Avenview HBT-C6POE-R Bedienungsanleitung

VIDEO WALLS VIDEO PROCESSORS

VIDEO MATRIX SWITCHES

EXTENDERS SPLITTERS WIRELESS

CABLES & ACCESSORIES

AV Connectivity, Distribution And Beyond...

HDBaseT HDMI CAT5/6/7Extender with

POE/LAN/RS-232/ Bi-directional IR

The contents of this document are provided in connection with Avenview Inc. (“Avenview”) products. Avenview makes no representations or

warranties with respect to the accuracy or completeness of the contents of this publication and reserves the right to make changes to specifications

and product descriptions at any time without notice. No license, whether express, implied, or otherwise, to any intellectual property rights is granted

by this publication. Except as set forth in Avenview Standard Terms and Conditions of Sale, Avenview assumes no liability whatsoever, and claims any

express or implied warranty, relating to its products are is strictly prohibited.

Model #: HBT-C6POE-R

Military Residential

Medical Aviation

Education Industrial

Corporate House Of Worship

www.avenview.com

Product Application & Market Sectors

www.avenview.com Page 3

TABLE OF CONTENTS

1. GETTING STARTED ..........................................................................................................................1

1.1 IMPORTANT SAFEGUARDS..............................................................................................................1

1.2 SAFETY INSTRUCTIONS ..................................................................................................................1

1.3 REGULATORY NOTICES FEDERAL COMMUNICATIONS COMMISSION (FCC) ........................... 2

2. INTRODUCTION ..............................................................................................................................3

2.1 PACKAGE CONTENTS .....................................................................................................................4

2.2 BEFORE INSTALLATION...................................................................................................................5

2.3 CABLE SPECIFICATIONS ..................................................................................................................5

3. APPLICATION DIAGRAM..................................................................................................................6

4. PANEL DESCRIPTION.......................................................................................................................7

INPUT PANEL (Receiver, HBT-C6POE-R) Front...............................................................................7

5. IR CABLE DEFINITIO........................................................................................................................8

6. INSTALLATION (HBT-C6POE-R)......................................................................................................9

7. GENERAL TROUBLESHOOTING...................................................................................................10

8. SPECIFICATIONS .............................................................................................................................11

www.avenview.com Page 1

SECTION 1: GETTING STARTED

1.1 IMPORTANT SAFEGUARDS

Please read all of these instructions carefully before you use the device. Save this manual for future reference.

What the warranty does not cover

•Any product, on which the serial number has been defaced, modified or removed.

•Damage, deterioration or malfunction resulting from:

•Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product modification, or failure to

follow instructions supplied with the product.

•Repair or attempted repair by anyone not authorized by us.

•Any damage of the product due to shipment.

•Removal or installation of the product.

•Causes external to the product, such as electric power fluctuation or failure.

•Use of supplies or parts not meeting our specifications.

•Normal wear and tear.

•Any other causes which does not relate to a product defect.

•Removal, installation, and set-up service charges.

1.2 SAFETY INSTRUCTIONS

The HBT-C6POE-R HDBaseT HDMI CAT5/6/7 Receiver has been tested for conformance to safety regulations and requirements,

and has been certified for international use. However, like all electronic equipments, the HBT-C6POE-R should be used with

care. Read the following safety instructions to protect yourself from possible injury and to minimize the risk of damage to the

unit.

!Do not dismantle the housing or modify the module.

!Dismantling the housing or modifying the module may result in electrical shock or burn.

!Refer all servicing to qualified service personnel.

!Do not attempt to service this product yourself as opening or removing housing may expose you to dangerous voltage

or other hazards

!Keep the module away from liquids.

!Spillage into the housing may result in fire, electrical shock, or equipment damage. If an object or liquid falls or spills on

to the housing, unplug the module immediately.

!Have the module checked by a qualified service engineer before using it again.

!Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device before cleaning.

1. GETTING STARTED

www.avenview.com Page 2

1.3 REGULATORY NOTICES FEDERAL COMMUNICATIONS COMMISSION (FCC)

This equipment has been tested and found to comply with Part 15 of the FCC rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation.

Any changes or modifications made to this equipment may void the user’s authority to operate this equipment.

Warning symbols Description

ONLY USE THE PROVIDED POWER CABLE OR POWER

ADAPTER SUPPLIED. DO NOT TAMPER WITH THE

ELECTRICAL PARTS. THIS MAY RESULT IN ELECTRICAL

SHOCK OR BURN.

DO NOT TAMPER WITH THE UNIT. DOING SO WILL

VOID THE WARRANTY AND CONTINUED USE OF THE

PRODUCT.

THE VIDEO BOARDS ARE VERY SENSITIVE TO STATIC.

