LCD REMOTE CONTROL TRANSMITTER: AS-LCD
Note: If the system is interfered by stronger radio
frequency around, sources of high voltage electric
power or such Obstacles like tall buildings and so
on, the transmission range may get shorter as the
system uses low out put powered frequency.
ACTIVE ARMING –LOCK & ARM:
1.Press
button on transmitter.
2.The siren will chirp once and parking light will flash once indicating that the
system is now armed. The vehicle doors will lock upon arming when interfaced
with the security system.
Note: Defective sensor reminder: If the siren or horn sounds 3 chirps, then you
have left a door, trunk, or hood lid ajar.
AJAR WARNING:
If the siren sounds 3
chirps, then you
have left a door,
trunk, or hood lid
ajar.
SILENT LOCK/UNLOCK OR ARM / DISARM:Press the
button or + buttons
together on the transmitter on the transmitter to arm or disarm your security
system with no chirp sound heard; arm / disarm confirmation will be through the
vehicles parking lights only.
SHOCK SENSOR / OPTIONAL SENSOR BY-PASS: Press the
button on the
transmitter twice within 3 seconds will arm the security system, by-pass the shock
sensor or the optional sensor connected to 4 pin plug. The system will chirp one
additional time to confirm the sensor bypass mode was activated. The sensor
bypass feature is programmed to activate for one arming cycle only. The security
system will return to normal operation during the next arming cycle.
PASSIVE LOCKING OR ARMING :Programmable
Active arming / disarming is controlling your security system via the remote
transmitter. This security system is equipped with an optional Passive Arming
feature, which allows the security system to arm 30 seconds after the last door is
closed. Operation is as follows.
1. Turn the ignition to the “OFF” position and exit the vehicle.
2. After all entrances are closed, the security system LED will flash fast for 30
seconds. If you reopen any door / hood / trunk, the security system LED will
stop flashing. It will begin flashing again once all vehicle entrances are closed.
3. After 30-second timer has elapsed, the security system will automatically
“ARM”. The siren or horn will chirp [1] time and the parking lights will flash [1]
time.
PASSIVE DOOR LOCKING: Programmable
The vehicle doors will automatically lock after passive arming cycle has been
completed.
ACTIVE UN-LOCKING –UNLOCK & DISARM:
1. Press the
button on the transmitter.
2. The siren will chirp twice and parking lights will flash twice to indicate that the
security system is now disarmed. The vehicle doors will unlock and disarm
when interfaced with the security system
Shock Sensor Ignition
Trigger Trigger
Clear the Flash Icon and Melody Sound:Cycle Ignition then
press the button first, within 3 seconds press and buttons
at the same time.It will clear theflash icon and melody sound
on the LCD screen transceiver
AUTOMATIC RE-ARM: If this feature is selected, the security system will
automatically re-arm itself 60 seconds after disarming with remote transmitter.
Automatic rearm will cancel if any door is opened before the 60 seconds timer
has elapsed.
DISARMING WITHOUT A TRANSMITTER
The Override function may be used if the remote transmitter is lost or
inoperative.
1. Enter the vehicle and turn the ignition switch to 'ON’ position. (Alarm will
sound.)
2. Within 10 seconds push and release the valet switch
The alarm will stop sounding and enter the disarm mode. You can now start and
operate the vehicle normally.
VALET MODE:
The valet switch allows you to temporarily bypass all alarm functions eliminating
the need to hand your transmitter to parking attendants or garage mechanics.
When the system is in valet mode, all alarm functions are bypassed, however,
the remote panic feature and remote door locks will remain operational.
Enter Valet Mode:
1. From the disarmed condition, turn
the ignition to “ON” position.
2. Push and hold valet switch for 2
seconds until the LED turns on.
The LED wills remain on as long
as the system is in 'valet mode'.
Exit Valet Mode:
1. Return to normal operation, turn ignition 'ON'.
Push and hold valet switch for 2 seconds; the LED will turn off indicating the system
is exiting the valet mode
PANIC FUNCTION:
The transmitter can be used as a remote panic switch to manually trigger the alarm
in case of emergency.
1.Press and hold the
button on the transmitter for 3 seconds. The alarm will
immediately sound.
2.During panic mode, the normal function of this transmitter button will be
suspended. The
buttons can be used to lock and unlock the doors (if the
option is installed), however once the
button is pressed, the vehicle’s starter
disable device, (where installed) will be enable allowing the vehicle to start.
3.To stop the alarm, press and hold the
button on the transmitter for 3
seconds. Also if the button is pressed and released, the panic mode will be
turned off immediately.
4.If the button is not pressed, the alarm will automatically stop after 30 seconds.
TRIGGER THE SYSTEM: (OPTIONAL) If alarm option is installed.
When armed, your vehicle is protected as follows:
1. Light impacts will trigger the warn-away signal. A long chirp from siren /horn.
2. Heavy impacts / Doors open / Hood open / Trunk open / Turning on the
ignition switch- All will trigger the programmed sequence.
Ignition Warn-away
TriggerTrigger
Clear the Flash Icon and Melody Sound: Cycle ignition then
press the button first, within 3 seconds press and
buttons at the same time. It will clear theflash icon and melody
sound on the LCD screen transceiver
