Avision BT-1007B Bedienungsanleitung
Flatbed Scanner User’s
Manual
Regulatory model: BT-1007B
Avision Inc.
ii
Trademarks
Microsoft is a U.S. registered trademark of Microsoft
Corporation.
Windows and MS-DOS are trademarks of Microsoft Corporation.
IBM, IBM PC are registered trademarks of International Business
Machines Corp.
Other brands and product names herein are trademarks or
registered trademarks of their respective holders.
Copyright
All rights reserved. No part of this publication may be
reproduced, transmitted, transcribed, stored in a retrieval
system, or translated into any language or computer language,
in any form or by any means, electronic, mechanical, magnetic,
optical, chemical, manual, or otherwise, without the prior
written permission of Avision Inc.
Material scanned by this product may be protected by
governmental laws and other regulations, such as copyright
laws, the customer is solely responsible for complying with all
such laws and regulations.
Warranty
The information contained in this document is subject to
change without notice.
Avision makes no warranty of any kind with regard to this
material, including, but not limited to, the implied warranties
of fitness for a particular purpose.
Avision shall not be liable for errors contained herein or for
incidental or consequential damages in connection with the
furnishing, performance, or use of this material.
User’s Manual
iii
Federal Communications Commission (FCC) compliance
information statement
Part 15
The product has been tested and found to comply with the
limits for a Class A digital device pursuant to Part 15 of the FCC
Rules. Operation is subject to the following two conditions: (1)
this device may not cause harmful interference and (2) this
device must accept any interference received including
interference that may cause undesired operation.
The FCC Class A limits are designed to provide reasonable
protection against harmful interference when the equipment is
operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction
manual may cause harmful interference in which case the user
will be required to correct the interference at his own expense.
CE Warning
This is a class A product. In a domestic environment this
product may cause radio interference in which case the user
may be required to take adequate measures.
iv
Disposal of Waste Equipment by Users in Private Union
This symbol on the product or on its packaging indicates that
the product can not be disposed of with your other household
waste. Instead it should be sent to appropriate facilities for
recovery and recycling in an effort to protect human health and
the environment. Fore more information about where you can
drop off your waste equipment for recycling, please contact
your local city office, your household waste disposal service or
the shop where you purchased the product.
As an ENERGY STAR® Partner, Avision Inc. has
determined that this product meets the ENERGY
STAR guidelines for energy efficiency.
System Requirements
¾IBM compatible PC 586, Pentium or higher
¾Microsoft Windows 2000, Windows XP, Windows
Vista/Windows 7
¾USB port 2.0 (compatible with USB 1.1)
¾At least 100 MB of free hard disk space (500 MB is
recommended)
¾At least 128 MB of system memory (512 MB of RAM is
recommended)
At least 1 GB of RAM for Windows Vista
¾A CD-ROM drive
User’s Manual
v
Table of Contents
1. Introduction.............................................................1-1
2. Scanner Installation..............................................2-1
2.1 Unlocking your scanner.................................2-2
2.2 Connecting to Power.....................................2-4
3. Completing Your First Scan................................3-1
3.1 Loading Your Paper ......................................3-1
3.2 Verifying Your Scanner Installation .................3-2
4. Using the Scanner Properties Dialog Box.....4-1
4.1 Buttons on the Scanner Properties Dialog Box..4-2
4.2 The Image Tab ............................................4-4
4.3 The Compression Tab ................................. 4-23
4.4 The Color Dropout Tab................................ 4-25
4.5 The Paper Tab ........................................... 4-29
4.6 The Multi-Feed Detection Tab....................... 4-36
4.7 The Preview Tab ........................................ 4-47
4.8 The Options Tab......................................... 4-48
4.9 The Setting Tab ......................................... 4-56
4.10 The Imprinter Tab .................................. 4-59
4.11 The Information Tab ............................... 4-62
5. ISIS Interface Operation ....................................5-1
6. Using the Buttons ..................................................6-1
6.1 Installing Button Manager .............................6-2
6.2 Checking Button Configurations Before Scanning6-3
6.3 Scanning From One Touch of the Buttons........6-5
7. Maintenance.............................................................7-1
7.1 Cleaning the Glass........................................7-1
8. Troubleshooting......................................................8-1
vi
8.1 Questions and Answers.................................8-1
8.2 Technical Service .........................................8-3
9. Specifications ..........................................................9-1
Index.......................................................................................a
User’s Manual
1-1
1. Introduction
Congratulations on your purchase of the Avision’s A3-sized flatbed
image scanner. Avision is one of the leading companies to make
high quality color image scanner.
Before you install and operate the new scanner, please take
a few minutes to read through this manual. It provides
proper instructions for you to unpack, install, operate and
maintain the scanner.
The following figure indicates the package contents. Please
check all the items against your checklist. If you do not
receive all the items, please contact your authorized local
dealer immediately.
1-2
1. Scanner main unit
2. Quick guide/CD
3. USB cable
4. Power cord/ Power adapter
Note:
1. Only use the AC adapter HEG42-240200-7L (Hitron)/DA-
48M24 (APD) included in the machine. Using other AC
adapters may damage the machine and void the warranty.
2. Please unpack the packing carefully, and check the contents
against the checklist. If any items are missing or damaged,
please contact your dealer immediately.
1
2
3 4
User’s Manual
2-1
2. Scanner Installation
Precautions
Keep the scanner out of direct sunlight. Direct
exposure to the sun or excessive heat may cause
damage to the unit.
Do not install the scanner in a humid or dusty place.
Place the scanner securely on an even, flat surface.
Tilted or uneven surfaces may cause mechanical or
paper-feeding problems.
Retain the scanner box and packing materials for
shipping purposes.
2-2
2.1 Unlocking your scanner
To protect the scanning unit from damage during
transportation, a lock switch is designed to keep the scanning
unit from moving. To unlock the scanner, move the lock switch
up as shown in Fig. 2-1.
Figure 2-1 Unlocking the Scanner
Figure 2-2 Home position
Unlocked
Locked
Scanning unit at
this position
before locking the
scanner
