc
Display information (title, chapter,
track, time, etc.).
Select the subtitle language and turn it
on/off
Select the audio language
Enlarge an image to 2, 3, or 4 times the
original size.1/2 1/3 1/4
Display the setup menu to select and
set items, and exit the setup menu.
10
H. Menu
A DVD is divided into sections called titles and chapters. When you
play a DVD’s root menu of the disc will appear on the screen of your
TV or Monitor. The contents of the menu vary from disc to disc. Press
MENU during playback to display the menu. Some DVDs only allow
you to select disc playback options using the DVD root menu.
I. Display
1. PLAYING TIME AND REMAINING TIME
a. During playback press the ‘DISPLAY’ button to display the cur-
rent Title Number (1), the total Number of Titles (2), the current
Chapter Number (3), the total Number of Chapters (4), and the
Playing elapsed Time for the title (5). The heading will disappear
automatically after 3 seconds if DISPLAY button is not pressed.
Title, Chapter Number, and Time Screen Display
b. Press ‘DISPLAY’ constantly to choose the options below in se-
quence.
Title Elapsed: The elapsed time of the title
Title Remain: The remaining time of the title
Chapter Elapsed: The elapsed time of the chapter
Chapter Remain: The remaining time of the chapter
Display Off: The DVD’s time Information will not be displayed.
Title Elapsed Title Remain Chapter Elapsed
Chapter Remain
Display Off
Dieses Handbuch passt für folgende Modelle
1
Inhaltsverzeichnis
Andere Audiovox Tragbarer DVD-Player Handbücher
Audiovox
Audiovox D8000XP Bedienungsanleitung
Audiovox
Audiovox D1809PK - DVD Player - 8 Bedienungsanleitung
Audiovox
Audiovox D1718PK - DVD Player - 7 Bedienungsanleitung
Audiovox
Audiovox D1500A Bedienungsanleitung
Audiovox
Audiovox Eddie Bauer PE702 Bedienungsanleitung
Audiovox
Audiovox MVDVD2 Bedienungsanleitung
Audiovox
Audiovox VBP3800 Bedienungsanleitung
Audiovox
Audiovox D1708 - DVD Player - 7 Bedienungsanleitung
Audiovox
Audiovox D1915 - DVD Player - 9 Bedienungsanleitung
Audiovox
Audiovox DS9106 Bedienungsanleitung
Audiovox
Audiovox FLO TV DFL710 Bedienungsanleitung
Audiovox
Audiovox D1420 Bedienungsanleitung
Audiovox
Audiovox DS7521PK Bedienungsanleitung
Audiovox
Audiovox D1988 Bedienungsanleitung
Audiovox
Audiovox DS9521PK Bedienungsanleitung
Audiovox
Audiovox D1805 Bedienungsanleitung
Audiovox
Audiovox D1809 - DVD Player - 8 Bedienungsanleitung
Audiovox
Audiovox VOD1221 P Bedienungsanleitung
Audiovox
Audiovox D1750T Bedienungsanleitung
Audiovox
Audiovox D1718ES - DVD Player - 7 Bedienungsanleitung