PLEASE ENSURE IF RACK MOUNTED OR INSTALLED ON A

SURFACE, IT SHOULD BE IN A GROUNDED ENVIROMENT.

www.avenview.com Page 3

2. INTRODUCTION

The Avenview HBT-C6POE-R HDBaseT Receiver CAT5/6/7 with POE, Bi-Directional IR and Ethernet has been designed to

extend High Definition video and multi-channel digital audio formats to any HD Monitor.

Video Signals: 4K2K@30 (Ultra HD), 3D, Deep Color, and Full HD 1080p 36-bit color depth.

Audio signals: Lossless Multi-channel audio formats (DTS-HD Master Audio, Dolby TrueHD).

Data Signals: Bi-Directional IR signals 30 KHz to 50 KHz over CAT5/6.

The HBT-C6POE-R includes one (1) unit: Receiving unit (Rx) HBT-C6POE-R with one (1) UTP output port which allows the

user to extend video and audio up to 100m (330ft). The HBT-C6POE-R also allows bi- directional IR control of the source

connected to the unit from the users IR remote control at the monitor side.

The bonus features with this device it can support PoE (Power over the CATx cable to the RX) also Internet (100Mbps Ethernet

service when connected to a Router). These features has been added to this unit to give the installer and user a complete

solution with the new trends in online streaming, network connected devices and new demand in Smart TV, Ultra HD monitors

and content.

- INPUT: HDMI with 3D & 4Kx2K, 1080p,HDCP and DVI compliant

- VIDEO BANDWIDTH: From 300MHz / 9 Gbps

- PC RESOLUTIONS: Up to VGA to WUXGA

- HD RESOLUTIONS: Up to 4Kx2K (3840x2160@30Hz and 4096x2160@24Hz)1080p (1920x1080@60Hz)

- AUDIO SUPPORTED: LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio

- AUDIO TRANSMISSION: (32-192kHz sample rate)

- SUPPORTS: CEC bypass

- DISTANCE: Up to 100 meters through CAT6e/6a/7 cables

- ETHERNET TRANSMISSION: Rate up to 100Mbps

- UNCOMPRESSED VIDEO: 1080p, 60 Hz, 36-bit

- SERVICE: USB for Manufacturer USE ONLY

- 3D SUPPORT: Follow by Display / TV’s EDID

- 5Play™ convergence: HDMI, LAN, PoE & Bi Directional Control (IR & RS-232)

NOTE:

- The PoE function is designed for powering compatible Receiver units only.

- The non-PoE Receivers has to be powered with a power supply.

- Receivers (Rx) from different manufactures would not be compatible.

- Displaying HDMI 4Kx2K resolution would require the standard 4Kx2K HDMI cable and display for accurate results.

www.avenview.com Page 4

2.1 PACKAGE CONTENTS

1HBT-C6POE-R X 1

IR EXTENDER X1

IR BLASTER X1

USER’S MANUAL X1

www.avenview.com Page 5

2.2 BEFORE INSTALLATION

•Put the product in an even and stable location. If the product falls down or drops, it may cause an injury or malfunction.

•Don’t place the product in too high temperature (over 50°C), too low temperature (under 0°C) or high humidity.

•Use the DC power adapter with correct specifications and supplied with the unit. If improper power supply is used the

unit may malfunction and cause a fire.

•Do not twist or pull by force ends of the UTP cable. It can cause malfunction.

2.3 CABLE SPECIFICATIONS

Cable Type Range Pixel clock rate Video Data Rate Supported Video

CAT5e/6 100m <=225MHz <=5.3Gbps

(HD Video)

Up to 1080p, 60Hz, 36 bits,

3D (Data rates lower than

5.3 Gbps or below 225 Mhz

TMDS clock).

70m >225MHz >5.3Gbps

(Ultra HD Video)

4K2K, 30Hz video formats

CAT6A/7 100m >225MHz >5.3Gbps

(Ultra HD Video)

4K2K, 30Hz video formats

www.avenview.com Page 6

3. APPLICATION DIAGRAM

www.avenview.com Page 7

4. PANEL DESCRIPTION

INPUT PANEL (Receiver, HBT-C6POE-R) Front

1. HDMI OUT: Connect to HDMI display Max 35ft via

HDMI Cable or cascade with another Avenview type

Transmitter

2. 2. LAN: Connect to Internet service sharing rate of

100Mbps within the link of Transmitter

3. 3. RS-232: Connect to a device that has the ability to Receive control commands via RS232 only with compatible

Transmitters.

INPUT PANEL (Receiver HBT-C6POE-R) Rear

4. IR 2 Blaster: Plug the IR Blaster cable for IR signal being

transmitted. Place IR Blaster within direct site of the

device being controlled.

5. IR 1 Extender: Plug the IR Extender cable for IR sig-

nal being received. Place IR Extender within direct

line of site with the IR Remote.

6. LED: Illuminate when both the input and output signals

are in sync.

7. CAT5e/6/7 IN Connect CAT5e/6/7 cable to extend

the signal up to 100m (330ft)

1 32

4 5 6 12
