Autophix ES910 Bedienungsanleitung
ES910
BMW MINI Rolls-Royce
www.autophix.com
BMW SCANNER
USER’S MANUAL
Table of Contents
1
SAFETY PRECAUTIONS
ABOUT ES910
1. Coverage
2. Other Features & Benefits
3. Includes
4. Appearance and Key Descriptions
OPERATION INSTRUCTIONS
1. Connect ES910
2. ES910 Features
2.1 Select Brand
2.2 Basic Functions
2.2.1 Version Information
2.2.2 Read Fault Codes
2.2.3 Erase Fault Codes
2.2.4 Read Datastream
2.3.2 DME/DDE Motor(Diesel)Electronics
2.3.3 Battery management
2.3 Special Functions
2.3.1 CBS Functions
2.3.4 EPB Electronic Parking brake
2.3.5 Steering-angle sensor
2.3.6 ABS/ACS/DSC Dynamic Stability Control
2.3.7 Special case
2.4 Erase All Systems Fault Codes
3. ES910 Tool Setup
3.1 Language
3.2 Device Information
1. Limited One Year Warranty
2. Service Procedures
WARRANTY AND SERVICE
2
3
3
3
4
4
6
6
6
6
8
9
10
10
11
12
12
13
13
14
15
15
16
16
17
18
18
19
19
19
To avoid body hurt and damage to the device or your car, please read
this manual carefully before using ES910.
The general testing process described in this manual is got by
technologist’s experience. Safety precaution is required in most of the
process to avoid body hurt and damage to the device or your car.
Prior to your using this device, please read vehicle maintenance code
and follow the safety precautions. Keep mention to the following
general safety precautions.
It generates CO and other poisonous air when engine run. To avoid this
kind of hurt, please repair the car in a well-air-ventilated location.
When an engine is running, many parts (such as the coolant fan,
pulleys, fan belt etc.) turn at high speed. To avoid serious injury, always
be aware of moving parts. Keep a safe distance from these parts as well
as other potentially moving objects.
Engine parts become very hot when the engine is running. To prevent
severe burns, avoid contact with hot engine parts.
Connecting or disconnecting test equipment when the ignition is ON
can damage test equipment and the vehicle's electronic components.
Turn the ignition OFF before connecting the ES910 or disconnecting
the ES910 from the vehicle's Data Link Connector (DLC).
Fuel and battery vapors are highly flammable. To prevent an explosion,
keep all sparks, heated items and open flames away from the battery
and fuel/ fuel vapors. DO NOT SMOKE NEAR THE VEHICLE DURING
TESTING.
SAFETY PRECAUTIONS
2
3
· Dimensions: 170mm X 96.2mm X 28.8mm.
· 2.8’LCD,320 X 240 easy-to-read backlit LCD display with adjustable
contrast .
· Operating Voltage: 8V-18V.
· Operating Temperature: 0°C-60°C(32-140°F).
· Storage Temperature: -20°C-70°C(4-158°F).
· Easy to use six-button operation(UP,DOWN,LEFT,RIGHT,ENTER,EXIT).
· CE、FCC、RoHS certification.
ES910 is a handy professional Scanner for BMW vehicles. It
supports all of OBD 16PIN BMW vehicles, including BMW, MINI
and Rolls-Royce brands vehicles, fastly detects Engine, ABS,
Airbags, Auto Transmission, Instrument and other control
systems.
1) BMW /MINI / Rolls-Royce.
2) ES910 Supports most of BMW vehicles between 1998 to 2001, and
works on all models after 2001.
ABOUT ES910
2. Other Features & Benefits
1. Coverage
4
1. 1pc x ES910 Scan Tool main unit
2. 1pc x User's Manual
3. 1pc x USB update cable
4. 1pc x Durable Nylon Storage Case
3. Includes
4. Appearance and Key Descriptions
8
1
2
6
3
5
4
7
5
1. LCD DISPLAY – Indicates test results. Backlit, 320 x 240 pixel
display with contrast adjustment
2. ENTER BUTTON – Confirms a selection (or action) from a menu.
3. EXIT BUTTON – Cancels a selection (or action) from a menu or
returns to the menu.
4. LEFT SCROLL BUTTON –in the menu mode through the menu
and sub menu move to the left, when rolling in a data interface,
use the left button can be moved to the last screen text
interface
5. RIGHT SCROLL BUTTON –In the menu mode through the
menu and sub menu item move to the right, when rolling in the
data interface, use the right button can be moved to the next
screen text interface
6. UP SCROLL BUTTON –in the menu mode through the menu
and sub menu item moving up. When retrieving data for more
than a screen by moving up the screen to the previous screen for
more data
7. DOWN SCROLL BUTTON –In the menu mode through the
menu and sub menu item moves down. When retrieving data
more than one screen, by moving down the screen to the next
screen for more data.
8. OBD-16PIN CONNECTOR – Connects the scan tool to the
vehicle’s Data Link Connector (DLC).
6
1.1 Turn the ignition on.
1.2 Locate the vehicle's 16-pin Data Link Connector (DLC).
OPERATION INSTRUCTIONS
1. Connect ES910
www.autophix.com
Main Menu
Tool SetupBMW
[Tool Setup] : Language / Device Information.
[BMW] : Select Brand BMW / MINI / Rolls-Royce.
(The main interface) (Main Menu)
1.3 Main menu function：
2. ES910 Features
2.1 Select Brand
Choose [BMW] and it displays as follow：
7
Main Menu
Tool SetupBMW
MINI
Rolls Royce
BMW
1/3
Select Brand
ES910 system is divided into three parts, each separated from each
other. Click [BMW], and then press the [Enter] button. The screen will
show all BMW car series. As follows.
1 Series
2 Series
3 Series
4 Series
5 Series
6 Series
7 Series
1/10
Select Series
E81/E82/E87/E88
F20/F21
1/2
Select Chassis
For example: Choose [1-Series] and it displays as follow：
8
2.2 Basic Functions
Basic Functions
Special Functions
Erase All Systems Fault Code
1/3
Select Function
For example: Choose [E81/E82/E87/E88] and it displays as follow：
System Scan
Manual Select
1/2
Select Function
Choose [Basic Functions] and it displays as follow：
System scan is to scan all vehicle systems.
Manual selection is to display all possible systems, select one of the
systems to diagnosis.
9
CAS Car Access System
DME/DDE Digtal motor/Diesel...
EKPS Fuel-pump control
EGS Transmission control
AL Active steering
DSC Dynamic Stability Control
RDC Tyre pressure control
1/51
Select System
2.2.1 Version Information
Choose [Manual Select] and it displays as follow：
Version Information
Read Fault Codes
Erase Fault Codes
Read Datastream
1/4
Select Function
Choose [DME/DDE Digtal motor/Diesel electronics] and it displays as
follow：
VIN : LV11356
Part Number : 7542300
Coding Index : 11
Diagnosis Index : 0020
Variant Index : 3451
Hardware Number : 00
1/4
Version Information
Choose [Version Information] and it displays as follow：
